Search Results (91)

Recently, diffractive optics systems have garnered increasing attention due to their myriad benefits in various applications, such as creating vortex beams, Bessel beams, or optical traps, while refractive optics systems still exhibit some disadvantages related to materials, substrates, and intensity shapes. The manufacturing of diffractive optical elements has become easier due to the development of lithography techniques such as direct laser writing, photo lithography, and electron beam lithography. In this paper, we improve the results from previous research and propose a new methodology to design and fabricate advanced binary diffractive optical elements that achieve a square focal spot independently, reducing reliance on additional components. By integrating a binary square zone plate with an axicon zone plate of the same scale, we employ machine learning for laser path optimization and direct laser lithography for manufacturing. This streamlined approach enhances simplicity, accuracy, efficiency, and cost effectiveness. Our upgraded binary diffractive optical elements are ready for real-world applications, marking a significant improvement in optical capabilities. Full article

This study investigates the application of additive manufacturing (AM) in fabricating transverse thermoelectric (TTE) composites, demonstrating the feasibility of this methodology for TTE material synthesis. Zinc oxide (ZnO), a wide-bandgap semiconductor with moderate thermoelectric performance, and copper (Cu), a highly conductive metal, were selected as base materials. These were formulated into stable paste-like feedstocks for direct ink writing (DIW). A custom dual-nozzle 3D printer was developed to precisely deposit these materials in pre-designed architectures. The resulting structures exhibited measurable transverse Seebeck effects. Unlike prior TE research primarily focused on longitudinal configurations, this work demonstrates a novel AM-enabled strategy that integrates directional compositional anisotropy, embedded metal–semiconductor interfaces, and scalable multi-material printing to realize TTE behavior. The approach offers a cost-effective and programmable pathway toward next-generation energy harvesting and thermal management systems. Full article

Direct ink writing (DIW) is an attractive, extrusion-based, additive manufacturing method for fabricating scaffold structures with controlled porosity using custom composite inks. Polycaprolactone–bioactive glass (PCL-BG) inks have gained attention for bone applications, but optimizing the formulation and fabrication of PCL-BG-based inks for improved printability and desired mechano-biological properties remains a challenge. This study employs a two-step design to systematically evaluate the effect of three factors in terms of PCL-BG composite printability and mechano-biological properties: ink preparation (acetone or dichloromethane (DCM) as the solvent, and mechanical compounding), the extrusion temperature (90 °C, 110 °C, and 130 °C), and the BG content (0%, 10%, and 20% BG). Pure PCL was used as the control. Rheological, calorimetric, and thermo-gravimetric analyses were conducted before printing. Cylindrical scaffolds and solid wells were printed to evaluate the printability, mechanical properties, and cytocompatibility. The scaffold porosity and pore size were carefully examined. Mechanical tests demonstrated that composite formulations with added BG and higher printing temperatures increased the elastic modulus and yield strength. However, PCL-DCM-BG combinations exhibited increased brittleness with higher BG content. Despite concerns about the toxic solvent DCM, the cytocompatibility was comparable to pure PCL for all ink preparation methods. The results suggest that the interaction between the ink preparation solvent, the BG content, and the printing temperature is critical for material design and fabrication planning in bone tissue engineering applications, providing insights into optimizing PCL-BG composite ink formulations for 3D printing in bone tissue engineering. Full article

Additive manufacturing (AM) has the potential to revolutionize the fabrication of continuous carbon fiber-reinforced polymer composites (CCFRPCs). Among AM techniques, direct ink writing (DIW) with ultraviolet (UV) curable resin shows promise for creating CCFRPCs with high manufacturing speed, high fiber volume fraction, and low energy consumption. However, issues such as incomplete curing and weak interfacial bonding, particularly in dense fiber bundles, limit the mechanical performance. This study addressed these challenges using pre-impregnated systems (PISs), which is a process developed to impregnate dry fiber bundles with partially cured resin before being used for DIW printing, to enhance resin-fiber adhesion and fiber–fiber bonding within fiber bundles. By optimizing resin viscosity and curing conditions in the PIS process, samples treated by PIS achieved improved mechanical properties. Tensile and bending tests revealed significant performance gains over non-PIS treated samples, with tensile stiffness increasing by at least 39% and bending stiffness by 45% in 3K fiber bundles. Tensile samples with thicker fiber bundles (6K and 12K) exhibited similar improvements. On the other hand, while all samples exhibit enhanced mechanical properties under bending deformation, the improvement of flexural stiffness and strength with thicker fiber bundles is shown to be less significant than those with 3K fiber bundles. Overall, composites made with PIS-treated fibers can enhance mechanical performance compared with those made with non-PIS-treated fibers, offering the scaling capability of printing thicker fiber bundles to reduce processing time while maintaining improved properties. It emphasizes the importance of refining the pre-processing strategies of large continuous fiber bundles in the AM process to achieve optimal mechanical properties. Full article

