The thermal vibration of thick Terfenol-D control law on functionally graded material (FGM) plates/cylindrical shells in nonlinear unsteady supersonic flow with third-order shear deformation theory (TSDT) is investigated by using the generalized differential quadrature (GDQ) method. The effects of the coefficient term of TSDT displacement models on the thermal stress and center displacement of Terfenol-D control law on FGM plates/cylindrical shells in nonlinear unsteady supersonic flow are investigated. The coefficient term of TSDT models of thick Terfenol-D control law on FGM plates/cylindrical shells provide an additional effect on the values of displacements and stresses. Full article

In this work, three composite materials based on Terfenol-D and PZT-type material were obtained with a classic sintering method using a combination of 0–3 phases, where the ferroelectric phase was doped PZT material (P) and the magnetic phase was Terfenol-D (T). The percentage of P and T components in the composites was variable, i.e., 90% P/10% T (P90-T10), 70% P/30% T (P70-T30), and 50% P/50% T (P50-T50). Structural, microstructure, dielectric, and magnetic properties and DC electric conductivity of multiferroic composites were investigated. Chemical composition analyses and X-ray studies showed a decomposition of the composite compositions, forming additional phases, most of which contained rare earth elements and Fe. Microstructural SEM-BE (backscattering) images distinguished areas of bright intensity with a dominant ferroelectric phase and dark areas with a dominant magnetic element dominance. Despite the composition decomposition, the composite materials retained good dielectric and magnetic properties at room temperature. The highest stability of dielectric parameters was maintained by the P90-T10 composition with high values of permittivity ε = 570 at room temperature RT (ε_m = 7300 at the phase transition temperature T_m) and the lowest dielectric tangent loss (tanδ of 0.32 and 1.94 for RT and T_m, respectively). Increasing the Terfenol-D share in the composite causes a significant increase in dielectric tangent loss and electrical conductivity, a decrease in permittivity, and an increase in the degree of phase transition blurring. The magnetic properties for all P-T composite compositions at RT were preserved and were 0.31 emu/g, 1.60 emu/g, and 4.56 emu/g for P90-T10, P70-T30, P50-T50, respectively. For the M-H hysteresis loop at room temperature, the maximum magnetization increased from 1.17 emu/g for (P90-T10) to 15.18 emu/g for (P50-T50), while the coercive field decreased from 271.8 mT for P90-T10 to 9.7 mT for P50-T50. It is also interesting to maintain the high saturation of the M-H magnetic hysteresis loop in the composite with the lowest Terfenol-D content (P90-T10). The magnetic properties for all P-T composite compositions at room temperature were preserved and were 0.31 emu/g, 1.60 emu/g, and 4.56 emu/g for P90-T10, P70-T30, and P50-T50, respectively. For the M-H hysteresis loop at RT, the maximum magnetization increased from 1.17 emu/g for (P90-T10) to 15.18 emu/g for (P50-T50), while the coercive field decreased from 0.272 T for P90-T10 to 0.001 T for P50-T50. It is also interesting to maintain the high saturation of the M-H magnetic hysteresis loop in the composite with the lowest Terfenol-D content (P90-T10). Due to the tendency to combine with oxygen and the high electric conductivity of Terfenol-D, limiting its amount in the composite composition is appropriate. At 10% of Terfenol-D, the composite has good dielectric properties, and the magnetic parameters remain satisfactory. Full article

A numerical, generalized differential quadrature (GDQ) method is presented on applied heat vibration for a thick-thickness magnetostrictive functionally graded material (FGM) plate coupled with a cylindrical shell. A nonlinear c₁ term in the z axis direction of a third-order shear deformation theory (TSDT) displacement model is applied into an advanced shear factor and equation of motions, respectively. The equilibrium partial differential equation used for the thick-thickness magnetostrictive FGM layer plate coupled with the cylindrical shell under thermal and magnetostrictive loads can be implemented into the dynamic GDQ discrete equations. Parametric effects including nonlinear term coefficient of TSDT displacement field, advanced nonlinear varied shear coefficient, environment temperature, index of FGM power law and control gain on displacement, and stress of the thick magnetostrictive FGM plate coupled with cylindrical shell are studied. The vibrations of displacement and stress can be controlled by the control gain algorithms in velocity feedback control law. Full article

