This study investigates the influence mechanism of key factors on the heating value of syngas during underground coal gasification (UCG) and proposes an optimization path for enhanced energy conversion efficiency based on typical global field test data. Integrating data review and pattern analysis, it systematically explores the influence of core factors, including coal seam characteristics, reactor structure, and gasification agent ratio. It is found that the relationship between syngas heating value and coal rank is not simply linear, with representative heating values ranging from 4.13 to 11.96 MJ/m³. Medium-rank coal, characterized by “medium volatile matter and low ash content”, yields high-heating-value syngas when paired with air/steam as the gasification agent. Shaftless reactor structures demonstrate superior overall performance compared to shaft-based designs, with the representative heating value improving from 3.83 MJ/m³ to 7.8 MJ/m³. The combination of U-shaped horizontal wells with the Controlled Retracting Injection Point (CRIP) technology improves the heating value. Effective control over the syngas heating value can be achieved by optimized composition and ratio of the gasification agent, with representative value of 9.10 MJ/m³ in oxygen-enriched steam gasification compared to 4.28 MJ/m³ in air gasification. Based on an evaluation of data fluctuation characteristics, the significance ranking of the factors is as follows: gasification agent, coal rank, and reactor structure. Consequently, an engineering optimization path for enhancing UCG syngas heating value is proposed: prioritize optimizing the composition and ratio of the gasification agent as the primary means of heating value control; on this basis, rationally select coal rank resources, focusing on process compatibility to mitigate performance fluctuations; and then incorporate advanced reactor structures to construct a synergistic and efficient gasification system. This research can provide theoretical support and data references for engineering site selection, process design, and operational control of UCG projects. Full article

With the increase in urban cableization rate and cable length, the overvoltage problem caused by the capacitive effect becomes more and more serious. To limit overvoltage and achieve regional reactive power balance, shunt reactors are installed in substations. Based on a series of previous research, a type of superconducting toroidal air-core reactor is presented in this paper. The aim is to improve the power density of reactive power compensation and reduce magnetic leakage and noise pollution. In this paper, the structural optimized design of a 10 kV/1 MVar reactor is carried out based on COMSOL and MATLAB. In consideration of the usage of high-temperature superconducting tapes and AC loss of the reactor, combined with critical current, this paper uses corresponding finite element method (FEM) models and the optimal solution set is obtained via multi-objective genetic algorithm (MOGA). Finally, the solutions are analyzed economically and the set of solutions with the lowest cost is obtained, which provides a reference for the actual fabrication of a toroidal reactor in Shanghai, and can be used in the design of superconducting reactors at higher voltage levels. Full article

The High Temperature Gas-cooled Reactor (HTGR) is a Generation IV advanced nuclear reactor, which can realize inherent safety and prevent core melt. The Institute of Nuclear and New Energy Technology (INET) of Tsinghua University developed a commercial-scale 200 MWe High Temperature gas-cooled Reactor Pebble bed Module project (HTR-PM), which entered commercial operation on 6 December 2023. A passive Reactor Cavity Cooling System (RCCS) was designed for HTR-PM to export heat from the reactor cavity during normal operation and also in accident conditions, keeping the safety of the reactor pressure vessel (RPV) and reactor cavity. The RCCS of HTR-PM has been designed as three independent sets; the normal operation of two sets of RCCS can guarantee the safety of the PRV and reactor activity. The heat can be transferred from the RPV to the final heat sink atmosphere through thermal radiation and natural convection in the reactor cavity, and the natural circulation of water and air in the RCCS. The CAVCO code was developed by the INET to simulate the behavior of an RCCS. In this paper, assuming different RPV temperatures and different ambient temperatures, as well as assuming all or parts of the RCCS sets work, the performances of RCCS are studied by CAVCO to evaluate its operational reliability, so as to provide a reference for further optimization. The analysis results indicate that even under hypothetically extremely RPV temperatures, two sets of RCCS could effectively remove heat without causing water boiling or system failure. However, during the winter when ambient temperatures are low, particularly when the reactor operates at a lower RPV temperature, additional attention must be given to the operational safety of the system. It is crucial to prevent system failure caused by the freezing of circulating water and the potential cracking of water-cooling pipes due to freezing. Depending on the reactor status and ambient conditions, one or all three sets of RCCS may need to be taken offline. In addition, the maximum heat removal capacity of the RCCS with only two sets operational exceeds the design requirement of 1.2 MW. When the ambient temperature fluctuates significantly, it may be advisable to increase the number of available RCCS sets to mitigate the effect of abrupt changes in cooling water temperature on pipeline thermal stress. Full article

