As a high-performance lightweight structural material with superior strength, Ti55531 titanium alloy has been widely adopted in critical load-bearing components such as landing gears and airframe frames in the aerospace sector to achieve significant weight reduction. However, when the tensile strength of Ti55531 exceeds 1250 MPa, the fracture toughness typically falls below 50 MPa·m^1/2. In this study, we addressed this challenge by precisely controlling the cooling rate during β annealing heat treatment. Through careful regulation of the cooling rate from the high-temperature β phase region to the aging temperature region, the Widmanstätten structure was successfully introduced into the Ti55531 titanium alloy. The experimental results demonstrate that this microstructure achieves a high tensile strength of 1252 MPa at a cooling rate of 2.5 °C/min, while simultaneously improving the elongation and fracture toughness to 9% and 84 MPa·m^1/2, respectively. Microstructural analysis reveals that the basket-weave structure plays a crucial role in maintaining high strength. Meanwhile, the Widmanstätten structure effectively increases the energy required for crack extension by resisting crack propagation and altering the crack propagation path, thus significantly enhancing fracture toughness. These findings offer a promising pathway for overcoming the traditional trade-off between strength and toughness in high-performance titanium alloys. Full article

Additive manufacturing (AM) of Ti-6Al-4V alloy is widely used in aerospace and medical fields due to its excellent strength and corrosion resistance. However, the microstructural heterogeneity induced by the AM process often results in fatigue properties inferior to those of their forged counterparts. Synchrotron Radiation Computed Tomography (SR-CT) was employed to conduct an in situ three-dimensional investigation of fatigue damage evolution in Ti-6Al-4V alloy fabricated via laser powder bed fusion (LPBF). Experimental results revealed phenomena of crack bridging and deflection, accompanied by the consistent presence of local high-density zones (LHDZs) throughout the fatigue damage progression. Combined with quantitative analysis of crack propagation rates, the influence of LHDZs on fatigue damage evolution was analyzed, and the relationship between AM processes, LHDZs, and fatigue damage was discussed. The results indicate that the basket-weave α-phase microstructure in Ti-6Al-4V prepared by LPBF exhibits a high correlation with the distribution of LHDZs, and the orientation of LHDZs aligns with the crack propagation direction. By adjusting process parameters such as cooling rate and temperature gradient, the formation of LHDZs can be modified, thereby influencing the fatigue properties of the material. This provides theoretical support for achieving process optimization of the fatigue properties of Ti-6Al-4V alloy prepared via LPBF. Full article

This study presents the development of a three-dimensional (3D) filament assembly model for predicting the air permeability of woven fabrics composed of spun yarns. To address the limitations of conventional single-line yarn models, the proposed framework incorporates fiber-level geometric representations using non-uniform rational B-splines (NURBS) and simulates multiple weave patterns—including plain, basket, twill, and rib—under various set density configurations. Each yarn was modeled with accurate filament distribution and cross-sectional layering, enabling the construction of realistic unit-cell-based CAD geometries. Computational fluid dynamics (CFD) simulations were performed using the k-ε turbulence model in SolidWorks Flow Simulation and validated against experimental measurements conducted under ISO 9237:1995 conditions. The filament assembly model achieved high predictive accuracy, exhibiting a lower of percentage prediction errors than the single-line yarn path model, thereby more effectively capturing airflow behavior through inter-yarn and intra-yarn pores. These findings highlight the capability of integrated CAD/CFD methodologies for virtual prototyping of breathable textiles and provide a robust foundation for high-precision performance prediction in functional and technical fabric design. Full article

This paper presents the fatigue limit of flax/PLA composites with different fiber reinforcement architectures. The configurations of the analyzed flax/PLA composites are [0°]₈, [0°/90°]_s, [+45°/−45°]_s, [90°]₄, stacking sequences, and basket weave laminates. The methods used to estimate the fatigue limit are the fitting of stress versus number of cycles data using Weibull and Basquin equations, the surface thermographic technique with bilinear and exponential models to analyze the evolution of temperature increment, and volumetric dissipated energy. According to the results found, superficial temperature and the maximum strain reached stabilization over 2000 cycles for σ_max/σ_ut < 0.7, which was used to determine cyclic stress–strain curves and the fatigue limit. The cyclic stress–strain shows a nonlinear behavior for all laminates, having a good correlation to the Ramberg–Osgood model. Furthermore, having the stabilized temperature and volumetric dissipated energy, the exponential model was used to evaluate the fatigue limit and compared to the values found by Basquin and bilinear models. The fatigue limit found by Basquin and bilinear models shows conservative values compared to the exponential models. The results also show that temperature measurement using infrared thermography is quite sensitive to the environmental temperature variation, especially at low stress applied, and finally, the comparison of these methods on different reinforcement configurations provides a guide to select a proper technique in each case. Full article