Polyimides (PIs) have been extensively used in thin film and micro-electromechanical system (MEMS) processes based on their excellent thermal and mechanical stability and high glass transition temperature. This research explores the development of a novel multilayer and multifunctional polymer composite electro-piezomagnetic device that can function as an energy harvester or sensor for current-carrying wires or magnetic field sensing. The devices consist of four layers of composite materials with a polyimide matrix. The composites have various nanoparticles to alter the functionality of each layer. Nanoparticles of Ag were used to increase the electrical conductivity of polyimide and act as electrodes; lead zirconate titanate was used to make the piezoelectric composite layer; and either neodymium iron boron (NdFeB) or Terfenol-D was used to make the magnetic and magnetostrictive composite layer, which was used as the proof mass. A novel all-polymer multifunctional polyimide composite cantilever was developed to operate at low frequencies. This paper compares the performance of the different magnetic masses, shapes, and concentrations, as well as the development of an all-magnetostrictive device to detect voltage or current changes when coupled to the magnetic field from a current-carrying wire. The PI/PZT cantilever with the PI/NdFeB proof mass demonstrated higher voltage output compared to the PI/Terfenol-D proof mass device. However, the magnetostrictive composite film could be operated without a piezoelectric film based on the Villari effect, which consisted of a single PI-Terfenol-D film. The paper illustrates the potential to develop an all-polymer composite MEMS device capable of acting as a magnetic field or current sensor. Full article

In order to improve the sensitivity and accuracy of the giant magnetostrictive material-fiber Bragg gratings’ (GMM-FBG) current sensor, in which the magnetostrictive modulator is Terfenol-D, the temperature effects on the FBG center wavelength and GMM magnetostriction coefficient are investigated to initiate an amending scheme in which temperature parameters are introduced into a GMM-FBG sensing model so as to calibrate current values. Based on electromagnetism theory, the magnetic structure is optimized in design to significantly increase the magnetic coupling efficiency and to homogenize magnetic distribution, employing finite element simulations of the electromagnetic field. The relevant experimental platform is constructed with a wavelength demodulation system. At the temperature range of 20~70 °C, response amplitudes of the current sensor are tested under various current values. The experimental results indicate that the sensitivity of the GMM-FBG current sensor decreases with the temperature increment and is also positively correlated to the target current. Through analyzing the response characteristics of the current sensor to temperature variation, a reasonable GMM-FBG sensing amelioration model with a temperature compensation coefficient is established based on a mathematical fitting method, according to which the current detecting accuracy can be increased by 4.8% while measuring 60 A current at the representative working temperature of 40 °C. Full article

Recently, the realization of electromagnetic wave signal transmission and reception has been achieved through the utilization of the magnetoelectric effect, enabling the development of compact and portable low-frequency communication systems. In this paper, we present a miniaturized low-frequency communication system including a transmitter device and a receiver device, which operates at a frequency of 44.75 kHz, and the bandwidth is 1.1 kHz. The transmitter device employs a Terfenol-D (80 mm × 10 mm × 0.2 mm)/PZT (30 mm × 10 mm × 0.2 mm)/Terfenol-D glued composite heterojunction magnetoelectric antenna and the strongest radiation in the length direction, while the receiver device utilizes a manually crafted coil maximum size of 82 mm, yielding a minimum induced electromagnetic field of 1 pT at 44.75 kHz. With an input voltage of 150 V, the system effectively communicates over a distance of 16 m in air and achieves reception of electromagnetic wave signals within 1 m in simulated seawater with a salinity level of 35% at 25 °C. The miniaturized low-frequency communication system possesses wireless transmission capabilities, a compact size, and a rapid response, rendering it suitable for applications in mining communication, underwater communication, underwater wireless energy transmission, and underwater wireless sensor networks. Full article

This paper presents a study of magnetoelectric (ME) properties of the PZT/Terfenol-D composite with a varying number of layers. The composite consists of piezoelectric and magnetostrictive phases that are mechanically coupled. The purpose of this setup is to gain control over the electric polarization of a material via an external magnetic field. Unlike most similar composites, our samples utilize a commercial piezoelectric patch instead of pure PZT. At present, researchers face two main problems regarding magnetoelectric materials: (i) the effect is observed far below room temperature for single-phase materials, and (ii) the ME coupling is too weak to be commercially viable. Our research was carried out via the lock-in technique on two PZT/Terfenol-D samples we synthesized. Relatively strong room-temperature magnetoelectric coupling between piezoelectric and magnetostrictive phases was observed for both samples. Two types of characteristics were investigated: (i) ME voltage versus magnetic AC field frequency, and (ii) ME voltage versus magnetic DC field. We detected multiple, grouped signal peaks ascribed to different resonance modes. Uniquely, the peaks form band-like characteristics which might be an important step in bringing the materials closer to wider commercial use. Full article

