Battery cell balancing is crucial in series-connected lithium-ion packs to maximize usable capacity, ensure safe operation, and prolong cycle life. This paper presents a comprehensive study and a novel adaptive duty-cycled hybrid balancing system that combines passive bleed resistors and an active switched-capacitor (SC) balancer, specifically designed for a 4-cell series-connected battery pack. This work also explored open circuit voltage (OCV)-driven adaptive pulse-frequency modulation (PFM) active balancing to achieve higher efficiency and better balancing speed based on different system requirements. Finally, this paper compares passive, active (SC-based), and adaptive duty-cycled hybrid balancing strategies in detail, including theoretical modeling of energy transfer and efficiency for each method. Simulation showed that the adaptive hybrid balancer speeds state-of-charge (SoC) equalization by 16.24% compared to active-only balancing while maintaining an efficiency of 97.71% with minimal thermal stress. The simulation result also showed that adaptive active balancing was able to achieve a high efficiency of 99.86% and provided an additional design degree of freedom for different applications. The results indicate that the adaptive hybrid balancer offered an excellent trade-off between balancing speed, efficiency, and implementation simplicity for 4-cell Li-ion packs, making it highly suitable for applications such as high-voltage portable chargers. Full article

As the demand for second-life lithium-ion battery applications continues to grow, efficient cell equalization has become essential to mitigate parameter inconsistencies and extend system longevity. Owing to their diverse origins and varying aging paths, second-life batteries exhibit significant parameter dispersion, which poses distinct challenges. In light of these issues, this paper presents a comprehensive review of passive, active, and dynamic equalization technologies. It analyzes the circuit topologies and control strategies associated with each method, with a particular focus on their applicability to second-life battery systems. Furthermore, emerging trends toward intelligent, modular, and adaptive equalization are discussed. Full article

In this work, a battery active grouping equalization control strategy based on model predictive control (MPC) was proposed, which can promote cell consistency, equalization speed and energy loss during the battery equalization process. The dynamic group equalization topology based on reconfigurable circuits can achieve dynamic grouping. Using a battery state observation estimator and the MPC controller, multiple non-adjacent cells can realize simultaneous equalization in a single equalization process. An algorithm is designed to determine the optimal energy transfer direction and the optimal equalization current. The objective function of this algorithm incorporates weight coefficients that represent the relative importance of equalization time and energy loss. Simulation tests are conducted to evaluate the battery pack state-of-charge (SOC) root mean square, average temperature, and equalization time under various weight coefficients. Compared with two other traditional equalization control strategies, the proposed strategy reduces the equalization time by 43.93%, decreases the battery pack SOC variance by 50.18%, and improves the energy transfer efficiency by 0.59%. Full article

The lithium-ion battery equalization system is a critical component in Low-Earth Orbit (LEO) satellite power supply systems, ensuring the consistency of battery cells, maximizing the utilization of battery pack capacity, and enhancing battery reliability and cycle life. In DC bus satellite power systems, passive equalization technology is widely adopted due to its simple structure and ease of control. However, passive equalization suffers from drawbacks such as complex thermal design and limited operation primarily during battery charging. These limitations can lead to inconsistent control over the depth of discharge of individual battery cells, ultimately affecting the overall lifespan of the battery pack. In contrast, active equalization technology offers higher efficiency, faster equalization speeds, and the ability to utilize digital control methods, making it the mainstream direction for the development of lithium-ion battery equalization technology. Nevertheless, active equalization often requires a large number of switches and energy storage components, involves complex control algorithms, and faces challenges such as large size and reduced reliability. Most existing active equalization techniques are not directly applicable to DC bus satellite power systems. In this study, based on the operational characteristics of LEO satellite power storage batteries, an active–passive hybrid equalization topology utilizing a switching matrix is proposed. This topology combines the advantages of a simple structure, ease of control, and high reliability. Its feasibility has been validated through experimental results. Full article

