A cascade control structure (CCS) is still the most commonly used control scheme in variable speed control (VSC) electrical drives with alternating current (AC) motors. Several tuning methods are used to select the coefficients of controllers applied in CCS. These approaches can be divided into analytical, empirical, and heuristic ones. Regardless of the tuning method used, there is still a question of whether the CCS is tuned optimally in terms of considered performance indicators to provide high-performance behavior of the electrical drive. Recently, artificial intelligence-based methods, e.g., swarm-based metaheuristic algorithms (SBMAs), have been extensively examined in this field, giving promising results. Moreover, the intensive development of artificial intelligence (AI) assistants based on large language models (LLMs) supporting decision-making processes is observed. Therefore, it is worth examining the ability of LLMs to tune the CCS in the VSC electrical drive. This paper investigates tuning methods for the cascade control structure equipped with PI-type current and angular velocity controllers for PMSM drive. Sets of CCS parameters from electrical engineers with different experiences are compared with reference solutions obtained by using the SBMA approach and LLMs. The novel LLM-based Tuning Assistant (TA) is developed and trained to improve the quality of responses. Obtained results are assessed regarding the drive performance, number of attempts, and time required to accomplish the considered task. A quantitative analysis of LLM-based solutions is also presented. The results indicate that AI-based tuning methods and the properly trained Tuning Assistant can significantly improve the performance of VSC electrical drives, while state-of-the-art LLMs do not guarantee high-performance drive operation. Full article

In extremely cold environments, when battery electric vehicles (BEVs) are navigating urban roads at low speeds, the limited heating capacity of the on-board heat pump system and positive temperature coefficient (PTC) device can lead to an inevitable decline in battery temperature, potentially falling below its permissible operating range. This situation can subsequently result in vehicle malfunctions and, in severe cases, traffic accidents. Henceforth, a novel battery self-heating method during driving is proposed to maintain battery temperature. This approach is ingeniously embedded within the heating mechanism within the motor driving system without any necessity to alter or modify the existing driving circuitry. In the meantime, the battery voltage can be regulated to prevent it from surpassing the limit, thereby ensuring the battery’s safety. This method introduces the dead zone into the space vector pulse width modulation (SVPWM) algorithm to form the newly proposed dSVPWM algorithm, which successfully changes the direction of the bus current in a PWM period and forms AC, and the amplitude of the battery alternating current (AC) can also be controlled by adjusting the heating intensity defined by the ratio of the dead zone and the compensation vector to the original zero vector. Through the Simulink model of the motor driving system, the temperature hysteresis locking strategy, grounded in the field-oriented control (FOC) method and employing the dSVPWM algorithm, has been confirmed to provide controllable and sufficiently stable motor speed regulation. During the low-speed phase of the China Light Vehicle Test Cycle (CLTC), the battery temperature fluctuation is meticulously maintained within a range of ±0.2 °C. The battery’s minimum temperature has been successfully locked at around −10 °C. In contrast, the battery temperature would decrease by a significant 1.44 °C per minute without the implementation of the temperature-locking strategy. The voltage of the battery pack is always regulated within the range of 255~378 V. It remains within the specified upper and lower thresholds. The battery voltage overrun can be effectively avoided. Full article

This article presents a suboptimal nonlinear control strategy to improve the dynamics of a three-phase alternating current (AC) motor. Using dynamic programming, the calculation of the Bellman function is avoided by determining a suboptimal control sequence that locally minimizes a quadratic performance index at each step. The motor’s fixed-frame nonlinear mathematical model controls the stator currents, rotor magnetic fluxes, and rotor angular speed by applying voltages to the stator. Experimental tests are conducted using a Delta VFD007EL11A variable frequency drive (VFD), demonstrating improved motor state behavior and performance compared to an optimal proportional integral (PI) control and a fixed reference input in the VFD. The experiments include set point changes and a comparative analysis of the energy consumption between both controllers considering two cases: free and with load on the motor shaft. Full article