Fiber-optic magnetic field sensors have garnered considerable attention in the field of marine monitoring due to their compact size, robust anti-electromagnetic interference capabilities, corrosion resistance, high sensitivity, ease of multiplexing and integration, and potential for large-scale sensing networks. To enable the detection of marine magnetic field vector information, we propose an optical fiber vector magnetic field sensor that integrates three single-axis sensors in an orthogonal configuration. Theoretical analysis and experimental verification are conducted to investigate its magnetic field and temperature sensing characteristics, and a sensitivity matrix is established to address the cross-sensitivity between the magnetic field and temperature; experimental tests were conducted to assess the vector response of the three-dimensional (3D) vector sensor across the three orthogonal axes; the obtained experimental results illustrate the commendable magnetic field vector response exhibited by the sensor in the orthogonal axes, enabling precise demodulation of vector magnetic field information. This sensor presents several advantages, including cost-effectiveness, easy integration, and reliability vectorially. Consequently, it holds immense potential for critical applications in marine magnetic field network detection. Full article

Sensors based on Fiber Bragg Grating (FBG) have remarkable benefits like small size, fast response, wide sensing distribution, and immunity to electromagnetic interference, allowing for their widespread application in numerous domains of physical parameter measurement in industrial engineering. In this work, a temperature-independent sensor of the magnetic field based on FBG and the magnetostrictive material Terfenol-D is suggested. By exploiting the distributed sensing characteristic of FBG, a sensing structure that remains unaffected by temperature is designed. The results demonstrate that within the magnetic induction intensity range of 0 mT to 50 mT, the sensitivity of the sensor can reach 7.382 pm/mT, exhibiting good linearity and repeatability. Compared with the control experiment and other sensors of the magnetic field containing Terfenol-D, the sensor has higher sensitivity, better repeatability, and good temperature stability. Full article

This paper proposes a multilevel three-dimensional constitutive model based on a microscopically phenomenological approach from the domain rotation mechanism, which is a fully coupled self-consistent homogenization scheme considering the interactions between elastic–inelastic strain and hysteresis. Considering the interactions among magnetic domains, grains, polycrystalline complexes, and macroscopic phenomenology, we predict the nonlinear magnetostrictive response of Terfenol-D under different types of external force loads and magnetic excitations in various thermal environments involving multi-fields of coupled magnetic, elastic, thermal, and mechanical phenomena. The average values of the mechanical bulk strains for different magnetization states are obtained at the grain scale utilizing Boltzmann functions and a self-consistent homogenization scheme. A Taylor series expansion of the Gibbs function concerning the field variables and an adapted Jiles–Atherton model are used to construct the hysteresis coupled constitutive relations at the macroscopic scale. The results associated with the experiments show that the established model can reasonably predict the magnetostrictive response under different external mixed stimuli. It can provide theoretical guidance for the precise control of nonlinear vibrations and the optimal design of the rotating giant magnetostrictive transducers at both microscopic and macroscopic multiple scales. Full article

In this study, magnetostriction measurements were performed on the ferromagnetic Heusler alloy, Ni₂MnGa_0.88Cu_0.12, which is characterized by the occurrence of the martensitic phase and ferromagnetic transitions at the same temperature. In the austenite and martensite phases, the alloy crystallizes in the L2₁ and D0₂₂-like crystal structure, respectively. As the crystal structure changes at the martensitic transition temperature (T_M), a large magnetostriction due to the martensitic and ferromagnetic transitions induced by magnetic fields is expected to occur. First, magnetization (M-H) measurements are performed, and metamagnetic transitions are observed in the magnetic field of μ₀H = 4 T at 344 K. This result shows that the phase transition was induced by the magnetic field under a constant temperature. Forced magnetostriction measurements (ΔL/L) are then performed under a constant temperature and atmospheric pressure (P = 0.1 MPa). Magnetostriction up to 1300 ppm is observed around T_M. The magnetization results and magnetostriction measurements showed the occurrence of the magnetic-field-induced strain from the paramagnetic austenite phase to the ferromagnetic martensite phase. As a reference sample, we measure the magnetostriction of the Ni₂MnGa-type (Ni₅₀Mn₃₀Ga₂₀) alloy, which causes the martensite phase transition at T_M = 315 K. The measurement of magnetostriction at room temperature (298 K) showed a magnetostriction of 3300 ppm. The magnetostriction of Ni₂MnGa_0.88Cu_0.12 is observed to be one-third that of Ni₅₀Mn₃₀Ga₂₀ but larger than that of Terfenol-D (800 ppm), which is renowned as the giant magnetostriction alloy. Full article

