This study proposes a novel drone-based semi-airborne total-field magnetometric resistivity (SA-TFMMR) system for high-resolution detection of conductive fracture zones in geologically hazardous terrains. The system integrates a high-power, low-frequency grounded-wire transmitter with a drone-mounted total-field magnetometer, achieving high survey efficiency and extensive data coverage in mountainous areas. We develop a 3D inversion framework incorporating terrain-adaptive depth weighting, which successfully images a dipping water-saturated fracture zone model beneath a reservoir overburden at a tunnel water gushing accident site. Sensitivity analyses of SA-TFMMR reveal that the effectiveness of detection is controlled by the source-target coupling and the orientation of the target body with respect to the geomagnetic field. Optimal current injection along target strike directions amplifies magnetic anomalies, and orthogonal multi-source configurations can enhance imaging resolution. This UAV-geophysical integration provides a paradigm for pre-disaster monitoring of water-related geohazards. Full article

The Dongzhongla deposit is a skarn-type lead–zinc ore deposit located in the eastern segment of the Gangdese metallogenic belt, situated in the Xizang province, China. The high-altitude mountainous terrain of the region poses significant challenges to ground-based exploration. To facilitate more accurate mineral exploration in the deposit and its surrounding area, a high-resolution airborne magnetic survey was conducted over the mining area and its periphery. The airborne magnetic data were processed using derivative and Euler deconvolution methods, yielding results that reflect the geological structural features of the study area. By integrating the geological characteristics of the ore deposit, we inferred that the areas of magnetic anomaly extensions and the peripheries of other magnetic anomalies are favorable zones for mineralization, providing positive leads for further mineral exploration. Full article

The exploration of porphyry deposits in Greenland has become increasingly important due to their significant economic potential. We utilized total magnetic intensity (TMI) and mobile magnetotelluric (MobileMT) airborne data to delineate potential porphyry mineralization zones. The TMI method was employed to map variations in the Earth’s magnetic field caused by subsurface geological features, including mineral deposits. By analyzing anomalies in TMI data, potential porphyry targets were identified based on characteristic magnetic signatures associated with mineralized zones. Complementing TMI data, MT airborne surveys provided valuable insights into the electrical conductivity structure of the subsurface. Porphyry deposits exhibited distinct conductivity signatures due to the presence of disseminated sulfide minerals, aiding in their identification and delineation. Integration of the TMI and MobileMT datasets allowed for a comprehensive assessment of porphyry exploration targets in Flammefjeld. The combined approach facilitates the identification of prospective areas with enhanced geological potential, optimizing resource allocation and exploration efforts. Overall, this study demonstrates the efficacy of integrating TMI and MobileMT airborne data for porphyry exploration in Greenland, offering valuable insights for mineral exploration and resource development in the region. Full article

Global demand for critical raw materials, including phosphorus (P) and rare earth elements (REEs), is on the rise. The south part of Norway, with a particular focus on the Southern Oslo Rift region, is a promising reservoir of Fe-Ti-P-REE resources associated with magmatic systems. Confronting challenges in mineral exploration within these systems, notably the absence of alteration haloes and distal footprints, we have explored alternative methodologies. In this study, we combine machine learning with geological expertise, aiming to identify prospective areas for critical metal prospecting. Our workflow involves processing over 400 rock samples to create training datasets for mineralization and non-mineralization, employing an intuitive sampling strategy to overcome an imbalanced sample ratio. Additionally, we convert airborne magnetic, radiometric, and topographic maps into machine learning-friendly features, with a keen focus on incorporating domain knowledge into these data preparations. Within a binary classification framework, we evaluate two commonly used classifiers: a random forest (RF) and support vector machine (SVM). Our analysis shows that the RF model outperforms the SVM model. The RF model generates a predictive map, identifying approximately 0.3% of the study area as promising for mineralization. These findings align with legacy data and field visits, supporting the map’s potential to guide future surveys. Full article

