The thermoplastic composite pipe (TCP) manufacturing process introduces defects that impact performance, such as voids, misalignment, and delamination. Consequently, there is an increasing demand for effective non-destructive testing (NDT) techniques to assess the influence of these manufacturing defects on TCP. The objective is to identify and quantify internal defects at a microscale, thereby improving quality control. A combination of methods, including NDT, has been employed to achieve this goal. The density method is used to determine the void volume fraction. Microscopy and void analysis are performed on pristine samples using optical micrography and scanning electron microscopy (SEM), while advanced techniques like X-ray computer tomography (XCT) and ultrasonic inspections are also applied. The interlayer between the reinforced and inner layers showed good consolidation, though a discontinuity was noted. Microscopy results confirmed solid wall construction, with SEM aligning with the XY axis slice, showing predominant fibre orientation around ±45° and ±90°, and deducing the placement orientation to be ±60°. Comparing immersion, 2D microscopy, and XCT methods provided a comparative approach, even though they could not yield precise void content values. The analysis revealed a void content range of 0–2.2%, with good agreement between microscopy and Archimedes’ methods. Based on XCT and microscopy results, an increase in void diameter at constant volume increases elongation and reduces sphericity. Both methods also indicated that most voids constitute a minority of the total void fraction. To mitigate manufacturing defects, understanding the material’s processing window is essential, which can be achieved through comprehensive material characterization of TCP materials. Full article

Aligned discontinuous fibre-reinforced composites are becoming more popular because they have the potential to offer stiffness and strength comparable to their continuous counterparts along with better manufacturability. However, the modelling of highly aligned discontinuous fibre composites is still in its infancy. This paper aims to provide a comprehensive review of the available literature to understand how modelling techniques have developed and consider whether all aspects which could affect the performance of aligned discontinuous fibre composites have been addressed. Here, for the first time, a broad view of the advantages, perspectives, and limitations of current approaches to modelling the performance and behaviour of aligned discontinuous fibre composites during alignment, forming, and mechanical loading is provided in one place as a route to design optimisation. Full article

The aim of this research is to investigate basalt as a natural mineral-based fibre together with a vitrimeric resin as a sustainable alternative to standard composite materials. Vitrimers combine the properties of thermoset and thermoplastic polymers, enabling the repair of specimens and hence prolonging the lifetime of the composite material. The micro-mechanical characteristics between the basalt fibres and the vitrimer resin are reported and shown to match those of a standard Skyflex K51 epoxy resin. Discontinuous (4 mm) basalt fibres were employed to produce aligned discontinuous fibre-reinforced composites (ADFRCs) using the high-performance discontinuous fibre (HiPerDiF) technology. The mechanical characteristics of the laminates were investigated through tensile testing and the fracture zones were analysed under a scanning electron microscope. By normalising the results by their respective fibre volume fraction, it was discovered that the vitrimer–basalt ADFRCs exhibited, on average, a 4% higher strength and a 25% higher stiffness compared to their basalt epoxy counterparts. The repair potential of the vitrimer ADFRC specimens was explored during low-temperature compression repair. Two approaches were tested using double-sided local- and full-patch repair. Both successfully recovered a significant amount of their prime strength. In conclusion, the potential of the sustainable vitrimer–basalt composite is shown by its competitive mechanical performance. Combining this with the manufacturing flexibility, repair potential, and recyclability of the material, the vitrimer–basalt composite seems to be a competitive alternative to standard glass epoxies. Full article

The aim of this study was to characterise the microstructural organisation of staple carbon fibre-reinforced polymer composites and to investigate their mechanical properties. Conventionally, fibre-reinforced materials are manufactured using continuous fibres. However, discontinuous fibres are crucial for developing sustainable structural second-life applications. Specifically, aligning staple fibres into yarn or tape-like structures enables similar usage to continuous fibre-based products. Understanding the effects of fibre orientation, fibre length, and compaction on mechanical performance can facilitate the fibres’ use as standard engineering materials. This study employed methods ranging from microscale to macroscale, such as image analysis, X-ray computed tomography, and mechanical testing, to quantify the microstructural organisations resulting from different alignment processing methods. These results were compared with the results of mechanical tests to validate and comprehend the relationship between fibre alignment and strength. The results show a significant influence of alignment on fibre orientation distribution, fibre volume fraction, tortuosity, and mechanical properties. Furthermore, different characteristics of the staple fibre tapes were identified and attributed to kinematic effects during movement of the sliver alignment unit, resulting in varying tape thicknesses and fuzzy surfaces. Full article