An H-bridge inverter with LC (inductor-capacitor) filter output allows the conversion of DC (direct current) power to AC (alternating current) power that has been used in a variety of applications, such as uninterruptible power supplies, AC motor drives, and renewable energy source systems. The fast finite-time sliding mode control (FFTSMC) features acceleration of the system state towards the equilibrium position as well as conserving insensitivity against internal parameter fluctuations as well as external load disturbances falling within the predetermined bounds. However, the FFTSMC would potentially witness chattering or steady-state errors as indefinite margins come to be exaggerated or underestimated. The chattering in the sliding mode control practice is oscillatory defective behavior. It induces inefficient operation, higher switching power losses in the transistor circuits, as well as saturated actuators, thus impairing the inverter’s output energy efficiency and raising harmonic distortion. Therefore, this paper presents the H-bridge inverter with LC filter output, which is controlled by a grey prediction fast finite-time sliding mode trajectory tracking. A more highly accurate grey prediction model based on the centered approximation methodology is deployed to vanish the chattering as well as steady-state errors. Taking into account the union of grey prediction and FFTSMC, a feedback-controlled H-bridge inverter with LC filter output allows attaining a highly efficient as well as quality sine-wave output voltage. The presented state-feedback control strategy is robust, less complex, attains more rapid convergence, and is highly accurate. The design process, computer simulation, as well as experimental results of the proposed state-feedback control strategy established that the H-bridge inverter with LC filter output has the capability to exhibit fast dynamic response time as well as good steady-state tracking behavior of the output voltage under step-loading changes and nonlinear loading conditions. Full article

In addition to their conventional use in electric motor drives, DC-DC converters have a variety of other uses, such as energy storage, energy conversion, cyber security systems, uninterruptible power supplies, and renewable energy systems. An innovative DC-DC converter is suggested in this article. Designing a new, high-gain DC-DC converter scheme known as a double-switch SEPIC-buck converter (DSSB) is possible after making some adjustments to the SEPIC converter that is currently known in accordance with accepted techniques. The output voltage magnitude of the proposed converter is either larger than or less than the input voltage magnitude and is the same sign as the input voltage. According to the theoretical and analytical study that has been supported by the real-world application, high voltage gain, low switching stress, and low inductor current ripple are the main characteristics of the proposed DSSB converter. The related small-signal model was also used to build the closed-loop system. The frequency response and output voltage behavior were investigated when the input source voltage abruptly changed as a step function. Based on the comparison study with other DC-DC converters, the DSSB converter outperforms currently known DC-DC converters such as Buck, SEPIC, Boost, Buck-Boost, and other SEPIC converter topologies in terms of voltage gain, harmonic content, normalized current ripple, dynamic performance, and efficiency. Additionally, the frequency response and control of the proposed converter using an alternate current (AC), small-signal, analysis-based, current-mode control technique are both provided. Thus, the DSSB is regarded as safe in overcurrent situations because of the small-signal analysis with the current control strategy. As a result of the verification of the proposed control technique, the resistance to changes in the DSSB parameters, improved dynamic performance, and higher control accuracy are further advantages of current-mode control based on small-signal analysis over other control approaches (PI controllers). Finally, the experimental and simulation results from Simplorer 7 and MATLAB/Simulink are used to validate the findings of the analytical and comparative investigation. Full article

An analysis of the operating conditions of the traction drives of an electric rolling stock with asynchronous traction motors was conducted. In the process of operation, the electric traction drive with both direct torque control and vector control was found to possibly experience unstable modes, both in terms of power supply and load. The models of electric locomotive traction drives with asynchronous electric motors with either vector or direct torque control were adapted to account for the possible presence of the aforementioned operational factors. As a result of the modeling, the starting characteristics of the electric traction drives with different control systems were obtained both in the absence and in the presence of power supply and load disturbances. The following cases were investigated for the drive with vector and direct torque control in the absence of power supply and torque disturbances: drive output at the rated speed of rotation of the electric motor shaft; 10% reduction in the rated speed; 10% increase in the rated speed. The comparison of the results obtained has demonstrated that, at lower than nominal frequencies, the electric traction drive with direct torque control has higher accuracy in its regulation of the rotational speed and torque, lower power consumption from the power supply, lower torque overshooting, but a higher level of torque pulsations than the electric traction drive with vector control. Meanwhile, at higher than nominal frequencies, the vector control has higher accuracy in its regulation of the speed, lower torque overshooting, shorter duration of transient processes, and lower torque pulsations than the direct torque control. Moreover, as a result of the investigations, the traction drive with direct torque control has been found to be more resistant to power supply and load disturbances. The results of this work are applicable to the investigation of the influence of electric traction drive control methods on the energy efficiency of the traction drive of an electric locomotive with an alternating current (AC). Full article

