Search Results (19)

This study investigates the mechanism behind the cavitation-induced noise in an automotive heater core and proposes a structural solution to eliminate it. Abnormal noise during cold-start conditions in a compact passenger vehicle was traced to cavitation in the heater core of the heating, ventilation, and air conditioning (HVAC) system. Controlled bench tests, in-vehicle measurements, and computational fluid dynamics (CFD) simulations were conducted to analyze flow behavior and identify the precise location and conditions for cavitation onset. Results showed that high flow rates and low coolant pressure generated vapor bubbles near the junction of the upper tank and outlet pipe, producing distinctive impulsive noise and vibration signals. Flow visualization using a transparent pipe and accelerometer data confirmed cavitation collapse at this location. CFD analysis indicated that the original geometry created a high-velocity, low-pressure region conducive to cavitation. A redesigned outlet with a tapered transition and larger diameter significantly improved flow conditions, raising the cavitation index and eliminating cavitation events. Experimental validation confirmed the effectiveness of the modified design. These findings contribute to improving the acoustic performance and reliability of automotive HVAC systems and offer broader insights into cavitation mitigation in fluid systems. Full article

Motivated by the strong transition to electric mobility we are witnessing currently, in this paper, we present a novel methodology to predict the dynamic behavior of heat, ventilation and air conditioning (HVAC) systems for electric vehicles. The approach is based on a lumped parameter energy balance between the vehicle cabin, the external loads (such as solar radiation, ventilation and metabolic load) and the HVAC system. Detailed models are used to obtain the time evolution of the heat transfer coefficients of each subsystem in the HVAC (i.e., evaporator and condenser) on the basis of correlations available in the literature. The model is validated on a real HVAC system, built ad hoc for a retrofitted electric vehicle, by comparing the results obtained from the model with experimental measurements performed in a climatic chamber. Then, some scenarios that represent interesting cases in electric automotive applications, such as vehicle cabin precooling during battery charging and a regulated driving cycle which simulates urban mobility, are considered. The energy consumption of the HVAC system is evaluated from the model in these scenarios and compared. The methodology herein presented is general and easily extendable to other systems, proving to be a powerful method to compare the energy consumption of HVAC systems under unsteady conditions with a more standard approach based on steady considerations. By this approach, it is shown that significant improvement can be obtained with a nonsteady approach. Full article

Electric vehicles (EVs) are rising in the automotive industry, replacing combustion engines and increasing their global market presence. These vehicles offer zero emissions during operation and more straightforward maintenance. However, for such systems that rely heavily on battery capacity, precisely determining the battery’s state of charge (SOC) presents a significant challenge due to its essential role in lithium-ion batteries. This research introduces a dual-phase testing approach, considering factors like HVAC use and road topography, and evaluating machine learning models such as linear regression, support vector regression, random forest regression, and neural networks using datasets from real-world driving conditions in European (Germany) and African (Morocco) contexts. The results validate that the proposed neural networks model does not overfit when evaluated using the dual-phase test method compared to previous studies. The neural networks consistently show high predictive precision across different scenarios within the datasets, outperforming other models by achieving the lowest mean squared error (MSE) and the highest R² values. Full article

The automotive industry is experiencing a surge in system complexity driven by the ever-growing number of interacting components, subsystems, and control systems. This complexity is further amplified by the expanding range of component options available to original equipment manufacturers (OEMs). OEMs work in parallel on more than one vehicle model, with multiple vehicle variants for each vehicle model. With the increasing number of vehicle variants needed to cater to diverse regional needs, development complexity escalates. To address this challenge, modern techniques like Model-Based Systems Engineering (MBSE), digitalization, and Artificial Intelligence (AI) are becoming essential tools. These advancements can streamline concept development, optimize thermal and HVAC system design across variants, and accelerate the time-to-market for next-generation EVs. The development of battery electric vehicles (BEVs) needs a strong focus on thermal management systems (TMSs) and heating, ventilation, and air conditioning (HVAC) systems. These systems play a critical role in maintaining optimal battery temperature, maximizing range and efficiency, and ensuring passenger comfort. This article proposes a digital prototype (DP) and AI-based methodology to specify BEV thermal system and HVAC system components in the concept phase. This methodology uses system and variant thinking in combination with digital prototype (DP) and AI to verify BEV thermal system architecture component specifications for future variants without extensive simulation. A BEV cabin cooling requirement of 22 °C to be achieved within 1800s at a high ambient temperature (45 °C) is required, and its verification is used to prove this methodology. Full article