Dry-type air-core reactors (DAR) are critical components in power systems but are prone to inter-turn short circuit faults which interrupt the symmetry of the winding structure. Inspired by the online detection of transformer winding deformation, the V-I method has been adapted to diagnose short circuit faults in reactors. However, the diagnostic criteria and thresholds of V-I method remain unclear. This paper presents a novel method for determining the threshold for detecting inter-turn short circuit faults in DAR, integrating V-I analysis with machine learning techniques. Specifically, Gradient Boosting Regression (GBR) is used to compute a standard diagnostic criterion value, and curve fitting is also used to define the threshold for identifying inter-turn short circuit faults. The experimental results demonstrate that this method effectively identifies fault conditions in DAR. Full article

Dry-type air-core reactors (DARs) often have inter-turn short circuit (ITSC) faults. However, traditional fault detection methods for DARs generally demonstrate poor timeliness and low sensitivity, and few methods combine intelligent algorithms for objective and accurate diagnosis. Therefore, a novel online diagnosis method for ITSC faults was proposed. First, the “field-circuit” coupling 2D model of reactors was established to simulate the impact of ITSC faults on the characteristics of various state parameters; accordingly, the Lissajous graph was introduced to characterize the short circuit fault. Then, the variation law of the Lissajous graph under different inter-turn fault layers, turns, and degrees was explored to verify the feasibilities of the proposed method. Finally, to achieve rapid diagnosis and fulfill the requirements of edge computing, a lightweight network model named MobileNetV3-Small was used and combined as a classifier to achieve accurate diagnosis of ITSC faults. The results robustly validate that the Lissajous graphical method can significantly reflect ITSC faults through observing the variation in the graph and feature parameters. Furthermore, the MobileNetV3-Small model achieves a diagnostic accuracy of up to 95.91%, which can further enhance the diagnostic accuracy of the ITSC fault degree. Full article

In order to avoid overheating of a BLDC permanent magnet (PM) motor at high speeds, this paper focuses on the loss reduction of a 90 W 47,000 r/min BLDC hollow-cup motor. It is proposed to provide an optimizing method for the series reactors and the parameterization of reactors in the motor system. The finite element method (FEM) is used to calculate and analyze the time harmonic of air-gap magnetic flux density, stator core loss, and rotor eddy current loss in two cases: with a series reactor and without a reactor. By parameterizing the inductance value, the optimal resistance value is determined to minimize motor loss. In addition, an electromagnetic–thermal coupling analysis is conducted, and the results show that the temperature distribution of the stator core, winding, and rotor are improved under reactor suppression. Finally, an experimental platform is built to verify the temperature increase and the efficiency of the motor load operation. A clear reference for the research and optimization analysis of motor loss reduction is provided. Full article

Preventing severe corrosion incidents caused by air ingress accidents in high-temperature gas-cooled reactors (HTGRs) while improving heat removal efficiency from the core is of paramount importance. To enhance both safety and efficiency, a sleeveless silicon carbide (SiC)-matrix fuel compact has been proposed. This study evaluates the 10-hour oxidation of reaction-sintered SiC (RS-SiC)-matrix fuel compact under the conditions of an air ingress accident within the temperature range of 1000 to 1400 °C. The oxidation tests were conducted in a stagnant air environment without flow. As a result, it is demonstrated that RS-SiC exhibits exceptional resistance to air oxidation up to 1400 °C, as shown by the thermogravimetric analysis (TGA), with minimal mass loss due to the oxidation of free carbon. Scanning electron microscopy with energy-dispersive X-Ray spectroscopy (SEM–EDX) analysis reveals that the morphology and thickness of the SiO₂ layer formed on the RS-SiC surface vary with temperature. At 1400 °C, uniform oxide layer thickness ranging from 1.59 to 4.10 μm and localized nodule-like oxide formations of approximately 10 μm are observed. In contrast, at 1000–1200 °C, thinner oxide layers are identified, indicating that oxide growth accelerates at higher temperatures. The oxidation rates measured provide insights into the mechanisms of oxide growth. Full article

