This study comprehensively analyzes the free vibration and transient response for a sandwich piezoelectric laminated beam with elastic boundaries in a thermal environment. Quasi-3D shear deformation beam theory (Q3DBT) and Hamilton’s principle are used to obtain the thermo-electro-mechanical coupling equations, and the method of reverberation-ray matrix (MRRM) is utilized to integrate the phase and scattering relationship of the structure in a unified approach. Specifically, the scattering relationship established by the Mixed Rigid-Rod Model (MRRM) via dual coordinate systems describes the general dynamic model of the beam using generalized displacements and generalized forces at the two endpoints. This analytical solution is compared with the finite element numerical results based on Solid5 and Solid45 elements. The similarity of this approach lies in the fact that solid elements can account for the Poisson effect of thick beams, while the difference is that solid elements have a certain width; here, the error is minimized by adopting a single-element division in the width direction. Comparison of the numerical results under different geometric parameters and boundary conditions with the simulation software proves that MRRM has good accuracy and stability in analyzing the dynamic performance of sandwich piezoelectric laminated beams. On this basis, a spring-supported boundary technology is introduced to expand the flexibility of classical boundary conditions, and a detailed parameterization study is conducted on the material properties of the base layer, including the material parameters, geometric property, and the external temperature. The study in this article provides many new results for sandwich-type piezoelectric laminated structures to help further research. Full article

A multiphysics-coupled 2–2 cement-based magnetoelectric composite model is established in COMSOL 6.2. This model is used to not only systematically investigate the magnetoelectric-coupling behavior, but also quantify the effects of the magnetic field, frequency, and layer-thickness ratio on the material’s magnetoelectric properties. The results demonstrate that the model effectively reproduces the internal stress–strain distribution and voltage evolution. Specifically, the magnetostrictive and piezoelectric layers exhibit mechanical responses with pronounced non-uniformity, which is attributed to boundary effects. The bias magnetic field plays a crucial regulatory role: the output voltage increases linearly from 0 to 2000 Oe and then saturates at higher fields. Under an alternating magnetic field, the composite exhibits pronounced resonance characteristics, whose frequency is jointly governed by structural dimensions and the bias field. The dynamic response was further analyzed using the magnetic flux density modulus, displacement profiles at selected locations, and voltage evolution across the piezoelectric layer. Notably, the thickness of each functional phase exerts a pronounced and distinct influence on the composite’s magnetoelectric coupling, with markedly different trends between phases. Optimization results show that a thin piezoelectric layer combined with a thick magnetostrictive layer yields the highest magnetoelectric performance. Additionally, the longitudinal and transverse magnetoelectric coefficients exhibit markedly different coupling mechanisms—this is owing to the misalignment between the magnetic-field and electric-polarization directions, and this difference further reveals the intrinsic anisotropy of the magnetoelectric response. Overall, this study provides a crucial theoretical foundation for the design and optimization of high-performance cement-based magnetoelectric composites. Full article

The Tankou area is a vital production capacity replacement area in the Jianghan oilfield. The recovery of the amount of erosion in Qianjiang Formation and Jinghezhen Formation is significant for studying this area’s tectonic evolution and geothermal history. The target layer, characterised by well-developed plastic materials, intense tectonic deformation, and insufficient well data, fails to meet the applicability criteria of the conventional denudation estimation methods. This study proposes a novel approach based on the structural strain characteristics. The method estimates the stratigraphic denudation by analysing residual formation features and fault characteristics. First, a stress analysis is performed using the fault characteristics, and the change law for the thickness of the target layer is summarised based on the characteristics of the residual strata to recover the amount of erosion in the profile. Second, a grid of the stratigraphic lines in the profiles of the main line and the tie line is used to complete the recovery of the amount of erosion in the plane through interpolation, and the results of the profile recovery are corrected again. Finally, the evolution results of the geological equilibrium method and the stress–strain analysis are compared to analyse the reasonableness of their differences and verify the accuracy of the erosion recovery results. The area of erosion in each layer increases from bottom to top. The amount of denudation in each layer gradually increases from the denudation area near the southern slope to the surrounding area. It converges to 0 at the boundary of the denudation area. The maximum amount of erosion is distributed in the erosion area close to the side of the residual layer with a low dip angle. The specific denudation results are as follows: Qian1 Member + Jinghezhen Formation has a denudation area of 6.3 km² with a maximum denudation thickness of 551 m; Qian2 Member has a denudation area of 2.6 km² with a maximum denudation thickness of 164 m; Qian3 Member has a denudation area of 2.3 km² with a maximum denudation thickness of 215 m; Upper Qian4 Submember has a denudation area of 1.54 km² with a maximum denudation thickness of 191 m; and Lower Qian4 Submember has a denudation area of 1.2 km² with a maximum denudation thickness of 286 m. This method overcomes the conventional denudation restoration approaches’ reliance on well logging and geochemical parameters. Using only seismic interpretation results, it achieves relatively accurate denudation restoration in the study area, thereby providing reliable data for timely analyses of the tectonic evolution, sedimentary facies, and hydrocarbon distribution patterns. In particular, the fault displacement characteristics can be employed to promptly examine how reasonable the results on the amount of denudation between faults are during the denudation restoration process. Full article

