Search Results (19)

Corrosion is one of the main causes of aircraft structural damage. The deepening of the corrosion depth will greatly endanger the safety of the crew. The Lamb wave array signal processing method can be used to estimate the direction of arrival (DOA) of the signal source. As a form of the Lamb wave array signal processing method, multiple-signal classification (MUSIC) has been gradually applied to the corrosion monitoring of aluminum plates. However, when MUSIC is used for Lamb wave DOA estimation, it has a low resolution and poor anti-interference ability. To improve it, the Lamb wave near-field source location (LWNFL) method is proposed in this paper. The new method adopts a double-sensor array arrangement. Firstly, the compressed sensing (CS) theory is combined with the Lamb wave near-field array model to obtain a DOA estimation of the corrosion. Here, the corrosion angle can be obtained using a CS reconstruction algorithm, and the noise interference can be suppressed by limiting a minimization of the l₂ norm. Then, the corrosion distance is calculated according to the Lamb wave arrival time difference between different sensors. Finally, the average of the positioning results from multiple excitation sensors is used as the final location of the corrosion. The proposed LWNFL method is verified on an aluminum plate. The experimental results show that the new method can accurately obtain the location of corrosion and has good resolution and strong anti-interference ability. Full article

For floating offshore wind turbines, a significant pitch and roll motion response of the platform can affect the acceleration and power generation of the nacelle. The damping plate is considered a type of attachment that can be used to reduce rotational motion, but research on its anti-rotational effect is limited. The objective of this work is to analyze the impact of installing damping plates and varying their sizes on the pitch motion response of semi-submersible platforms, while also proposing optimization strategies for damping plate design. Firstly, a comparison between numerical simulations and experimental measurements validates the accuracy of the CFD calculations. Subsequently, different sizes of damping plates are proposed for the platforms, followed by simulations under various conditions. Finally, comprehensive data analysis is conducted. The findings suggest that installing damping plates enhances both the platform’s added moment of inertia and damping coefficients while simultaneously amplifying its motion response in regular waves. Furthermore, increasing the size of damping plates leads to an increase in both the added moment of inertia and motion response for the platform, whereas the damping coefficient exhibits an initial increasing trend followed by a subsequent decrease. Ultimately, it is found that increasing the distance between damping plates and the free surface significantly reduces wave-induced loads on the platform. Full article

Focusing on the bending wave characteristic of plate–shell structures, this paper derives the complex band curve of piezoelectric phononic crystal based on the equilibrium differential equation in the plane stress state using COMSOL PDE 6.2. To ascertain the computational model’s accuracy, the computed complex band curve is then cross-validated against real band curves obtained through coupling simulations. Utilizing this model, this paper investigates the impact of structural and electrical parameters on the bandgap range and the attenuation coefficient in the bandgap. Results indicate that the larger surface areas of the piezoelectric sheet correspond to lower center bands in the bandgap, while increased thickness widens the attenuation coefficient range with increased peak values. Furthermore, the influence of inductance on the bandgap conforms to the variation law of the electrical LC resonance frequency, and increased resistance widens the attenuation coefficient range albeit with decreased peak values. The incorporation of negative capacitance significantly expands the low-frequency bandgap range. Visualized through vibration transfer simulations, the vibration-damping ability of the piezoelectric phononic crystal is demonstrated. Experimentally, this paper finds that two propagation modes of bending waves (symmetric and anti-symmetric) result in variable voltage amplitudes, and the average vibration of the system decreases by 4–5 dB within the range of 1710–1990 Hz. The comparison between experimental and model-generated data confirms the accuracy of the attenuation coefficient calculation model. This convergence between experimental and computational results emphasizes the validity and usefulness of the proposed model, and this paper provides theoretical support for the application of piezoelectric phononic crystals in the field of plate–shell vibration reduction. Full article