Graphite is considered to be one of Europe’s most critical minerals. It is necessary for the transition from hydrocarbon fuel to electricity due to its use in batteries that power electronic devices and electric transport. In the past, high-quality exposed graphite was found in Norway without today’s advanced geophysical and geological methods. Norway is a key destination in Europe for graphite production. With an increasing demand for graphite, there have been efforts to systematically survey the country using modern geophysical and geological methods to find hidden graphite deposits. Among the various geophysical survey methods, electrical and electromagnetic (EM) methods are the first choice for the exploration of graphite due to the material’s high electrical conductivity. Airborne surveys are often used to cover a large area for a regional reconnaissance survey to locate the sites with potential mineral deposits before performing ground geophysical and geological surveys. Therefore, frequency-domain helicopter EM (HEM) and airborne magnetic surveys were performed in Northern Norway to locate interesting anomalies which were followed by ground surveys such as electrical resistivity tomography (ERT), charged-potential (CP), self-potential (SP), ground EM, and geological surveys. Some locations were also investigated with drilling and petrophysical core-sample analysis. In this paper, we present helicopter EM and magnetic data, 3D inversion of HEM data, and a successful ground follow-up survey result from the Vesterålen district in Northern Norway. The HEM survey identified previously known and new graphite occurrences, both partially exposed or buried, which were confirmed using ground surveys, drilling, and laboratory analysis of the samples. Full article

This investigation establishes an integrated method for rare earth elements (REE) exploration through a very promising and advanced exploration prospect in the Alces Lake area (SK, Canada) by assessing the integrated analysis of several multisource geophysical datasets. The resulting outcome provides important lithostructural information to the well-exposed, mineralized middle-to-lower crust at Alces Lake, comprising deep-seated poly-phase folds, ductile shear zones, and brittle faults. Geophysical–geological models of the Alces Lake property were constructed at different scales. The area of interest is located within the Beaverlodge Domain, about 28 km north of the Athabasca Basin’s northern margin. It contains some of the highest-grade rare earth elements (REE) in the world with the REE hosted predominantly in monazites within quartzo-feldspathic granitic to biotite–garnet–monazite–zircon-rich restite-bearing/cumulate mush melt pegmatites of anatectic origin (abyssal). Geophysical magnetic, gravity, and radiometric data were used together with Shuttle Radar Topography Mission (SRTM) images to facilitate the processing, modeling, and interpretation. Consequently, major structures were identified at different scales; however, the emphasis was given to studying those at the district/camp scale. The REE zones discovered to date occur within a large district-scale refolded synformal anticline. The eastern limb of this folded structure comprises a 30–40 km long, NW-trending shear zone/fault corridor with deep-seated structural crustal roots that may have served as the major pathway for ascending fluids/melts and facilitated the emplacement of mineralization. Thus, shear zones, faults, and folds in combination with lithological contacts/rheological contrasts appear to control residual/cumulate pegmatite emplacement and monazite deposition. Anomalies obtained from the airborne equivalent thorium survey data prove to be the most useful for REE pegmatite exploration. The results herein provide new interpretation and modeling perspectives leading to a better understanding of the distribution and lithostructural controls of REE on the property, and to new guidelines for future exploration programs at Alces Lake and elsewhere in northern Saskatchewan. Full article

The Princess Elizabeth Land landscape in East Antarctica was shaped by a complex process, involving the supercontinent’s breakup and convergence cycle. However, the lack of geological knowledge about the subglacial bedrock has made it challenging to understand this process. Our study aimed to investigate the structural characteristics of the subglacial bedrock in the Mount Brown region, utilizing airborne geophysical data collected from the China Antarctic Scientific Expedition in 2015–2017. We reconstructed bedrock density contrast and magnetic susceptibility models by leveraging Tikhonov regularized gravity and magnetic inversions. The deep bedrock in the inland direction exhibited different physical properties, indicating the presence of distinct basement sources. The east–west discontinuity of bedrock changed in the inland areas, suggesting the possibility of large fault structures or amalgamation belts. We also identified several normal faults in the western sedimentary basin, intersected by the southwest section of these survey lines. Furthermore, lithologic separators and sinistral strike-slip faults may exist in the northeast section, demarcating the boundary between Princess Elizabeth Land and Knox Valley. Our study provides new insights into the subglacial geological structure in this region, highlighting the violent impact of the I-A-A-S (Indo-Australo-Antarctic Suture) on the subglacial basement composition. Additionally, by identifying and describing different bedrock types, our study redefines the potential contribution of this region to the paleocontinent splicing process and East Antarctic basement remodeling. Full article

