Search Results (11)

Background: In recent years, intravascular micro-axial blood pumps have been increasingly used in the treatment of patients with cardiogenic shock. The flow rate of such blood pumps requires adjustment based on the patient’s physiological condition. Compared to a stable flow state with fixed rotation speed, adjusting the speed of blood pump impeller to alter flow rate may lead to additional hemolysis. This study aimed at elucidating the relationship between adjusting interval of a blood pump’s impeller speed and the hemolysis index. Methods: By comparing simulation results with P-Q characteristic curves of the blood pump measured by experiments, the accuracy of the blood pump flow field simulation model was confirmed. In this study, a drainage tube was employed as the device analogous to an intravascular micro-axial blood pump for achieving similar shear stress levels and residence times. The hemolysis finite element prediction method based on a power-law model was validated through hemolysis testing of porcine blood flow through the drainage tube. The validated models were subsequently utilized to investigate the impact of impeller speed adjusting intervals on hemolysis in the blood pump. Results: Compared to steady flow, the results demonstrate that the hemolysis index increased to 6.3% when changing the blood pump flow rate from 2 L/min to 2.5 L/min by adjusting the impeller speed within 0.072 s. Conclusions: An adjustment time of impeller speed longer than 0.072 s can avoid extra hemolysis when adjusting the intravascular micro-axial blood pump flow rate from 2 L/min to 2.5 L/min. Full article

The majority of bearingless permanent magnet slice motors (BPMSMs) used in commercially available rotary blood pumps use a two-phase configuration, but it is unclear as to whether or not a comparable three-phase configuration would offer a better performance. This study compares the performance of two-phase and three-phase BPMSM configurations. Initially, two nominal designs were manufactured and empirically tested for their performance characteristics, namely, the axial stiffness, radial stiffness, and current force. Subsequently, finite element analysis (FEA) models were developed based on these nominal devices and validated against the empirical results. Simulations were then employed to assess the sensitivity of performance characteristics to variations in seven different geometric features of the models for both configurations. Our findings indicate that the nominal three-phase design had a higher axial stiffness and radial stiffness, but resulted in a lower axial-to-radial-stiffness ratio when compared to the nominal two-phase design. Additionally, while the nominal two-phase design shows a higher current force, the nominal three-phase design proves to be slightly superior when the force generated is considered relative to the power usage. Notably, the three-phase configuration demonstrates a greater sensitivity to dimensional changes in the geometric features. We observed that alterations in the air gap and rotor length lead to the most significant variations in performance characteristics. Although most changes in specific geometric features entail equal tradeoffs, increasing the head protrusion positively influences the overall performance. Moreover, we illustrated the interdependent nature of the head height and rotor height on the performance characteristics. Overall, this study delineates the strengths and weaknesses of each configuration, while also providing general insights into the relationship between specific geometric features and performance characteristics of BPMSMs. Full article

Inlet boundary conditions (BC) are one of the uncertainties which may influence the prediction of flow field and hemolysis in blood pumps. This study investigated the influence of inlet BC, including the length of inlet pipe, type of inlet BC (mass flow rate or experimental velocity profile) and turbulent intensity (no perturbation, 5%, 10%, 20%) on the prediction of flow field and hemolysis of a benchmark centrifugal blood pump (the FDA blood pump) and a commercial axial blood pump (Heartmate II), using large-eddy simulation. The results show that the influence of boundary conditions on integral pump performance metrics, including pressure head and hemolysis, is negligible. The influence on local flow structures, such as velocity distributions, mainly existed in the inlet. For the centrifugal FDA blood pump, the influence of type of inlet BC and inlet position on velocity distributions can also be observed at the diffuser. Overall, the effects of position of inlet and type of inlet BC need to be considered if local flow structures are the focus, while the influence of turbulent intensity is negligible and need not be accounted for during numerical simulations of blood pumps. Full article

Human activity recognition (HAR) extensively uses wearable inertial sensors since this data source provides the most information for non-visual datasets’ time series. HAR research has advanced significantly in recent years due to the proliferation of wearable devices with sensors. To improve recognition performance, HAR researchers have extensively investigated other sources of biosignals, such as a photoplethysmograph (PPG), for this task. PPG sensors measure the rate at which blood flows through the body, and this rate is regulated by the heart’s pumping action, which constantly occurs throughout the body. Even though detecting body movement and gestures was not initially the primary purpose of PPG signals, we propose an innovative method for extracting relevant features from the PPG signal and use deep learning (DL) to predict physical activities. To accomplish the purpose of our study, we developed a deep residual network referred to as PPG-NeXt, designed based on convolutional operation, shortcut connections, and aggregated multi-branch transformation to efficiently identify different types of daily life activities from the raw PPG signal. The proposed model achieved more than 90% prediction F1-score from experimental results using only PPG data on the three benchmark datasets. Moreover, our results indicate that combining PPG and acceleration signals can enhance activity recognition. Although, both biosignals—electrocardiography (ECG) and PPG—can differentiate between stationary activities (such as sitting) and non-stationary activities (such as cycling and walking) with a level of success that is considered sufficient. Overall, our results propose that combining features from the ECG signal can be helpful in situations where pure tri-axial acceleration (3D-ACC) models have trouble differentiating between activities with relative motion (e.g., walking, stair climbing) but significant differences in their heart rate signatures. Full article