The application of air-core reactors in power systems is extensive and primarily aimed at enhancing system stability, limiting short-circuit currents, and providing reactive power compensation. Currently, the type most commonly used in power systems is the cylindrical-shaped air-core reactor (CAR), known for its stable mechanical structure and mature manufacturing process. However, the external magnetic field generated by this reactor propagates over a considerable distance in the air, which can interfere with the normal operation of many power electronic devices. This paper presents a comparative analysis between a novel annular-shaped air-core bridge arm reactor (AABAR) and the widely used cylindrical-shaped air-core bridge arm reactor (CABAR) within a DC transformer system. The comparison focuses on the magnetic field distribution, including magnetic flux density, magnetic field radiation range, and magnetic field energy, as well as the attenuation characteristics of these physical quantities. The concept of magnetic clearance (MC) is introduced as a quantitative metric. Through finite element simulation software (AEDT 2021 R1), it is demonstrated that the annular-shaped air-core reactor design can significantly improve spatial utilization and reduce the actual usage space of the reactors in DC transformer systems. Full article

Dry-type air-core shunt reactors are integral components in power transmission and distribution networks, designed to control reactive power and enhance system stability. However, inter-turn short-circuit faults (ISCFs) are common occurrences in shunt reactors, which are caused by various factors, including manufacturing defects, insulation degradation, or operational stresses. At the early stage of the ISCFs, the current does not reach a sufficient level to activate the protective equipment. These faults may lead to serious consequences, such as overheating, insulation breakdown, and even catastrophic failures, posing risks to the entire power system. Therefore, developing an effective and reliable detection method for ISCFs at the early stage is paramount. In this paper, a new method named the fault detection factor (FDF) based on equivalent resistance is presented to detect the slight ISCFs in dry-type air-core shunt reactors considering insulation resistance. In addition, the effect of noise signal existence in the monitoring process is taken into account. A moving average filter is adopted to guarantee both the sensitivity and the reliability of the proposed method. Ultimately, the simulation results of the FDF under different conditions are presented, which show the effectiveness and potential of the proposed method in observing and monitoring slight ISCFs. Full article

A reactor is an important piece of equipment used for reactive power compensation in power system and has a significant impact on the safe operation of power system. Thermal behavior is one of the main causes of reactor failures. For an accurate analysis of the thermal behavior of reactors, electromagnetic–thermal–fluid multi-physics coupling modeling is chosen. However, there is a huge difference in size between the overall structure of the reactor and its insulating material, which makes it difficult to perform mesh generation, resulting in dense mesh and significantly increased solution degrees of freedom, thus making the solution of the reactor’s multi-physics field model very time-consuming. To address this, this paper proposes a simplified processing method to accelerate the solution calculation of the reactor’s multi-physics model. This method calculates the equivalent turns of each encapsulate with parallel coils in the reactor, simplifying the encapsulate into a single-layer coil, thereby greatly reducing the division and solution degrees of freedom of the multi-physics model, and thus accelerating the simulation calculation. Taking a BKDCKL-20000/35 dry-type air-core shunt reactor as an example, the outer diameter of the coil is nearly 12,000 times bigger than the coil insulation, which is a huge size difference. Both refined models and simplified models are established. Compared to the simulation results of the detailed model, the simplified model demonstrates good accuracy; the maximum relative error of temperature is just 2.19%. Meanwhile, the computational time of the simplified model is reduced by 35.7%, which shows promising effectiveness and significant potential for applying the optimization design and operation prediction of dry-type air-core shunt reactors for enhanced thermal performance. Full article

Series iron core reactors are one of the most commonly used electrical equipments in power systems, which can limit short-circuit currents and suppress harmonic waves from capacitor banks. However, the vibration of the reactor will not only generate noise pollution but also diminish the service life of the reactor and jeopardize power system safety. In order to reduce the vibration noise in the core disc region of the reactor, the vibration characteristics of a core reactor are calculated by modifying the anisotropy parameters of the Young’s modulus of the core disc lamellar structure and introducing the core magnetostriction effect based on the simulation analysis method of electromagnetic and mechanical coupling. A detachable single-phase series core reactor model is established, and the validity of the simulation calculation is measured and verified. At the same time, from the perspective of improving the air gap size of the series core reactor and the arrangement of electrical steel sheets, the corresponding iron core vibration reduction scheme is given. The average vibration reduction in the reactor is about 11.6% after comprehensive improvement according to the vibration reduction scheme, which provides an effective method for realizing the vibration and noise reduction in the reactor. Full article

