This paper investigates the quality of global cloud fraction and cloud-top height products provided by the third edition of the CM SAF cLoud, Albedo and surface RAdiation dataset from the AVHRR data (CLARA-A3) climate data record (CDR) produced by the EUMETSAT Climate Monitoring Satellite Application Facility (CM SAF). Compared with with CALIPSO–CALIOP cloud lidar data and six other cloud CDRs, including the predecessor CLARA-A2, CLARA-A3 has improved cloud detection, especially over ocean surfaces, and improved geographical variation and cloud detection efficiency. In addition, CLARA-A3 exhibits remarkable improvements in the accuracy of its global cloud-top height measurements. For example, in tropical regions, previous underestimations for high-level clouds are reduced by more than 2 km. By taking advantage of more realistic descriptions of global cloudiness, this study attempted to estimate trends in the observable fraction of low-level clouds, acknowledging their importance in producing a net climate cooling effect. The results were generally inconclusive in the tropics, mainly due to the interference of El Nino modes during the period under study. However, the analysis found small negative trends over oceanic surfaces outside the core tropical region. Further studies are needed to verify the significance of these results. Full article

Given the important role of clouds in our planet’s climate system, it is crucial to further improve our understanding of their governing processes as well as the resulting spatio-temporal variability of their properties. This co-variability of different cloud optical properties is adequately represented through the well-established concept of cloud regimes. The focus of the present study lies on the creation of a cloud regime dataset over Europe, named “Cloud Regime dAtAset based on the CLAAS-2.1 climate data record” (CRAAS), in order to analyze their variability and their changes at different spatio-temporal scales. In addition, co-occurrences between the cloud regimes and large-scale weather patterns are investigated. The CLoud property dAtAset using Spinning Enhanced Visible and Infrared (SEVIRI) edition 2.1 (CLAAS-2.1) data record, which is produced by the Satellite Application Facility on Climate Monitoring (CM SAF), was used as the basis for the derivation of the cloud regimes over Europe for a 14-year period (2004–2017). In particular, the cloud optical thickness (COT) and cloud top pressure (CTP) products of CLAAS-2.1 were used in order to compute 2D histograms. Then, the k-means clustering algorithm was applied to the generated 2D histograms in order to derive the cloud regimes. Eight cloud regimes were identified, which, along with the geographical distribution of their frequency of occurrence, assisted in providing a detailed description of the climate of the cloud properties over Europe. The annual and diurnal variabilities of the eight cloud regimes were studied, and trends in their frequency of occurrence were also examined. Larger changes in the frequency of occurrence of the produced cloud regimes were found for a regime associated to alto- and nimbo-type clouds and for a regime connected to shallow cumulus clouds and fog (−0.65% and +0.70% for the time period of the study, respectively). Full article

The study compares the performance of satellite-based datasets and the Ångström–Prescott (AP) model in estimating the daily global horizontal irradiance (GHI) for stations in South Africa. The daily GHI from four satellites (namely SOLCAST, CAMS, NASA SSE, and CMSAF SARAH) and the Ångström–Prescott (AP) model are evaluated by validating them against ground observation data from eight radiometric stations located in all six macro-climatological regions of South Africa, for the period 2014-19. The evaluation is carried out under clear-sky, all-sky, and overcast-sky conditions. CLAAS-2 cloud fractional coverage data are used to determine clear and overcast sky days. The observed GHI data are first quality controlled using the Baseline Surface Radiation Network methodology and then quality control of the HelioClim model. The traditional statistical benchmarks, namely the relative mean bias error (rMBE), relative root mean square error (rRMSE), relative mean absolute error (rMAE), and the coefficient of determination (R²) provided information about the performance of the datasets. Under clear skies, the estimated datasets showed excellent performance with maximum rMBE, rMAE, and rRMSE less than 6.5% and a minimum R² of 0.97. In contrast, under overcast-sky conditions there was noticeably poor performance with maximum rMBE (24%), rMAE (29%), rRMSE (39%), and minimum R2 (0.74). For all-sky conditions, good correlation was found for SOLCAST (0.948), CMSAF (0.948), CAMS (0.944), and AP model (0.91); all with R2 over 0.91. The maximum rRMSE for SOLCAST (10%), CAMS (12%), CMSAF (12%), and AP model (11%) was less than 13%. The maximum rMAE for SOLCAST (7%), CAMS (8%), CMSAF (8%), and AP model (9%) was less than 10%, showing good performance. While the R2 correlations for the NASA SSE satellite-based GHI were less than 0.9 (0.896), the maximum rRMSE was 18% and the maximum rMAE was 15%, showing rather poor performance. The performance of the SOLCAST, CAMS, CMSAF, and AP models was almost the same in the study area. CAMS, CMSAF, and AP models are viable, freely available datasets for estimating the daily GHI at South African locations with quantitative certainty. The relatively poor performance of the NASA SSE datasets in the study area could be attributed to their low spatial resolution of 0.5° × 0.5° (~55 km × 55 km). The feasibility of the datasets decreased significantly as the proportion of sky that was covered by clouds increased. The results of the study could provide a basis/data for further research to correct biases between in situ observations and the estimated GHI datasets using machine learning algorithms. Full article