DcAFF (discontinuous aligned fibre filament) is a novel material for fused filament fabrication (FFF) 3D printing made of highly aligned discontinuous fibres produced using high performance discontinuous fibre (HiPerDiF) technology. It reinforces a thermoplastic matrix to provide high mechanical performance and formability. Accurate printing of DcAFF poses a challenge, especially for complex geometries, because: (i) there is a discrepancy between the path where the filament experiences the adhering pressure from the filleted nozzle and the nozzle path; and (ii) the rasters display poor adhesion to the build platform immediately after deposition, which causes the filament to be dragged when the printing direction changes. This paper explains the implication of these phenomena on steering capabilities and examines the techniques for improving DcAFF printing accuracy. In the first approach, the machine parameters were adjusted to improve the quality of the sharp turning angle without changing the desired path, but this showed insignificant effects in terms of precision improvements. In the second approach, a printing path modification with a compensation algorithm was introduced. The nature of the inaccuracy of the printing at the turning point was studied with a first-order lag relationship. Then the equation to describe the deposition raster inaccuracy was determined. A proportional–integral (PI) controller was added to the equation to calculate the nozzle movement in order to bring the raster back to the desired path. The applied compensation path is shown to give an accuracy improvement in curvilinear printing paths. This is particularly beneficial when printing larger circular diameter curvilinear printed parts. The developed printing approach can be applied with other fibre reinforced filaments to achieve complex geometries. Full article

This paper explores the use of Discontinuous Aligned Fibre Filament (DcAFF), a novel discontinuous fibre reinforced thermoplastic filament for 3D printing, to produce structural complex parts. Compared to conventional composite manufacturing, 3D printing has great potential in steering fibres around small structural features. In this current study, the initial thin carbon fibre (CF)-poly(L-lactic acid) (PLA) tape, produced with the High Performance Discontinuous Fibre (HiPerDiF) technology, is now reshaped into a circular cross-section filament, the DcAFF, using a bespoke machine designed to be scalable to high production rates rather than using a labour-intensive manual moulding method as in previous work. The filaments are then fed to a general-purpose 3D printer. Tensile and open-hole tensile tests were considered in this paper for mechanical and processability of DcAFF. The 3D printed specimens fabricated with the DcAFF show superior tensile properties compared to other PLA-based 3D printed composites, even those containing continuous fibres. Curvilinear open-hole tensile test samples were fabricated to explore the processability and performances of such material in complex shapes. The mechanical performance of the produced specimens was benchmarked against conventionally laid-up specimens with a cut hole. Although the steered specimens produced have lower strength than the fully consolidated samples, the raster generated by the printing path has turned the failure mechanism of the composite from brittle to ductile. Full article

Discontinuous fibre reinforced composites enable the manufacture of integrated structural components via the complex flow process of compression moulding. However, such processes can lead to the formation of detrimental weld-lines. Here, the meso-structure of carbon fibre sheet moulding compounds (C-SMC) was analysed using conventional non-destructive techniques and automated eddy current (EC) scanning, as well as destructive methods, in an attempt to identify defects such as weld-lines in this class of materials. Compression-moulded plaques with forced weld-lines in two different configurations (adjacent and opposing flow joints) were analysed, showing up to 80% strength reduction versus a defect-free plaque. The EC-determined local fibre orientation and elucidated local microstructure matched those obtained using conventional techniques, showing a dramatic fibre tow alignment parallel to the weld-lines. It was found that failure occurred in proximity to the “non-uniformity” defect regions identified by EC analyses, demonstrating the use of robot-guided EC for successful defect detection in C-SMC structures. Full article