The stability of a backfill roof is critical to ensure safe production in underhand drift-and-fill mining. In this method, the basket weave drift layout is widely accepted. However, there is currently limited research on the displacement distribution and strength requirement of the backfill roof with this drift layout. To address the gap, a three-dimensional numerical model was established with FLAC3D, with the Maoping Lead–Zinc Mine as the engineering background, to investigate the stability of a backfill roof with the basket weave drift layout. In numerical simulations, an iterative search method was applied to determine the strength requirements of the backfill roof. The results show that the displacement of the backfill roof with the basket weave drift layout shows columnar or strip-like distribution patterns. The strength requirements (unconfined compressive strength) of the backfill roof in limited equilibrium for drift sizes of 3.5 m × 3.0 m, 4.5 m × 4.0 m, and 5.5 m × 5.0 m were determined to be 1.34 MPa, 1.57 MPa, and 2.38 MPa, respectively. A comparison was also made between the strength requirement predicted by traditional analytical solutions and those obtained from numerical simulations, which shows that traditional solutions tend to yield conservative results. The method and analysis process employed in this study can provide valuable references for backfill strength design in mines using underhand drift-and-fill mining. Full article

Ti-6Al-4V (Ti64) alloy is widely utilized in the aerospace industry due to its high strength, fatigue resistance, corrosion resistance, and cryogenic properties. However, its high raw material costs and machining difficulties necessitate the development of efficient manufacturing processes. This study evaluates the mechanical reliability and microstructure of Ti64 components fabricated using wire laser additive manufacturing (WLAM) and subsequently joined via tungsten inert gas (TIG) welding. The WLAM process produces refined microstructures with superior mechanical properties by minimizing defects; however, insufficient process optimization may result in a lack of fusion (LOF) and porosity. Microstructural analysis revealed that the WLAM deposits exhibited a fine basket-weave α structure with an average α-lath width of 1.27 ± 0.69 μm, while the TIG-welded region exhibited a coarsened α-lath, reaching 3.02 ± 2.06 μm, which led to a reduction in ductility. Tensile testing demonstrated that the WLAM deposits exhibited superior mechanical properties, with a yield strength of 910 MPa, ultimate tensile strength of 1015 MPa, and elongation of 12.8%, outperforming conventional wrought Ti64 alloys. Conversely, the TIG-welded joints exhibited reduced mechanical properties, with a yield strength of 812 MPa, ultimate tensile strength of 917 MPa, and elongation of 7.5%, primarily attributed to microstructural coarsening in the weld region. The findings of this study confirm that WLAM enhances the mechanical properties of Ti64, whereas TIG welding may introduce structural weaknesses. This research provides insight into the microstructural evolution and mechanical behavior of WLAM-fabricated Ti64 components, with valuable implications for their application in aerospace structures. Full article

The resistance to near-threshold fatigue crack growth and its correlation with the microstructure of the Ti-5Al-3Mo-3V-2Zr-2Cr-1Nb-1Fe alloy were investigated. K-decreasing fatigue crack propagation rate tests were conducted on compact tension samples (ASTM standard) with a stress ratio R of 0.1 and a frequency of 15 HZ in a laboratory atmosphere. At a similar strength level of 1200 MPa, the sample with a fine basket-weave microstructure (F-BW) displayed the slowest near-threshold fatigue crack propagation rate compared with the samples with equiaxed (EM) and basket-weave (BW) microstructures. The fatigue threshold value (ΔK_th) was 4.4 MPa·m^1/2 for F-BW, 3.6 for BW, and 3.2 for EM. The fracture surfaces and crack profiles were observed by scanning electron microscopy (SEM) and electron backscatter diffraction (EBSD) to elucidate the mechanism of fatigue crack propagation in the near-threshold regime. The results revealed that the near-threshold crack growth in the three samples was primarily transgranular. The crack always propagated parallel to the crystal plane, with a high Schmid factor. In addition, the near-threshold fatigue crack growth behavior was synergistically affected by the crack tip plastic zone and crack bifurcation. The increased fatigue crack propagation resistance in F-BW was attributed to the better stress/strain compatibility and greater number of interface obstacles in the crack tip plastic zone. Full article