This work shows a three-dimensional (3D) layerwise model for static and free vibration analyses of functionally graded piezomagnetic materials (FGPM) spherical shell structures where magnetic and elastic fields are completely coupled. The 3D magneto-elastic governing equations for spherical shells are made of the three equations of equilibrium in three-dimensional form and the three-dimensional divergence equation for the magnetic induction. Governing equations are written in the orthogonal mixed curvilinear reference system ($\alpha$, $\beta$, z) allowing the analysis of several curved and flat geometries (plates, cylindrical shells and spherical shells) thanks to proper considerations of the radii of curvature. The static cases, actuator and sensor configurations and free vibration investigations are proposed. The resolution method uses the imposition of the Navier’s harmonic forms in the two in-plane directions and the exponential matrix methodology in the transverse normal direction. Single-layered and multilayered simply-supported FGPM structures have been investigated. In order to understand the behavior of FGPM structures, numerical values and trends along the thickness direction for displacements, stresses, magnetic potential, magnetic induction and free vibration modes are proposed. In the results section, a first assessment phase is proposed to demonstrate the validity of the formulation and to fix proper values for the convergence of results. Therefore, a new benchmark section is presented. Different cases are proposed for several material configurations, load boundary conditions and geometries. The possible effects involved in this problem (magneto-elastic coupling and effects related to embedded materials and thickness values of the layers) are discussed in depth for each thickness ratio. The innovative feature proposed in the present paper is the exact 3D study of magneto-elastic coupling effects in FGPM plates and shells for static and free vibration analyses by means of a unique and general formulation. Full article

This paper establishes a physical model for the non-contact rotary screen coating process based on a spacecraft structural plate and proposes a theoretical expression for the adhesive thickness of the non-contact rotary screen coating. The thickness of the adhesive is a critical factor influencing the quality of the optical solar reflector (OSR) adhesion. The thickness of the adhesive layer depends on the equivalent fluid height and the ratio of the fluid flow rate to the squeegee speed below the squeegee. When the screen and fluid remain constant, the fluid flow rate below the squeegee depends on the pressure at the tip of the squeegee. The pressure is also a function related to the deformation characteristics and speed of the squeegee. Based on the actual geometric shape of the wedge-shaped squeegee, the analytical expression for the vertical displacement of the squeegee is obtained as the actual boundary of the flow field. The analytical expression for the deformation angle of the squeegee is used to solve the contact length between the squeegee and the rotary screen. It reduces the calculation difficulty compared with the previous method. Based on the theory of rheology and fluid mechanics, the velocity distribution of the fluid under the squeegee and the expression of the dynamic pressure at the tip of the squeegee were obtained. The dynamic pressure at the tip of the squeegee is a key factor for the adhesive to pass through the rotary screen. According to the continuity equation of the fluid, the theoretical thickness expression of the non-contact rotary screen coating is obtained. The simulation and experimental results show that the variation trend of coating thickness with the influence of variables is consistent. Experimental and simulation errors compared to theoretical values are less than 5%, which proves the rationality of the theoretical expression of the non-contact rotary screen coating thickness under the condition of considering the actual squeegee deformation. The existence of differences proves that a small part of the colloid remains on the rotary screen during the colloid transfer process. The expression parameterizes the rotary screen coating model and provides a theoretical basis for the design of automatic coating equipment. Full article

The objective of the present paper is to demonstrate the effects of shear deformation and large deflections on the piezoelectric materials and structures which often serve as substrate layers of multilayer composite sensors and actuators. Based on a displacement-unified high-order shear deformation theory and the von Kármán geometric nonlinearity, a general theory (governing equations and associated boundary conditions) for the analysis of piezoelectric beams is developed using Hamilton’s principle. Nonlinear effects due to the coupling between extensional and bending responses in beams with moderately large rotations but small strains are included. A bending problem for a piezoelectric beam is solved analytically, and the obtained results are compared to the results available in the literature. The numerical results show that both shear deformation effects and von Kármán geometric nonlinearity have a stiffening effect and therefore reduce the displacements. The influence of geometric nonlinearity is more prominent in the case of thin beams, while the effects of shear deformation dominate in the case of thick beams. The proposed unified methodology for the analysis of bending problems is independent of the thickness of the piezoelectric beam. Full article