Background: Hemocompatibility of left ventricular assist devices is essential for preventing adverse events. In this study, we compared the hemocompatibility of an axial-flow (Sputnik) to a centrifugal-flow (HeartMate 3) pump. Methods: Both pumps were integrated into identical in vitro test circuits, each filled with 75 mL heparinized human blood of the same donor. During each experiment (n = 7), the pumps were operated with equal flow for six hours. Blood sampling and analysis were performed on a regular schedule. The analytes were indicators of hemolysis, coagulation activation, platelet count and activation, as well as extracellular vesicles. Results: Sputnik induced higher hemolysis compared to the HeartMate 3 after 360 min. Furthermore, platelet activation was higher for Sputnik after 120 min onward. In the HeartMate 3 circuit, the platelet count was reduced within the first hour. Furthermore, Sputnik triggered a more pronounced increase in extracellular vesicles, a potential trigger for adverse events in left ventricular assist device application. Activation of coagulation showed a time-dependent increase, with no differences between both groups. Conclusions: This experimental study confirms the hypothesis that axial-flow pumps may induce stronger hemolysis compared to centrifugal pumps, coming along with larger amounts of circulating extracellular vesicles and a stronger PLT activation. Full article

For a blood pump, the blood flow channel and impeller parameters directly affect the performance of the pump and the resulting blood circulation. The flow channel in particular has a great impact on the hydraulic performance of the pump (e.g., flow and pressure), which directly determines the overall performance of the blood pump. Traditional bearing-supported blood pumps can cause mechanical damage to blood cells, leading to hemolysis and thrombosis. In this study, therefore, we designed a conical spiral axial blood pump with magnetic levitation. The blood pump was supported by electrodynamic bearings in the radial direction and electromagnetic bearings in the axial direction. The impeller and the front and rear hubs were integrated to minimize blood stagnation and reduce the formation of thrombosis. The hub had a conical spiral flow channel design, which not only reduced the size of the impeller but also increased blood flow and pressure while meeting the design requirements. Computational fluid dynamics (CFD) analysis was used to analyze the flow field of the axial blood pump, a power function model was used to establish a hemolysis prediction model, and the particle tracking method was used to obtain the flow trajectories of individual blood cells, thereby predicting hemolysis-related performance of the blood pump. The simulation results showed that the main high shear stress area in the blood pump was located in the impeller inlet and the clearance between the top of the impeller and the inner chamber of the blood pump. When the hub taper angle of the blood pump was 0.72° and the clearance was 0.3 mm, the average hemolysis prediction value was 0.00216. This prediction value was smaller than that of traditional axial blood pumps. These findings can provide an important reference for the structural design of axial blood pumps and for reducing the hemolysis prediction value. Full article

Ventricular assist devices or total artificial hearts can be used to save patients with heart failure when there are no donors available for heart transplantation. Blood pumps are integral parts of such devices, but traditional axial flow blood pumps have several shortcomings. In particular, they cause hemolysis and thrombosis due to the mechanical contact and wear of the bearings, and they cause blood stagnation due to the separation of the front and rear guide wheel hubs and the impeller hub. By contrast, the implantable axial flow, maglev blood pump has the characteristics of no mechanical contact, no lubrication, low temperature rise, low hemolysis, and less thrombosis. Extensive studies of axial flow, maglev blood pumps have shown that these pumps can function in laminar flow, transitional flow, and turbulent flow, and the working state and performance of such pumps are determined by their support mechanisms and flow channel. Computational fluid dynamics (CFD) is an effective tool for understanding the physical and mechanical characteristics of the blood pump by accurately and effectively revealing the internal flow field, pressure–flow curve, and shear force distribution of the blood pump. In this study, magnetic levitation supports were used to reduce damages to the blood and increase the service life of the blood pump, and a conical impeller hub was used to reduce the speed, volume, and power consumption of the blood pump, thereby facilitating implantation. CFD numerical simulation was then carried out to optimize the structural parameters of the conical axial maglev blood pump, predict the hemolysis performance of the blood pump, and match the flow channel and impeller structure. An extracorporeal circulation simulation platform was designed to test whether the hydraulic characteristics of the blood pump met the physiological requirements. The results showed that the total pressure distribution in the blood pump was reasonable after optimization, with a uniform pressure gradient, and the hemolysis performance was improved. Full article