Bolts have the advantages of simple installation and easy removal. They are widely applied in aerospace and high-speed railway traffic. However, the loosening of bolts under mixed loads can lead to nonlinear decreases in pre-loading. This affects the safety performance of the structure and may lead to catastrophic consequences. Existing techniques cannot be used to monitor the bolt performance status in time. This has caused significant problems with the safety and reliability of equipment. In order to study the relaxation law of bolt pre-loading, this paper carries out an experimental analysis for 8.8-grade hexagonal bolts and calibrates the torque coefficient. We also studied different loading waveforms, nickel steel plate surface roughnesses, tangential displacement frequencies, four different strengths and bolt head contact areas of the bolt, the initial pre-loading, and the effects of tangential cyclic displacement on pre-loading relaxation. This was done in order to accurately predict the degree of bolt pre-loading loosening under external loads. The laws are described using the allometric model function and the nine-stage polynomial function. The least squares method is used to identify the parameters in the function. The results show that bolts with a smooth surface of the connected structure nickel steel flat plate, high-frequency working conditions, half-sine wave, and a high-strength have better anti-loosening properties. Taking 5–10 cycles of cyclic loading as a boundary, the pre-loading relaxation is divided into two stages. The first stage is a stage of rapid decrease in bolt pre-loading, and the second stage is the slow decrease process. The performance prediction study shows that the allometric model function is the worst fitted, at 71.7% for the small displacement condition. Other than that, the allometric model function and the nine-stage polynomial function can predict more than 85.5% and 90.4%, which require the use of least squares to identify two and ten unknown parameters, respectively. The complexity of the two is different, but both can by better indicators than the pre-loading relaxation law under specific conditions. It helps to improve the monitoring of bolt loosening and the system use cycle, and it can provide theoretical support for complex equipment working for a long time. Full article

A structure located in seismic regions must have a resistance capacity based on current seismic design codes and maintain this capacity for its design life. However, the responses of structures to several major earthquakes worldwide over the past decade have demonstrated the inadequacy of current seismic design codes. Thus, there is a need for an accurate method for assessing the strength of structures under seismic loads. Accordingly, this study aimed to numerically review the structural performance of a typical firefighting water tank equipped with an anti-wave plate under seismic loads. Quasi-static and transient structural analysis methods were developed to determine the structural strength of the water tank. In addition, a one-way fluid–structure interaction (FSI) method was developed to analyse the effect of the anti-wave plate on the liquid-sloshing motion in and the structural strength of the water tank. Moreover, convergence tests were performed to aid the development of mesh models and grid models for finite element method and finite volume method analyses, respectively. Subsequently, the structural responses of the water tank were determined via quasi-static, transient, and one-way FSI analyses. Finally, the effectiveness of the anti-wave plate for mitigating the sloshing pressure in the water tank and the structural responses according to the pressure change were analyzed. The commercial software ANSYS Workbench (ver. 2020R2) was used. Full article

The transient surface current density reflects the external coupling of the electromagnetic pulse (EMP) to the tested device. In this paper, the generation mechanism and measurement principle of conductor surface current density are introduced, and the surface current density distribution irradiated by EMP on a typical aircraft structure is simulated and analyzed. The traditional surface current density is usually measured by B-dot antenna, but its output signal is the differential of the measured signal, so additional integrators or numerical integration of the measured data are required. In this paper, a self-integrating surface current sensor based on optical fiber transmission is designed based on the shielded loop antenna with gap structure. The output signal is the real signal waveform to be measured. Compared with coaxial cables, integrated optical fiber transmission improves the anti-interference ability of long-distance transmission signals. At the same time, the design process of the sensor is introduced in detail. The bandwidth of the sensor is 300 kHz~500 MHz, the sensitivity is calibrated at 1.23 (A·m⁻¹)/mV, and the dynamic range is ±25~1400 A·m⁻¹ (35 dB). The surface current of a metal plate is measured in a bounded wave electromagnetic pulse simulator using a detector developed in this paper. The test results show that the developed sensor has good engineering applicability. Full article

A comb-type floating breakwater is a new wave dissipation structure with particular force and dissipation performance advantages due to the two wave-reflecting surfaces. In this article, physical model experiments are used to study the hydrodynamic characteristics of a fixed floating comb breakwater and two structural optimization-based measures under the combined action of regular waves, irregular waves, and wave currents. The effects of factors such as the relative width, relative wave height, water flow velocity, and irregular waves on the transmission coefficient of the breakwater are analyzed. In addition, the characteristics of the transmission wave waveform are analyzed based on the time and frequency domains. The results show that (1) the wave transmission coefficient of a comb-type floating breakwater is lower than that of a rectangular floating box for long-period waves, while the transmission coefficient is larger than that of a rectangular floating box for short-period waves. (2) Under combined current and waves, the superimposition of bidirectional currents can increase the transmission coefficient, and the transmission coefficient increases with increasing current speed. The superimposition of the anti-directional current can decrease the transmission coefficient. (3) Moreover, with the same wave parameters, the transmission coefficient for irregular waves is larger than that of regular waves. (4) Finally, extending the bottom plate and adding lower baffles can effectively enhance the wave dissipation effect of the comb-type floating breakwater while also stabilizing the transmitted wave waveform. Full article

