Search Results (36)

Piezoelectric ceramic actuators are widely used in precision positioning and sensor-integrated micro-motion systems, but their accuracy is limited by asymmetric, rate-dependent hysteresis and by residual disturbances that remain after feedforward linearization. This study develops a self-contained modeling and control framework that combines an explicit rising/falling branch polynomial model, frequency-dependent coefficient maps, direct inverse feedforward compensation, and disturbance-observer-based adaptive sliding-mode feedback. The actuator is represented as a multilayer piezoelectric stack coupled to an equivalent electrical-mechanical-sensing plant. A branch-state logic resolves the multivalued inverse mapping, and a numerical order-sensitivity study shows that the seventh-order model provides the lowest validation RMSE while avoiding the endpoint growth observed at higher orders. Laboratory measurements at 1, 5, 10, 20, 50, and 100 Hz, together with attenuated, triangular, random-amplitude, step, and 2 Hz sinusoidal tests, are used for validation. The proposed branch model reduces static maximum relative fitting error from 4.50–6.21% for the classical P-I model to 1.28–2.58%. Direct inverse compensation reduces linearity error from 8.56–13.88% to 0.53–1.024%, and the hybrid controller achieves a 1% settling time of 8.6 ms, a maximum tracking error of 0.0051 micrometers, and an RMSE of 0.0012 micrometers. The results demonstrate an embedded-oriented compromise between model accuracy, online computational simplicity, and robust closed-loop precision. Full article

Piezoelectric flexure micro-positioning stages are essential micromotion actuators for micro-assembly, atomic force microscopy and nano-manufacturing, but intrinsic hysteresis nonlinearity of piezoelectric stacks distorts the linear voltage-to-displacement mapping and induces significant micro-positioning errors. Conventional hysteresis compensation based on offline-calibrated Krasnosel’skii-Pokrovskii (KP) models cannot adapt to time-varying excitation, whereas state-of-the-art adaptive KP control requires auxiliary dynamic equations and imposes high computational overhead on miniature real-time controllers. To address these limitations, this paper develops a single-degree-of-freedom micromotion positioning device equipped with symmetric two-stage displacement amplification mechanisms and straight circular flexure hinges. ANSYS finite element simulations validate the mechanical stiffness, structural safety and linear amplification characteristic of the micro-positioning stage, achieving a maximum output stroke of 95.95 μm. A discretized KP hysteresis model is constructed to accurately capture the asymmetric rate-dependent hysteresis of piezoelectric stacks. On this basis, a lightweight adaptive inverse control framework is proposed, which realizes online tuning of KP weights through gradient descent iteration only relying on real-time position feedback, eliminating static pre-calibration and extra dynamic correction links. Tracking experiments under 0.1–2 Hz sinusoidal waveforms and 3–7 V variable-amplitude sinusoidal waveforms are implemented. Experimental results show that the proposed approach reduces the root-mean-square error (RMSE) by 7.41–85.65% and the mean absolute percentage error (MAPE) by 7.56–87.81% compared with uncompensated open-loop micromotion control. The combined micro-flexure mechanical design and adaptive hysteresis compensation strategy greatly improves positioning accuracy and anti-interference capacity, offering a low-computation technical route for high-performance micro-positioning systems. Full article

