In this article, we propose an equivalent 2-D finite element analysis (FEA) process considering the 3-D flux of an outer rotor permanent magnet synchronous motor (PMSM). In the motor, 3-D flux such as axial leakage flux (ALF) and overhang fringing flux (OFF) are influenced based on design variables. Three-dimensional FEA is required to consider the components of 3-D flux. However, 3-D FEA is inefficient to use during the design process because of time-consuming. Therefore, we propose an equivalent FEA that considers the 3-D flux. First, the effects of ALF and OFF according to design variables such as rotor inner and outer diameter, stack length, and overhang length. Second, the 3-D flux is converted into a coefficient. Finally, it is applied to 2-D FEA. Using the proposed process, motor performance considering 3-D flux can be quickly predicted. The proposed performance prediction process is verified through simulation and experiment. Full article

This paper proposes a harmonic screening-based method for calculating the cogging torque of the axial flux permanent magnet synchronous motor. The magnetic field energy in the air gap is derived from the air gap flux and the magnetomotive force of rotor. The cogging torque is then obtained using the energy-based method. Compared with finite element analysis, the proposed approach is significantly faster while maintaining high accuracy. It is particularly effective for scenarios involving stator staggering, which can facilitate quick calculation of cogging torques of many different staggering angles, offering rapid insights into motor performance during the initial design. The method achieves a similarity accuracy with FEA results and reduces computation time, demonstrating both its efficiency and reliability. Full article

In this study, an axial flux double airgap permanent magnet-assisted synchronous reluctance motor (AF-Pma-SynRM) was designed for electric vehicles (EVs). The AF-Pma-SynRM model employs a forced liquid cooling method (cooling jacket) for a high current density. The model was tested using multi-objective optimization and multi-physics analysis. The AF-Pma-SynRM design has achieved 95.6 Nm of torque, 30 kW of power, and 93.8% efficiency at a 3000 rpm rated speed. The motor exhibits a maximum speed of 10,000 rpm, 253.1 Nm of torque, and 65 kW of output power. This study employs a novel barrier structure for axial motors characterized by fixed outer and inner dimensions, and is suitable for mass production. In the final stage, the motor was cooled using the cooling jacket method, and the average temperature of the winding was measured as 73.83 °C, and the average magnet temperature was 66.44 °C at a nominal power of 30 kW. Also to show variable speed performance, an efficiency map of the AF-Pma-SynRM is presented. Full article

A PCB stator axial flux permanent magnet (AFPM) motor is presented that overcomes the manufacturing challenges associated with the complex geometry of conventional stators by employing a PCB substrate. Traditionally, AFPM motors are produced by winding coils around the stator teeth, a process that requires specialized winding machinery and is both labor intensive and time consuming, ultimately incurring considerable manufacturing costs and delays. In contrast, PCB substrates offer significant advantages in manufacturability and mass production, effectively resolving these issues. Furthermore, the primary material used in PCB substrates, FR-4, exhibits a permeability similar to that of air, resulting in negligible electromagnetic cogging torque. Cogging torque arises from the attraction between permanent magnets and stator teeth, creating forces that interfere with motor rotation and generate unwanted vibration, noise, and potential mechanical collisions between the rotor and stator. In the PCB stator design, the conventional PCB circuit pattern is replaced by the motor’s coil configuration, and the absence of stator teeth eliminates these interference issues. Consequently, a slotless motor configuration with minimal vibration and noise is achieved. The PCB AFPM motor has been applied to a vehicle-mounted electric water pump (EWP), where mass production and space efficiency are critical. In an EWP, which integrates the impeller with the motor, it is essential that vibrations are minimized since excessive vibration could compromise impeller operation and, due to fluid resistance, require high power input. Moreover, the AFPM configuration facilitates higher torque generation compared to a conventional radial flux permanent magnet synchronous motor (RFPM). In a slotless AFPM motor, the absence of stator teeth prevents core flux saturation, thereby further enhancing torque performance. AC losses occur in the conductors as a result of the magnetic flux produced by the permanent magnets, and similar losses arise within the PCB circuits. Therefore, an optimized PCB circuit design is essential to reduce these losses. The Constant Trace Conductor (CTC) PCB circuit design process is proposed as a viable solution to mitigate AC losses. A 3D finite element analysis (3D FEA) model was developed, analyzed, fabricated, and validated to verify the proposed solution. Full article

Accurate performance prediction in the design phase of permanent magnet synchronous motors (PMSMs) is essential for optimizing efficiency and functionality. While 2-D finite element analysis (FEA) is commonly used due to its low computational cost, it overlooks important 3-D flux components such as axial leakage flux (ALF) and fringing flux (FF) that affect motor performance. Although 3-D FEA can account for these flux components, it is computationally expensive and impractical for rapid design iterations. To address this challenge, we propose a performance prediction method for interior permanent magnet synchronous motors (IPMSMs) that incorporates 3-D flux effects while reducing computational time. This method uses deep transfer learning (DTL) to transfer knowledge from a large 2-D FEA dataset to a smaller, computationally costly 3-D FEA dataset. The model is trained in 2-D FEA data and fine-tuned with 3-D FEA data to predict motor performance accurately, considering design variables such as stator diameter, axial length, and rotor design. The method is validated through 3-D FEA simulations and experimental testing, showing that it reduces computational time and accurately predicts motor characteristics compared to traditional 3-D FEA approaches. Full article

