This research explores an improved operation of a recently studied converter, the so-called two-phase sixth-order boost converter (2P6OBC). The converter consists of a symmetric design of power stations followed by an LC filter; its improved operation incorporates an asymmetric pulse width modulation (PWM) scheme for transistor switching, sometimes known as an interleaved PWM approach. The new operation leads to improved performance for the 2P6OBC. Along with studying the 2P6OBC, one of the contributions of this research is providing design equations for the converter and comparing it versus the interleaved (or multiphase) boost converter, known for its competitiveness and advantages; the single-phase boost topology was also included in the comparison. The comparison consisted of a design scenario where all converters must achieve the same power conversion with an established maximum switching ripple, and then the stored energy in passive components is compared. Although the 2P6OBC requires a greater number of components, the total amount of stored energy is smaller. It is known that the stored energy is related to the size of the passive components. Still, the article includes a discussion of this topic. The new operation of the converter offers more streamlined, cost-effective, and efficient alternatives for a range of applications within power electronics. The final design of the 2P6OBC required only 68% of the stored energy in inductors compared to the multiphase boost converter, and 60% of the stored energy in capacitors. This result is outstanding, considering that the multiphase boost converter is a very competitive topology. Experimental results are provided to validate the proposed concept. Full article

This research articles proposes a comparative symmetric examination of the four maximum-power point-tracking algorithms under partial shaded conditions, including Conservative MPPT, Grey Wolf Optimization, and Fast Terminal Sliding Mode MPPT. In addition, the genetic algorithm MPPT, particle-swarm optimization MPPT, Grey Wolf optimization MPPT, and perturb and observe MPPT are included in this study. A smart method was to use Fast Terminal Sliding Mode Grey Wolf Optimization algorithms under partly shadowed situations on a global MPPT. This study included a GWO methodology that successfully set the efficient FTSM controller parameters such that the global maximum-power photovoltaic (PV) device point-tracking was monitored under partial shading. In the MATLAB setting and test performance, it was programmed for the suggested methodology of changing the shade pattern status dynamically. The findings were assessed and compared with other symmetric algorithms. Unlike other algorithms, the methodology used herein wasa less accurate way to monitor a global MPP. These methods were also evaluated and contrasted with PV arrays under various partial shadowing circumstances. The experimental investigations were used to verify the control techniques and stability analysis based on the asymmetric nonlinear load method of analysis in a closed-loop design. Full article

This paper presents a new approach to compensate for the current imbalance of an interleaved DC–DC buck converter (IBC), in which the current sensors are not involved in the operation of the converter when it is connected to an invariable load. The current sensors are only used during the offline identification process that builds the universal fuzzy model of the converter’s steady states. Model building involves an upstream identification phase, followed by further dimensionality reduction of the model and error minimization. The method presented here discusses the mathematical complexity of the analytical modelling of hybrid systems and opposes it with a complexity-reduced identification by learning from data. An offline rendered model of the stable and steady states of the IBC is used as a mapping of the required inverter output current to n-fold asymmetric duty cycles, which are distributed among the IBC phases to allow arbitrarily accurate load sharing. The mapping is carried out in the mathematically normalized space of variables or in the physical sense RMS values, achieving the desired robustness in a noisy environment and stability. The final and canonical feedback control is built from the standard and optimized PI controller, which is compensated by the identified IBC model correction. The only measured feedback of the whole controller is the output voltage. Even when applied to the simulation model (physical MATLAB platform) of a two-phase IBC with the built-in system asymmetry, the presented methodology is also applicable to the n-phase IBC without loss of generality. Full article

The DC-Link capacitor plays a crucial role as far as power density and reliability are concerned: it occupies approximately 40% of the inverter, and causes approximately 30% of its failures. Asymmetrical dual three-phase (ADTP) multiphase arrangements are gaining relevance in the automotive sector for powertrain applications. This work focuses on reducing the impact that the widely used double zero sequence injection (DZSI) family of PWM techniques have on such a bulky and failure-prone component in an ADTP arrangement by means of interleaving techniques. By using the double Fourier integral formalism, the input current spectra and the overall performance of these PWM techniques have been derived, in terms of current rms value and voltage ripple in the DC-Link capacitor. Simulations have shown that choosing an adequate interleaving scheme and angle considerably relieves both current and voltage stresses on the DC-Link capacitor compared to noninterleaved operation. Reductions of 84% current rms and 86% voltage ripple have been achieved at static operating points. Finally, by averaging the rms current over WLTP standard driving cycle, reductions up to 26% have been obtained under more realistic conditions. All this would enhance the reliability and reduce the size of the onboard capacitors in future electric vehicles. Full article

The Reduced Asymmetric Neutral Point Clamped converter topology for unipolar driven, multiphase switched reluctance machines is proposed in this paper. This topology shares similarities with the conventional NPC and Asymmetric-NPC topologies, however it is unique in that the components for the capacitor string and outer semiconductor switches are shared among all the phases for a reduced component count. Some switching state combinations are not possible during commutation overlap between motor phases, resulting in minor torque transients during regenerative braking. A custom modulation scheme is implemented with fixed frequency, phase-shifted carrier waveforms that allow for automatic balancing of the neutral point voltage and interleaved switching of the semiconductor switches. A simple torque observer control architecture is used with minor adjustments for arbitrating torque contribution priorities between phases during handover. Full article