Numerical simulations of atmospheric dispersion and dose assessment were performed for the Jordan Research and Training Reactor (JRTR) to evaluate its radiological effects on surrounding population and the environment. A three-dimensional atmospheric dispersion model was applied to investigate the behavior of the radionuclides released into the air, and a dose assessment model was used to estimate the radiological impact on the population residing in nearby cities around the JRTR. Considering full core meltdown an accidental scenario, most of the source term was assumed to be released from the JRTR. Simulations were performed to calculate the air and deposition concentrations of radioactive materials for July 2013 and January 2014. The monthly averaged values of concentrations, depositions, and dose rates were analyzed to identify the most harmful effects in each month. The results showed that relatively harmful effects occurred in January 2014, and the total annual dose rate was estimated to be approximately 1 mSv outside the 10 km radius from JRTR. However, the impact of a nuclear accident is not as severe as it might seem, as the affected area is not highly populated, and appropriate protective measures can significantly reduce the radiation exposure. This study provides useful information for emergency preparedness and response planning to mitigate the radiological consequences of a nuclear accident at the JRTR. Full article

The paper presents a method for obtaining electrochemically active ultrafine composites of iron oxides, superparamagnetic ‘core/shell’ γ-Fe₂O₃/defective α-Fe₂O₃, which involved modifying sol-gel citrate synthesis, hydrothermal treatment of the formed sol, and subsequent annealing of materials in the air. The synthesized materials’ phase composition, magnetic microstructure, and structural, morphological characteristics have been determined via X-ray analysis, Mossbauer spectroscopy, scanning electron microscopy (SEM), and adsorption porometry. The mechanisms of phase stability were analyzed, and the model was suggested as FeOOH → γ-Fe₂O₃ → α-Fe₂O₃. It was found that the presence of chelating agents in hydrothermal synthesis encapsulated the nucleus of the new phase in the reactor and interfered with the direct processes of recrystallization of the structure with the subsequent formation of the α-Fe₂O₃ crystalline phase. Additionally, the conductive properties of the synthesized materials were determined by impedance spectroscopy. The electrochemical activity of the synthesized materials was evaluated by the method of cyclic voltammetry using a three-electrode cell in a 3.5 M aqueous solution of KOH. For the ultrafine superparamagnetic ‘core/shell’ γ-Fe₂O₃/defective α-Fe₂O composite with defective hematite structure and the presence of ultra-dispersed maghemite with particles in the superparamagnetic state was fixed increased electrochemical activity, and specific discharge capacity of the material is 177 F/g with a Coulomb efficiency of 85%. The prototypes of hybrid supercapacitor with work electrodes based on ultrafine composites superparamagnetic ‘core/shell’ γ-Fe₂O₃/defective α-Fe₂O₃ have a specific discharge capacity of 124 F/g with a Coulomb efficiency of 93% for current 10 mA. Full article

The analysis of harmonic currents in distribution networks of industrial facilities and the associated filtering stages is essential to optimize the production of these installations. Dry-type air-core reactors are one of the main elements of harmonic filter banks. A thermal analysis of these reactors in conventional steel plants and an evaluation of the criteria used to adjust the corresponding thermal protections are proposed in this paper. Accordingly, harmonic currents through the different filter branches are assessed. The proposed methodology builds a thermal magnetic model using the finite element method (FEM) whereby electromagnetic fields, currents and losses are emulated, to allow for recreating the actual coil temperature. The study aims at increasing the reliability of filtering systems by lowering the number of unscheduled shutdowns due to conservative adjustments of thermal protections. Full article

This paper presents an effective technique based on an artificial neural network algorithm utilized for circuit parameter identification in lightning impulse generation for low inductance loads such as low voltage windings of a power transformer, a large distribution transformer and an air core reactor. The limitation of the combination between Glaninger’s circuit and the circuit parameter selection from Feser’s suggestions in term of producing an impulse waveform to be compliant with standard requirements when working with a low inductance load is discussed. In Feser’s approach, the circuit parameters of the generation circuit need to be further adjusted to obtain the waveform compliant with the standard requirement. In this process, trial and error approaches based on test engineers’ experience are employed in the circuit parameter selection. To avoid the unintentional damage from electrical field stress during the voltage waveform adjustment process, circuit simulators, such as Pspice and EMTP/ATP, are very useful to examine the generated voltage waveform before the experiments on the test object are carried out. In this paper, a system parameter identification based on an artificial neural network algorithm is applied to determine the appropriate circuit parameters in the test circuit. This impulse voltage generation with the selected circuit parameters was verified by simulations and an experiment. It was found that the generation circuit gives satisfactory impulse voltage waveforms in accordance with the standard requirement for the maximum charging capacitance of 10 µF and the load inductance from 400 µH to 4 mH. From the simulation and experimental results of all cases, the approach proposed in this paper is useful for test engineers in selection of appropriate circuit components for impulse voltage tests with low inductance loads instead of employing conventional trial and error in circuit component selection. Full article
