Diffusion bonding with an interlayer is considered an effective means of obtaining Mg/Al dissimilar alloy joints. However, at low temperatures, it is often impossible to simultaneously achieve joints between the interlayer and Mg/Al under the same bonding parameters. For this reason, the interlayer is usually prefabricated on the substrate, followed by conducting diffusion bonding. Due to the higher diffusion rate of atoms in the liquid phase compared to atoms in the solid phase, creating a liquid phase field in diffusion bonding to reduce diffusion resistance and thus omitting the step of prefabricating the interlayer is a feasible approach. In this study, solid-state diffusion bonding and TLP (transient liquid phase) diffusion bonding were combined. The low-temperature diffusion bonding of the Mg/Al alloy was achieved under the same parameters using a Zn/Sn composite interlayer, utilizing the formation of a Zn-Sn eutectic liquid phase and the complete melting of Sn during heating without requiring a prefabricated interlayer. Unlike conventional composite interlayers used in diffusion bonding, the Sn layer of the Zn/Sn composite interlayer completely melts into liquid and is squeezed out of the bonding interface at the bonding temperature. The Mg/Zn interface was bonded by solid-state diffusion bonding, while the Al/Zn interface was joined through TLP diffusion bonding. Research on the bonding temperature showed that the bonding temperature range was narrow and that variation in the bonding temperature had a significant impact on the microstructure of the joints. Full article

Although magnesium alloys show potential as structural and functional materials, they are difficult to join using traditional welding methods because of their low melting points and active chemical properties. Their poor weldability impedes their universal application. Ultrasound-assisted transient liquid-phase bonding (U-TLP) is a novel method used for magnesium alloy bonding, but in almost all related studies, a heating device has been required, and the types of solders are limited. In this study, gallium was used as solder to bond AZ31 magnesium alloy with ultrasonic assistance at room temperature (without a heating device) due to the low melting temperature of gallium and its compatibility with other metals when forming intermetallic compounds (IMCs). The variations in the products, microstructure, fracture characteristics, and shear strength of the joints were investigated. A reliable joint composed of IMCs (Mg₂Ga₅, H-MgGa₂, and Mg₂Ga) and a eutectic structure was obtained after an ultrasonic duration of 3 s. Significantly, the plasticity of the joint was improved due to ultrasonic effects, which included the accelerated element diffusion process, the refinement of grains to nanometer particles, and the homogenization of organization. Thus, the highest shear strength of 14.65 MPa at 4 s was obtained, with obvious cleavage fracture characteristics in the region of the IMCs. Full article

5A06 aluminum alloy bar was brazed by temperature gradient transient liquid phase diffusion welding (TG-TLP). The effects of brazing temperature on the microstructure and the tensile strength of the brazing joints were investigated. Three typical brazing filler alloys (1^# Al-20Cu-6Si-2Ni, 2^# Al-10Cu-10Si-3Mg-1Ga, and 3^# Al-6Cu-10Si-2Mg-10Zn) were prepared by smelting, and TG-TLP diffusion bonding was carried out at different brazing temperatures (550 °C~590 °C). The results show that with the increase in brazing temperature, the oxide films at the brazing junction are easier to be broken and dispersed, but the oxidation extent will also increase. The oxidation products enriched were mainly Al₂O₃ and SiO₂ at the brazing junction. There are different optimal brazing temperatures corresponding to the different filler alloys. For 1^#, the optimal temperature is 570 °C; for 2^# is 580 °C; for 3^# is 580 °C. For 1^# brazing joints, the maximum tensile strength was 113 MPa, and for 2^# was 122.4 MPa. Under the experimental conditions of this study, the maximum tensile strength of the TG-TLP joint is 147.4 MPa of 3^# brazing sample (at 580 °C), which has increased by 30% and 20% compared to 1^# and 2^# respectively. The nickel-rich phase at the interface (of 1^# brazing filler) could form a brittle fracture, which was unfavorable for interface bonding. For TG-TLP brazing of 5A06, the filler alloy with high Al:Cu ratio (12:1 wt.%) needs a sufficient temperature gradient to exert the film-breaking effect, while the filler alloy with low Al:Cu ratio (3.6:1 wt.%) needs to accurately control its brazing temperature to avoid excessive oxidation. There are many research gaps in the influence of brazing material composition and brazing temperature on the microstructure and mechanical properties of 5A06 aluminum alloy TG-TLP joints. The research results can provide a theoretical basis for formulating the TG-TLP brazing specification of 5A06 aluminum alloy. Full article