The absence of standardized evaluation methodologies for single-layer dimensional accuracy significantly hinders the broader implementation of direct ink writing (DIW) technology. Addressing the critical need for precision non-contact assessment in DIW fabrication, this study develops a novel machine vision-based framework for dimensional accuracy evaluation. The methodology encompasses three key phases: (1) establishment of an optimized hardware configuration with integrated image processing algorithms; (2) comprehensive investigation of camera calibration protocols, advanced image preprocessing techniques, and high-precision contour extraction methods; and (3) development of an iterative closest point (ICP) algorithm-enhanced evaluation system. The experimental results demonstrate that our machine vision system achieves 0.04 mm × 0.04 mm spatial resolution with the ICP convergence threshold optimized to 0.001 mm. The proposed method shows an 80% improvement in measurement accuracy (0.001 mm) compared to conventional approaches. Process parameter optimization experiments validated the system’s effectiveness, showing at least 76.3% enhancement in printed layer dimensional accuracy. This non-contact evaluation solution establishes a robust framework for quantitative quality control in DIW applications, providing critical insights for process optimization and standardization efforts in additive manufacturing. Full article

Direct Ink Writing (DIW) is an advanced additive manufacturing 3D-printing technique with significant potential for producing hydrogels in biomedical and engineering applications. This study presents a comprehensive rheological analysis of the yielding and recovery properties critical for ensuring the printability of carboxymethyl cellulose (CMC)-based hydrogels incorporating atenolol, an antihypertensive agent, as the active ingredient. The viscoelastic properties under shear conditions were examined using Large Amplitude Oscillatory Shear (LAOS) testing. To obtain both qualitative and quantitative insight into hydrogel dynamics, Lissajous-Bowditch plots and Fourier Transform (FT) coefficients were analyzed. The evaluation of stress signal anharmonicity and the decomposition of stress into its elastic and viscous components allowed for distinguishing structural evolution under flow among the tested hydrogels. Additionally, the analysis of the Sequence of Physical Processes (SPP) during each deformation cycle provided deeper insight into oscillatory yielding behavior, emphasizing the role of elastic strains in determining printability. Overall, the study offers valuable understanding of the nonlinear viscoelastic behavior of CMC-based hydrogels, providing a framework for optimizing hydrogel formulations in DIW applications. Full article

Direct ink writing (DIW) of low-yield-stress UV-curable silicone rubber faces challenges in maintaining dimensional accuracy due to post-extrusion swelling and viscoelastic deformation. This study proposes an ultraviolet-follow curing (UFC) method to enhance geometric precision by UV-follow curing (UFC) during deposition. The effects of UFC on filament dimensions—including width, length, cross-sectional geometry, and roundness—were systematically investigated. The mechanical properties of the printed structures were also evaluated to assess their functional integrity. The experimental results demonstrated that UFC effectively reduced extrusion swelling, achieving a filament-width deviation reduction of 22–81% and a filament-length deviation of 1.4–1.8% compared to conventional DIW. The printed rings exhibited improved roundness uniformity with reduced geometric fluctuations. Crucially, UFC enhances dimensional accuracy without compromising the mechanical performance of low-yield-stress silicones, providing a viable strategy for the high-precision additive manufacturing of soft elastomeric architectures. Full article

