The high-power drive of an impulse sound source with drilling makes the system’s life short and difficult to integrate. This report firstly establishes the pulse discharge experimental system and finite element model, and compares and verifies the typical parameters. Second, the study examines how the energy storage capacitor’s charging voltage, discharge electrode gap, and liquid environment conductivity influence the electroacoustic performance of needle series electrodes. Subsequently, the optimal electrode configuration is identified under power constraints, yielding electroacoustic parameters and curves suitable for low-power impulsive sound sources. The findings reveal that the needle–plate electrode outperforms others in pre-breakdown duration, peak impulse wave strength, highest sound pressure level, and electroacoustic conversion efficiency. However, its higher power demand can be mitigated by lowering the charging voltage and narrowing the electrode gap. The charging voltage of the power-limited needle–plate electrode is only 3.5 kV, the impulse wave intensity reaches 1.27 MPa, and the peak system power is effectively controlled within 6.66 kW. A stable 288 dB SPL output is maintained up to 1 kHz, and above 250 dB in the wide bandwidth of 1–100 kHz. Needle–plate electrodes provide broadband excitation and high intensity SPL output despite power limitations. Full article

Beam-type structures used in aerospace applications may experience simultaneous broadband dynamic excitation and thermal loads. Design sensitivity, as a powerful tool for structural optimization and reliability analysis, is investigated in this work. The broadband dynamic response and its sensitivity to input parameters for a Euler–Bernoulli beam in a thermal environment are examined using an efficient wave-based method (WBM). First, the accuracy of the simulation for predicting the broadband dynamic response is validated. Then, the influence of thermal effects on the dynamic response is investigated. Further, the normalized sensitivities of the dynamic response with respect to thermal loads, material properties, and geometric parameters are studied. The simulation results highlight the critical role of thermally generated compressive forces in governing structural dynamics. The normalized sensitivities with respect to different input parameters can vary across the broadband frequency band. In the low-frequency ranges, the sensitivities with respect to thermal load, thermal expansion coefficient, the cross-section area, and moment of inertia are dominant. In the high-frequency ranges, the cross-section area, moment of inertia, elastic modulus, and density have major influence on the dynamic response. All the parameters investigated could significantly affect the mid-frequency dynamic response. Full article

The bandwidth and output power of underwater acoustic transmitters are important for high-performance sonar detection systems. A mismatch between the impedance of the transducer and the transmitting circuit results in a low power factor, significantly limiting the sonar’s operating bandwidth and detection range. In addition, the radial head structure of the Tonpilz transducer plays an important role in determining the radiation characteristics of the sound field. This paper proposes a new radiation head structure along with an impedance-matching network circuit. First, a mathematical model of active power is established based on the Krimholtz–Leedom–Matthaei (KLM) model of the transducer. The adaptive Gauss–Newton algorithm is then used to calculate the parameters of the broadband impedance-matching network components, ultimately determining the network parameters and the structure of the transducer’s radiation head. Experimental results indicate that the transmitter voltage response of the proposed transducer is 6 dB higher than that of a conventional transducer and can be further increased by 5 dB with impedance matching. The impedance-matching network enhances the power factor of the transducer by 3.2 times, expands the frequency band by a factor of 1.6, and significantly enhances the acoustic field radiation characteristics of the underwater acoustic transducer. Full article

To achieve the broadband applicability of standard voltage transformers in “dual high” power systems, an equivalent circuit model of the standard voltage transformer is first established. Using the complex magnetic permeability method and utilizing existing core parameters, the excitation impedance values are obtained. Next, based on the equivalent circuit model, the no-load error function of the standard voltage transformer is analyzed, and through simulation, the no-load error response curve of the standard voltage transformer in the frequency range of 20 Hz to 3000 Hz is derived. The simulation results indicate that within the 20 Hz to 700 Hz range, both the no-load ratio error and the no-load angular error meet the accuracy requirements, with the ratio error within ±0.05% and the angular error within 2′. Additionally, the derivation of the error transfer function demonstrates the correlation between the no-load error values and the number of turns and cross-sectional area of the standard voltage transformer. Simulation results, obtained by increasing and decreasing the number of turns and cross-sectional area by 10%, provide valuable insights for the error compensation and structural design of standard voltage transformers. Full article