As a technology for micro-deformed solid-phase connection, transient liquid phase (TLP) diffusion bonding plays a key role in the manufacture of heating components of aero engines. However, the harmful brittle phase and high hardness limit the application of TLP diffusion bonding in nickel-based superalloys. In this paper, a new strategy in which a low-boron and high-titanium interlayer can restrain the brittle phase and reduce the hardness of the TLP-diffusion-bonded joint is proposed. With this strategy, the Ni₃Al joint can achieve a high strength of 860.84 ± 26.9 MPa under conditions of 1250 °C, 6 h and 5 MPa. The microhardness results show that the average microhardness of the joint area is 420.33 ± 3.15 HV and is only 4.3% higher than that of the Ni₃Al base material, which proves that this strategy can effectively inhibit the formation of the harmful brittle phase in the joint area. The results of EBSD show that 7.7% of the twin boundaries exist in the isothermal solidification zone, and only small amounts of secondary precipitates are observed at the grain boundaries in the joint, which indicates that twin boundaries may play a dominant role in crack initiation. This study provides a feasible avenue to suppress the brittle phase in TLP-diffusion-bonded joints. Full article

The dissimilar joining of martensitic and ferritic stainless steels have been developed that needs corrosion resistance and enhanced mechanical properties. In this study, the transient liquid-phase bonding of martensitic stainless steel 410 and super-ferritic stainless steel 446 was conducted with a nickel-based amorphous interlayer (BNi-2) at constant temperature (1050 °C) and increasing times of 1, 15, 30, 45, and 60 min. For characterization of the TLP-bonded samples, optical microscopy and scanning emission microscopy equipped with energy-dispersive X-ray spectroscopy were used. To investigate the mechanical properties of TLP-bonded samples, the shear strength test method was used. Finally, the X-ray diffraction method was used for microstructural investigation and phase identification. The microstructural study showed that the microstructure of base metals changed: the martensitic structure transited to tempered martensite, including ferrite + cementite colonies, and the delta phase in super-ferritic stainless steel dissolved in the matrix. During the transient liquid-phase bonding, the aggregation of boron due to its diffusion to base metals resulted in the precipitation of a secondary phase, including iron–chromium-rich borides with blocky and needle-like morphologies at the interface of the molten interlayer and base metals. On the other hand, the segregation of boron in the bonding zone resulted from a low solubility limit, and the distribution coefficient has induced some destructive and brittle phases, such as nickel-rich (Ni₃B) and chromium-rich boride (CrB/Cr₂B). By increasing the time, significant amounts of boron have been diffused to a base metal, and diffusion-induced isothermal solidification has happened, such that the isothermal solidification of the assembly has been completed under the 1050 °C/60 min condition. The distribution of the hardness profile is relatively uniform at the bonding zone after completing isothermal solidification, except the diffusion-affected zone, which has a higher hardness. The shear strength test showed that increasing the holding time was effective in achieving the strength near the base metals such that the maximum shear strength of about 472 MPa was achieved. Full article

Alumina ceramics were joined by a transient liquid phase (TLP) bonding method at relatively lower temperatures, using mixed powders of Bi₂O₃ and ZnO with different weight ratios as interlayers between the ceramic components. Bonding was achieved at 750 °C for several of the prepared interlayer mixtures, which makes the applied approach attractive due to the relatively lower joining temperature and potentially low fabrication costs. Measurements by SEM and EDX were used to study the microstructure and chemical analysis of the obtained joints. It also allowed us to investigate the diffusion mechanism occurring in the systems, which resulted in the hypothesis that Zn²⁺/ZnO diffuses through the ceramics. XRD and Raman spectra were acquired to examine the reaction products that formed during the thermal treatment. The results showed that both ZnO and Bi₂O₃ react with each other as well as with alumina to form spinel and other products. Full article

The use of a Zn/Ag–Cu–Zn/Zn multi-interlayer was observed to avoid the formation of Mg–Al binary intermetallic compounds (IMCs), which cause embrittlement and low strength of bonding when dissimilar metals such as Mg/Al are joined using ultrasound-assisted transient liquid phase bonding (U-TLP). The change in the microstructure and mechanical properties of the AZ31B/LY12 joints at 410, 440, and 460 °C with prolonging ultrasonic treatment (UST) time was investigated. The results showed that the diffusion of Ag and Cu was faster into the brazing seam on the LY12 side than that on the AZ31B side with increasing UST and temperature. The IMCs on both sides of the joints were transformed with the diffusion of Ag and Cu. The transformation made the fracture path shift from the AZ31B side (410, 440 °C) to the LY12 side (460 °C), and the maximum shear strength of the joints from 43.3 (410 °C) to 65.7 (440 °C) to 84.7 MPa (460 °C). The IMCs on the surface of the fracture path corresponding to the joints with optimal mechanical properties changed from Mg₇Zn₃+MgZn₂+α-Mg (410 °C) to MgZnCu+Mg₇Zn₃ (440 °C) to Al₂Cu (460 °C). Full article