The inconsistency of individual lithium-ion batteries causes the voltage imbalance of the batteries. An effective voltage-balancing circuit is essential to improve the inconsistency of series-connected batteries. This paper presents an isolated resonant voltage-balancing circuit for series-connected lithium-ion batteries based on a multi-port transformer. This circuit utilizes the multi-port transformer to enable free energy flow among the batteries. Without any direct transmission path between the capacitor and the battery string, it achieves full isolation between them. The resonant circuit is adopted to realize the soft-switching operation. Compared with other active balancing circuits, the proposed circuit requires only half a winding and one transistor per individual battery. Consequently, the proposed circuit enhances power density and further improves efficiency and reliability. Additionally, a fixed-group-number control strategy is introduced to enhance the circuit’s equalization voltage capabilities. Finally, a prototype of the voltage-balancing circuit for 24 series-connected lithium-ion batteries is established to verify the effectiveness and feasibility of the proposed circuit. Full article

To enhance equalization efficiency and address the issue of traditional equalization methods overlooking temperature factors, this paper proposes a multilayer equalization circuit for both intra-group and inter-group balancing. The traditional Buck-Boost equalization topology between groups is improved by incorporating a two-way interleaved inductor structure, which helps reduce equalization idle time. An adaptive fuzzy control equalization strategy for multiple objectives is applied to the topology. The state of charge (SOC) and temperature of the battery are used as key variables for equalization, with the equalization current dynamically adjusted based on changes in the SOC and temperature. This approach improves the balance between equalization speed and temperature control, reducing equalization time while limiting battery temperature rise. A simulation model is developed using MATLAB/Simulink. The simulation results demonstrate that, compared to the traditional Buck-Boost equalization topology, the proposed topology reduces equalization time by 15.1%. Additionally, under three different operating conditions, the equalization cotnrol strategy designed in this paper improves time efficiency by over 14% compared to traditional methods, while also reducing both the maximum temperature and temperature difference. Full article

With the increasing emphasis on emission reduction targets, the low-carbon sustainable transformation of industrial energy supply systems is crucial. Addressing the urgent issue of reducing industrial carbon emissions, this study presents an integrated industrial energy supply system (IRE-CCUS-BESS-SPS) that incorporates renewable energy; calcium-based carbon capture, utilization, and storage (CCUS); and battery energy storage systems (BESSs) to improve energy efficiency and sustainability. The system model is designed to achieve a cost-effective and environmentally low-impact energy supply, validated through Aspen Plus V11.0 and Matlab R2019b simulations. The system’s performance is evaluated using a 4E index system encompassing economy, environment, energy, and exergy. The findings indicate that the system’s lifetime net present value (NPV) is positive, with a payback period of 6.09 years. Despite a 12.9% increase in the overall economic cost, carbon emissions are significantly reduced by 59.78%. The energy supply composition includes 48.60% from fuel oil and 22.10% from biomass, with an additional 270.04 kW of heat provided by waste heat boilers. The equalization costs for CO₂ removal (LCCR) and methanation (LCOM) are 122.95 CNY/t and 10908.35 CNY/t, respectively, both exceeding current carbon emission trading costs and methane prices. This research offers a robust framework for designing sustainable industrial energy systems that integrate renewable energy, CCUS, and energy storage technologies for low-carbon operations. The analysis also suggests that government policies, such as direct financial subsidies or tax relief, are effective in accelerating the adoption of CCUS technology. Full article