Simultaneous illumination and communication using solid-state lighting devices like white light-emitting diode (LED) light sources is gaining popularity. The white light LED comprises a single-colored yellow phosphor excited by the blue LED chip. Therefore, color-quality determining parameters like color-rendering index (CRI), correlated color temperature (CCT), and CIE 1931 chromaticity coordinates of generic white LED sources are poor. This article presents the development of multi-color phosphors excited by a blue LED to improve light quality and bandwidth. A multi-layer stacking of phosphor layers excited by a blue LED led to the quenching of photoluminescence (PL) and showed limited bandwidth. To solve this problem, a lens-free, electrically powered, broadband white light source is designed by mounting multi-color phosphor LEDs in a co-planar ring-topology. The CRI, CCT, and CIE 1931 chromaticity coordinates of the designed lamp (DL) were found to be 90, 5114 K, and (0.33, 0.33), respectively, which is a good quality lamp for indoor lighting. CRI of DL was found to be 16% better than that of white LED (WL). Assessment of visible light communications (VLC) feasibility using the DL includes time interval error (TIE) of data pattern or jitter analysis, eye diagram, signal-to-noise ratio (SNR), fast Fourier transform (FFT), and power spectral density (PSD). DL transmits binary data stream faster than WL due to a reduction in rise time and total jitter by 31% and 39%, respectively. The autocorrelation function displayed a narrow temporal pulse for DL. The DL is beneficial for providing high-quality illumination indoors while minimizing PL quenching. Additionally, it is suitable for indoor VLC applications. Full article

An experimental study is presented on the possibility of using the fluorescence from organic dyes as a broadband light source together with a monochromator for applications in excitation–emission matrix (EEM) fluorescence spectroscopy. A high-power single-chip light-emitting diode (LED) was chosen as an excitation source with a central output wavelength at 365 nm to excite a fluorescent solution of Coumarin 1 dye dissolved in ethanol. Two excitation configurations were investigated: direct excitation from the LED and excitation through an optical-fiber-coupled LED. A Czerny–Turner monochromator with a diffraction grating was used for the spectral tuning of the fluorescence. A simple method was investigated for increasing the efficiency of the excitation as well as the fluorescence signal collection by using a diffuse reflector composed of barium sulfate (BaSO₄) and polyvinyl alcohol (PVA). As research objects, extra-virgin olive oil (EVOO), Coumarin 6 dye, and Perylene, a polycyclic aromatic hydrocarbon (PAH), were used. The results showed that the light-emitting-diode-induced fluorescence was sufficient to cover the losses on the optical path to the monochromator output, where a detectable signal could be obtained. The obtained results reveal the practical possibility of applying the fluorescence from dyes as a light source for food system analysis by EEM fluorescence spectroscopy. Full article

The chirped pulse amplification (CPA) systems based on transition-metal-ion-doped chalcogenide crystals are promising powerful ultrafast laser sources providing access to sub-TW laser pulses in the mid-IR region, which are highly relevant for essential scientific and technological tasks, including high-field physics and attosecond science. The only way to obtain high-peak power few-cycle pulses is through efficient laser amplification, maintaining the gain bandwidth ultrabroad. In this paper, we report on the approaches for mid-IR broadband laser pulse energy scaling and the broadening of the gain bandwidth of iron-doped chalcogenide crystals. The multi-pass chirped pulse amplification in the Fe:ZnSe crystal with 100 mJ level nanosecond optical pumping provided more than 10 mJ of output energy at 4.6 μm. The broadband amplification in the Fe:ZnS crystal in the vicinity of 3.7 μm supports a gain band of more than 300 nm (FWHM). Spectral synthesis combining Fe:ZnSe and Fe:CdSe gain media allows the increase in the gain band (~500 nm (FWHM)) compared to using a single active element, thus opening the route to direct few-cycle laser pulse generation in the prospective mid-IR spectral range. The features of the nonlinear response of carbon nanotubes in the mid-IR range are investigated, including photoinduced absorption under 4.6 μm excitation. The study intends to expand the capabilities and improve the output characteristics of high-power mid-IR laser systems. Full article