Understanding the melting of the deposited layer is crucial for the armature’s melting process and sliding electrical contact performance. This study first establishes contact models for both the boundary lubrication state (BLS) and squeezed-film lubrication state (SFLS). A three-dimensional magnetic diffusion model is then constructed to simulate interface current distribution in these contact states. It is discovered that the maximum current density on the surface of the armature shows a decreasing trend as the thickness of the deposited layer grows. Then, a calculation model for the deposited layer’s melting thickness under BLS is developed. For SFLS, Reynolds and energy equations are used to construct models for liquid film thickness and the deposited layer’s melting thickness. The results indicate that the deposited layer’s melting thickness under BLS is significantly greater than that under SFLS. Specifically, the melting thickness decreases with launching displacement in BLS and increases under SFLS. In SFLS, the deposited layer’s melting can suppress armature melting, though it remains nearly equivalent to that observed with polished rail. These findings provide a foundation for deposited layer control technology, which is essential for enhancing sliding electric contact performance and launching efficiency. Full article

A spatial problem of elasticity theory is solved for a layer located on two bearings embedded in it. The bearings are represented as thick-walled pipes embedded in the layer parallel to its boundaries. The pipes are rigidly connected to the layer, and contact-type conditions (normal displacements and tangential stresses) are specified on the insides of the pipes. Stresses are set on the flat surfaces of the layer. The objective of this study is to obtain the stress–strain state of the body of the layer under different geometric characteristics of the model. The solution to the problem is presented in the form of the Lamé equation, whose terms are written in different coordinate systems. The generalized Fourier method is used to transfer the basic solutions between coordinate systems. By satisfying the boundary and conjugation conditions, the problem is reduced to a system of infinite linear algebraic equations of the second kind, to which the reduction method is applied. After finding the unknowns, using the generalized Fourier method, it is possible to find the stress–strain state at any point of the body. The numerical study of the stress state showed high convergence of the approximate solutions to the exact one. The stress–strain state of the composite body was analyzed for different geometric parameters and different pipe materials. The results obtained can be used for the preliminary determination of the geometric parameters of the model and the materials of the joints. The proposed solution method can be used not only to calculate the stress state of bearing joints, but also of bushings (under specified conditions of rigid contact without friction on the internal surfaces). Full article

A 3D problem in linear elasticity is considered for a thin inhomogeneous layer subject to transverse compression. For the first time, the effect of arbitrary vertical inhomogeneity is elucidated. Two sets of boundary conditions along the faces of the layer are adapted for modelling transverse compression. Robust asymptotic formulae involving repeated integrals across the thickness are derived for displacements and stresses. As an illustration, numerical results are presented for the elastic moduli having a transverse parabolic variation. The obtained results have a potential to be implemented in modern technology, including manufacturing and design of functionally graded materials. Full article

The safety-grade water-intake immersed tunnel plays a vital role in the nuclear power cooling system, and its seismic safety is crucial. This paper employs the response displacement method and dynamic time-history analysis using the finite element software ANSYS to construct a beam–spring model and a 3D finite element model of a shield tunnel and foundation. It also develops equivalent linear dynamic constitutive and viscoelastic boundary element subprograms. This study focuses on the weak joint sections of immersed tunnels, conducting a seismic performance analysis under extreme safety earthquake conditions (SL-2). The results indicate that the joint stiffness of immersed tunnels and the increase in seismic peak values do not affect the trend of joint opening variation with longitudinal position. The change in joint opening is primarily located where the thickness of the cover layer changes abruptly or where the soil hardness is unevenly distributed. The joint opening is mainly influenced by seismic forces when considering static and dynamic superposition. When the stiffness of the joint GINA water stop exceeds a certain value, the correlation between stiffness change and joint compression–tension variation gradually weakens. This research can provide a reference for the seismic design of similar projects. Full article

In order to explore the flexural behavior of a concrete sandwich panel under concentrated boundary conditions, based on Kirachhoff’s elastic thin plate theory in this paper, the geometric deformation, physical conditions, and equilibrium relationship of a sandwich panel are deduced by constructing the layered analysis model of the sandwich panel, the basic differential equation of the flexural deformation of the concrete sandwich thin plate is obtained, and the mathematical expression of the internal force and displacement under the boundary condition of concentrated support is given. Combined with an engineering example, the proposed calculation method is verified. The results show that, in the arrangement of reliable connectors for concrete sandwich panels, the concrete wythes bear the load while the contribution of the core layer to the bending capacity of the structure can be ignored. When subjected to a laterally distributed load, the sandwich panel mainly experiences out-of-plane bending deformation, and the bending normal stress in the concrete panel layer shows a linear non-uniform distribution along the thickness direction of the panel. The bending deformation performance and bearing efficiency of a concrete sandwich slab with the change in concentrated support position have significant effects, and the load transfer efficiency can be improved by optimizing the arrangement of supports. Except for small local areas near the supports, the bending stress distribution and deformation behavior of the concrete sandwich panel can be accurately analyzed by the calculation method established in this paper. Full article