This study assesses the performance of six global horizontal irradiance (GHI) clear sky models, namely: Bird, Simple Solis, McClear, Ineichen–Perez, Haurwitz and Berger–Duffie. The assessment is performed by comparing 1-min model outputs to corresponding clear sky reference 1-min Baseline Surface Radiation Network quality controlled GHI data from 13 South African Weather Services radiometric stations. The data used in the study range from 2013 to 2019. The 13 reference stations are across the six macro climatological regions of South Africa. The aim of the study is to identify the overall best performing clear sky model for estimating minute GHI in South Africa. Clear sky days are detected using ERA5 reanalysis hourly data and the application of an additional 1-min automated detection algorithm. Metadata for the models’ inputs were sourced from station measurements, satellite platform observations, reanalysis and some were modelled. Statistical metrics relative Mean Bias Error (rMBE), relative Root Mean Square Error (rRMSE) and the coefficient of determination (R²) are used to categorize model performance. The results show that each of the models performed differently across the 13 stations and in different climatic regions. The Bird model was overall the best in all regions, with an rMBE of 1.87%, rRMSE of 4.11% and R² of 0.998. The Bird model can therefore be used with quantitative confidence as a basis for solar energy applications when all the required model inputs are available. Full article

Climate Monitoring Satellite Application Facility (CM SAF) surface solar irradiance (SSI) products were compared with ground-based observations over the Piedmont region (north-western Italy) for the period 1990–2016. These products were SARAH-2.1 (Surface Solar Radiation DataSet—Heliosat version 2.1) and CLARA-A2 (Cloud, Albedo and Surface Radiation dataset version A2). The aim was to contribute to the discussion on the representativeness of satellite SSI data including a focus on high-elevation areas. The comparison between SSI averages shows that for low OCI (orographic complexity index) stations, satellite series have higher values than corresponding ground-based observations, whereas for high OCI stations, SSI values for satellite records are mainly lower than for ground stations. The comparison between SSI anomalies highlights that satellite records have an excellent performance in capturing SSI day-to-day variability of ground-based low OCI stations. In contrast, for high OCI stations, the agreement is much lower, due to the higher uncertainty in both satellite and ground-based records. Finally, if the temporal trends are considered, average low-elevation ground-based SSI observations show a positive trend, whereas satellite records do not highlight significant trends. Focusing on high-elevation stations, the observed trends for ground-based and satellite records are more similar with the only exception of summer. This divergence seems to be due to the relevant role of atmospheric aerosols on SSI trends. Full article

Clouds are one of the major uncertainties of the climate system. The study of cloud processes requires information on cloud physical properties, in particular liquid water path (LWP). This parameter is commonly retrieved from satellite data using look-up table approaches. However, existing LWP retrievals come with uncertainties related to assumptions inherent in physical retrievals. Here, we present a new retrieval technique for cloud LWP based on a statistical machine learning model. The approach utilizes spectral information from geostationary satellite channels of Meteosat Spinning-Enhanced Visible and Infrared Imager (SEVIRI), as well as satellite viewing geometry. As ground truth, data from CloudNet stations were used to train the model. We found that LWP predicted by the machine-learning model agrees substantially better with CloudNet observations than a current physics-based product, the Climate Monitoring Satellite Application Facility (CM SAF) CLoud property dAtAset using SEVIRI, edition 2 (CLAAS-2), highlighting the potential of such approaches for future retrieval developments. Full article