Direct ink writing (DIW) enables the additive manufacturing of silicone elastomers, offering an alternative to traditional moulding and casting methods for applications from healthcare products to machine–human interaction sensors. Polydimethylsiloxane (PDMS) foam, a porous silicone elastomer, is valued for its elasticity, chemical and thermal resistance, hydrophobicity, and biocompatibility. The emulsion templating method is a simple and cost-effective approach to create silicone foams by incorporating and later removing a sacrificial dispersed phase from the PDMS precursor. This study developed glycerol/PDMS emulsion-based inks for DIW using high-shear centrifugal mixing, with ethanol as a solvent to remove the glycerol template, creating silicone foam. An optimal glycerol dosage of 50 parts per hundred rubber (phr) produced foam with 27.63% porosity and pore diameter up to 4.66 µm. Each 10 phr increase in glycerol content raised porosity by 10% and average pore diameter by 2 µm. Both tensile and compressive behaviour inversely correlated with porosity, with a 10% porosity rise in the silicone foam reducing tensile strength by 0.07 MPa and stiffness by 0.02 MPa. Models with strong data alignment were developed to benefit researchers in 3D printing to customize silicone foams (pore properties, mechanical properties, compressive properties) based on specific application requirements. Full article

Polymers have been heavily used in manufacturing for decades, and with their use, improvements in the desired materials via composite materials utilizing a polymer matrix have been commonplace. Naturally, the increase in polymer additive manufacturing has come with an increase in interest in additively manufacturing polymer composites. This paper primarily covers the fused deposition modeling (FDM) method, ultraviolet (UV)-cured resin methods, multiple resin printing, and embedded sensors associated with additive manufacturing. In particular, the manufacturing and subsequent effect on material properties compared to unreinforced and unmodified 3D-printed polymers, the tradeoffs required in doing so, and the mechanisms behind these effects are discussed. The manufacturing methodology used or developed and the mechanisms behind these selections are discussed along with insights that could be gathered from material property effects seen across different studies. The mechanisms discussed also focus on the mechanisms between the different materials comprising the composite produced. Full article

This work investigates the sustainable reuse of expanded polystyrene (EPS) waste through a multi-cycle physical recycling process involving dissolution in acetone and subsequent manufacturing via Direct Ink Write (DIW) 3D printing and casting. Morphology and mechanical properties were evaluated as a function of the manufacturing technique and number of dissolution cycles. Morphological analysis revealed that casted specimens better replicated the target geometry, while voids in 3D-printed specimens aligned with the printing direction due to rapid solvent evaporation. These voids contributed to slightly reduced stiffness in 3D-printed specimens compared to casted ones, particularly for transverse printing orientation. The defoaming process during dissolution significantly increased the density of the material, as well as removed low molecular weight additives like plasticizers, leading to a notable enhancement in stiffness. Successive dissolution cycles led to increased removal of plasticizers, enhancing stiffness up to 52 times (cast), 42 times (longitudinally printed), and 35 times (transversely printed) relative to as-received EPS waste. The glass transition temperature remained unchanged, confirming the preservation of polymer integrity. This work highlights the potential of EPS inks for sustainable, multi-cycle recycling, combining enhanced mechanical performance with the flexibility of 3D printing for complex, cost-effective designs, aligning with circular economy principles. Full article

High-entropy alloys (HEAs) have drawn substantial attention on account of their outstanding properties. Additive manufacturing (AM), which has emerged as a successful approach for fabricating metallic materials, allows for the production of complex components based on three-dimensional (3D) computer-aided design (CAD) models. This paper reviews the advancements in the AM of HEAs, encompassing a variety of AM techniques, including selective laser melting (SLM), selective laser sintering (SLS), selective electron beam melting (SEBM), directed energy deposition (DED), binder jetting (BJT), direct ink writing (DIW), and additive friction stir deposition (AFSD). Additionally, the study discusses the powders and wires utilized in AM, the post-processing of AM-processed HEAs, as well as the mechanical and corrosion properties of these alloys. The unique ultra-fine and non-equilibrium microstructures achieved through AM result in superior mechanical properties of HEAs, like improved strength and ductility. However, research regarding certain aspects of HEA AM, such as fatigue properties and creep deformation behavior, is still relatively scarce. Future research should focus on overcoming the existing limitations and exploring the potential of HEAs in various applications. Full article