Wire rope isolators (WRIs) exhibit typical nonlinear and asymmetric hysteretic behavior, with their mechanical performance being significantly influenced by the coupled effects of multiple parameters. This study investigates the dynamic response of large-sized spiral WRIs under axial loading. Within the framework of an asymmetric hysteresis model, a novel algebraic closed-form formulation is adopted for parameter identification and numerical simulation. Furthermore, a characteristic parameter, A, is introduced to quantify the unique mechanical behavior induced by the structural configuration of WRIs. Five types of large-sized spiral WRIs are selected as test specimens. For each WRI, tests are conducted under 30 distinct working conditions, yielding a total of 150 cyclic loading tests across all scenarios. By systematically varying the displacement amplitude, loading frequency, and preloading pressure, the influences of these key parameters on the dynamic characteristics of WRIs are comprehensively analyzed. These characteristics encompass the axial hysteresis loop shape, energy dissipation capacity, equivalent viscous damping, and average secant stiffness. The results indicate that these three loading parameters exert substantial effects on the mechanical properties of large-sized WRIs. Additionally, the simulated hysteresis curves derived from the identified parameters exhibit excellent agreement with the experimental observations. Compared with conventional mechanical models, the proposed algebraic closed-form model demonstrates slightly higher fitting accuracy, thereby validating its effectiveness and applicability in characterizing the mechanical behavior of large-sized WRIs. This research provides a crucial reference for the engineering application of large-sized spiral WRIs and facilitates the broader adoption of the proposed modeling approach. Full article

Although the cyclic bending behavior of circular and elliptical steel tubes has been widely studied, the combined effects of major-to-minor axis length ratio and curvature ratio on the deformation characteristics and buckling life of galvanized steel elliptical tubes remain insufficiently understood. This study experimentally investigates the cyclic bending response and failure behavior of galvanized steel elliptical tubes with major-to-minor axis length ratios of 1.5, 2.0, 2.5, and 3.0 under curvature ratios of −1, −0.5, and 0. The curvature ratio is defined as the minimum controlled curvature divided by the maximum controlled curvature. Buckling is defined as the cycle at which a pronounced 20% drop in peak bending moment is observed. The response is characterized by moment (N⋅m)–curvature (m⁻¹) hysteresis and minor-axis variation with curvature, while failure is evaluated using the relationship between curvature range and number of cycles to buckling. The results show that stable elastoplastic hysteresis loops develop for all curvature ratios, with slight cyclic relaxation observed at curvature ratios of −0.5 and 0. Increasing the axis length ratio slightly reduces the peak moment under a fixed curvature ratio. Minor-axis variation increases progressively with cycle number, exhibiting serrated curves at an axis ratio of 1.5 and butterfly-shaped curves at higher axis ratios. Symmetric behavior is observed at a curvature ratio of −1, whereas asymmetric responses occur at −0.5 and 0. The failure results indicate that larger curvature ranges and higher axis length ratios reduce the number of cycles to buckling, while curvature ratios closer to −1 enhance buckling life. On a log–log scale, the relationship between curvature range (m⁻¹) and number of cycles to buckling becomes linear. A theoretical model is proposed and shows good agreement with the experimental results. Full article

Social acceleration and recurrent structural shocks increase habitus–field mismatch, yet similar exposure does not produce uniform trajectories of daily well-being or suicidal distress. This paper asks how comparable structural strain can generate divergent, path-dependent outcomes and why suicidal vulnerability may persist after objective conditions improve. We develop a theory-building, concept-driven framework that integrates Bourdieu’s practice theory with social and behavioural scholarship on stress, anomie, and despair, and conceptualises these dynamics as social hysteresis. The regime-based model specifies two ideal-typical response orientations through which mismatch can stabilise: an anomic regime marked by shame, withdrawal, and inwardly directed harm, and a radicalising regime marked by grievance framing, moral indignation, and organised participation, without implying violent extremism. Represented through hysteresis loops, the framework implies multistability, asymmetric switching thresholds, and scarring, providing a mechanism for persistence and non-linearity in distress trajectories. The model derives testable expectations for longitudinal panel and experience-sampling designs and suggests that prevention and intervention design should combine reductions in mismatch with relational and institutional infrastructures that facilitate regime shifts and reopen the space of possibles. Full article