Joining heat conducting alloys, such as copper and its alloys, to heat resistant nickel-based superalloys has vast applications in nuclear power plants (including future fusion reactors) and liquid propellant launch vehicles. On the other hand, fusion welding of most dissimilar alloys tends to be unsuccessful due to incompatibilities in their physical properties and melting points. Therefore, solid-state processes, such as diffusion bonding, explosive welding, and friction welding, are considered and commercially used to join various families of dissimilar materials. However, the solid-state diffusion bonding of copper alloys normally results in a substantial deformation of the alloy under the applied bonding load. Therefore, transient liquid phase (TLP) bonding, which requires minimal bonding pressure, was considered to join copper alloy (C18150) to a nickel-based superalloy (GH4169) in this work. BNi-2 foil was used as an interlayer, and the optimum bonding time (keeping the bonding temperature constant as 1030 °C) was determined based on microstructural examinations by optical microscopy (OM), scanning electron microscopy (SEM), energy dispersive spectrometry (EDS), tensile testing, and nano-hardness measurements. TLP bonding at 1030 °C for 90 min resulted in isothermal solidification, hence obtained joints free from eutectic phases. All of the tensile-tested samples failed within the copper alloy and away from their joints. The hardness distribution across the bond zone was also studied. Full article

Phase transformations and the melting range of the interlayer BNi-3 were investigated by differential scanning calorimetry, which showed three stages of crystallization during heating. There were three exothermic peaks that indicated crystallization in the solid state. The cobalt-based X-45 and FSX-414 superalloys were bonded with interlayer BNi-3 at a constant holding time of 10 min with bonding temperatures of 1010, 1050, 1100, and 1150 °C using a vacuum diffusion brazing process. Examination of microstructural changes in the base metals with light microscopy and scanning electron microscopy coupled with X-ray spectroscopy based on the energy distribution showed that increasing temperature caused a solidification mode, such that the bonding centerline at 1010 °C/10 min included a γ-solid solution, Ni₃B, Ni₆Si₂B, and Ni₃Si. The athermally solidified zone of the transient liquid phase (TLP)-bonded sample at 1050 °C/10 min involved a γ-solid solution, Ni₃B, CrB, Ni₆Si₂B, and Ni₃Si. Finally, isothermal solidification was completed within 10 min at 1150 °C. The diffusion-affected zones on both sides had three distinct zones: a coarse block precipitation zone, a fine and needle-like mixed-precipitation zone, and a needle-like precipitation zone. By increasing the bonding temperature, the diffusion-affected zone became wider and led to dissolution. Full article

Transient liquid phase (TLP) diffusion bonding of DZ40M cobalt-based superalloy was carried out using a self-made NiCrCoWB intermediate layer. The typical microstructure of the joint was investigated. The effect of holding time on the microstructural evolution and the tensile strength of the brazed joints was studied. The tensile strength of the joints TLP bonded at 1160 °C for 60 min reached the maximum value of 487 MPa, which was 88.6% of the base metal strength. The diffusion of boron and the evolution of the eutectic zone were numerically studied. The time needed for isothermal solidification completion was calculated and predicted, which was well in accordance with the experimental results. Full article

Similar and dissimilar material joints of AISI grade 304 (1.4301) and AISI grade 316 (1.4401) austenitic stainless steel by solid state diffusion bonding and transient liquid phase (TLP) bonding are of interest to academia and industry alike. Appropriate bonding parameters (bonding temperature, bonding time, and bonding pressure) as well as suitable surface treatments, bonding atmosphere (usually high vacuum or protective gas) and interlayers are paramount for successful bonding. The three main parameters (temperature, time, and pressure) are interconnected in a strong non-linear way making experimental data important. This work reviews the three main parameters used for solid state diffusion bonding, TLP bonding and to a smaller degree hot isostatic pressing (HIP) of AISI grade 304 and AISI grade 316 austenitic stainless steel to the aforementioned materials (similar joints) as well as other materials, namely commercially pure titanium, Ti-6A-4V, copper, zircaloy and other non-ferrous metals and ceramic materials (dissimilar joints). Full article