Airborne geophysical surveys serve as an effective tool for litho-structural mapping, providing extensive and high-resolution underground information. They offer vital data support for the interpretation and analysis of lithologies and structures, complementing surface geological mapping. In the study area of the Nanpanjiang-Youjiang metallogenic belt in southeast China, we obtained high-resolution aeromagnetic and gamma-ray spectrometry data covering an area of approximately 27,000 km², which facilitated the conduct of litho-structural mapping. The total magnetic intensity, reduction to the pole, and directional derivative maps generated from the aeromagnetic data, efficiently identified concealed rocks and faults. Additionally, the total count, potassium, thorium to potassium ratio, and ternary maps generated from the airborne gamma-ray spectrometry data demonstrated advantages in distinguishing carbonate rocks from clastic rocks. They also provided more comprehensive geological information, refining the structural strike and location interpreted by the aeromagnetic data. The litho-structural map produced in this study significantly contributes to our understanding of the structures in the Nanpanjiang area and offers valuable guidance for successful mineral exploration endeavors. Full article

Orphaned oil and gas wells represent an important environmental and economic development concern in areas where historical energy exploration and production activity pre-dated regulations on well abandonment documentation practices. From an economic development perspective, these wells pose a subsurface risk to infrastructure development, while the environmental impact of orphaned wells is largely associated with uncontrolled emissions of both fluids and gasses, most notably atmospheric methane. Often neglected in regulatory oversight, methane emissions from orphaned wells contribute to global greenhouse gas concentrations and without proper mitigation, these emissions contribute to and further exacerbate global climate change processes. An inherent challenge of remediation efforts targeting orphaned wells is the consistent observation that only a fraction of located and identified wells produce the majority of methane emissions, yet no methodology exists to effectively separate out heavy emitters without visiting and assessing each and every well. We demonstrate that emitting wells have certain defined characteristics largely pertaining to the presence and integrity of metal casing to the surface, which can be distinguished as an organized high intensity magnetic anomaly in low-altitude UAV-based aeromagnetic surveys. In this paper, we present a database of identified and ground-truthed wellsites correlated to their magnetic signatures and provide a roadmap to initial prioritization of wellsites for subsequent remediation activities that can be implemented in complex environments where other survey options are not feasible. In a regulatory environment where resources dedicated to wellsite remediation are limited, we propose implementing this methodology as a key element of a targeted approach to wellsite prioritization for subsequent remediation activity. Full article

UAVs represent a tremendous opportunity to perform geophysical and repeated experiments, particularly in volcanic contexts. Their ability to be deployed rapidly and fly at various altitudes and the fact that they are easy to operate despite complex field conditions make them attractive for magnetic surveys. Detailed maps of the magnetic field in turn bring key constraints on the rocks’ composition, thermal anomalies, intrusive systems, and crustal contrast evolution. Yet, raw magnetic field measurements require careful processing to minimize directional, positional, and crossover errors. Moreover, stitching together adjacent or overlapping surveys acquired at different times and altitudes is not a trivial task. Therefore, it is challenging in remote areas to directly evaluate the consistency of a survey and to ascertain the success of the field mission. In this paper, we present a fast algorithm allowing for a quick-look modeling of scalar magnetic intensity measurements. The approach relies on rectangular harmonic analysis (RHA). The field measurements are automatically corrected for a global main field. Then, they are projected along this main field and modeled in terms of RHA functions. The software can exploit the quality indices provided with data and a procedure is applied to mitigate the effect of outliers. Maps for the scalar and the vector anomaly fields are readily built on an interpolated regular grid leveled at a constant altitude. In order to assess the modeling and the inversion procedures, analyses are carried out with synthetic measurements derived from a high-resolution global lithospheric magnetic field model estimated on the French aeromagnetic grid and at UAV locations with some added nonrandom noise. These analyses indicate that RHA is efficient for first-order and direct mapping of the crustal magnetic field structures measured by UAVs but that it could be applied on airborne and marine magnetic intensity data covering dense and large geographical extensions. Full article

In recent years, the development of airborne magnetic survey technology based on unmanned aerial vehicles (UAVs) has been rapidly advancing. The commonly used systems are the fixed-wing UAV-based, multi-rotors UAV-based, and unmanned helicopters-based magnetic survey systems. And, a type of hybrid UAV that uses a vertical takeoff and landing (VTOL) and fixed-wing cruise mode is increasingly being used to carry airborne magnetic survey systems. To meet the requirements of most UAVs for small-sized and lightweight payloads, a miniature magnetic survey system was developed and integrated into a hybrid fixed-wing UAV and formed an aeromagnetic survey system. And, a peripheral mineral exploration test was conducted in a known porphyry copper–gold deposit in southeastern China using the system. By processing the collected magnetic data with 3D inversion of susceptibilities, potential ore-bearing intrusive rocks were quickly identified and delineated, providing clues for peripheral mineral exploration in the mining area. Full article