To address the issue of hysteresis nonlinearity adversely affecting the tracking accuracy of piezoelectric actuators, an improved particle swarm optimization (PSO) algorithm is proposed to improve the accuracy of hysteresis model parameter identification. Additionally, a discrete-time linear quadratic optimal tracking (DLQT) control strategy incorporating hysteresis compensation is developed to improve tracking performance. This study employs the Hammerstein model to characterize the nonlinear hysteresis behavior of piezoelectric actuators. Regarding parameter identification, the conventional PSO algorithm tends to suffer from premature convergence and being trapped in local optima. To address this, a cross-variation mechanism is introduced to enhance population diversity and improve global search ability. Furthermore, adaptive and dynamically adjustable inertia weights are designed based on evolutionary factors to balance exploration and exploitation, thereby enhancing convergence and identification accuracy. The inertia weights and learning factors are adaptively adjusted based on the evolutionary factor to balance local and global search capabilities and accelerate convergence. Benchmark function tests and model identification experiments demonstrate the improved algorithm’s superior convergence speed and accuracy. In terms of control strategy, a hysteresis compensator based on an asymmetric hysteresis model is designed to improve system linearity. To address the issues of incomplete hysteresis compensation and low tracking accuracy, a DLQT controller is developed based on hysteresis compensation. Hardware-in-the-loop tracking control experiments using single and composite frequency reference signals show that the relative error is below 3.3% in the no-load case and below 4.5% in the loaded case. Compared with the baseline method, the proposed control strategy achieves lower root-mean-square error and maximum steady-state error, demonstrating its effectiveness. Full article

The present study intends to assess the ratcheting response of SA508 and SA333 steel alloys subjected to asymmetric loading cycles at various operating temperatures of 298, 573, and 623K through a hardening framework developed by Ahmadzadeh–Varvani (A-V) and the finite element analysis structured by the Chaboche hardening model (CH) in the ANSYS software program. The dynamic recovery terms in the A-V and CH hardening framework consisted of temperature-dependent parameters and functions to address the dynamic strain aging (DSA) phenomenon at high temperatures of 573 and 623 K. The DSA phenomenon reported at elevated temperatures was attributed to the interactions of solute atoms and dislocations with a certain temperature, resulting in higher material strength and lower ratcheting deformation. The coefficients of these frameworks were analytically determined through stress–strain hysteresis loops obtained from the strain-controlled cyclic tests. The FE analysis was applied to numerically evaluate backstress evolution through use of the CH model. Two popular nonlinear brick and tetrahedron element types were examined to study the convergence of the elemental system with various numbers of elements. This ensured the independence of the simulated results from the number of elements and their convergence. The simulated ratcheting responses for brick and tetrahedron solid elements were compared to those predicted analytically by the A-V hardening rule and experimentally measured values. The predicted and simulated ratcheting data were found to be in good agreement with the measured data. The predicted and simulated ratcheting results generated using the A-V and FEA approaches showed $R^2$ values of 0.96 and 0.85, respectively, when compared with the experimental data. Full article

To understand the asymmetric flow of a slender body with low-aspect ratio fins, a wind tunnel experiment was carried out, and the asymmetric flow was observed when the pair of fins had a symmetric deflection angle of 30° at a small angle of attack and zero sideslip angle at transonic speeds. The unsteady characteristics of flow around the moving fins, especially for the evolution of the asymmetric flow, was carefully numerically investigated via the RANS method. To verify the numerical method, the experimental steady wind tunnel data of the NACA 0012 airfoil with sinusoidal pitching motion were adopted. A hysteresis loop exists as a function of the deflection angle during the upstroke and downstroke motions. The side force is periodic due to the asymmetric flow peaks at the downstroke and their peak value appeared at around δz = 25°, which was independent of the deflection frequency. As the deflection frequency increased, the asymmetric flow formed at a higher deflection angle during the upstroke motion, but decayed at a lower deflection angle during the downstroke motion, resulting in a more significant unsteady hysteresis effect. Full article