Liquefaction occurs in saturated sandy and silty soils due to transient and repetitive seismic loads. The result is a loss of soil strength caused by increased pore pressure. In this study, the response of buried pipes in the Iskenderun region during the earthquakes centered in the subprovinces of Pazarcık and Elbistan in Kahramanmaraş, Turkey, on 6 February 2023, has been investigated utilizing numerical analyses using geological data from two different areas. The effects of shallow and deep rock layers, pipe diameter, burial depths, and boundary conditions have been evaluated. In the analyses, records from two stations located in Iskenderun during the Pazarcık, Kahramanmaraş earthquake have been utilized, taking into account records from shallow rock (station no. 3116) and thick soil layers (station no. 3115), as determined from shear wave velocities. Modeling conducted using station 3116 records has revealed the effect of shallow rock layers on pipe displacement, indicating less damage in areas where the rock layer is close to the surface. The pipe uplift risk is higher when the bedrock is deep, and the overlying soil layer is liquefiable (station no. 3115). It has been determined that depth to bedrock significantly influences upward movement of the pipe. In the areas where the bedrock is deep, expanding the boundary conditions has helped reduce the effects of settlements outside the pipe, preventing the occurrence of pipe uplift. Increasing the pipe diameter has increased the amount of uplift. The analysis results are consistent with field observations. Full article

The aim of this research is to investigate the frequency of conical-shaped shells, consisting of different materials, based on higher-order shear deformation theory (HSDT). The shells are of non-uniform thickness, consisting of two to six symmetric cross-ply layers. Simply supported boundary conditions were used to analyse the frequency of conical-shaped shells. The differential equations, consisting of displacement and rotational functions, were approximated using spline approximation. A generalised eigenvalue problem was obtained and solved numerically for an eigenfrequency parameter and associated eigenvector of spline coefficients. The frequency of shells was analysed by varying the geometric parameters such as length of shell, cone angle, node number in circumference direction and number of layers, as well as three thickness variations such as linear, sinusoidal and exponential. It was also evident that by varying geometrical parameters, the mechanical parameters such as stress, moment and shear resultants were affected. Research results concluded that for three different thickness variations, as the number of layers of conical shells increases, the frequency values decrease. Moreover, by varying length ratios and cone angles, shells with variable thickness had lower frequency values compared to shells of constant thickness. The numerical results obtained were verified through the already existing literature. It is evident that the present results are very close to the already existing literature. Full article

The stability of the vertical flow that occurs when gas displaces oil from a reservoir is investigated. It is assumed that the oil and gas areas are separated by a layer saturated with water. This method of oil displacement, called water-alternating-gas injection, improves the oil recovery process. We consider the linear stability of two boundaries that are flat at the initial moment, separating, respectively, the areas of gas and water, as well as water and oil. The instability of the interfaces can result in gas and water fingers penetrating into the oil-saturated area and causing residual oil. Two cases of perturbation evolution are considered. In the first case, only the gas–water interface is perturbed at the initial moment, and in the second case, small perturbations of the same amplitude are present on both surfaces. It is shown that the interaction of perturbations at interfaces depends on the thickness of the water-saturated layer, perturbation wavelength, oil viscosity, pressure gradient and formation thickness. Calculations show that perturbations at the oil–water boundary grow much slower than perturbations at the gas–water boundary. It was found that, with other parameters fixed, there is a critical (or threshold) value of the thickness of the water-saturated layer, above which the development of perturbations at the gas–water boundary does not affect the development of perturbations at the water–oil boundary. Full article

The generation of hydro-mechanical resonance is related to the transition of the boundary layer and the development of vortex shedding. The application effect of suction control in hydrodynamics is equally deserving of consideration as an active control technique in aerodynamics. This study examines how suction control affects the flow field of the NACA0009 blunt trailing edge hydrofoil using the γ transition model. Firstly, the accuracy of the numerical method is checked by performing a three-dimensional hydrofoil numerical simulation. Based on this, three-dimensional hydrofoil suction control research is conducted. According to the results, the suction control increases the velocity gradient in the boundary layer and delays the position of transition. The frequency of vortex shedding in the wake region lowers, and the peak value of velocity fluctuation declines. The hydrofoil hydrodynamic performance may be successfully improved with a proper selection of the suction coefficient via research of the suction coefficient and suction position on the flow field around the hydrofoil. The lift/drag ratio goes up as the suction coefficient goes up. The boundary layer displacement thickness and momentum thickness are at their lowest points, and the velocity fluctuation amplitude in the wake region is at its lowest point as the suction coefficient C_μ = 0.003. When the suction slots are at the leading edge, the momentum loss in the boundary layer is minimal and the velocity fluctuation in the wake zone is negligible. Full article