Driving is a ubiquitous activity that requires both motor skills and cognitive focus. These aspects become more problematic for some seniors, who have underlining medical conditions and tend to lose some of these capabilities. Therefore, driving can be used as a controlled environment for the frequent, non-intrusive monitoring of bio-physical and cognitive status within drivers. Such information can then be utilized for enhanced assistive vehicle controls and/or driver health monitoring. In this paper, we present a novel multi-modal smart steering sleeve (S${}^3$) system with an integrated sensing platform that can non-intrusively and continuously measure a driver’s physiological signals, including electrodermal activity (EDA), electromyography (EMG), and hand pressure. The sensor suite was developed by combining low-cost interdigitated electrodes with a piezoresistive force sensor on a single, flexible polymer substrate. Comprehensive characterizations on the sensing modalities were performed with promising results demonstrated. The sweat-sensing unit (SSU) for EDA monitoring works under a 100 Hz alternative current (AC) source. The EMG signal acquired by the EMG-sensing unit (EMGSU) was amplified to within 5 V. The force-sensing unit (FSU) for hand pressure detection has a range of 25 N. This flexible sensor was mounted on an off-the-shelf steering wheel sleeve, making it an add-on system that can be installed on any existing vehicles for convenient and wide-coverage driver monitoring. A cloud-based communication scheme was developed for the ease of data collection and analysis. Sensing platform development, performance, and limitations, as well as other potential applications, are discussed in detail in this paper. Full article

In order to meet the safety requirements of automobile braking, to improve the braking energy recovery rate of pure electric buses and increase their driving range, the maximum regenerative braking force that the motor can provide is used to determine the front and rear wheel friction braking force distribution curve. A parallel regenerative braking control strategy, A, is proposed to make full use of the motor performance. Aiming at the problems of low power density and short cycle life with a single power battery, a composite energy system composed of power batteries and supercapacitors is designed, and an alternative energy control strategy, D, using real-time wavelet transform control is proposed. The required power is decomposed into high-frequency components and low-frequency components by using the wavelet transform control, in which the high-frequency power is borne by the supercapacitor to avoid impact on the power battery. The simulation model was created using MATLAB/Simulink software, and the simulation was carried out under combined cycle conditions to verify the effectiveness of the control strategy. The simulation results showed that compared with the original vehicle control strategy, adopting the A regenerative braking control strategy can reduce the battery SOC drop by 5.15%, increase the relative increase by 47.9%, and improve the braking energy recovery rate. Compared with the traditional logic threshold regenerative braking control strategy, AC, the AD control strategy can effectively reduce the impact of the peak current and high-frequency demands of the power battery on the battery. The maximum output current of the battery was reduced by 39.5%. The decrease in battery SOC decreased by 0.69%, and the relative increase increased by 12.43%. The driving range and braking performance of the vehicle have thus been effectively improved. Full article

The synchronous homopolar motor (SHM) with an excitation winding on the stator and a toothed rotor is a good alternative to traction induction motors for hybrid mining trucks. The main problem in the design of the SHM electric drives is that the magnetic flux forms three-dimensional loops and, as a result, the lack of high-quality optimization methods, which leads to the need to overrate the installed power of the inverter. This article discusses the procedure and results of optimization of a commercially available 370 kW traction SHM using the Nelder–Mead method. The objective function is composed to mainly improve the following characteristics of the traction SHM: total motor power loss and maximum armature winding current. In addition, terms are introduced into the objective function to make it possible to limit the voltage, the loss in the excitation winding, and the maximum magnetic flux density in the non-laminated sections of the magnetic core. As a result of the optimization, the motor losses and the maximum current required by the motor from the inverter were significantly reduced. The achieved reduction in the maximum current allows the cost of the IGBT modules of the inverter to be reduced by 1.4 times (by $ 2295), and also allows the AC component of the DC-link current to be reduced by the same amount. Full article