In large-scale industrial and commercial energy storage systems, as well as ground power station energy storage systems, the trend is to adopt large-capacity battery cells to reduce system construction costs. It is essential to screen the consistency of battery cells during the initial design phase. In conventional energy storage systems, battery clusters utilize multiple batteries connected in series, which can lead to differential attenuation over time and inconsistent state of charge (SOC) among the batteries. The “barrel effect” diminishes the effective capacity of the energy storage system. To mitigate this issue, a DC–DC converter cascaded energy storage system has been developed, incorporating precise charge and discharge management for each battery module within a cluster. By implementing SOC equalization control at the module level, it mitigates the barrel effect and enables full utilization of each battery module’s charging and discharging capabilities, thereby enhancing the overall charge–discharge capacity of the energy storage system. However, when considering only the SOC equalizing factor, its effectiveness may be limited by constraints such as DC–DC converter power limitations and device voltage stress levels. Therefore, a novel SOC equalization control method that considers both SOH and SOC variations across battery modules is proposed here. Through a droop control methodology combined with closed-loop control implementation on eight DC–DC converter cascaded energy storage systems, we validate the improved effectiveness achieved by incorporating SOH-aware SOC equalization control. The energy storage system has the capability to enhance both charging and discharging capacities, achieving a remarkable increase of 1.85% every 10 min, thereby yielding significant economic advantages. Full article

Early SOC balancing techniques primarily centered on simple hardware circuit designs. Passive balancing circuits utilize resistors to consume energy, aiming to balance the SOC among batteries; however, this approach leads to considerable energy wastage. As research progresses, active balancing circuits have garnered widespread attention. Successively, active balancing circuits utilizing capacitors, inductors, and transformers have been proposed, enhancing balancing efficiency to some extent. Nevertheless, challenges persist, including energy wastage during transfers between non-adjacent batteries and the complexity of circuit designs. In recent years, SOC balancing methods based on software algorithms have gained popularity. For instance, intelligent control algorithms are being integrated into battery management systems to optimize control strategies for SOC balancing. However, these methods may encounter issues such as high algorithmic complexity and stringent hardware requirements in practical applications. This paper proposes a fast state-of-charge (SOC) balance control strategy that incorporates a weighting factor within a modular battery energy storage system architecture. The modular distributed battery system consists of battery power modules (BPMs) connected in series, with each BPM comprising a battery cell and a bidirectional buck–boost DC-DC converter. By controlling the output voltage of each BPM, SOC balance can be achieved while ensuring stable regulation of the DC bus voltage without the need for external equalization circuits. Building on these BPMs, a sliding mode control strategy with adaptive acceleration coefficient weighting factors is designed to increase the output voltage difference of each BPM, thereby reducing the balancing time. Simulation and experimental results demonstrate that the proposed control strategy effectively increases the output voltage difference among the BPMs, facilitating SOC balance in a short time. Full article

This paper describes active battery balancing based on a bidirectional buck converter, a flyback converter, and battery cells by using the proposed chain-loop comparison strategy. The role of the bidirectional buck converter is to charge/discharge the battery pack. During the charging period, the converter is in buck mode, and its output is controlled by constant current/voltage; during the discharging period, the converter is in boost mode, and its output is controlled by constant voltage. The role of the flyback converter is voltage equalization of the battery pack, and its output is controlled by constant current. A chain-loop comparison strategy is used to control battery voltage equalization. In this work, three equalization modes, namely, charging balance, discharging balance, and static balance, were considered. The voltage difference between the maximum and minimum is 0.007 V after a balancing time of 19.75 min, 0.005 V after a balancing time of 24 min, and 0.007 V after a balancing time of 20 min for charging balance, discharging balance, and static balance, respectively. Full article

This research aims at proposing an alternative to improve the efficiency of electric vehicles (EVs) and reduce greenhouse gas (GHG) emissions in the context of electric mobility. A photovoltaic and wind hybrid energy system was installed in a Chok S2 electric vehicle. In addition, a charge equalization system was included to balance and maximize the performance of each of the EV’s five batteries connected in series. The results show a 20% improvement in vehicle efficiency after conducting tests on a 17 km Andean route. The photovoltaic system generated 535 W, while the wind system generated 135 W/s at a speed of 45 km/h. These findings highlight the potential of hybrid renewable energy systems to improve the efficiency and range of electric vehicles. Full article