In the present work, we have synthesized rare-earth ion modified Bi_4−xRE_xTi₂Fe0_.7Co_0.3O_12−δ (RE = Dy, Sm, La) multiferroic compounds by the conventional solid-state route. Analysis of X-ray diffraction by Rietveld refinement confirmed the formation of a polycrystalline orthorhombic phase. The morphological features revealed a non-uniform, randomly oriented, plate-like grain structure. The peaks evident in the Raman spectra closely corresponded to those of orthorhombic Aurivillius phases. Dielectric studies and impedance measurements were carried out. Asymmetric complex impedance spectra suggested the relaxation of charge carriers belonging to the non-Debye type and controlled by a thermally activated process. Temperature-dependent AC conductivity data showed a change of slope in the vicinity of the phase transition temperature of both magnetic and electrical coupling natures. Based on the universal law and its exponent nature, one can suppose that the conduction process is governed by a small polaron hopping mechanism but significant distortion of TiO₆ octahedral. The doping of the A-sites with rare-earth element ions and changes in the concentrations of Fe and Co ions located on the B-sites manifested themselves in saturated magnetic hysteresis loops, indicating competitive interactions between ferroelectric and canted antiferromagnetic spins. The magnetic order in the samples is attributed to pair-wise interactions between adjacent Fe³⁺–O–Fe³⁺, Co^2+/3+–O–Co^3+/2+, and Co^2+/3+–O–Fe³⁺ ions or Dzyaloshinskii–Moriya interactions among magnetic ions in the adjacent sub-lattices. As a result, enhanced magnetoelectric coefficients of 42.4 mV/cm-Oe, 30.3 mV/cm-Oe, and 21.6 mV/cm-Oe for Bi_4−xDy_xTi₂Fe0_.7Co_0.3O_12−δ (DBTFC), Bi_4−xLa_xTi₂Fe0_.7Co_0.3O_12−δ (LBTFC), and Bi_4−xSm_xTi₂Fe0_.7Co_0.3O_12−δ (SBTFC), respectively, have been obtained at lower magnetic fields (<3 kOe). The strong coupling of the Aurivillius compounds observed in this study is beneficial to future multiferroic applications. Full article

This study presents a finite element-based ratcheting assessment of additively manufactured aluminum 4043 samples undergoing asymmetric loading cycles. The Chaboche material model in ANSYS was utilized and the effects of mesh and element type were examined. Different element numbers were used in a thorough convergence study to obtain independent meshing structures. The coefficients of this model were defined through stress–strain hysteresis loops determined from the strain-controlled tests. The backstress evolution and the corresponding yield surface translation in the deviatoric stress space were discussed as three different mesh elements of linear brick, quadratic tetrahedron, and quadratic brick were adopted. The magnitude of backstress was affected as different element types were employed. The first-order brick elements resulted in the highest backstress increments, while the lowest backstresses were determined when quadratic brick elements were taken. Backstress increments are positioned in an intermediate level with the use of quadratic tetrahedron elements. The choice of the element type, shape, and number influenced material ratcheting response over the loading process. The use of quadratic brick elements elevated the simulated ratcheting curves. The quadratic tetrahedron and linear brick elements, however, suppressed ratcheting level as compared with those of experimental data. The closeness of the simulated ratcheting results to those of the measured values was found to be highly dependent on these finite element variables. Full article

Exchange bias (EB) is a unidirectional anisotropy occurring in exchange-coupled ferromagnetic/antiferromagnetic systems, such as thin films, core–shell particles, or nanostructures. In addition to a horizontal shift of the hysteresis loop, defining the exchange bias, asymmetric loops and even vertical shifts can often be found. While the effect is used in hard disk read heads and several spintronics applications, its origin is still not fully understood. Especially in nanostructures with their additional shape anisotropies, interesting and often unexpected effects can occur. Here, we provide an overview of the most recent experimental findings and theoretical models of exchange bias in nanostructures from different materials. Full article