Gradient refractive index (GRIN) lenses have been widely used for many applications. However, the traditional manufacturing methods of GRIN lenses are very time-consuming and only suitable for macro-scale operations. In addition, those methods do not have the ability to produce other GRIN optical components with complex refractive index profiles like aspheric or freeform components. We report here an approach to produce GRIN micro-optical components in chalcogenide glass based on a direct laser writing technique. Using this approach, we are able to locally modulate the refractive index of the glass subtrates and create an arbitrary refractive index profile. To prove the flexibility of the method for the production of GRIN micro-optics, we fabricated GRIN micro-lenses and a micro-Fresnel axicon (Fraxicon). The optical properties of micro-lenses can be controlled by varying the writing parameters or the substrate thickness. As a result, the working distance of the micro-lenses can extend from 0 to more than 1000 $\mathsf{\mu }$m. Also, the micro-Fraxicon exhibits the ability to convert a Gaussian beam to a Bessel-like beam which concentrates the mid-infrared light into an approximately 1200 $\mathsf{\mu }$m long confinement zone. Full article

The present work demonstrates the manufacturing process of a pneumatic bellow actuator with an embedded sensor, utilizing a novel manufacturing approach through the complete use of additive manufacturing techniques, such as direct ink writing (DIW) and traditional fused deposition modeling (FDM) methods. This study is innovative in its integration of a dielectric electroactive polymer (DEAP) structure with sensing electrodes made of conductive carbon grease (CCG), showcasing a unique application of a 3D-printed DEAP with CCG electrodes for combined DEAP sensing and pneumatic actuation. Initial experiments, supported by computational simulations, evaluated the distinct functionality of the DEAP sensor by itself under various pressure conditions. The findings revealed a significant change in capacitance with applied pressure, validating the sensor’s performance. After sensor validation, an additive manufacturing process for embedding the DEAP structure into a soft pneumatic actuator was created, exhibiting the system’s capability for dual sensing and actuation, as the embedded sensor effectively responded to applied actuation pressure. This dual functionality represents an advancement in soft actuators, especially in applications that require integrated and responsive actuation and sensing capabilities. This work also represents a preliminary step in the development of a 3D-printed dual-modality actuator (pneumatic and electrically activated DEAP) with embedded sensing. Full article

The emergence of additive manufacturing technologies for fiber-reinforced thermoset composites has greatly bolstered their utilization, particularly within the aerospace industry. However, the ability to precisely measure the interface strength between the fiber and thermoset matrix in additively manufactured composites has been constrained by the cumbersome nature of single-fiber pull-out experiments and the need for costly instrumentation. This study aims to introduce a novel methodology for conducting single-fiber pull-out tests aimed at quantifying interface shear strength in additively manufactured thermoset composites. Our findings substantiate the viability of this approach, showcasing successful fiber embedding within composite test specimens and precise characterization of fiber pull-out strength using a conventional mechanical testing system. The test outcome revealed an average interfacial strength value of 2.4 MPa between carbon fiber and the thermoset epoxy matrix, aligning with similar studies in the existing literature. The outcome of this study offers an affordable and versatile test methodology to revolutionize composite material fabrication for superior mechanical performance. Full article

Composite materials represent the evolution of material science and technology, maximizing the properties for high-end industry applications. The fields concerned include aerospace and defense, automotive, or naval industries. Additive manufacturing (AM) technologies are increasingly growing in market shares due to the elimination of shape barriers, a plethora of available materials, and the reduced costs. The AM technologies of composite materials combine the two growing trends in manufacturing, combining the advantages of both, with a specific enhancement being the elimination of the need for mold manufacturing for composites, or even post-curing treatments. The challenge of AM composites is to compete with their conventional counterparts. The aim of the current paper is to present the additive manufacturing process across different spectrums of finite element analyses (FEA). The first outcomes are building definition (support definition) and the optimization of deposition trajectories. In addition, the multi-physics of melting/solidification using computational fluid dynamics (CFD) are performed to predict the fiber orientation and extrusion profiles. The process modelling continues with the displacement/temperature distribution, which influences porosity, warping, and residual stresses that influence characteristics of the component. This leads to the tuning of the technological parameters, thus improving the manufacturing process. Full article