Thermal comfort is very important for the well-being and safety of vehicle occupants, as discomfort can elevate stress, leading to distracted attention and slower reaction times. This creates a riskier driving environment. Addressing this, high-induction air diffusers emerge as a significant innovation, enhancing indoor environmental quality (IEQ) by efficiently mixing cool air from the heating ventilation and air conditioning (HVAC) system with the cabin’s ambient air. This process ensures uniform airflow, diminishes temperature discrepancies, prevents draft sensations, and boosts overall air quality by improving air circulation. In addition to enhancing thermal comfort in vehicles, the novel air diffuser also offers significant potential for personalized ventilation systems, allowing for individualized control over airflow and temperature, thereby catering to the specific comfort needs of each occupant. This study introduces a novel air diffuser that demonstrates a 48% improvement in air entrainment compared to traditional diffusers, verified through Ansys Fluent simulations and laser Doppler velocimetry (LDV) measurements. At a fresh airflow rate of 31.79 m³/h, the total air entrainment rate at 0.6 m for the standard air diffuser is 73.36 m³/h, while for the innovative air diffuser, it is 109.26 m³/h. This solution has the potential to increase the level of thermal comfort and air quality within vehicles, and also signals potential applications across various enclosed spaces, underscoring its importance in advancing automotive safety and environmental standards. Full article

The epidemic caused by the coronavirus infection SARS-CoV-2 at the beginning of 2022 affected approximately 500 million people in all countries. The source of infection is the particles of the virus, which, when breathing, talking, and coughing, are released with the respiratory droplets and aerosol dust of an infected person. Actions aimed at combating and minimizing the consequences of coronavirus infection led to taking measures in scientific areas to investigate the processes of the spread of viral particles in the air, in ventilation, and air conditioning systems of premises and transport, filtration through masks, the effect of partitions, face shields, etc. The article presents a mathematical model of the spread of viral particles in technological transport. Air intake diverters and the operator’s respiratory tract are the sources of the virus. The Euler–Lagrange approach was used to simulate liquid droplets in a flow. Here, the liquid phase is considered as a continuous medium using Navier–Stokes equations, the continuity equation, the energy equation, and the diffusion equation. Accounting for diffusion makes it possible to explicitly model air humidity and is necessary to consider the evaporation of droplets (changes in the mass and size of particles containing the virus). Liquid droplets are modeled using the discrete-phase model (DPM), in which each particle is tracked in a Lagrange coordinate system. The DPM method is effective, since the volume fraction of particles is small relative to the total volume of the medium, and the interaction of particles with each other can be neglected. In this case, the discrete and continuous phases are interconnected through the source terms in the equations. The averaged RANS equations are solved numerically using the k-ω turbulence model in the Ansys Fluent package. The task was solved in a static form and in the time domain. For a non-stationary problem, the stabilization time of the variables is found. The simulation results are obtained in the form of fields of pressures, velocities, temperatures and air densities, and the field of propagation of particles containing the virus. Various regimes were studied at various free flow rates and initial velocities of droplets with viral particles. The results of trajectories and velocities of particles, and particle concentrations depending on time, size, and on the evaporability of particles are obtained. Full article

Vehicle Heating, ventilation, and air conditioning (HVAC) systems can accumulate and recirculate highly infectious respiratory diseases via aerosols. Integrating Ultraviolet Subtype C (UVC) light-emitting diodes (LEDs) to complement automobile HVAC systems can protect occupants from developing allergies, experiencing inflammatory problems, or acquiring respiratory infectious diseases by inactivating pathogenic organisms. UVC can add little to no static pressure with minimal space, unlike mercury lamps which are larger and heavier. Additionally, UVC LEDs are effective at low voltage and have no mercury or glass. While previous experiments have shown UVC LED technology can reduce bacteriophage Phi6 concentrations by 1 log in 5 min (selected as the average time to clean the cabin air), those studies had not positioned LED within the HVAC itself or studied the susceptibility of the surrogate at the specific wavelength. This study aimed to assess the disinfection performance of UVC LEDs in automotive HVAC systems and determine the dose–response curve for bacteriophage Phi6, a SARS-CoV-2 surrogate. To achieve this, UVC LEDs were installed in a car HVAC system. To determine inactivation efficacy, a model chamber of 3.5 m³, replicating the typical volume of a car, containing the modified automobile HVAC system was filled with bacteriophage Phi6, and the HVAC was turned on with and without the UVC LEDs being turned on. The results revealed that HVAC complemented with UVC reduced bacteriophage Phi6 levels significantly more than the HVAC alone and reduced the viral concentration in the cabin by more than 90% viral reduction in less than 5 min. The performance after 5 min is expected to be significantly better against SARS-CoV-2 because of its higher sensitivity to UVC, especially at lower wavelengths (below 270 nm). HVAC alone could not achieve a 90% viral reduction of bacteriophage Phi6 in 15 min. Applying UVC LEDs inside an HVAC system is an effective means of quickly reducing the number of aerosolized viral particles in the chamber, by inactivating microorganisms leading to improved cabin air quality. Full article

