Driven by technological advancements and accelerated infrastructure development, an increase in the need to monitor the performance of prominent structures such as bridges, metro-corridors, and sea-link bridges is being advocated by experts to predict and minimize any hazards resulting from the degradation of the structures over time. However, accessing and replacing the batteries becomes problematic and expensive when the sensors are instrumented in remote areas of the bridge structures, especially when the sensors are embedded. For these reasons, a strong case can be made for harvesting and storing ambient energy from the surroundings to drive the sensors for structural health monitoring (SHM). This study aims to introduce a new trapezoidal strain-amplifying sensor/energy harvester (TSAH) for civil engineering structures that uses flexural strain amplification to enhance energy harvesting from structural vibrations. TSAH also serves as a sensor for integrated energy harvesting and SHM. This article examines the influence of the geometric properties of TSAH on strain amplification via numerical investigations under a specific set of external loads. Based on numerical studies, the sensors are bonded to the trapezoidal strain-amplifying plate to develop and assess the TSAH. Experimental investigations were carried out first in the laboratory to evaluate the effectiveness of the TSAH over the directly bonded (DB) sensors with two different types of piezo-transducers for energy harvesting. The host structure was exposed to impact and shaker vibrations for the laboratory research. For the various scenarios taken into consideration in the study, the typical amplification factor for peak voltage is determined to be between 1.45 and 3.75, while for the power, it is between 1.09 and 6.08. Further, for field verification, the TSAH configuration was evaluated on a real-life bridge structure, viz the Chipiyana rail over-bridge (ROB), Asia’s heaviest steel ROB located on the Delhi–Meerut expressway. The field experiments also establish the superior performance of TSAH, with an amplification factor ranging from 1.75 to 3.75 for peak voltage and 3.75 to 5.53 for peak power. As compared to the previously proposed curved configuration in the literature, the TSAH configuration is suitable for brittle sensors as well. Its ability to be permanently bonded by epoxy/welding, or temporarily using magnets, bolts, or clamps, offers it versatility over other surface bonded/embedded configurations. As a result of this, it imparts reusability in case of any damage, which promotes the goal of sustainability. Full article

Suspension bridges are the most common type of bridge used to cross the ocean. The cable clamps in suspension bridges clamp the main cables by bolt preload, but the elastic interaction of the bolts reduces the preload, which is detrimental to the force in suspension bridges. However, research on the factors influencing the elastic interaction of cable clamp bolts in suspension bridges is currently limited. This paper aims to explore the law of influence of external factors on the elastic interaction of bolts through a combined approach of theoretical analysis, full-scale experiment, and finite element simulation. The results indicate that the average preload loss was reduced by about 27% when the elastic modulus was increased by about 110%. The average preload loss was reduced by about 45% when the bolt center distance was increased by 75%. The number of bolts has a small effect on the elastic interaction, which can be ignored. When the preload of bolt installation was increased by 133%, the average preload loss was reduced by approximately 125%, which was almost a linear relationship. Tightening the bolt from the center bolt creates greater elastic interaction. The conclusions can provide suggestions for reducing the elastic interaction of bolts in the design and construction of suspension bridge cable clamps. Full article

Friction-type bolted joints are widely used in both the civil and aerospace industries. Uncontrolled excessive bolt clamping force can cause damage to the laminated fiber-reinforced polymeric (FRP) composite through the thickness and damage the joint before applying the service loads. The effect of the friction coefficient (between 0 and 0.3), bolt clearance, joint type, and other parameters on failure modes and the maximum bolt clamping force of the carbon FRP lapped joint is studied. A three-dimensional finite element (FE) model consisting of a bolt, a washer, a laminate FRP composite plate, and steel plates was developed for the simulation of the double- (3DD) and single (3DS)-lapped bolted joint. The FE model was validated by using experimental results and was able to predict the experimental results by a difference of between 2.2 and 6.7%. The joint capacity of the clamping force was found to be greatly increased by adopting the double lap technique, which involves placing an FRP composite plate between two steel plates. Also, it was recommended to use an internal washer diameter less than or equal to the FRP composite plate hole diameter since a larger washer clearance can produce higher contact pressure and reduce the resistance by 22%. In addition, reducing the bolt head diameter can lead to a 65% reduction in the 3DS joint clamping strength. Full article

Al_0.6CoFeNi₂V_0.5 high entropy alloy was successfully designed and prepared via the nonconsumable arc-melting process, and it was annealed at 600 °C, 800 °C, and 1000 °C for 4 h. Its microstructure and mechanical properties were studied. The as-cast alloy consisted of FCC and BCC phases, and no phase transformation occurred during annealing at 600 °C. Hard Al₃V-type metal compounds precipitated during annealing at 800 °C, and BCC particles precipitated in the FCC matrix during annealing at 1000 °C. After annealing, the strength and hardness of Al_0.6CoFeNi₂V_0.5 high-entropy alloy both showed a decreasing trend, because the annealing process eliminated the internal stress in this alloy. However, as the annealing temperature increased, the strength and hardness of the Al_0.6CoFeNi₂V_0.5 high-entropy alloy samples gradually increased. This is because the hard Al₃V metal compounds precipitated when the annealing temperature was 800 °C, which produced the “second phase strengthening” effect. At 1000 °C, the larger volume fraction of the hard and fine BCC phase (21.81%) diffusely precipitated; the precipitation of this BCC phase not only produced a “second phase strengthening” effect, which also resulted in “solid solution strengthening”, ultimately exhibiting enhanced hardness and strength. These findings have important theoretical reference value for the study of the microstructure and mechanical properties of high-entropy alloys. And, this study plays a significant role in promoting the research and development of new component materials that bear compressive loads, such as columns in large factory buildings, supports for cranes, and clamping bolts for rolling mills in practical mechanical engineering. Full article