Traditional fuel vehicles are currently still the main means of transportation when people travel. It brings convenience to their travels, but it also causes energy shortages and environmental pollution. With the development of science and technology and the popularization of green environmental protection, electric vehicles have gradually entered people’s lives, greatly alleviating these problems. As a power supply device for electric vehicles, the performance of batteries directly affects various indicators of vehicles. Due to their long lifespan and high energy density, lithium-ion batteries are now the preferred source of power for electric vehicles. However, due to various factors in the manufacturing and operation of lithium-ion batteries, there are often differences among individual cells. The power balance and performance of a battery pack are closely related. Thus, battery equalization is an important standard for a battery management system to work normally, and it is also one of the various battery management application problems. This paper reviews battery equalization systems and various active equalization circuits and summarizes the working principle and research progress of each active equalization circuit. Then, various active equalization circuits are analyzed and compared, and dynamic equalization for a second-life battery is introduced to enrich this review of equalization technology. Finally, the above contents are summarized and prospected. In order to obtain the best outcomes, different equalization circuits need to be chosen for various situations. Full article

Sustainable transportation is crucial in addressing global road safety and environmental challenges. This study introduces a novel photonic radar system, leveraging Linear Frequency-Modulated Continuous Wave (LFMCW) technology for high-speed data transmission. Operating in a homodyne configuration, this system uses a single oscillator to generate both signal and reference waveforms. It incorporates mode division multiplexing (MDM) to enable the detection and ranging of multiple targets, even under adverse atmospheric conditions. To counter atmospheric attenuation, the system is equipped with a 2 × 2 MIMO technique and an Infinite Impulse Response (IIR) filter. Numerical simulations demonstrate the system’s superior performance in range resolution and target detection, achieving significant power improvements. The IIR filter further enhances detection, achieving a power improvement of 200% for target 1 and 276% for target 2. With low power requirements and enhancement through IIR filter equalization, this system presents a viable option for battery-operated vehicles. This innovative approach offers a low-power high-efficiency solution suitable for battery-operated vehicles, promoting safer and more reliable sustainable transportation. Full article

In order to address the energy imbalance issue of a series-connected lithium-iron battery pack, this paper proposes an active equalization method based on a reduced-order solving strategy for the Hanoi Tower problem. The proposed scheme utilizes a combined structure of a switching-network circuit and a bidirectional Cuk converter and leverages an ultracapacitor cell as the energy-transfer carrier. Simulation and comparison demonstrate that the exchange of unbalanced energy within the battery pack can be achieved. The proposed approach can effectively achieve various balancing modes such as cell-to-cell, cell-to-string, string-to-cell, and string-to-string with a relatively fast balancing speed. Full article

The utilization of photovoltaic (PV) generation to charge storage batteries in recreational vehicles (RVs) is becoming increasingly prevalent. However, the performance of PV generation systems is hindered by the mismatch caused by different module types and varying environmental conditions. This discrepancy negatively impacts the output performance of PV modules, resulting in reduced system efficiency. To address this issue, this paper explored the series–parallel output characteristics of different types of PV modules and summarized the methods for configuring PV modules in a mixed-structure PV generation system for RV energy supplementation. Building upon this foundation, a novel equalization scheme based on extremum-seeking control (ESC) is introduced. The scheme initially employs a forward–flyback converter (FFC) to equalize the current among series-connected PV modules, followed by matching the voltage between parallel-connected PV module strings. Finally, the ESC is utilized to optimize the real-time output power of the PV generation system, thereby enhancing overall system efficiency. Through simulation experiments conducted on a PV generation system with four types of mixed-connection PV modules employing the PLECS simulation platform, simulated results demonstrate the effectiveness of the proposed scheme in improving PV module output performance and maximum power tracking efficiency. The simulation data reveal that the proposed scheme achieves an impressive average tracking efficiency of 99.15%, surpassing the efficiency of the global maximum power point tracking scheme based on an enhanced perturb and observe algorithm. Full article