Understanding the implications of introducing increasing shares of low-carbon technologies such as heat pumps and electric vehicles on the electricity network demand patterns is essential in today’s fast changing energy mixture. Application of heat pumps for heating and cooling, combined with the rooftop installation of photovoltaic panels, is already considered as a convenient retrofitting strategy towards building electrification. This may further profit from the parallel, rapid electrification of the automotive powertrain, as demonstrated in the present study. Exploitation of the combined battery storage of the house owners’ electric car(s) may help cover, to a significant degree, the building’s and cars’ electricity needs. To this end, an efficient single family house’s energy system with an optimized rooftop PV installation, heat pump heating and cooling, and two high efficiency electric cars is studied by transient simulation. The use of TRNSYS simulation environment makes clear the interaction of the house’s heating, ventilation, and air conditioning (HVAC) system, the house’s and cars’ batteries, and the rooftop PV system in transient operation. The building’s and EV’s energy performance on a daily, monthly, and seasonal level is compared with the respective demand curves and energy sources of the Greek electricity network. The specific design of the house’s energy system makes it a net exporter of electricity to the grid, to an annual amount of 5000 kWh. On the other hand, electricity imports are slightly exceeding 400 kWh and limited to the first two months of the year. In addition to the self-sufficiency of the household, the impact to the electricity grid becomes favorable due to the phase shift of the electricity export towards the late afternoon hours, thus assisting the evening ramp-up and adding to the grid’s stability and resilience. Based on the results of this study, the possibility of combining the financial incentives for the purchase of an EV with those for the installation of rooftop PV in the owners’ house is very promising and worth considering, due to the demonstrated synergy of electrical storage with the rooftop photovoltaic installations. Full article

This work is aimed at the experimental characterisation of air quality and thermal profile within an electric vehicle cabin, measuring at the same time the HVAC system energy consumption. Pollutant concentrations in the vehicle cabin are measured by means of a low-cost system of sensors. The effects of the HVAC system configuration, such as fresh-air and recirculation mode, on cabin air quality, are discussed. It is shown that the PM concentrations observed in recirculation mode are lower than those in fresh-air mode, while VOC concentrations are generally higher in recirculation than in fresh-air mode. The energy consumption is compared in different configurations of the HVAC system. The novelty of this work is the combined measurement of important comfort parameters such as air temperature distribution and air quality within the vehicle, together with the real time energy consumption of the HVAC system. A wider concept of comfort is enabled, based on the use of low-cost sensors in the automotive field. Full article

The automotive industry has set a highly demanding standard to meet customer satisfaction. The paper aimed to detail how quality analysis has been conducted to state the main causes that generated nonconformities of heat, ventilation and air conditioning (HVAC) systems. Problems have been reported on HVAC systems, such as noise, not being cold enough and moldy smell issues. All three problems determined by customer reports initiated the first contribution of this paper, namely by an initial quality study, and generated the investigation using is/is not problem scoping, data analysis, and graphical analysis. Pareto analysis and the Plan, Do, Check and Act (PDCA) approach are used to highlight the traceability of the actions performed in the evaluation of the problems and the detection of the causes related to each problem. The data analysis process and the data obtained from the analysis are the core of this paper. An immediate action plan is proposed, concluding with the hypothesis that the root cause is the blockage of the heater. This methodology has significant potential for being implemented, even for other components in the same industry or different sectors. Full article

In electric-powered cars, the production of which is increasing, the HVAC system is responsible for most of the noise inside the car’s cabin, causing significant discomfort for passengers. Moreover, the noise produced by the HVAC affects the perceptible sound inside the car cabin, significantly impacting the perceived quality of the vehicle. It is thus essential to investigate and quantify people’s preferences concerning HVAC noise. Our previous research revealed differences in the HVAC noise between hybrid electric (HEV) and internal combustion engine (ICEV) vehicles. A subsequent factor analysis revealed that the adjectives used to describe the sounds can be grouped into two main dimensions: Aesthetic and Loudness. The present paper highlights the results of a listening test that aimed to identify possible differences in the perception of HVACs’ sound quality between Italian and Japanese subject groups, for ICEV and HEV, in different functioning conditions. Results revealed that the most remarkable difference emerges at high air flow rates, where the Japanese group perceived the quality of sound and annoyance, respectively, to be significantly lower and significantly higher than the Italian group. Full article

The alternative control concept using emission from the machine has the potential to reduce energy consumption in HVAC systems. This paper reports on a study of alternative inputs for a control system of HVAC using machine learning algorithms, based on data that are gathered in a welding area of an automotive factory. A data set of CO${}_2$, fine dust, temperatures and air velocity was logged using continuous and gravimetric measurements during two typical production weeks. The HVAC system was reduced gradually each day to trigger fluctuations of emission. The data were used to train and test various machine learning models using different statistical indices, consequently to choose a best fit model. Different models were tested and the Long Short-Term Memory model showed the best result, with 0.821 discrepancy on R${}^2$. The gravimetric samples proved that the reduction of air exchange rate does not correlate to escalation of fine dust linearly, which means one cannot rely on just gravimetric samples for HVAC system optimization. Furthermore, by using machine learning algorithms, this study shows that by using commonly available low cost sensors in a production hall, it is possible to correlate fine dust data cost effectively and reduce electricity consumption of the HVAC. Full article