The instability in rare-earth material supply and rising costs have driven research into rare-earth-free electric motors. Among various alternatives, wound rotor synchronous motors (WRSMs) stand out due to their adjustable excitation, enabling high torque at low speeds, and efficient field weakening at high speeds. Unlike permanent magnet synchronous motors (PMSMs), WRSMs offer greater operational flexibility and eliminate the risk of demagnetization. However, accurately modeling WRSMs remains challenging, especially when considering axial fringing flux and leakage components, which significantly affect motor performance. To address this challenge, this paper proposes a 3D nonlinear magnetic equivalent circuit (MEC) model that explicitly incorporates axial flux components and leakage paths in WRSMs with overhang rotor structures. Unlike conventional 2D MEC models, which fail to capture axial flux interactions, the proposed approach improves prediction accuracy while significantly reducing computational costs compared to full 3D finite element analysis (FEA). The model was validated through comparisons with 3D FEA simulations and experimental back-EMF measurements, demonstrating its accuracy and computational efficiency. The results confirm that the 3D nonlinear MEC model effectively captures axial flux paths and leakage components, making it a valuable tool for WRSM design and analysis. Future research will focus on further refining the model, incorporating hysteresis loss modeling, and developing hybrid MEC–FEA simulation techniques to enhance its applicability. Full article

Aiming at the defects of long axial size and low torque density of the existing radial flux permanent magnet motor, this paper proposes an axial flux permanent magnet synchronous motor (AFPMM) with a double-stator and single-rotor structure based on the design requirements of the motor for mechanical dogs’ electric drive joints. The finite element method is employed to evaluate the static magnetic field, load characteristics, and associated losses. The analysis indicates that the average magnetic flux density in the air gap reaches approximately 0.95 T, with a rated torque of around 2.72 N.m, a peak torque of 7.6 N.m, and an efficiency of approximately 87.73%. The electromagnetic torque model is developed using the Maxwell tensor method, allowing for the effects of critical structural parameters on torque to be investigated. By optimizing the design for torque density, an improvement of nearly 20% is achieved. A prototype was fabricated and tested, demonstrating good agreement between simulation and experimental results. This research introduces a novel approach for designing axial flux motors with high torque and power densities. Full article

Shaftless propulsion technology delivers high efficiency and low noise for subsea installations and marine vessels. To enhance thrust performance, the streamlined aft-body contour imposes stringent demands on geometric compatibility between the rim-driven thruster (RDT) motor and hull. This necessitates advanced electromagnetic characterization of conical motors. This paper proposes an equivalent magnetic circuit model (EMCM) that accounts for end effects and magnetic saturation in both the stator and rotor cores for the magnetic field analysis of conical permanent magnet synchronous motor (CPMSM). A 3D EMCM is developed by decomposing the air-gap flux into radial/axial/tangential components. End-field nonlinearities are addressed via lumped-parameter network modeling. Innovatively, a trapezoidal expanded magnet layout and magnet-pole-trimming technology are adopted to ensure sinusoidal flux distribution. Finally, a 10.5 kW prototype with a conical angle of 6.7 degrees is designed using the EMCM and verified through a finite-element analysis (FEA) and experiments. This research provides a theoretical framework for the rapid electromagnetic analysis of the CPMSM. Full article

The axial flux permanent magnet synchronous motor (APMSM) has the advantages of short axial size, high efficiency, and high power density. However, the three-dimensional magnetic circuit structure of this type of motor results in a longer calculation time, which is not conducive to rapid design and optimization. In order to quickly and accurately complete the preliminary calculation and optimization of axial flux permanent magnet synchronous motors, this paper proposes an improved equivalent calculation method for two-dimensional multi-layer linear motors. This method is based on the traditional two-dimensional multi-layer linear motor equivalent method, taking into account the complexity of geometric model establishment and simulation condition settings and applying the principle of analogy to achieve significant simplification of geometric modeling and simulation settings. The article elaborates on the correlation and differences between the proposed method and existing methods and verifies the calculation accuracy through finite element calculation. The results indicate that the improved two-dimensional multi-layer linear motor equivalent calculation method proposed in this article can significantly reduce calculation time while ensuring calculation accuracy and has good application prospects in preliminary design and parameter optimization processes. Full article