Composite waste is a growing issue due to the increased global demand for products manufactured from these advanced engineering materials. Current reclamation methods produce short length fibres that, if not realigned during remanufacture, result in low-value additives for non-structural applications. Consequently, to maximise the economic and functional potential, fibre realignment must occur. The High Performance Discontinuous Fibre (HiPerDiF) technology is a novel process that produces highly aligned discontinuous fibre-reinforced composites, which largely meet the structural performance of virgin fibres, but to date, the environmental performance of the machine is yet to be quantified. This study assessed the environmental impacts of the operation of the machine using life cycle assessment methodology. Electrical energy consumption accounts for the majority of the greenhouse gas emissions, with water consumption as the main contributor to ecosystem quality damage. Suggestions have been made to reduce energy demand and reuse the water in order to reduce the overall environmental impact. The hypothetical operation of the machine across different European countries was also examined to understand the impacts associated with bulk material transport and electricity from different energy sources. It was observed that the environmental impact showed an inverse correlation with the increased use of renewable sources for electricity generation due to a reduction in air pollutants from fossil fuel combustion. The analysis also revealed that significant reductions in environmental damage from material transport between the reclamation facility to the remanufacturing site should also be accounted for, and concluded that transportation routes predominantly via shipping have a lower environmental impact than road and rail haulage. This study is one of the first attempts to evaluate the environmental impact of this new technology at early conceptual development and to assess how it would operate in a European scenario. Full article

Sustainable fibre reinforced polymer composites have drawn significant attention in many industrial sectors as a means for overcoming issues with end-of-life regulations and other environmental concerns. Plant based natural fibres are considered to be the most suitable reinforcement for sustainable composites since they are typically from renewable resources, are cheap, and are biodegradable. In this study, a number of plant based natural fibres-curaua, flax, and jute fibres-are used to reinforce epoxy, poly(lactic acid) (PLA), and polypropylene (PP) matrices to form aligned discontinuous natural fibre reinforced composites (ADNFRC). The novel HiPerDiF (high performance discontinuous fibre) method is used to produce high performance ADNFRC. The tensile mechanical, fracture, and physical (density, porosity, water absorption, and fibre volume fraction) properties of these composites are reported. In terms of stiffness, epoxy and PP ADNFRC exhibit similar properties, but epoxy ADNFRC shows increased strength compared to PP ADNFRC. It was found that PLA ADNFRC had the poorest mechanical performance of the composites tested, due principally to the limits of the polymer matrix. Moreover, curaua, flax (French origin), and jute fibres are found to be promising reinforcements owing to their mechanical performance in epoxy and PP ADNFRC. However, only flax fibre with desirable fibre length is considered to be the best reinforcement constituent for future sustainable ADNFRC studies in terms of mechanical performance and current availability on the market, particularly for the UK and EU. Full article

In this work, aligned discontinuous fibre composite (ADFRC) tapes were developed and investigated as precursors for a novel 3D printing filament. ADFRCs have the potential to achieve mechanical performance comparable to continuous fibre reinforced composites, given sufficient fibre length and high level of alignment, and avoid many of the manufacturing difficulties associated with continuous fibres, e.g., wrinkling, bridging and corner radii constraints. Their potential use for fused filament fabrication (FFF) techniques was investigated here. An extensive down-selection process of thermoplastic matrices was performed, as matrix properties significantly impact both the processing and performance of the filament. This resulted in four candidate polymers (ABS, PLA, Nylon, PETG) which were used to manufacture ADFRC tapes with a V_f of 12.5% using the high performance discontinuous fibre (HiPerDiF) technology and an in-house developed continuous consolidation module. Tensile stiffness and strength up to 30 GPa and 400 MPa respectively were recorded, showing that a discontinuous fibre filament has the potential to compete with continuous fibre filaments. Full article

The composites industry generates considerable volumes of waste in a wide variety of forms, from the production of by-products to end-of-life parts. This paper focuses on the remanufacturing of dry fibre off-cuts, produced during the composite fabric weaving process, into highly aligned discontinuous fibre prepreg tapes with High Performance Discontinuous Fibre (HiPerDiF) technology. Unidirectional laminate specimens are prepared using various combinations of fibre lengths and tested in tension, obtaining a stiffness of 80 GPa, a strength of 800 MPa, and a failure strain of 1%. Several applications are envisaged for the produced tape: adhesive film, feedstock for filament winding, and tow for weaved fabrics. This work demonstrates the possibility to extract value from what is currently considered manufacturing waste. Full article

