Robot grinding requires a constant interaction force between the tool and the workpiece, even under inclination changes. This paper proposes a compact single-axis pneumatic constant-force floating compensator (CFFC) to achieve constant force output. The proportional pressure valve and pressure sensor are used to regulate the cylinder’s pressure. Pneumatic components and sensors are integrated into the narrow space between the cylinder and the slide rail. Embedded controller, power, and communication modules are developed and integrated into a control box and interact with the operator by a touch screen. The mathematical models of the compensator are established and the stability and response dynamics are analyzed through transfer functions. A dual-loop force controller based on active disturbance rejection control (ADRC) is designed to address bias load, inclination change, friction, and the sealing cover spring effect. The outer loop is compensated by displacement, tilt, and pressure sensors, and the unmodeled dynamics are estimated by an extended state observer (ESO) and a recursive least square (RLS). Finally, the CFFC is installed on a testing platform to simulate grinding conditions. The experimental results show that even under large floating stroke, inclination changes, and biased load, the CFFC can still quickly and stably output the desired grinding force. Full article

The inherent static instability of bicycles poses significant safety risks, driving research into active stabilization systems within the broader field of autonomous vehicle control. This study proposes a Variable-Speed Control Moment Gyroscope (VSCMG) system for bicycle attitude stabilization, aiming to enhance rider safety and system endurance by addressing the high power consumption of traditional Single-Gimbal CMG (SGCMG) systems. A single-axis balance model was developed, employing a proportional–derivative (PD) controller to compute the total torque demand, combined with least-squares-based power-constrained optimization and a center-of-mass alignment algorithm to achieve stable control. Experimental validation was conducted on a simplified single-axis balancing setup, designed as an abstracted bicycle model for verification purposes, equipped with two VSCMG units. This setup demonstrated the rapid stabilization of a 15.5° tilt to near 0°, with significantly reduced steady-state power consumption compared to SGCMG systems, and an effective mitigation of external disturbances at 4000 RPM, though oscillations increased at 1500 RPM. The VSCMG system achieves a balance between stability and energy efficiency through dynamic flywheel speed adjustment, and future research can enhance disturbance rejection capabilities by varying the speed, offering a viable approach for long-endurance autonomous bicycles. Full article

The spacecraft microgravity simulation air-bearing platform is a crucial component of the spacecraft ground testing system. Special disturbances, such as the flatness and roughness of the contact surface between the air bearings and the granite platform, increasingly affect the control accuracy of the simulation experiment as the number of air bearings increases. To address this issue, this paper develops a novel compensation control system based on Active Disturbance Rejection Control (ADRC), which estimates and compensates for the disturbing forces and moments caused by the roughness and levelness of the contact surface, thereby improving the control precision of the spacecraft ground simulation system. A dynamic model of the multi-air-bearing platform under disturbance is established. A cascade ADRC algorithm based on the Linear Extended State Observer (LESO) is designed. The Gauss–Newton iteration method is used to identify the parameters of the sliding friction coefficient and the tilt angle of the air-bearing platform. A full-physics simulation experimental platform for spacecraft with rotor-based propulsion is constructed, and the proposed algorithm is validated. The experimental results show that on a marble surface with a flatness of grade 00, an overall tilt angle of 0–1 degrees, and a surface friction coefficient of 0–0.01, the position control accuracy for the simulated spacecraft can reach 1.5 cm, and the attitude control accuracy can reach 1°. Under ideal conditions, the identification accuracy for the contact surface friction coefficient is 2 × 10⁻⁴, and the recognition accuracy for the overall levelness of the marble surface can reach 1 × 10⁻³, laying the foundation for high-precision ground simulation experiments of spacecraft in multi-air-bearing scenarios. Full article

The unmanned quad tilt-rotor eVTOL (QTRV) is a variable-configuration aircraft that combines the features of vertical takeoff and landing (VTOL), hovering, and high-speed cruising, making its control system design particularly challenging. The flight dynamics of the QTRV differ significantly between the VTOL and cruise modes, and are further influenced by rotor tilt and external wind disturbances. Developing a unified, highly coupled nonlinear full-flight dynamics model facilitates flight control system design and simulation verification. To ensure stable tilt of the QTRV, a tilt corridor was established, along with the design of its tilt route and manipulation strategy. An adaptive neural network active disturbance rejection controller (ANN-ADRC) is proposed to ensure stable flight across all modes, reducing the control parameters and simplifying tuning while effectively estimating and compensating for unknown disturbances in real time. A hardware-in-the-loop (HIL) simulation system was designed for full-mode flight control simulation, and the results demonstrated the effectiveness of the proposed control method. Full article