Developing effective tools and strategies to promote motor learning is a high-priority scientific and clinical goal. In particular, motor-related areas have been investigated as potential targets to facilitate motor learning by noninvasive brain stimulation (NIBS). In addition to shedding light on the relationship between motor function and oscillatory brain activity, transcranial alternating current stimulation (tACS), which can noninvasively entrain oscillatory brain activity and modulate oscillatory brain communication, has attracted attention as a possible technique to promote motor learning. This review focuses on the use of tACS to enhance motor learning through the manipulation of oscillatory brain activity and its potential clinical applications. We discuss a potential tACS–based approach to ameliorate motor deficits by correcting abnormal oscillatory brain activity and promoting appropriate oscillatory communication in patients after stroke or with Parkinson’s disease. Interpersonal tACS approaches to manipulate intra- and inter-brain communication may result in pro-social effects and could promote the teaching–learning process during rehabilitation sessions with a therapist. The approach of re-establishing oscillatory brain communication through tACS could be effective for motor recovery and might eventually drive the design of new neurorehabilitation approaches based on motor learning. Full article

The usage of BLDC motors in the low-power range is increasing rapidly in home appliances such as ceiling fans. This has necessitated the development of reliable, compact and efficient AC-DC power supplies for motor drive circuitry. This paper presents a power supply design consisting of an AC-DC isolated PFC Cuk converter with integrated magnetics that supplies a single-shunt voltage source inverter for the sensorless drive of the BLDC fan motor. The proposed power supply design is comprised of an integrated magnetics structure in which the two inductors and the transformer windings share the same core. The zero input and output ripple current conditions have been derived from the reluctance model of the magnetic assembly. Smooth operation of the motor by minimizing the motor torque ripples is evident from the results. The Cuk converter operates in continuous conduction mode (CCM), employing the current multiplier method. The CCM-based current multiplier control loop ensures a near-unity power factor as well as low total harmonic distortion in the supply current. The current loop also provides over-current protection, enhancing reliability of the system. Moreover, the speed of the BLDC motor is controlled by the field oriented control (FOC) algorithm, which enables direct operation with alternate energy sources such as batteries and solar photovoltaic panels. The performance of the proposed supply is validated: motor torque ripple is reduced to only 2.14% while maintaining 0.999 power factor and only 4.72% THD at full load. Failure modes analysis has also been performed through software simulations, using the PLECS simulation environment. Due to the reliable power supply design with low ripples, it is well suited for low-power BLDC motors in home appliances and small power tools, in addition to ceiling fans. Full article

In this paper, a stator inductance identification process is proposed. The process is based on a three-level neutral-point-clamped (NPC) inverter-fed induction motor (IM) drive with a standstill condition. Previously, a low-speed alternating current (AC) injection test for stator inductance identification was proposed to overcome practical problems in conventional identification methods for three-level NPC inverter-based IM drives. However, the low-speed AC injection test-based identification method has some problems if a heavy load or mechanical brake is connected, as these can forcibly bring the rotor to a standstill during parameter identification. Since this low-speed testing-based identification assumes the motor torque is considerably lower in low-speed operations, some inaccuracy is inevitable in this kind of standstill condition. In this paper, the proposed current injection speed generator is based on the previously studied low-speed test-based stator inductance identification method, but the proposed approach gives more accurate estimates under the aforementioned standstill conditions. The proposed method regulates the speed for sinusoidal low-frequency AC injection on the basis of the instantaneous reactive and air-gap active power ratio. This proposed stator inductance identification method is more accurate than conventional fixed low-frequency AC signal injection identification method for three-level NPC inverter-fed IM drive systems with a locked-rotor standstill condition. The proposed method’s accuracy and reliability were verified by simulation and experiment using an 18.5 kW induction motor. Full article