The aim of this article is to investigate the effect of atmospheric conditions on the tightening behaviour of HV bolts in structural bolt sets. The article describes the results of experimental tests carried out for bolt sets of a selected type. The parts of the joined sets were stored according to the specified six different conditions for four weeks before assembly. Paper, cardboard boxes and anticorrosion foils were used as protection against atmospheric conditions. The behaviour of unassembled and assembled bolt sets was also taken into account. The variation in the friction coefficient depending on the clamping force and storage conditions of the bolt sets was demonstrated. This applies both to the contact between the joining elements on the threaded surfaces and to the area between the bolt head and the bearing surface of the nut and washer. Full article

The hydraulic pipeline vibration noise is one of the main noise sources in submarine stealth conditions. Taking the local hydraulic system of a certain type of submarine as the research object, a model is first developed to simulate water hammer pressures and to study the influence of component parameters on the generation and transmission of water hammers. Then, using the maximum water hammer as the excitation, fluid–structure interaction (FSI) vibration characteristics analysis of the pipeline is carried out. Additionally, the simulation method of clamp bolt pre-tightening is discussed. Finally, the modal test of various specifications of the pipeline is carried out. The results show that the error between the simulation and the test results is within 10%, which verifies the correctness of the model settings. On this basis, with the position of the clamp as the independent variable and the maximum stress of pipelines as the dependent variable, the optimization of pipeline passive vibration control is carried out by genetic algorithm, and the finite element verification shows that the pipeline vibration stress is effectively reduced. Full article

In this review paper, first of all, an analysis of the circular economy and its application to steel structures is carried out. It highlights the need to apply the philosophy of Design for Deconstruction or Design for Disassembly (DfD) from the conception of the structure so that it can be truly reconfigurable. Then, a brief review of the different types of connections for steel structures is conducted, comparing the level of research and development of each of them and the degree of reconfiguration that is possible to obtain. Subsequently, the article focuses on the type of connection using clamps, a key point of this work and on which, to date, there are no state-of-the-art studies. It describes the types of clamps, their principle of operation, the types of connections developed with them, and the results of the different investigations that allow for calculating these types of connections. A summary is also given of how these connection types work according to the geometrical characteristics of the clamp and the bolt so that this review work can serve as a driver for the widespread use of clamp-based connections by researchers and engineers in the design and manufacturing of demountable and reconfigurable steel structures. Finally, some conclusions are given, indicating the advantages and disadvantages of this connection system and future lines of research. Full article

The fiber-reinforced polymeric (FRP) composite can be joined by adhesive bonding or mechanically fastening the composite element. Carbon fiber-reinforced polymers (CFRP) and glass fiber-reinforced polymers (GFRP) are the most common types of polymers. Mechanically fastened or bolted joints do not need treatments, and the surface temperature and other environmental effects such as humidity do not affect its strength. In this research, the previous research that describes the behavior of the composite bolted joint (CBJ) is presented and summarized including the modes of failure of the CBJ, and the experimental works that explain the bearing failure (BF) of the CBJ. In addition, the effects of bolt clamping force (BCF) and techniques that are used to simulate the progressive failure and damage in composite materials and finite element simulation works are surveyed. Full article

Droplets with a core–shell structure formed from two immiscible liquids are used in various industrial field owing to their useful physical and chemical characteristics. Efficient generation of uniform core–shell droplets plays an important role in terms of productivity. In this study, monodisperse core-shell droplets were efficiently generated using a flexural bolt-clamped Langevin-type transducer and two micropore plates. Water and silicone oil were used as core and shell phases, respectively, to form core–shell droplets in air. When the applied pressure of the core phase, the applied pressure of the shell phase, and the vibration velocity in the micropore were 200 kPa, 150 kPa, and 8.2 mm/s, respectively, the average diameter and coefficient of variation of the droplets were 207.7 μm and 1.6%, respectively. A production rate of 29,000 core–shell droplets per second was achieved. This result shows that the developed device is effective for generating monodisperse core–shell droplets. Full article