With the extensive application of composite laminates in protective structures, new materials and new structures have been developed rapidly. As an excellent impact-resistant material, aramid fiber is widely used in the field of protective structures. Aramid laminates show excellent performance in anti-penetration, but there is no research on its anti-explosive characteristics. In this paper, a kind of aramid–steel composite target (ASCT) plate protective structure is proposed innovatively. The failure mode and damage mechanism of three kinds of ASCT plates with equal area density and single-layer steel plates under a local explosion load are studied, and the most effective composite mode is given. The results show that the aramid laminates stuck on the back explosion surface ASCT (SA) exhibit the best anti-explosion effect, which is center deflection reduced by 12% and 18% compared with a single-layer steel plate (S-1) and an equal-thickness steel plate (S-2), respectively. Plate ASCT (SA), plate ASCT (AS), and ASCT (SAS) plate center tear failure did not occur. The analysis shows that different combinations change the propagation of stress waves in the structure, which in turn affects the failure of the composite plate. The critical failure dose of different structural configuration plates is obtained by simulation. The influence of explosion center distance, explosive charge, and bonding thickness of aramid laminate on the central deflection of steel plate was discussed by dimensional analysis, and the empirical formula of central deflection of the aramid–steel composite target plate was obtained. The research results can provide a theoretical basis and reference for the lightweight and efficient protection of composite structural armor. Full article

This paper demonstrates that a graded-index (GRIN) phononic lens, combined with a channel waveguide, can focus anti-symmetric Lamb waves for extraction by a detector with strong directional sensitivity. Guided ultrasonic wave inspection is commonly applied for structural health monitoring applications; however, obtaining sufficient signal amplitude is a challenge. In addition, fiber Bragg grating (FBG) sensors have strong directional sensitivity. We fabricate the GRIN structure, followed by a channel waveguide starting at the focal point, using a commercial 3D printer and mount it on a thin aluminum plate. We characterize the focusing of the A₀ mode Lamb wave in the plate, traveling across the GRIN lens using 3D laser Doppler vibrometry. We also measure the extraction of focused energy using an FBG sensor, examining the optimal sensor bond location and bond length in the channel of the waveguide for maximum signal extraction. The measured amplification of the ultrasound signal is compared to theoretical predictions. The results demonstrate that significant amplification of the waveform is achieved and that selecting the location of the FBG sensor in the channel is critical to optimizing the amplification. Full article

A cylindrical resonator gyroscope is a kind of Coriolis gyroscope, which measures angular velocity or angle via processing of the standing wave. The symmetry of a cylindrical resonator is destroyed by different degrees of geometric nonuniformity and structural damage in the machining process. The uneven mass distribution caused by the asymmetry of the resonator can be expressed in the form of a Fourier series. The first three harmonics will reduce the anti-interference ability of the resonator to the external vibration, as well as increase the angular random walk and zero-bias drift of the gyroscope. In this paper, the frequency split of different modes caused by the first three harmonic errors and the displacement of the center of the cylindrical resonator bottom plate are obtained by simulation, and the relationship between them is explored. The experimental results on five fused silica cylindrical resonators are consistent with the simulation, confirming the linear relationship between the n = 1 frequency split and second harmonic error. A method for evaluating the first three harmonic errors of fused silica cylindrical resonators is provided. Full article

To study the mechanical deformation characteristics and anti-explosion mechanisms of steel-structure protective doors under chemical explosion shock wave loads, numerical simulations of loads and door damage were carried out using the AUTODYN and LS-DYNA software based on model tuning with actual field test results. The finite element simulation results were compared with the test results to verify the accuracy of the simulation model and material parameters. A parametric analysis was carried out on the influencing factors of the anti-explosion performance of the beam–plate steel structure protective door under typical shock wave loads. The impact of the material strength and geometry of each part of the protective door on its anti-explosion performance was studied. The results showed that the protective door sustained a uniform shock wave load and that increasing the steel strength of the skeleton could significantly reduce the maximum response displacement of the protective door. The steel strength increase of the inner and outer panels had little or a negligible effect on the anti-explosion performance of the protective door. The geometric dimensions of different parts of the protective door had different effects on the anti-explosion performance. Increasing the skeleton height had the most significant effect on the anti-explosion performance. The skeleton’s I-steel flange thickness and the inner and outer panel thicknesses had less significant effects. Full article