In this study, a (TiB + TiC + Y₂O₃)/α-Ti composite was prepared by induction skull melting to investigate its creep behavior and microstructure evolution under different temperatures and stresses. The results show that the microstructure of the composite in the as-cast state is a basket-weave structure, and the main phase composition is α lamella, containing a small amount of β phase and equiaxed α phase. The creep life of the composite decreases significantly when the temperature is increased from 650 °C to 700 °C, and the steady-state creep rate is increased by 1 to 2 orders of magnitude. The creep stress exponent at 650 °C and 700 °C is 2.92 and 2.96, respectively, and the creep mechanism of the titanium matrix composite is dominated by dislocation movement. TiB and TiC exhibit synergistic strengthening effects, and Y₂O₃ remains stable during creep. The reinforcements strengthen the composite by impeding the dislocation movement. The accelerated dissolution of β phase is one of the major reasons for the decrease of creep properties of composite with increasing temperature and stress. Silicide precipitation was observed near the reinforcements and dissolved β-Ti, mainly in elliptical or short rod shapes, which pins dislocations and improves the creep performance of the composite. The results of this study can provide theoretical guidance and practical reference for the subsequent development and application of hybrid reinforced titanium matrix composites. Full article

The welding of TC4 titanium alloy sheets with a thickness of 1 mm was successfully accomplished by a swinging laser. The microstructure and mechanical properties of the welding seam under different swing amplitudes were studied. In this paper, the microstructure, phase composition, mechanical properties, and fracture morphology of the weld with swing frequency of 50 Hz and different swing amplitudes (0.2 mm, 1 mm, 2 mm, and 3 mm) were tested and analyzed. The results show that basket-weave microstructures are present in the fusion zone of welds under different oscillation amplitudes, but the morphology of martensite within the basket-weave differs. The weld microstructure is mainly composed of acicular α′ martensite, initial α phase, secondary α phase, and residual β phase. The hardness of the weld is higher than that of the base metal, and the overall hardness decreases from the weld center to the base metal. When the oscillation amplitude A = 1 mm, the weld microstructure has the smallest average grain size, the highest microhardness (388.86 HV), the largest tensile strength (1115.4 MPa), and quasi-cleavage fracture occurs. At an oscillation amplitude of A = 2 mm, the tensile specimen achieves the maximum elongation of 14%, with ductile fracture as the dominant mechanism. Full article

The main goal of this study is the comparison of different reinforcement architectures on the low-velocity impact behavior of green composites. The study includes the comparison of unidirectional, basket weave, and twill weave flax/PLA composites, they are subjected to unidirectional tensile tests, drop-weight impact tests, and after-impact compression tests. Results show that the unidirectional composite demonstrates superior tensile strength and initial modulus due to reduced fiber crimp, while basket weave exhibits the highest energy absorption capability and strain capacity attributed to its higher fiber–weight ratio and fiber crimp. Unidirectional composite also shows a larger impacted damage area compared to basket weave and twill weave, attributed to its internal architecture. Residual compressive strength across all composites decreased by 40% compared to the reference sample. However, the reduction in stiffness after impact was different, UD/PLA composite stiffness was reduced by 30% while the reduction in BW/PLA and T/PLA composites was about 20%. Full article

With the development of lightweight aerospace structures, the use of the high-quality and efficient laser welding of near-α titanium alloys has received widespread attention and favor thanks to its superior comprehensive performance. The welding experiment of 3 mm thick TA15 titanium alloy was carried out by YAG laser welding, and the material weldability, microstructure, microhardness, and mechanical properties of welded joints were systematically studied. The results indicated that laser welding of TA15 titanium alloy can produce well-formed welded joints without defects such as cracks and porosity. The welded metal used was a typical basket-weave microstructure composed of a large number of α′ martensitic phases and a small number of high-temperature residual β phases, and the heat-affected zone was a staggered arrangement of undissolved α phase and needle-like α′ martensite. The microhardness of the welded joint showed a hump distribution, and the hardness of WM fluctuated between 410 and 450 HV since the martensitic transformation occurred during the solidification of the weld under thermal cycling, and the β phase changed to the needle-like α′ phase. The tensile test indicated that the fracture position was located in the base metal area, and the fracture morphology showed the equiaxial dimple morphology of different sizes in a ductile fracture mode. The welded metal had the lowest impact performance (average value of 5.3 J) because the weld area was predominantly coarse α′ martensite. This experiment conducted systematic, in-depth, and extensive research on welding processes, hardness, tensile, impact, and fracture mechanisms. Based on the special product applications in the aerospace field, it was more targeted and conducive to promoting the application of the welding process in this material. Full article