Data from the Advanced Very High Resolution Radiometer (AVHRR) have been used to create several long-duration data records of geophysical variables describing the atmosphere and land and water surfaces. In the Climate Monitoring Satellite Application Facility (CM SAF) project, AVHRR data are used to derive the Cloud, Albedo, and Radiation (CLARA) climate data records of radiation components (i.a., surface albedo) and cloud properties (i.a., cloud cover). This work describes the methodology implemented for the additional estimation of the Outgoing Longwave Radiation (OLR), an important Earth radiation budget component, that is consistent with the other CLARA variables. A first step is the estimation of the instantaneous OLR from the AVHRR observations. This is done by regressions on a large database of collocated observations between AVHRR Channel 4 (10.8 µm) and 5 (12 µm) and the OLR from the Clouds and Earth’s Radiant Energy System (CERES) instruments. We investigate the applicability of this method to the first generation of AVHRR instrument (AVHRR/1) for which no Channel 5 observation is available. A second step concerns the estimation of daily and monthly OLR from the instantaneous AVHRR overpasses. This step is especially important given the changes in the local time of the observations due to the orbital drift of the NOAA satellites. We investigate the use of OLR in the ERA5 reanalysis to estimate the diurnal variation. The developed approach proves to be valuable to model the diurnal change in OLR due to day/night time warming/cooling over clear land. Finally, the resulting monthly mean AVHRR OLR product is intercompared with the CERES monthly mean product. For a typical configuration with one morning and one afternoon AVHRR observation, the Root Mean Square (RMS) difference with CERES monthly mean OLR is about 2 Wm⁻² at 1° × 1° resolution. We quantify the degradation of the OLR product when only one AVHRR instrument is available (as is the case for some periods in the 1980s) and also the improvement when more instruments are available (e.g., using METOP-A, NOAA-15, NOAA-18, and NOAA-19 in 2012). The degradation of the OLR product from AVHRR/1 instruments is also quantified, which is done by “masking” the Channel 5 observations. Full article

Cloud screening in satellite imagery is essential for enabling retrievals of atmospheric and surface properties. For climate data record (CDR) generation, cloud screening must be balanced, so both false cloud-free and false cloudy retrievals are minimized. Many methods used in recent CDRs show signs of clear-conservative cloud screening leading to overestimated cloudiness. This study presents a new cloud screening approach for Advanced Very-High-Resolution Radiometer (AVHRR) and Spinning Enhanced Visible and Infrared Imager (SEVIRI) imagery based on the Bayesian discrimination theory. The method is trained on high-quality cloud observations from the Cloud-Aerosol Lidar with Orthogonal Polarization (CALIOP) lidar onboard the Cloud-Aerosol Lidar and Infrared Pathfinder Satellite Observations (CALIPSO) satellite. The method delivers results designed for optimally balanced cloud screening expressed as cloud probabilities together with information on for which clouds (minimum cloud optical thickness) the probabilities are valid. Cloud screening characteristics over 28 different Earth surface categories were estimated. Using independent CALIOP observations (including all observed clouds) in 2010 for validation, the total global hit rates for AVHRR data and the SEVIRI full disk were 82% and 85%, respectively. High-latitude oceans had the best performance, with a hit rate of approximately 93%. The results were compared to the CM SAF cLoud, Albedo, and surface RAdiation dataset from AVHRR data–second edition (CLARA-A2) CDR and showed general improvements over most global regions. Notably, the Kuipers’ Skill Score improved, verifying a more balanced cloud screening. The new method will be used to prepare the new CLARA-A3 and CLAAS-3 (CLoud property dAtAset using SEVIRI, Edition 3) CDRs in the EUMETSAT Climate Monitoring Satellite Application Facility (CM SAF) project. Full article