This paper demonstrates the generation of broadband emission in the visible and infrared ranges induced by a concentrated beam of infrared radiation from CsPbBr₃ ceramics doped with Yb³⁺ ions. The sample was obtained by the conventional solid-state reaction method, and XRD measurements confirmed the phase purity of the material crystallizing in the orthorhombic system. Spectroscopic measurements required further sample preparation in the form of ceramics using a high-pressure press. The research showed that as the excitation power increases, the emission intensity does not increase linearly from the beginning of the experiment. Irradiation of the material results in the accumulation of the delivered energy. Absorption of a sufficient number of photons triggers avalanche emission. It was found that the most intense luminescence is produced in a vacuum. Changes in conductivity were also observed, where the excitation was able to lower the resistivity of the material and it was highly dependent on the excitation power. The mechanism responsible for the generation of the observed phenomenon involving intervalence charge transfer (IVCT) transitions has been postulated. Full article

Nonlinear multi-stable piezoelectric energy harvesters show broadband frequency spectra and excellent energy harvesting performance, owing to their high output power related to inter-well transitions. However, existing quad-stable piezoelectric energy harvesters contain too many structural parameters, which makes the systems clumsy, and increases the difficulties of dynamic analysis and structural optimization. Herein, a nonlinear quad-stable piezoelectric energy harvester, with only one external magnet, is proposed based on the magnetic force characteristics between a ring magnet and a rectangular magnet. Under selected structural parameters, as the magnet spacing increases, the stability characteristic of the harvester changes from quad-stability to bi-stability, and then to mono-stability. The transformation of the stability characteristic results from the changes in the variation rate of the vertical magnetic force. Subsequently, under the filtered Gaussian white noise within the frequency range of 0–120 Hz, the energy harvesting performance of the harvester is simulated by the classic fourth-order Runge-Kutta method. Simulation results show that the performance of the harvester under the quad-stable structural parameters is better than that under the bi-stable structural parameters, independent of whether the excitation acceleration is small or large. This result is related to the potential well characteristics under the quad-stable and bi-stable structural parameters. More specifically, the potential well depths under the quad-stable and bi-stable structural parameters are almost the same, but the distance between the two outer potential wells under the quad-stable structural parameters is larger than that under the bi-stable structural parameters. Finally, a fabricated prototype is used to measure the experimental performance of the harvester. The experimental data and the estimated data share the same trend. This study provides a new conception and technical method for the design, optimization, and application of quad-stable piezoelectric energy harvesters. Full article

To overcome high periodic maintenance requirements, difficult replacement, and large application limitations of wireless sensor nodes powered by chemical batteries during the vibration control process of stiffened plates, a two-degree-of-freedom diagonal beam piezoelectric vibration energy harvester was proposed. Multidimensional energy harvesting and broadband work are integrated into one structure through the combined action of oblique angle, mass blocks, and piezoelectric beam. The mechanical model of the beam is established for theoretical analysis; the output characteristics of the structure are analyzed by finite element simulation; a piezoelectric energy harvesting experimental bench is built. The results show that: The structure has a wider harvesting band, multi-order resonant frequency, multi-dimensional energy harvesting, and higher output voltage and power than the traditional cantilever structures. The output performance of the specimens with 45° oblique angle, 5 g:5 g mass ratio, and 0.2 mm thickness of piezoelectric substrate is good in the frequency band of 10~40 Hz. When the excitation frequency is 28 Hz, the output voltage of the sextuple array structure reaches 19.20 V and the output power reaches 7.37 mW. The field experiments show that the harvester array can meet the requirements of providing auxiliary energy for wireless sensor nodes in the process of active vibration control of stiffened plates. Full article

Semiconductor superluminescent light-emitting diodes (SLEDs) have emerged as ideal and vital broadband light sources with extensive applications, such as optical fiber-based sensors, biomedical sensing/imaging, wavelength-division multiplexing system testing and optoelectronic systems, etc. Self-assembled quantum dots (SAQDs) are very promising candidates for the realization of broadband SLED due to their intrinsic large inhomogeneous spectral broadening. Introducing excited states (ESs) emission could further increase the spectral bandwidth. However, almost all QD-based SLEDs are limited to the ground state (GS) or GS and first excited state (ES₁) emission. In this work, multiple five-QD-layer structures with large dot size inhomogeneous distribution were grown by optimizing the molecular beam epitaxy (MBE) growth conditions. Based on that, with the assistance of a carefully designed mirror-coating process to accurately control the cavity mirror loss of GS and ESs, respectively, a broadband QD-SLED with three simultaneous states of GS, ES₁ and second excited-state (ES₂) emission has been realized, exhibiting a large spectral width of 91 nm with a small spectral dip of 1.3 dB and a high continuous wave (CW) output power of 40 mW. These results pave the way for a new fabrication technique for high-performance QD-based low-coherent light sources. Full article