Ultrasound-assisted transient liquid phase bonding (U-TLP) has been regarded as a promising brazing process to join magnesium alloys with a Sn and Zn interlayer; however, the formation of brittle magnesium intermetallic compounds (Mg₂Sn, MgZn, and MgZn₂) compromises the mechanical properties of the joints. In this study, Mg alloy U-TLP joints with a Ni interlayer were evaluated based on shear strength and hardness measurement. Microstructural evolution along with ultrasonic duration time and intermetallic compound formation were characterized using X-ray diffraction and electron microscopy methods. The results show that incremental ultrasonic durations of up to 30 s lead to the microstructural evolution from the Mg₂Ni layer, eutectic compounds (Mg₂Ni and α-Mg) to α-Mg (Ni), accompanied by shear strength increases. The maximum value of the shear strength is 107 MPa. The role that ultrasound vibration played in brazing was evaluated, and showed that the MgO film was broken by the acoustic softening effect when the interlayer and base metal were solid. As the MgO and Mg substrate have different stress reduction τ, this plastic mismatch helps to break the oxide film. Additionally, the diffusion between the solid Mg substrate and Ni interlayer is accelerated greatly by the acoustic pressure based on the DICTRA dynamic calculation. Full article

The effect of bonding temperature on the microstructure and mechanical properties of transient liquid phase (TLP) joints of GH4169 superalloy was investigated. Joining processes were carried out at 1040–1100 °C for 30 min using BNi-2 solder paste. The results showed that three distinct microstructural zones were formed in the joint region: an athermal solidification zone (ASZ), consisting of eutectic compounds; an isothermal solidification zone (ISZ), consisting of γ solid solution; and a diffusion affected zone (DAZ), consisting of Ni-Cr rich boride and Cr-Nb-Mo-rich boride compounds. With increasing bonding temperature, the amounts of eutectic compounds in ASZ first decreased and then increased. A eutectic-free joint centerline was obtained at 1080 °C. The maximum bonding shear strength reached 728.03 MPa due to the completion of isothermal solidification. Fractographic studies revealed that the boride compounds in ASZ and the intermetallic compounds in DAZ were the main causes for the failure of joints. The fracture mode of the sample bonded at 1040 °C was brittle, and the fracture path was along the ASZ. However, the fracture mode of the sample bonded at 1080 °C was ductile, and the fracture occurred along the DAZ. Full article

Ti-6Al-4V and Mg-AZ31 were bonded together using the Transient Liquid Phase Bonding Process (TLP) after coating both surfaces with zinc. The zinc coatings were applied using the screen printing process of zinc paste. Successful bonds were obtained in a vacuum furnace at 500 °C and under a uniaxial pressure of 1 MPa using high frequency induction heat sintering furnace (HFIHS). Various bonding times were selected and all gave solid joints. The bonds were successfully achieved at 5, 10, 15, 20, 25, and 30 min. The energy dispersive spectroscopy (EDS) line scan confirmed the diffusion of Zn in both sides but with more diffusion in the Mg side. Diffusion of Mg into the joint region was detected with significant amounts at bonds made for 20 min and above, which indicate that the isothermal solidification was achieved. In addition, Ti and Al from the base alloys were diffused into the joint region. Based on microstructural analysis, the joint mechanism was attributed to the formation of solidified mixture of Mg and Zn at the joint region with a presence of diffused Ti and Al. This conclusion was also supported by structural analysis of the fractured surfaces as well as the analysis across the joint region. The fractured surfaces were analyzed and it was concluded that the fractures occurred within the joint region where ductile fractures were observed. The strength of the joint was evaluated by shear test and found that the maximum shear strength achieved was 30.5 MPa for the bond made at 20 min. Full article

The prospect of joining titanium alloys to advanced ceramics and producing components with extraordinary and unique properties can expand the range of potential applications. This is extremely attractive in components for the automotive and aerospace industries where combining high temperature resistance, wear resistance and thermal stability with low density materials, good flowability and high oxidation resistance is likely. Therefore, a combination of distinct properties and characteristics that would not be possible through conventional production routes is expected. Due to the differences between the coefficients of thermal expansion (CTE) and Young's modulus of metals and ceramics, the most appropriate methods for such dissimilar bonding are brazing, diffusion bonding, and transient liquid phase (TLP) bonding. For the joining of titanium alloys to ceramics, brazing appears to be the most promising and cost-effective process although diffusion bonding and TLP bonding have clear advantages in the production of reliable joints. However, several challenges must be overcome to successfully produce these dissimilar joints. In this context, the purpose of this review is to point out the same challenges and the most recent advances that have been investigated to produce reliable titanium alloys and ceramic joints. Full article