As the fibre reinforced plastic composites gain larger and larger share in industry, the problem of joining them with metal elements becomes significant. The current paper is the first part of the literature review, which gathers and evaluates knowledge about methods suitable for mechanical joining of composite and metal elements. This paper concerns bolted joining, because this method of mechanical joining is widely used for joining composite materials. The paper describes failure modes of bolted joints in composite materials, the influence of the bolt clamping torque, the clearance between the bolt and the hole and aging on the performance of the joint, drilling techniques used in composite materials in order to minimize damages, different fastener types, inspection techniques, and finally, the techniques that have been developed in order to improve the strength of the bolted joints in composites. Since the hole drilled in a composite material in order to perform bolted joining is a weak point of the structure, those techniques: bonded inserts, titanium foil internal inserts, fibre steering, additional reinforcement, and moulded holes, mainly aim to improve the strength of the hole in the composite. The techniques have been discussed in details and compared with each other in the summary section. Full article

The friction-type high-strength bolted (FHSB) T-stub connection has been widely used in steel structures, due to their good fatigue resistance and ease of installation. While the current studies on FHSB T-stub connections mainly focus on the structural behaviors under both shear and tensile force, no research has been reported on the mechanical responses of the connections under the combined effects of shear and compression. To make up for this gap, this paper presents a novel FHSB T-stub connection, which is simple in structure, definite in load condition, and easy to construct. Static load tests were carried out on 21 specimens under different shear–compression ratios, and the finite-element (FE) models were created for each specimen. The failure modes, initial friction loads and ultimate strengths of the specimens were compared in details. Then, 144 FE models were adopted to analyze the effects of the friction coefficient, shear–compression ratio, bolt diameter and clamping force on the initial friction load and ultimate strength. The results showed that the FHSB T-stub connection under shear and compression mainly suffers from bolt shearing failure. The load–displacement curve generally covers the elastic, yield, hardening and failure stage. If the shear–compression ratio is small and the friction coefficient is large, its curve only contains the elastic and failure stage. The friction coefficient and shear–compression ratio have great impacts on the initial friction load and ultimate strength. For every 1 mm increase in bolt diameter, the initial friction load increased by about 10%, while the ultimate strength increased by about 8.5%. For each 10% increase/decrease of the design clamping force, the initial friction load decreases/increases by 7.8%, while the ultimate load remains basically the same. The proposed formula of shear capacity and self-lock angles of FHSB T-stub connection can be applied to the design of CSS-enhanced prestressed concrete continuous box girder bridges (PSC-CBGBs) and diagonal bracing. Full article

The aim of this study is to design and test a new, simple, and reusable linear variable differential transformer (LVDT)-based in situ bolt preload monitoring system (L-PMS) during fastening of a truck wheel assembly. Instead of measuring the elongation of a bolt, the distance between the end surfaces of both the bolt and nut was monitored via the L-PMS. The distance obtained from the L-PMS was experimentally correlated with the actual preload measured by a washer-type load cell. Since the variation of the distance is related to the stiffness of the bolt and clamped parts, a finite element analysis was also conducted to predict the sensitivity of L-PMS. There was a strong linear relationship between the distance and bolt preload after the bolt and nut were fully snugged. However, a logarithm-shaped nonlinear relationship was irregularly observed before getting snugged, making it difficult to define a clear relationship. In order to tackle this issue, an arc-shaped conductive line was screen-printed onto the surface of the clamped parts using a conductive carbon paste. The results show that a resistance variation of the conductive line during fastening enables to determine the snug point, so the L-PMS combined with resistance measurement results in an approximately ±6% error in the measurement of bolt preload. The proposed L-PMS offers a simple but highly reliable way for measuring bolt preload during fastening, which could be utilized in a heavy-truck production line. Full article

A macroscopic constitutive model is proposed in this research to reproduce the uniaxial transition ratcheting behaviors of the superelastic shape memory alloy (SMA) undergoing cyclic loading, based on the cosine-type phase transition equation with the initial martensite evolution coefficient that provides the predictive residual martensite accumulation evolution and the nonlinear feature of hysteresis loop. The calculated results are compared with the experimental results to show the validity of the present computational procedure in transition ratcheting. Finite element implementation for the self-loosening behavior of the superelastic SMA bolt is then carried out based on the proposed constitutive model to analyze the curves of stress-strain responses on the bolt bar, clamping force reduction law, dissipation energy change law of the bolted joint for different external loading cases, and preload force of the bolt. Full article

A modified large thrust ultrasonic linear motor using a T-shape configuration composed of two orthogonal sandwich-type transducers has been proposed in this paper. It is an improved version of a previous T-shape motor. The vertical transducer is used to generate the normal force between the driving foot and slider, while the other push-pull–type horizontal transducer is applied to generate driving force to push the working platform. By superimposing the two longitudinal vibrations, the proposed motor generates an elliptical movement on the driving foot. In order to improve the vibration characteristics and amplify the driving vibration amplitude, the shape of the driving foot and horn have been redesigned and optimized. The finite element method (FEM) is used to adjust the structural parameters to degenerate the two working mode frequencies. The prototype has been fabricated and its mechanical output ability has been measured. The output characteristics of the modified motor, compared with the previous T-shape motor, achieve a relatively high level. The typical no-load speed and maximum output thrust of the prototype are 0.83 m/s and 56 N under an exciting voltage of 150 V_rms. Full article