On the basis of elaborating on the regional geological background, this paper analyzes the lithological and sedimentary characteristics and explorative prospects of new strata with oil and gas in the southern and surrounding areas of Dayangshu Basin. Based on the latest high-precision airborne gravity and magnetic comprehensive survey data, combined with the latest data from geological explorations, physical surveys, and drilling, and the use of basin structure layering combination methods, we clarified the characteristics of the bottom of the Jurassic–Cretaceous and the occurrence characteristics of the Upper Paleozoic in the study area and revealed the determinative effect of multi-period structures on the most important sedimentary layers. Then, we summarized the accumulation conditions and prediction methods of hydrocarbons and proposed the oil and gas prospects of these deep new strata. The results show that the Liuhe Sag in Dayangshu Basin, the depression in the northeast of Longjiang Basin, and the northern parts of the Taikang swell have good source–reservoir–cap combination conditions and favorable structural characteristics for oil and gas, where there is a high potential for exploration. Full article

Full 3D inversion of time-domain Airborne ElectroMagnetic (AEM) data requires specialists’ expertise and a tremendous amount of computational resources, not readily available to everyone. Consequently, quasi-2D/3D inversion methods are prevailing, using a much faster but approximate (1D) forward model. We propose an appraisal tool that indicates zones in the inversion model that are not in agreement with the multidimensional data and therefore, should not be interpreted quantitatively. The image appraisal relies on multidimensional forward modeling to compute a so-called normalized gradient. Large values in that gradient indicate model parameters that do not fit the true multidimensionality of the observed data well and should not be interpreted quantitatively. An alternative approach is proposed to account for imperfect forward modeling, such that the appraisal tool is computationally inexpensive. The method is demonstrated on an AEM survey in a salinization context, revealing possible problematic zones in the estimated fresh–saltwater interface. Full article

With the rapid development of unmanned aerial vehicles (UAVs) technology, using UAVs for magnetic surveys is a booming branch. However, the magnetic interference generated by the UAV hinders the further application of UAV magnetic survey systems. In addition to the interference caused by the UAV maneuvering, the dynamic interference of airborne equipment has also been found and become one of the factors restricted by the detection accuracy of magnetic surveys. This paper proposes a multi-source two-channel linear time-invariant (MTLI) correlation model, considering the maneuvering magnetic interference and airborne equipment magnetic interference. The magnetic interference can be estimated and compensated by interference correlation without current sensors. Compared with the traditional aeromagnetic compensation process and other compensation methods considering the magnetic interference of airborne equipment, the proposed method can provide stable compensation effects in maneuvers and smooth flight, and the workflow is simple and fast. The actual flight experiment is conducted, and the results show that the two kinds of UAV interference fields are suppressed significantly with a root mean square error of 0.0062 and 0.0296 nT in smooth flight and maneuvering flight. Full article

Investigating deserted medieval castles and villages in remote rural areas paired with a scarcity of meaningful written sources is a challenging task that can be significantly enhanced by the use of non-invasive archaeological prospection methods. Furthermore, the interpolation of stratigraphic relationships among maps by analysing paths and field boundaries, as performed by Klaus Schwarz in the 1980s, can also contribute significantly. Thus, in order to resolve numerous unanswered questions, a multidisciplinary approach is required. In this paper we present preliminary archaeological prospection data using magnetics and airborne laser scanning (ALS) as well as methodological considerations on the systematic analysis of historical maps on the site of Dernberg, a medieval motte-and-bailey castle with an adjoining deserted village. The magnetic data and corresponding aerial images, although not providing decisive information on internal structures, show several historical roads that allow for the localisation of the village at the foot of the castle hill, as well as other pathways and defensive structures. Data derived from laser scanning surveys carried out by uncrewed aerial vehicles, respectively, drone flights allow for a significant gain in information compared to publicly available ALS data. In a methodological discussion on the systematic analysis of historical maps, the site of Dernberg is used to illustrate not only how such an analysis can determine chronological sequences with respect to the pattern of former agricultural field systems and road networks, but that these assumptions can be confirmed in part by geophysical surveys. Full article