In this paper, a bandpass filter (BPF) was developed utilizing GaAs-based integrated passive device technology which comprises an asymmetrical spiral inductor and an interleaved array capacitor, possessing two tuning modes: coarse-tuning and fine-tuning. By altering the number of layers and radius of the GaAs substrate metal spheres, capacitance variation from 0.071 to 0.106 pF for coarse-tuning, and of 0.0015 pF for fine-tuning, can be achieved. Five air bridges were employed in the asymmetrical spiral inductor to save space, contributing to a compact chip area of 0.015λ₀ × 0.018λ₀. The BPF chip was installed on the printed circuit board artwork with Au bonding wire and attached to a die sink. Measured results demonstrate an insertion loss of 0.38 dB and a return loss of 21.5 dB at the center frequency of 2.147 GHz. Furthermore, under coarse-tuning mode, variation in the center frequency from 1.956 to 2.147 GHz and transmission zero frequency from 4.721 to 5.225 GHz can be achieved. Under fine-tuning mode, the minimum tuning value and the average tuning value of the proposed BPF can be accurate to 1.0 MHz and 4.7 MHz for the center frequency and 1.0 MHz and 12.8 MHz for the transmission zero frequency, respectively. Full article

This paper introduces a novel converter topology based on an independent controlled double-boost configuration. The structure was achieved by combining two independent classic boost converters connected in parallel at the input and in series at the output. Through proper control of the two boost converters, an interleaved topology was obtained, which presents a low ripple for the input current. Being connected in series at the output, a three-level structure was attained with twice the voltage gain of classic boost and interleaved topologies. A significant feature of the proposed converter is the possibility of independent operation of the two integrated boost converters, in both symmetrical and asymmetrical modes. This feature may be particularly useful in voltage balancing or interconnection with bipolar DC grids/applications. The operation principle, simulations, mathematical analysis, and laboratory prototype experimental results are presented. Full article

Paralleled boost asymmetric configurations operating in discontinuous conduction mode (DCM) are suitable for integrating dissimilar green energy generating sources and control algorithms in versatile scenarios where voltage step-up, low cost, stable operation, low output ripple, uncomplicated design, and acceptable efficiency are needed. Unfortunately, research has mainly been conducted on the buck, sepic, switched-capacitor, among other asymmetric configurations operating in continuous conduction mode (CCM), to the authors’ knowledge. For asymmetric boost type topologies, achieving simultaneous CCM is not a trivial task, and other problems such as circulating currents arise. Research for interleaved converters cannot be easily extended to asymmetric boost topologies due to the dissimilarity of control algorithms and types of sources and parallel stages. This paper analytically establishes properties of stability, output ripple, output voltage, and design for asymmetrical paralleled boost converters operating in DCM with simultaneous or phase delayed (sequential) triggering. A 300 W experimental design and the respective tests allow validation of such properties, resulting in an easy-to-implement configuration with acceptable efficiency. Full article

An interleaved high-step-up current sharing DC–DC converter with coupled inductors is proposed in this paper. The operation principle and property of this converter are analyzed. The ripple of the input current in the proposed converter is decreased significantly by using the two-phase parallel interleaved input. The voltage gain is extended and the switch voltage stress is reduced by the coupled inductors. The leakage inductance of the coupled inductors reduces the reverse-recovery problem of the output diode, resulting in the reduction of reverse-recovery losses. As there are two interleaved phases in the proposed converter, the third winding of each coupled inductor is embedded in another phase. With this design, when the leakage inductance or duty cycle is asymmetrical, the current sharing performance is still positive. Consequently, the new topology is very suitable for applications to occasions with low voltage input and high voltage output, such as the fuel cell power system. Finally, the performance of this topological circuit is verified by a prototype with 500 W output. Full article

This paper proposes, for the first time, a two-source asymmetric turbo-coded-cooperative spatial modulation (SM) scheme over the slow Rayleigh fading channel. As in any coded cooperative communication, the interleaver plays a vital role in mitigating the harsh effect of the wireless channel. Therefore, the code matched interleaver (CMI) is effectively used in the proposed design. The simulated results reveal that the bit error rate (BER) performance of the proposed coded cooperative communication system outperforms the asymmetric turbo-coded non-cooperative scheme under identical conditions. This prominent performance improvement has been made possible due to the joint asymmetric turbo decoding at the destination node. Furthermore, to check the effectiveness of the proposed scheme, we have also developed a two-source asymmetric turbo-coded cooperative scheme based on the vertical bell labs layered space-time (VBLAST), incorporating the CMI as the suitable benchmark. It is observed that the proposed scheme employing SM has a better BER performance than the VBLAST scheme under identical conditions. Full article

A previous article has presented the members of the asymmetrical interleaved dc/dc switching converters family as very appropriate candidates to interface between photovoltaic or fuel cell generators and their loads because of their reduced ripple and increased current processing capabilities. After a review of the main modeling methods suitable for high-order converters operating, as the asymmetrical interleaved converters (AIC) ones, in discontinuous current conduction mode a full-order averaged model has been adapted and improved to describe the dynamic behavior of AIC. The excellent agreement between the mathematical model predictions, the switched simulations and the experimental results has allowed for satisfactory design of a linear-quadratic regulator (LQR) in a fuel-cell application example, which demonstrates the usefulness of the improved control-oriented modeling approach when the switching converters operate in discontinuous conduction mode. Full article

A novel asymmetrical interleaved dc/dc switching converters family intended for photovoltaic and fuel cell applications is presented in this paper. The main requirements on such applications are small ripples in the generator and load, as well as high voltage conversion ratio. Therefore, interleaved structures and voltage multiplier cells have been asymmetrically combined to generate new converters, which inherently operate indiscontinuous conduction mode. The novel family is derived from boost, buck-boost and flyback-based structures. This converter family is analyzed to obtain the design equations and synthesize a design process based on the typical requirements of photovoltaic and fuel cell applications. Finally, the experimental results validate the characteristics and usefulness of the asymmetrical interleaved converter family. Full article