A tip-tilt mirror (TTM) control method is designed to enhance the control bandwidth and ensure the rejection performance of the adaptive optics (AO) tip-tilt correction system. Optimized with the Smith predictor and filter, linear active disturbance rejection (LADRC) is adopted to achieve the tip-tilt correction. An AO tip-tilt correction experimental platform was built to validate the method. Experimental results show that the proposed method improves the control bandwidth of the system by at least 3.6 times compared with proportional–integral (PI) control. In addition, under the same control bandwidth condition, compared with the Smith predictor and proportional–integral (PI–Smith) control method, the system is more capable of rejecting internal and external disturbances, and its dynamic response performance is improved by more than 29%. Full article

In order to overcome the influence of internal and external disturbances caused by rotor tilt motion and gust disturbance on the full flight mode control of a tilt-rotor unmanned aerial vehicle (UAV), a design method using fuzzy backstepping control based on an extended-state observer (FBS-ESO) is proposed. In this paper, fuzzy control is used to tune the parameters of the backstepping control law online, and the extended-state observer estimates the total disturbance of the controlled system to improve the controller’s robustness and anti-disturbance capability. This paper designs the attitude control system of a tilt-rotor UAV based on an FBS-ESO controller. The control performance of the FBS-ESO controller is tested in a hardware-in-loop simulation of the attitude control system. The simulation results show that changing the rotor tilt angle will destroy the stability of the traditional backstepping controller and active disturbance rejection controller (ADRC). In contrast, the FBS-ESO controller maintains good control performance. In addition, the performance of the FBS-ESO controller is not be significantly affected by adding external gust disturbance or changing the UAV parameters in the simulation. These disturbances significantly impact the traditional backstepping controller and ADRC. Therefore, the FBS-ESO controller has better anti-disturbance capabilities and robustness, as well as higher attitude control accuracy. Full article

This paper presents a robust control strategy for controlling the flight of an unmanned aerial vehicle (UAV) with a passively (fixed) tilted hexarotor. The proposed controller is based on a robust extended-state observer to estimate and reject internal dynamics and external disturbances at runtime. Both the stability and convergence of the observer are proved using Lyapunov-based perturbation theory and an ultimate bound approach. Such a controller is implemented within a highly realistic simulation environment that includes physics motors, showing an almost identical behavior to that of a real UAV. The controller was tested for flying under normal conditions and in the presence of different types of disturbances, showing successful results. Furthermore, the proposed control system was compared with another robust control approach, and it presented a better performance regarding the attenuation of the error signals. Full article

This paper proposes a unified attitude controller based on the modified linear active disturbance rejection control (LADRC) for a dual-tiltrotor unmanned aerial vehicle (UAV) with cyclic pitch to achieve accurate attitude control despite its nonlinear and time-varying characteristics during flight mode transitions. The proposed control algorithm has higher robustness against model mismatch compared with the model-based control algorithms. The modified LADRC utilizes the state feedbacks from the onboard sensors like IMU and Pitot tube instead of the mathematical model of the plane. It has less dependency on the accurate dynamics model of the dual-tiltrotor UAV, which can hardly be built. In contrast to the original LADRC, an actuator model is integrated into the modified LADRC to compensate for the non-negligible slow rotor flapping dynamics and servo dynamics. This modification eliminates the oscillation of the original LADRC when applied on the plant with slow-response actuators, such as propeller and rotors of the helicopter. In this way, the stability and performance of the controller are improved. The controller replaces the gain-scheduling or the control logic switching by a unified controller structure, which simplifies the design approach of the controller for different flight modes. The effectiveness of the modified LADRC and the performance of the unified attitude controller are demonstrated in both simulation and flight tests using a dual-tiltrotor UAV. The attitude control error is less than ±4° during the conversion flight. The control rising time in different flight modes is all about 0.5 s, despite the variations in the airspeed and tilt angle. The flight results show that the controller guarantees high control accuracy and uniform control quality in different flight modes. Full article

Incorporating linear-scanning micro-electro-mechanical systems (MEMS) micromirrors into Fourier transform spectral acquisition systems can greatly reduce the size of the spectrometer equipment, making portable Fourier transform spectrometers (FTS) possible. How to minimize the tilting of the MEMS mirror plate during its large linear scan is a major problem in this application. In this work, an FTS system has been constructed based on a biaxial MEMS micromirror with a large-piston displacement of 180 μm, and a biaxial H∞ robust controller is designed. Compared with open-loop control and proportional-integral-derivative (PID) closed-loop control, H∞ robust control has good stability and robustness. The experimental results show that the stable scanning displacement reaches 110.9 μm under the H∞ robust control, and the tilting angle of the MEMS mirror plate in that full scanning range falls within ±0.0014°. Without control, the FTS system cannot generate meaningful spectra. In contrast, the FTS yields a clean spectrum with a full width at half maximum (FWHM) spectral linewidth of 96 cm⁻¹ under the H∞ robust control. Moreover, the FTS system can maintain good stability and robustness under various driving conditions. Full article