Giant magnetostrictive transducer can be widely used in active vibration control, micro-positioning mechanism, energy harvesting system, and ultrasonic machining. Hysteresis and coupling effects are present in transducer behavior. The accurate prediction of output characteristics is critical for a transducer. A dynamic characteristic model of a transducer is proposed, by providing a modeling methodology capable of characterizing the nonlinearities. To attain this objective, the output displacement, acceleration, and force are discussed, the effects of operating conditions on the performance of Terfenol-D are studied, and a magneto-mechanical model for the behavior of transducer is proposed. A prototype of the transducer is fabricated and tested to verify the proposed model. The output displacement, acceleration, and force have been theoretically and experimentally studied at different working conditions. The results show that, the displacement amplitude, acceleration amplitude, and force amplitude are about 49 μm, 1943 m/s², and 20 N. The error between the model and experimental results are 3 μm, 57 m/s², and 0.2 N. Calculation results and experimental results show a good agreement. Full article

The magnetic field is a vital physical quantity in nature that is closely related to human production life. Magnetic field sensors (namely magnetometers) have significant application value in scientific research, engineering applications, industrial productions, and so forth. Accompanied by the continuous development of magnetic materials and fiber-sensing technology, fiber sensors based on the Magneto-Refractive Effect (MRE) not only take advantage in compact structure, superior performance, and strong environmental adaptability but also further meet the requirement of the quasi-distributed/distributed magnetic field sensing; they manifest potential and great application value in space detection, marine environmental monitoring, etc. Consequently, the present and prevalent Magneto-Refractive Magnetic Field Fiber Sensors (MR-MFSs) are briefly summarized by this paper, proceeding from the perspective of physicochemical properties; design methods, basic performance and properties are introduced systematically as well. Furthermore, this paper also summarizes key fabrication techniques and future development trends of MR-MFSs, expecting to provide ideas and technical references for staff engaging in relevant research. Full article

The geometry–dependent magnetoelectric (ME) and exchange bias (EB) effects of the nano ME sensor were investigated. The sensor consisted of the Longitudinal–Transverse (L–T) mode bi–layer bar structure comprising the ferromagnetic (FM) and ferroelectric (FE) materials and the anti–ferromagnetic (AFM) material. The bi–layer ME coefficient was derived from constitutive equations and Newton’s second law. The trade–off between peak ME coefficient and optimal thickness ratio was realized. At the frequency × structure length = 0.1 and 1200, minimum and maximum peak ME coefficients of the Terfenol–D/PZT bi-layer were around 1756 and 5617 mV/Oe·cm, respectively, with 0.43 and 0.19 optimal thickness ratios, respectively. Unfortunately, the bi-layer could not distinguish the opposite magnetic field directions due to their similar output voltages. PtMn and Cr₂O₃, the AFM, were introduced to produce the EB effect. The simulation results showed the exchange field starting at a minimum PtMn thickness of 6 nm. Nevertheless, Cr₂O₃ did not induce the exchange field due to its low anisotropy constant. The tri–layer ME sensor consisting of PZT (4.22 nm)/Terfenol–D (18 nm)/PtMn (6 nm) was demonstrated in sensing 2 Tbit/in² magnetic bits. The average exchange field of 5100 Oe produced the output voltage difference of 12.96 mV, sufficient for most nanoscale magnetic sensing applications. Full article

To reduce the heating of the Terfenol-D rod and evaluate its working efficiency, six kinds of Terfenol-D rods were designed, and the temperature field of the rods was simulated and calculated using the finite element method to obtain the temperature distribution. The results showed that the untreated rod had the highest temperature; the temperature was higher in the middle and lower at both ends; higher on the outer diameter surface; and lower on the inside. When compared to the untreated rod, the temperatures of sliced rods and slit rods decreased, and the temperature of sliced rods was lower than that of slit rods; the temperature of slit rods was higher in the middle and lower at both ends; the temperature distribution of sliced rods was more uniform relatively; the slice treatment rod had the lowest temperature and the best heat suppression effect. Three structural rods were chosen and manufactured from a total of six that were tested. It shows that the temperature of all rods was higher in the middle and lower at both ends after 30 min of operation. The actual temperature of untreated rod was 34 °C, the actual temperature of radially slit rod was 32 °C, and the actual temperature of sliced rod at both ends was 28 °C. The tested temperature distributions of three rods agreed with the calculated ones. Full article