We study the so-called self-polarization phenomenon in single, electroded PbTiO₃ crystals. In this case, near the electrodes, surface layers are formed with a chemically modified perovskite structure. This generates a built-in electric polarization, which cannot be switched permanently by an external electric field. While the initial samples, having two such surface layers with opposite directions of built-in polarization, exhibit ordinary symmetric hysteresis loops, the “asymmetric” samples, with one of these surface layers removed, show asymmetric hysteresis loops. To describe our experimental findings, we combine two kinds of models: one is phenomenological, utilizing the above general features; and the other is ab initio, taking into account the actual atomic structure at the bulk ferroelectric–surface layer–electrode interface. Namely, the ab initio calculations show that the electric polarization within the surface layer occurs due to the shifts of the relaxed Ti ions with respect to the oxygen ion octahedra on the PbO-terminated surface. We ascribe the self-polarization effect to the occurrence of the built-in electric field resulting from the formation of Pb-O planes within the surface layer. Full article

The results of the asymmetric magneto-optical rotation in the magnetoplasmonic nanocomposite study are presented. The asymmetry is observed in spectra of magneto-optical rotation when a magneto-optical medium with a plasmonic subsystem is magnetized along or against the radiation wave vector. The asymmetry is observed as vertical displacement of a magneto-optical hysteresis loop too. Such asymmetry is detected in magnetoplasmonic nanocomposite, which consists of a magneto-optical layer of Bi substituted iron-garnet intercalated with a plasmonic subsystem of gold self-assembled nanoparticles. It is shown that the physical reason for the asymmetric magneto-optical rotation is the manifestation of the Cotton–Mouton birefringence effect when the normal magnetization of the sample to a radiation wave vector appears due to the magnetic component of the electromagnetic field of resonating nanoparticles. This effect is additive to the basic magneto-optical Faraday Effect. Full article

Ion current rectification (ICR) is the ratio of ion current by forward bias to backward bias and is a critical indicator of diode performance. In previous studies, there have been many attempts to improve the performance of this ICR, but there is the intrinsic problem for geometric changes that induce ionic rectification due to fabrication problems. Additionally, the high ICR could be achieved in the narrow salt concentration range only. Here, we propose a multi-layered bipolar ionic diode based on an asymmetric nanochannel network membrane (NCNM), which is realized by soft lithography and self-assembly of homogenous-sized nanoparticles. Owing to the freely changeable geometry based on soft lithography, the ICR performance can be explored according to the variation of microchannel shape. The presented diode with multi-layered configuration shows strong ICR performance, and in a broad range of salt concentrations (0.1 mM~100 mM), steady ICR performance. It is interesting to note that when each anion-selective (AS) and cation-selective (CS) NCNM volume was similar to each optimized volume in a single-layered device, the maximum ICR was obtained. Multi-physics simulation, which reveals greater ionic concentration at the bipolar diode junction under forward bias and less depletion under backward in comparison to the single-layer scenario, supports this tendency as well. Additionally, under different frequencies and salt concentrations, a large-area hysteresis loop emerges, which indicates fascinating potential for electroosmotic pumps, memristors, biosensors, etc. Full article

Transformers, reactors and other electrical equipment often work under harmonics and DC-bias working conditions. It is necessary to quickly and accurately simulate the hysteresis characteristics of soft magnetic materials under various excitation conditions in order to achieve accurate calculations of core loss and the optimal design of electrical equipment. Based on Preisach hysteresis model, a parameter identification method for asymmetric hysteresis loop simulation is designed and applied to the simulation of hysteresis characteristics under bias conditions of oriented silicon steel sheets. In this paper, the limiting hysteresis loops of oriented silicon steel sheets are obtained through experiments under different working conditions. The first-order reversal curves(FORCs) with asymmetric characteristics is generated numerically, and then the Everett function is established under different DC bias conditions. The hysteresis characteristics of the oriented silicon steel sheets under harmonics and DC bias are simulated by improving FORCs identification method of the Preisach model. By comparing the results of simulation and experiment, the effectiveness of the proposed method is verified, so as to provide an important reference for material production and application. Full article