Rotor suspension stability is one of the important performance indexes of a blood pump and the basis of determining whether the blood pump can be used in a clinic. Compared with the traditional magnetic suspension system, a single-winding, bearingless motor has the advantages of a compact structure, simple control system and low power consumption. In this pursuit, the present study aimed to envisage and design the magnetic suspension system coupled with a single-winding bearingless motor and permanent magnet bearings, establish the theoretical models of axial force and electromagnetic torque, and calculate the stiffness of the magnetic suspension system at the equilibrium point. Addressing the problem of the negative axial stiffness of the magnetic suspension system being negative, which leads to the instability of the suspension rotor, the hydrodynamic bearing structure was proposed and designed, and the critical stiffness to realize the stable suspension of the rotor was obtained based on the stability criterion of the rotor dynamics model. The optimal structural parameters of the hydrodynamic bearing are selected by integrating various factors based on the solution of the Reynolds equation and a stiffness analysis. Furthermore, the vibration experiment results proved that the blood pump rotor exhibited a good suspension stability, and the maximum offset under the impact external fluid was no more than 2 μm. Full article

To accurately assess the hemolysis risk of the ventricular assist device, this paper proposed a cell destruction model and the corresponding evaluation parameters based on multiphase flow. The single-phase flow and multiphase flow in two patient-specific total cavopulmonary connection structures assisted by a rotationally symmetric blood pump (pump-TCPC) were simulated. Then, single-phase and multiphase cell destruction models were used to evaluate the hemolysis risk. The results of both cell destruction models indicated that the hemolysis risk in the straight pump-TCPC model was lower than that in the curved pump-TCPC model. However, the average and maximum values of the multiphase flow blood damage index (mBDI) were smaller than those of the single-phase flow blood damage index (BDI), but the average and maximum values of the multiphase flow particle residence time (mPRT) were larger than those of the single-phase flow particle residence time (PRT). This study proved that the multiphase flow method can be used to simulate the mechanical behavior of red blood cells (RBCs) and white blood cells (WBCs) in a complex flow field and the multiphase flow cell destruction model had smaller estimates of the impact shear stress. Full article

Given the fact that physical exertion leads to blood glucose fluctuations, type one diabetes mellitus (T1D) may potentially constitute a barrier for obtaining a sufficient amount of exercise. The main purpose of the study was to compare the level of physical activity between children with T1D (n = 215) and healthy controls (n = 115) and to assess the physical activity of the study group in relation to the applied method of insulin therapy, i.e., the use of insulin pen vs. insulin pump. The level of physical activity was assessed with a hip-worn tri-axial accelerometer (ActiGraph GT3X+) used by the subjects for an uninterrupted period of seven days. Children with T1D had significantly lower median values of total time of moderate (213.3 vs. 272.1 min), vigorous (135.3 vs. 19.6 min) and moderate-to-vigorous (347.4 vs. 467.4 min) physical activity compared to healthy peers respectively, (p < 0.001) in all cases. In addition, the total median number of steps was significantly lower (53,631 vs. 67,542 steps), (p < 0.001). The method of insulin therapy was not associated with significant differences in physical activity level (p > 0.001). The level of physical activity in children and adolescents with T1D is lower than in their healthy peers and does not depend on the insulin therapy method. Full article

The impact of left ventricular assist devices (LVADs) for the treatment of advanced heart failure has played a significant role as a bridge to transplant and more recently as a long-term solution for non-eligible candidates. Continuous flow left ventricular assist devices (CF-LVADs), based on axial and centrifugal design, are currently the most popular devices in view of their smaller size, increased reliability and higher durability compared to pulsatile flow left ventricular assist devices (PF-LVADs). The trend towards their use is increasing. Therefore, it has become mandatory to understand the physics and the mathematics behind their mode of operation for appropriate device selection and simulation set up. For this purpose, this review covers some of these aspects. Although very successful and technologically advanced, they have been associated with complications such as pump thrombosis, haemolysis, aortic regurgitation, gastro-intestinal bleeding and arterio-venous malformations. There is perception that the reduced arterial pulsatility may be responsible for these complications. A flow modulation control approach is currently being investigated in order to generate pulsatility in rotary blood pumps. Thrombus formation remains the most feared complication that can affect clinical outcome. The development of a preoperative strategy aimed at the reduction of complications and patient-device suitability may be appropriate. Patient-specific modelling based on 3D reconstruction from CT-scan combined with computational fluid dynamic studies is an attractive solution in order to identify potential areas of stagnation or challenging anatomy that could be addressed to achieve the desired outcome. The HeartMate II (axial) and the HeartWare HVAD (centrifugal) rotary blood pumps have been now used worldwide with proven outcome. The HeartMate III (centrifugal) is now emerging as the new promising device with encouraging preliminary results. There are now enough pumps on the market: it is time to focus on the complications in order to achieve the full potential and selling-point of this type of technology for the treatment of the increasing heart failure patient population. Full article