The traditional radial flux PMSM and axial flux PMSM have an effective air gap on only one side, between the stator and rotor, and only the effective air gap generates electromagnetic torque. There are defects in the magnetic-field utilization, and it is difficult to improve the torque density. Therefore, this paper proposes an axial–radial-flux permanent-magnet synchronous motor (ARF-PMSM), which combines radial flux with axial flux, to be used in an elevator-traction machine-drive motor. The characteristics of the ARF-PMSM are that the stator core is made of a soft magnetic composite material and the winding is annular. The motor has three effective air gaps, which can achieve high torque density without increasing the overall dimensions. In this paper, the mechanical structure and operation mechanism of the ARF-PMSM are introduced, and the characteristics of its magnetic circuit structure are analyzed by using the equivalent magnetic circuit method. The torque characteristics and other electromagnetic characteristics of the ARF-PMSM, the traditional surface-mounted PMSM, and the spoke-type PMSM are compared and analyzed using the finite element method. The research results show that the proposed motor has high torque density, which provides a new design idea in the form of a high-torque-density PMSM for use in elevator-traction machines. Full article

There is a trend to go towards low gear-ratio or even direct-drive actuators in novel robotic applications in which high-torque density electric motors are required. The Yokeless and Segmented Armature Axial Flux Permanent Magnet Synchronous Machine is therefore considered in this work. In these applications, the motors should be capable to deliver high torque at standstill for long periods of time. This can cause overheating of the motors due to a concentration of the losses in a single phase; hence, it becomes necessary to derate the motor torque. In this work the influence of the slot/pole combination, the addition of a thermal end-winding interconnection and the equivalent thermal conductivity of the winding body on the torque performance at standstill will be studied both experimentally via temperature measurements on a prototype stator, and via a calibrated 3D thermal Finite Element model. It was found that both a good choice of the slot/pole combination and the addition of a thermal end-winding interconnection have a significant influence on the torque performance at standstill, and allow up to 8% increase in torque at standstill in comparison to a reference design. Full article

The core design elements of the motor for the co-robot joint are miniaturization and high torque. In this paper, a dual rotor axial-flux permanent magnet (DRAFPM) motor is proposed to improve the performance of robot joints. DRAFPM motors have the advantage of reducing iron loss and minimizing volume because they can remove stator yoke. When designing a motor with the same volume, it can be designed to increase the height of the fixed ruler by the thickness of the yoke of the fixed ruler and increase the number of turns. In the case of existing axial-flux permanent magnet (AFPM) motors, the shape of the three-dimensional structure is limited by radial laminating of stator. Therefore, considering the production of 3D printing, the shape of stator shoe is designed. The optimal design problem of DRAFPM motor consists of real and integer design variables. In addition, due to the structural characteristics of DRAFPM motors, 3D finite element analysis (FEA) is required, so it takes a long time to interpret. Therefore, this paper proposes an efficient optimal design process to optimize the remaining real design variables after prioritizing the integer design variables. The proposed optimization process is applied to the DRAFPM motor for robot joints, and the optimal design plan satisfying the design function is derived from various design variables to prove the validity of the optimization process. Full article

This paper presents the application of shallow neural networks (SNNs): multi-layer perceptron (MLP) and self-organizing Kohonen maps (SOMs) to the early detection and classification of the stator and rotor faults in permanent magnet synchronous motors (PMSMs). The neural networks were trained based on the vector coming from measurements on a real object. The elements of the input vector of SNNs constituted the selected amplitudes of the diagnostic signal spectrum. The stator current and axial flux were used as diagnostic signals. The test object was a 2.5 kW PMSM motor supplied by a frequency converter operating in a closed-loop control structure. The experimental verification of the proposed diagnostic system was carried out for variable load conditions and values of the supply voltage frequency. The obtained results were compared with an approach based on a deep neural network (DNN). The research presented in the article confirm the possibility of detection and assessing the individual damage of stator winding and permanent magnets as well as the simultaneous faults of the PMSM stator and rotor using SNNs with simple signal preprocessing. Full article

In this paper, an axial slot-less permanent magnet synchronous motor (ASFPMSM) was designed to increase the power density. The iron core of the stator was replaced with block coils, and the stator back yoke was removed because 3D printing can provide a wide range of structures of the stator. The proposed model also significantly impacts efficiency because it can reduce iron loss. To meet size and performance requirements, coil thickness and number of winding layers in the block, the total amount of magnet, and pole/slot combinations were considered. The validity of the proposed model was proved via finite elements analysis (FEA). Full article

Owing to the development of electric vehicles (EVs), research and development are underway to minimize torque ripple in relation to vibration and noise in EV motors. Although there are various ways to reduce torque ripple, this study analyzes the torque ripple, cogging torque, total harmonic distortion (THD), and magnetic flux density distribution for the three rotor shapes of interior permanent magnet synchronous motors, which are widely employed in EVs. To reduce the torque ripple while retaining the required average torque, the barrier shape is optimized, and wedge skew is applied. First, regarding the rotor barrier shape, torque ripple is primarily reduced by designing the rotor barrier shape with the response surface method, which is an experimental design method. Additionally, the wedge skew shape considering the bidirectional rotation and fabrication was applied to the stator shoe as a step and analyzed using three-dimensional finite element analysis. When designing the wedge skew, the layer subdivision according to the axial length, wedge skew diameter, and wedge skew position was analyzed and improved. The torque ripple reduction method in this paper can be applied not only to motors for EVs or Hybrid EVs (HEVs) but also all types of permanent magnet synchronous motors. Full article