Cardiac troponin-I (cTnI) is a well-known biomarker for the diagnosis and control of acute myocardial infarction in clinical practice. To improve the accuracy and reliability of cTnI electrochemical immunosensors, we propose a multilayer nanostructure consisting of Fe₃O₄-COOH labeled anti-cTnI monoclonal antibody (Fe₃O₄-COOH-Ab₁) and anti-cTnI polyclonal antibody (Ab₂) conjugated on Au-Ag nanoparticles (NPs) decorated on a metal–organic framework (Au-Ag@ZIF-67-Ab₂). In this design, Fe₃O₄-COOH was used for separation of cTnI in specimens and signal amplification, hierarchical porous ZIF-67 extremely enhanced the specific surface area, and Au-Ag NPs synergically promoted the conductivity and sensitivity. They were additionally employed as an immobilization platform to enhance antibody loading. Electron microscopy images indicated that Ag-Au NPs with an average diameter of 1.9 ± 0.5 nm were uniformly decorated on plate-like ZIF-67 particles (with average size of 690 nm) without any agglomeration. Several electrochemical assays were implemented to precisely evaluate the immunosensor performance. The square wave voltammetry technique exhibited the best performance with a sensitivity of 0.98 mA mL cm⁻² ng⁻¹ and a detection limit of 0.047 pg mL⁻¹ in the linear range of 0.04 to 8 ng mL⁻¹. Full article

In this research, beam focusing in lithium niobate plate was studied for fundamental anti-symmetric (A₀) and symmetric (S₀) Lamb waves, and the shear-horizontal (SH₀) wave of zero-order. Using the finite element method, appropriate configuration of the interdigital transducer with arc-like electrodes was modeled accounting for the anisotropy of the slowness curves and dispersion of the modes in the plate. Profiles of the focalized acoustic beams generated by the proposed transducer were theoretically analyzed. Based on the result of the analysis, relevant delay lines were fabricated and transfer functions (insertion loss) of the line were measured for SH₀ wave in YX-lithium niobate plate. Using an electron scanning microscope, distribution of the electric fields of the same wave were visualized. The results of this study may be useful for hybrid devices and sensors combining nano and acoustoelectronic principles. Full article

The optical vortex (OV) has drawn considerable attention owing to its tremendous advanced applications, such as optical communication, quantum entanglement, and on-chip detectors. However, traditional OV generators suffer from a bulky configuration and limited performance, especially in the ultraviolet range. In this paper, we utilize a large bandgap dielectric material, niobium pentoxide (Nb₂O₅), to construct ultra-thin and compact transmission-type metasurfaces to generate and detect the OV at a wavelength of 355 nm. The meta-atom, which operates as a miniature half-wave plate and demonstrates a large tolerance to fabrication error, manipulates the phase of an incident right-handed circular polarized wave with high cross-polarized conversion efficiency (around 86.9%). The phase delay of $\pi$ between the orthogonal electric field component is attributed to the anti-parallel magnetic dipoles induced in the nanobar. Besides, focused vortex generation (topological charge l from 1 to 3) and multichannel detection (l from −2 to 2) are demonstrated with high efficiency, up to 79.2%. We envision that our devices of high flexibility may have potential applications in high-performance micron-scale integrated ultraviolet nanophotonics and meta-optics. Full article

Self-stabilization quantum key distribution (QKD) systems are often based on the Faraday magneto-optic effect such as “plug and play” QKD systems and Faraday–Michelson QKD systems. In this article, we propose a new anti-quantum-channel disturbance decoder for QKD without magneto-optic devices, which can be a benefit for the photonic integration and applications in magnetic environments. The decoder is based on a quarter-wave plate reflector–Michelson (Q–M) interferometer, with which the QKD system can be free of polarization disturbance caused by quantum channel and optical devices in the system. The theoretical analysis indicates that the Q–M interferometer is immune to polarization-induced signal fading, where the operator of the Q–M interferometer corresponding to Pauli Matrix σ₂ makes it satisfy the anti-disturbance condition naturally. A Q–M interferometer based time-bin phase encoding QKD setup is demonstrated, and the experimental results show that the QKD setup works stably with a low quantum bit error rate about 1.3% for 10 h over 60.6 km standard telecommunication optical fiber. Full article