Reducing the noise and improving the sound quality of vehicles’ interior space is one of the challenges to enhance passengers’ experience. This is an ever-growing issue as entirely electric cars are becoming commonplace, making previously unnoticed noise a significant problem. Heating, Ventilation and Air Conditioning (HVAC) units are a major noise source in a vehicle’s interior space, yet automotive manufacturers only give a maximum dB specification to HVAC unit manufactures. Problematic noise is only typically identified once the unit is within the vehicle at the late stages of a project. Psychoacoustics is the study of human perception to sound, allowing unpleasant noise to be identified within recorded data. Within this study, an industrial prototype HVAC unit was analysed using a 96-channel acoustic camera capable of isolating and locating noise sources from the unit using beamforming. In addition to identifying the location of noise sources, several psychoacoustic metrics were used, such as sharpness and loudness, to identify undesirable noise within an extensive data set due to the vast range of test configurations. Testing was conducted to analyse the unit. Within the initial testing, an ‘annoying’ sound was identified at a particular motor RPM, and this was located using the camera to an area which indicated that it was a result of structural resonance. In addition, present was a high-frequency source which could not be located accurately. The results of this testing enable modifications to the unit to be made early in its’ development, either structurally to alter the resonance of the unit or within the settings to ensure certain RPMs are avoided. Full article

It is broadly acknowledged that there is an urgent need to reduce carbon-based mobility systems and increase renewable energy alternatives. The automotive industry is one of the greatest consumers of energy in the world. It is fronted with many challenges that aim at reducing carbon emissions. Renewable energy costs are getting cheaper and more cost effective. However, well devised design and control strategies are also needed in order to optimize any systems that are adopted in this field. Previous research shows that the energy consumption for non-traction purposes may be of the same scale as the energy used to move rolling stock, and in some cases even larger. The Kingdom of Saudi Arabia is very interested in the implementation of policies that aim at reducing energy consumption and encouraging renewable energy programs. Under its Vision 2030 development program, the Kingdom of Saudi Arabia is looking to produce 30% of its energy from renewables and other sources, with solar energy playing an important role. The work presented in this paper is aimed at an investigation of design and control strategies to reduce energy consumption and to propose a cleaner source of energy to power Princess Nourah Bint Abdulrahman University’s Automated People Mover (PNU-APM). Two areas of applications have been investigated for adopting these types of technology. Firstly, a p-v solar energy option that could be adopted for implementation in potential applications since the metro system is already in full operation using electricity. Secondly, design and control strategies including exploiting solar energy for a metro operation are discussed and investigated. A number of strategies to reduce heating, ventilation, and air conditioning (HVAC) load, which happens to be the biggest energy consumer, have been discussed. Results show great potential in energy savings with adopting p-v solar sources as well as implementation of few suggested control strategies. Some deliberations of some of the drawbacks of solar energy are also offered. Full article

Mechanical Engineering (ME) includes the design, manufacturing, assembly, and maintenance of mechanical subsystems for Architecture, Engineering, Construction, and Owner-Operator (AECO) projects. The intense adoption of information and communication technology in the AECO started with building product modelling, which was originally pioneered in the ME domain (i.e., automotive industry). The complexity and limited openness of product models paved the way for Building Information Modelling (BIM). Today, BIM workflows require an exchange of interoperable architecture, structure, and MEP/HVAC models and their seamless integration into a shared BIM model. Many specialized ME systems exist (i.e., medical gases and vacuum) for which BIM is not mature enough and where the role of BIM has not yet been studied. Therefore, a comprehensive cross-disciplinary analysis on the mutual influence of the BIM and the ME domain is needed for researchers and professionals. It identifies research fields and trends at the intersection of BIM and ME and analyzes their scope, limitations, and requirements for future extensions of BIM for better integration with ME. The analysis is based on an extensive literature search considering the interdisciplinary nature of ME. The initial collection of papers has undergone a rigorous bibliometric analysis that used a text mining approach for validation. Results show the field “Industry 4.0” as the most prosperous BIM influencing research field, followed by “Energy optimisation” and “Environmental Product Declaration”, while identifying “Geometric optimisation” and “Reinforced material” as the trendiest. Finally, conclusions on the impact of BIM on ME were drawn and 11 research opportunities were identified. This paper provides directions for studies where research is focused on the integration of ME systems in BIM workflows and on the extension of BIM capability to model future ME systems. Full article