Growing environmental concerns and stringent waste-flow regulations make the development of sustainable composites a current industrial necessity. Natural fibre reinforcements are derived from renewable resources and are both cheap and biodegradable. When they are produced using eco-friendly, low hazard processes, then they can be considered as a sustainable source of fibrous reinforcement. Furthermore, their specific mechanical properties are comparable to commonly used, non-environmentally friendly glass-fibres. In this study, four types of abundant natural fibres (jute, kenaf, curaua, and flax) are investigated as naturally-derived constituents for high performance composites. Physical, thermal, and mechanical properties of the natural fibres are examined to evaluate their suitability as discontinuous reinforcements whilst also generating a database for material selection. Single fibre tensile and microbond tests were performed to obtain stiffness, strength, elongation, and interfacial shear strength of the fibres with an epoxy resin. Moreover, the critical fibre lengths of the natural fibres, which are important for defining the mechanical performances of discontinuous and short fibre composites, were calculated for the purpose of possible processing of highly aligned discontinuous fibres. This study is informative regarding the selection of the type and length of natural fibres for the subsequent production of discontinuous fibre composites. Full article

In order to increase the material throughput of aligned discontinuous fibre composites using technologies such as HiPerDiF, stability of the carbon fibres in an aqueous solution needs to be achieved. Subsequently, a range of surfactants, typically employed to disperse carbon-based materials, have been assessed to determine the most appropriate for use in this regard. The optimum stability of the discontinuous fibres was observed when using the anionic surfactant, sodium dodecylbenzene sulphonate, which was superior to a range of other non-ionic and anionic surfactants, and single-fibre fragmentation demonstrated that the employment of sodium dodecylbenzene sulphonate did not affect the interfacial adhesion between fibres. Rheometry was used to complement the study, to understand the potential mechanisms of the improved stability of discontinuous fibres in aqueous suspension, and it led to the understanding that the increased viscosity was a significant factor. For the shear rates employed, fibre deformation was neither expected nor observed. Full article

Conventional composite materials reinforced with continuous fibres display high specific strength but have a number of drawbacks including: the elastic-brittle behaviour, difficulties in producing defect-free components of complex shape with high-volume automated manufacturing processes, and inherent lack of recyclability. Highly aligned, discontinuous fibre-reinforced composites (ADFRCs) are truly beneficial for mass production applications, with the potential to offer better formability and comparable mechanical properties with continuous fibre-reinforced composites. In previous publications, the High Performance Discontinuous Fibre (HiPerDiF) technology has been shown to offer the possibility to intimately hybridise different types of fibres, to achieve pseudo-ductile tensile behaviour, and remanufacture reclaimed fibres into high-performance recycled composites. However, to date, the work has been conducted with unidirectional (UD) laminates, which is of limited interest in engineering applications with mechanical stresses acting across many directions; this paper reports, for the first time, the mechanical behaviour of quasi-isotropic (QI) ADFRCs. When compared with randomly-oriented discontinuous fibre composites (RODFRCs), QI ADFRCs offer enhanced stiffness (+26%) and strength (+77%) with higher consistency, i.e., a reduction of the coefficient of variance from the 25% of RODFRCs to the 6% of ADFRCs. Furthermore, hybrid QI ADFRCs retain the pseudo-ductility tensile behaviour previously observed in unidirectional (UD) lay-up. Full article

The feasibility of using the HiPerDiF (high performance discontinuous fibre) method to manufacture highly aligned discontinuous fibres intermingled hybrid composites with flax and reclaimed carbon fibres (rCF), and the potential benefits of so doing, are investigated in this paper. It is demonstrated that, despite their hydrophilic nature, flax fibres are not affected by this water-based process. Intermingled flax/rCF hybrid composites are characterised in terms of their tensile and vibrational response. It is concluded that natural/rCF fibre hybrid composites can be a viable solution for those applications where a reduction in primary mechanical properties, e.g., stiffness and strength, is an acceptable trade-off for the enhancement of secondary properties, e.g., noise, vibration, and harshness (NVH) mitigation, and the reduction of monetary costs. Full article