A weakly-coupled multicore fiber can generate supermodes when the multi-cores are closer to enter the evanescent power coupling region. The high sensitivity strain sensors using tapered four-core fibers (FCFs) were demonstrated. The fan-in and fan-out couplers were used to carry out light coupling between singlemode fibers and the individual core of the FCFs. A broadband lightsource from superlumminescent diodes (SLDs) was launched into one of the four cores arranged in a rectangular configuration. When the FCF was substantially tapered, the asymmetric supermodes were produced to generate interferences through this corner-core excitation scheme. During tapering, the supermodes were excited based on a tri-core structure initially and then transited to a rectangular quadruple-core structure gradually to reach the sensitivity of 185.18 pm/μԑ under a tapered diameter of 3 μm. The asymmetric evanescent wave distribution due to the corner-core excitation scheme is helpful to increase the optical path difference (OPD) between supermodes for improving the strain sensitivity. Full article

Coherent propagation of supermodes in a multicore fiber is promising for power scaling of fiber laser systems, eliminating the need for the active feedback system to maintain the phases between the channels. We studied the propagation of broadband pulsed radiation at a central wavelength of 1030 nm in a multicore fiber with coupled cores arranged in a square array. We designed and fabricated a silica multicore fiber with a 5 × 5 array of cores. For controllable excitation of a desired supermode, we developed a beam-forming system based on a spatial light modulator. We experimentally measured intensity and phase distributions of the supermodes, in particular, the in-phase and out-of-phase supermodes, which matched well the numerically calculated profiles. We obtained selective excitation and coherent propagation of broadband radiation with the content of the out-of-phase supermode of up to 90% maintained without active feedback. Using three-dimensional numerical modeling with allowance for a refractive index profile similar to those of the developed fiber, we demonstrated stable propagation of the out-of-phase supermode and collapse of the in-phase supermode at a high signal power. Full article

Symmetrical antenna array is useful for omni bearing beamforming adjustment with multiple receivers. Beam-forming techniques using evolution algorithms have been studied for multi-user resource allocation in simultaneous wireless information and power transfer (SWIPT) systems. In a high-capacity broadband communication system there are many users with wearable devices. A transmitter provides simultaneous wireless information and power to a particular receiver, and the other receivers harvest energy from the radio frequency while being idle. In addition, the ray bounce tracking method is used to estimate the multi-path channel, and the Fourier method is used to perform the time domain conversion. A simple method for reducing the frequency selective effort of the multiple channels using the feed line length instead of the digital phase shifts is proposed. The feed line length and excitation current of the transmitting antennas are adjusted to maximize the energy harvest efficiency under the bit error rate (BER) constraint. We use the time-domain multipath signal to calculate the BER, which includes the inter symbol interference for the wideband system. In addition, we use multi-objective function for optimization. To the best of our knowledge, resource allocation algorithms for this problem have not been reported in the literature. The optimal radiation patterns are synthesized by the asynchronous particle swarm optimization (APSO) and self-adaptive dynamic differential evolution (SADDE) algorithms. Both APSO and SADDE can form good patterns for the receiver for energy harvesting. However, APSO has a faster convergence speed than SADDE. Full article

Perfect broadband absorbers have increasingly been considered as important components for controllable thermal emission, energy harvesting, modulators, etc. However, perfect absorbers which can operate over a wide optical regime is still a big challenge to achieve. Here, we propose and numerically investigate a perfect broadband near-infrared absorber based on periodic array of four isosceles trapezoid prism (FITP) unit cell made of titanium (Ti) over a continuous silver film. The structure operates with low quality (Q) factor of the localized surface plasmon resonance (LSPR) because of the intrinsic high loss, which is the foundation of the broadband absorption. The high absorption of metal nanostructures mainly comes from the power loss caused by the continuous electron transition excited by the incident light inside the metal, and the resistance loss depends on the enhanced localized electric field caused by the FITP structure. Under normal incidence, the simulated absorption is over 90% in the spectrum ranging from 895 nm to 2269 nm. The absorber is polarization-independent at normal incidence, and has more than 80% high absorption persisting up to the incident angle of ~45° at TM polarization. Full article
