This paper proposes a balanced dynamic Time Division Multiple Access bus architecture with a novel selectable–sequence–counter arbitration circuit. Most existing dTDMA-related studies focus on wireless communications, which involve significantly different architectural assumptions, design constraints, and implementation platforms compared to digital bus systems. Our comparative analysis was carried out against the only available implementation in the literature, aligning to the target domain of digital buses. The proposed SSC-based arbiter, evaluated on a 65 nm CMOS process, demonstrates superior performance, achieving substantial reductions in area and power consumption with an approximated linear resource scaling as the number of connected devices to the bus increases, unlike the quadratic growth in the conventional architecture. Thus, this work offers a practical and yet efficient novel dTDMA architecture solution for on-chip communication. Full article

As the resolution and conversion speed of time-to-digital conversion (TDC) chips continue to improve, the bit error rate also increases, leading to a decrease in the linearity of TDC and seriously affecting measurement accuracy. This paper presents a high-linearity, low-power-consumption, and wide dynamic range TDC that was achieved based on the SMIC 180 nm BCD process. Compared with previous research methods, the proposed phase arbiter structure can eliminate sampling errors and improve the linearity of TDC. The preprocessing circuit can eliminate fixed errors caused by START and STOP signal transmission delays. Post-simulation results show that the TDC has high linearity, with ranges of DNL and INL being −0.98 LSB < DNL < 0.93 LSB and −0.88 LSB < INL < 0.95 LSB, respectively. The highest resolution is 156 ps, the maximum measurement time range is 1.2 μs, and the power consumption is 1.625 mW. The overall system architecture of TDC is very simple, and it can be applied to dToF LIDAR to measure photon flight time, capable of measuring a range of up to hundreds of meters, with an accuracy of 2.25 cm, high linearity, and without any post-processing or time calibration. Full article

Edge computing (EC) faces unique security threats due to its distributed architecture, resource-constrained devices, and diverse applications, making it vulnerable to data breaches, malware infiltration, and device compromise. The mitigation strategies against EC data security threats include encryption, secure authentication, regular updates, tamper-resistant hardware, and lightweight security protocols. Physical Unclonable Functions (PUFs) are digital fingerprints for device authentication that enhance interconnected devices’ security due to their cryptographic characteristics. PUFs produce output responses against challenge inputs based on the physical structure and intrinsic manufacturing variations of an integrated circuit (IC). These challenge-response pairs (CRPs) enable secure and reliable device authentication. Our work implements the Arbiter PUF (APUF) on Altera Cyclone IV FPGAs installed on the ALINX AX4010 board. The proposed APUF has achieved performance metrics of 49.28% uniqueness, 38.6% uniformity, and 89.19% reliability. The robustness of the proposed APUF against machine learning (ML)-based modeling attacks is tested using supervised Support Vector Machines (SVMs), logistic regression (LR), and an ensemble of gradient boosting (GB) models. These ML models were trained over more than 19K CRPs, achieving prediction accuracies of 61.1%, 63.5%, and 63%, respectively, thus cementing the resiliency of the device against modeling attacks. However, the proposed APUF exhibited its vulnerability to Multi-Layer Perceptron (MLP) and random forest (RF) modeling attacks, with 95.4% and 95.9% prediction accuracies, gaining successful authentication. APUFs are well-suited for device authentication due to their lightweight design and can produce a vast number of challenge-response pairs (CRPs), even in environments with limited resources. Our findings confirm that our approach effectively resists widely recognized attack methods to model PUFs. Full article

The branch prediction units (BPUs) generally have security vulnerabilities, which can be used by attackers to tamper with the branches, and the existing protection methods cannot defend against these attacks. Therefore, this article proposes a hardware security protection method for conditional branches of embedded systems. This method calculates the number of branch target buffer (BTB) updates every 80 clock cycles. If the number exceeds the set threshold, the BTB will be locked and prevent any process from tampering with the BTB entries, thereby resisting branch prediction analysis (BPA) attacks. Moreover, to prevent attackers from stealing the critical information of branches, the method designs the hybrid arbiter physical unclonable function (APUF) circuit to encrypt and decrypt the directions, addresses, and indexes of branches. This circuit combines the advantages of double APUF and Feed-Forward APUF, which can enhance the randomness of output response and resist machine learning attacks. If attackers still successfully tamper with the branches and disrupt the control flow integrity (CFI), this method detects tampering with the instruction codes, jump addresses, and jump directions in a timely manner through dynamic and static label comparison. The proposed method is implemented and tested on FPGA. The experimental results show that this method can achieve fine-grained security protection for conditional branches, with about 5.4% resource overhead and less than 5.5% performance overhead. Full article