This study uses the finite element method (FEM) to investigate the effect of key structural parameters on the impact resistance of E-glass 3D orthogonal woven (3DOW) composites subjected to low-velocity impact. These structural parameters include the number of y-yarn layers, the path of the binder yarn (z-yarn), and the density of the x-yarn. Using ABAQUS, yarn-level finite element (FE) models are created based on the measured geometrical parameters and validated for energy absorption and damage behavior from experimental data gathered from the previous study. The results from finite element analysis (FEA) indicate that the x-yarn density and the binder path substantially influenced the composites’ damage behavior and impact performance. Increasing x-yarn density in 3DOW leads to a 15% increase in energy absorption compared to models with reduced x-yarn densities. Moreover, as the x-yarn density increases, crack lengths at the back face of the resin matrix decrease in the y-yarn direction but increase in the x-yarn direction. The basket weave structure absorbs less energy than plain and 2 × 1 twill structures due to the less constrained weft primary yarns. These results underscore the importance of these structural parameters in optimizing 3DOW composite for better impact performance, providing valuable insights for the design of advanced composite structures. Full article

The Ti-4Al-2V (wt. %) titanium alloy has garnered widespread applications across diverse fields due to its exceptional strength-to-weight ratio, high toughness, specific strength, and corrosion resistance. The welding of Ti-4Al-2V titanium alloy components is often necessary in manufacturing processes, where the reliability of a welded joint critically influences the overall service life of these components. Consequently, a comprehensive understanding of the welded joint’s microstructure and mechanical properties is imperative. In this study, Ti-4Al-2V titanium alloy was welded using multi-layer and multi-pass TIG welding techniques, and a detailed examination was conducted to analyze the microstructure and grain morphology of each microzone of the welded joint. The results revealed the presence of an initial α phase and a secondary lamellar α phase in the heat affected zone (HAZ). Meanwhile, the fusion zone (FZ) primarily comprised a coarse secondary α phase and a small amount of an acicular martensitic α’ phase. Both the recrystallization zone and the superheated zone exhibited a distinct preferred orientation, with grains smaller than 10 μm accounting for 65.9% and 55.1%, respectively. To assess the mechanical properties of the various microzones and the typical microstructure within the welded joint, nanoindentation tests were performed. The results indicated that the recrystallization zone possessed a higher nanohardness (3.753 GPa) than the incomplete recrystallization zone (3.563 GPa) and the superheated zone (3.48 GPa). Among all the microzones, the FZ exhibited the lowest average nanohardness (3.058 GPa). Notably, the basket-weave microstructure demonstrated the highest average nanohardness, reaching 3.93 GPa. This was followed by the fine-grain microstructure, which possessed a slightly lower nanohardness. The Widmanstätten microstructure, on the other hand, exhibited the lowest nanohardness among the three microstructures within the HAZ. Therefore, the basket-weave microstructure stands out as the most desirable microstructure to achieve in the welded joint. In summary, this study provides a comprehensive characterization and analysis of the microstructure and properties of Ti-4Al-2V titanium alloy TIG welds, aiming to contribute to the optimization of the TIG welding process for Ti-4Al-2V titanium alloy. Full article

This study investigates the effects of the number of layers, x-yarn (weft) density, and z-yarn (binder) path on the mechanical behavior of E-glass 3D orthogonal woven (3DOW) composites during low-velocity impacts. Meso-level finite element (FE) models were developed and validated for 3DOW composites with different yarn densities and z-yarn paths, providing analyses of stress distribution within reinforcement fibers and matrix, energy absorption, and failure time. Our findings revealed that lower x-yarn densities led to accumulations of stress concentrations. Furthermore, changing the z-yarn path, such as transitioning from plain weaves to twill or basket weaves had a noticeable impact on stress distributions. The research highlights the significance of designing more resilient 3DOW composites for impact applications by choosing appropriate parameters in weaving composite designs. Full article

This study delves into the impact toughness of medium-thick (12 mm thick) titanium alloy joints crafted through a multi-layer, multi-pass welding technique that blends laser-arc (MIG) hybrid welding technology. Microstructural scrutiny, employing optical microscopy, SEM and TEM, unveils a consistent composition across weld passes, with prevailing α/α′ phases interspersed with some β phase, resulting in basket-weave structures primarily dominated by acicular α′ martensite. However, upper regions exhibit Widmanstatten microstructures, potentially undermining joint toughness. Hardness testing indicates higher values in cosmetic layers (~420 HV) compared to backing layers and bending tests manifest superior toughness in lower joint regions, attributed to smaller grain sizes induced by repetitive welding thermal cycles. Impact toughness assessment unveils diminished values in the weld metal (WM) compared to the heat-affected zone (HAZ) and base material (BM), amounting to 91.3% of the base metal’s absorption energy. This decrement is ascribed to heightened porosity in upper regions and variations in grain size and phase composition due to multi-layer, multi-pass welding. Microstructural analysis proximal to failure sites suggests one mechanism wherein crack propagation is impeded by the β phase at acute crack angles. In essence, this study not only underscores the practicality of laser-MIG hybrid welding for medium-thick TC4 alloy plates but also underscores the reliability of joint mechanical properties. Full article