The modular multilevel matrix converter is a relatively new power converter topology suitable for high-power alternating current (AC)-to-AC applications. Several publications in the literature have highlighted the converter capabilities, such as full modularity, fault-redundancy, control flexibility and input/output power quality. However, the topology and control of this converter are relatively complex to realise, considering that the converter has a large number of power-cells and floating capacitors. To the best of the authors’ knowledge, there are no review papers where the applications of the modular multilevel matrix converter are discussed. Hence, this paper aims to provide a comprehensive review of the state-of-the-art of the modular multilevel matrix converter, focusing on implementation issues and applications. Guidelines to dimensioning the key components of this converter are described and compared to other modular multilevel topologies, highlighting the versatility and controllability of the converter in high-power applications. Additionally, the most popular applications for the modular multilevel matrix converter, such as wind turbines, grid connection and motor drives, are discussed based on analyses of simulation and experimental results. Finally, future trends and new opportunities for the use of the modular multilevel matrix converter in high-power AC-to-AC applications are identified. Full article

Due to its scalability, reliability, high power quality and flexibility, the modular multilevel converter is the standard solution for high-power high-voltage applications in which an AC–DC–AC connection is required such as high-voltage direct-current transmission systems. However, this converter presents some undesired features from both structural and operational perspectives. For example, it presents a high number of components, which results in high costs, size, weight and conduction losses. Moreover, the modular multilevel converter presents problems dealing with DC-side faults, with unbalanced grid conditions, and many internal control loops are required for its proper operation. In variable-frequency operation, the modular multilevel converter presents some serious limitations. The most critical are the high-voltage ripples, in the submodule capacitors, at low frequencies. Thus, many different AC–AC converter solutions, with modular multilevel structure, have been proposed as alternatives for high-power machine-drive applications such as offshore wind turbines, pumped-hydro-storage systems and industrial motor drives. These converters present their own drawbacks mostly related to control complexity, operational limitations, size and weight. This paper introduces an entirely new medium-voltage AC–AC modular multilevel converter solution with many operational and structural advantages in comparison to the modular multilevel converter and other alternative topologies. The proposed converter presents high performance at low frequencies, regarding the amplitude of the voltage ripples in the submodule capacitors, which could make it very suitable for machine-drive applications. In this paper, an analytical description of the voltage ripples in the submodule capacitors is proposed, which proves the high performance of the converter under low-frequency operation. Moreover, the proposed converter presents high performance under unbalanced grid conditions. This important feature is demonstrated through simulation results. The converter solution introduced in this paper has a simple structure, with decoupled phases, which leads to the absence of undesired circulating currents and to a straightforward control, with very few internal control loops for its proper operation, and with simple modulation. Since the converter phases are decoupled, no arm inductors are required, which contributes to the weight and size reduction of the topology. In this paper, a detailed comparison analysis with the modular multilevel converter is presented based on number of components, conduction and switching losses. This analysis concludes that the proposed converter solution presents a reduction in costs and an expressive reduction in size and weight, in comparison to the modular multilevel converter. Thus, it should be a promising solution for high-power machine-drive applications that require compactness and lightness such as offshore wind turbines. In this paper, simulation results are presented explaining the behavior of the proposed converter, proving that it is capable of synthesizing a high-power-quality load voltage, with variable frequency, while exchanging power with the grid. Thus, this topology could be used to control the machine speed in a machine-drive application. Finally, experimental results are provided to validate the topology. Full article

Owing to the benefits of programmable and parallel processing of the field programmable gate arrays (FPGAs), they have been widely used to the realization of digital controllers and motor drive systems. In this study, we adopt the FPGA chip to realize the Linear Shaft Motor (LSM) drive system which includes the position, speed and current vector controls. Linear shaft motor is a special motor which has the magnet as the shaft and stator coils are on the forcer. Thus, it reveals a small mechanical time constant. In addition, the electrical side can be looked as a general three-phase Alternating Current (AC) system which can be powered by inverter and vector control technique can be applied to the system. The designed system needs high performance calculation ability about position/speed control and vector current control loops. The mathematical model of linear shaft motor drive system is first built and simulated by MATLAB/Simulink and the accuracy about the effect from the speed estimation method is proposed. The resulting digital model of the drive system is stored into Verilog Hardware Description Language (Verilog HDL) codes and realized by FPGA. At last, the hardware circuits as well as the power module are used to test the performance of the developed hardware system in terms of the trapezoidal velocity profile. The experimental results show that the designed system realized by FPGA has attained the desired performance. Full article