Convolutional neural networks (CNNs) have demonstrated significant superiority in modern artificial intelligence (AI) applications. To accelerate the inference process of CNNs, reconfigurable CNN accelerators that support diverse networks are widely employed for AI systems. Given the ubiquitous deployment of these AI systems, there is a growing concern regarding the security of CNN accelerators and the potential attacks they may face, including hardware Trojans. This paper proposes a hardware Trojan designed to attack a crucial component of FPGA-based CNN accelerators: the reconfigurable interconnection network. Specifically, the hardware Trojan alters the data paths during activation, resulting in incorrect connections in the arithmetic circuit and consequently causing erroneous convolutional computations. To address this issue, the paper introduces a novel detection technique based on physically unclonable functions (PUFs) to safeguard the reconfigurable interconnection network against hardware Trojan attacks. Experimental results demonstrate that by incorporating a mere 0.27% hardware overhead to the accelerator, the proposed hardware Trojan can degrade the inference accuracy of popular neural network architectures, including LeNet, AlexNet, and VGG, by a significant range of 8.93% to 86.20%. The implemented arbiter-PUF circuit on a Xilinx Zynq XC7Z100 platform successfully detects the presence and location of hardware Trojans in a reconfigurable interconnection network. This research highlights the vulnerability of reconfigurable CNN accelerators to hardware Trojan attacks and proposes a promising detection technique to mitigate potential security risks. The findings underscore the importance of addressing hardware security concerns in the design and deployment of AI systems utilizing FPGA-based CNN accelerators. Full article

As semiconductor technology evolves, computing platforms attempt to integrate hundreds of processing cores and associated interconnects into a single chip. Network-on-chip (NoC) technology has been widely used for data exchange centers in recent years. As the core element of the NoC, the round-robin arbiter provides fair and fast arbitration, which is essential to ensure the high performance of each module on the chip. In this paper, we propose a low-latency fair switch arbiter (FSA) architecture based on the tree structure search algorithm. The FSA uses a feedback-based parallel priority update mechanism to complete the arbitration within the leaf nodes and a lock-based round-robin search algorithm to guarantee global fairness. To reduce latency, the FSA keeps the lock structure only at the leaf node so that the complexity of the critical path does not increase. Meanwhile, the FSA achieves a critical path with only $O\left(lo{g}_{4}N\right)$ delay by using four input nodes in parallel. The latency of the proposed circuit is on average 22.2% better than the existing fair structures and 8.1% better than the fastest arbiter, according to the synthesis results. The proposed architecture is well suited for high-speed network-on-chip switches and has better scalability for switches with large numbers of ports. Full article

The usage of single-photon avalanche diode arrays is becoming increasingly common in various domains such as medical imaging, automotive vision systems, and optical communications. Nowadays, thanks to the development of microelectronics technologies, the SPAD arrays designed for these applications has been drastically well-facilitated, allowing for the manufacturing of large matrices. However, there are growing challenges for the design of readout circuits with the needs of reducing their energy consumption (linked to the usage cost) and data rate. Indeed, the design of the readout circuit for the SPAD array is generally based on synchronous logic; the latter requires synchronization that may increase the dead time of the SPADs and clock trees management that are known to increase power consumption. With these limitations, the long-neglected asynchronous (clockless) logic proved to be a better alternative because of its ability to operate without a clock. In this paper, we presented the design of a 16-to-1 fixed-priority tree arbiter readout circuit for a SPAD array based on asynchronous logic principles. The design of this circuit was explained in detail and supported by simulation results. The manufactured chip was tested, and the experimental results showed that it is possible to record up to 333 million events per second; no reading errors were detected during the data extraction test. Full article

Classical cryptographic methods that inherently employ secret keys embedded in non-volatile memory have been known to be impractical for limited-resource Internet of Things (IoT) devices. Physical Unclonable Functions (PUFs) have emerged as an applicable solution to provide a keyless means for secure authentication. PUFs utilize inevitable variations of integrated circuits (ICs) components, manifest during the fabrication process, to extract unique responses. Double Arbiter PUFs (DAPUFs) have been recently proposed to overcome security issues in XOR PUF and enhance the tolerance of delay-based PUFs against modeling attacks. This paper provides comprehensive risk analysis and performance evaluation of all proposed DAPUF designs and compares them with their counterparts from XOR PUF. We generated different sets of real challenge–response pairs CRPs from three FPGA hardware boards to evaluate the performance of both DAPUF and XOR PUF designs using special-purpose evaluation metrics. We show that none of the proposed designs of DAPUF is strictly preferred over XOR PUF designs. In addition, our security analysis using neural network reveals the vulnerability of all DAPUF designs against machine learning attacks. Full article