Five satellite top-of-atmosphere (TOA) albedo products over land were evaluated in this study including global products from the Advanced Very High Resolution Radiometer (AVHRR) (TAL-AVHRR), Moderate Resolution Imaging Spectroradiometer (MODIS) (TAL-MODIS), and Clouds and the Earth’s Radiant Energy System (CERES); one regional product from the Climate Monitoring Satellite Application Facility (CM SAF); and one harmonized product termed Diagnosing Earth’s Energy Pathways in the Climate system (DEEP-C). Results showed that overall, there is good consistency among these five products, particularly after the year 2000. The differences among these products in the high-latitude regions were relatively larger. The percentage differences among TAL-AVHRR, TAL-MODIS, and CERES were generally less than 20%, while the differences between TAL-AVHRR and DEEP-C before 2000 were much larger. Except for the obvious decrease in the differences after 2000, the differences did not show significant changes over time, but varied among different regions. The differences between TAL-AVHRR and the other products were relatively large in the high-latitude regions of North America, Asia, and the Maritime Continent, while the differences between DEEP-C and CM SAF in Europe and Africa were smaller. Interannual variability was consistent between products after 2000, before which the differences among the three products were much larger. Full article

Can we build stable Climate Data Records (CDRs) spanning several satellite generations? This study outlines how the ClOud Fractional Cover dataset from METeosat First and Second Generation (COMET) of the EUMETSAT Satellite Application Facility on Climate Monitoring (CM SAF) was created for the 25-year period 1991–2015. Modern multi-spectral cloud detection algorithms cannot be used for historical Geostationary (GEO) sensors due to their limited spectral resolution. We document the innovation needed to create a retrieval algorithm from scratch to provide the required accuracy and stability over several decades. It builds on inter-calibrated radiances now available for historical GEO sensors. It uses spatio-temporal information and a robust clear-sky retrieval. The real strength of GEO observations—the diurnal cycle of reflectance and brightness temperature—is fully exploited instead of just accounting for single “imagery”. The commonly-used naive Bayesian classifier is extended with covariance information of cloud state and variability. The resulting cloud fractional cover CDR has a bias of 1% Mean Bias Error (MBE), a precision of 7% bias-corrected Root-Mean-Squared-Error (bcRMSE) for monthly means, and a decadal stability of 1%. Our experience can serve as motivation for CDR developers to explore novel concepts to exploit historical sensor data. Full article

The EUMETSAT Satellite Application Facility on Climate Monitoring (CM SAF) provides satellite-based climate data records of essential climate variables of the energy budget and water cycle. The data records are generally distributed in NetCDF format. To simplify the preparation, analysis, and visualization of the data, CM SAF provides the so-called CM SAF R Toolbox. This is a collection of R-based tools, which are optimized for spatial data with longitude, latitude, and time dimension. For analysis and manipulation of spatial NetCDF-formatted data, the functionality of the cmsaf R-package is implemented. This R-package provides more than 60 operators. The visualization of the data, its properties, and corresponding statistics can be done with an interactive plotting tool with a graphical user interface, which is part of the CM SAF R Toolbox. The handling, functionality, and visual appearance are demonstrated here based on the analysis of sunshine duration in Europe for the year 2018. Sunshine duration in Scandinavia and Central Europe was extraordinary in 2018 compared to the long-term average. Full article

Clouds are of high importance for the climate system but they still remain one of its principal uncertainties. Remote sensing techniques applied to satellite observations have assisted tremendously in the creation of long-term and homogeneous data records; however, satellite data sets need to be validated and compared with other data records, especially ground measurements. In the present study, the spatiotemporal distribution and variability of Total Cloud Cover (TCC) from the Satellite Application Facility on Climate Monitoring (CM SAF) Cloud, Albedo And Surface Radiation dataset from AVHRR data—edition 2 (CLARA-A2) and the International Satellite Cloud Climatology Project H-series (ISCCP-H) is analyzed over Europe. The CLARA-A2 data record has been created using measurements of the Advanced Very High Resolution Radiometer (AVHRR) instrument onboard the polar orbiting NOAA and the EUMETSAT MetOp satellites, whereas the ISCCP-H data were produced by a combination of measurements from geostationary meteorological satellites and the AVHRR instrument on the polar orbiting satellites. An intercomparison of the two data records is performed over their common period, 1984 to 2012. In addition, a comparison of the two satellite data records is made against TCC observations at 22 meteorological stations in Europe, from the European Climate Assessment & Dataset (ECA&D). The results indicate generally larger ISCCP-H TCC with respect to the corresponding CLARA-A2 data, in particular in the Mediterranean. Compared to ECA&D data, both satellite datasets reveal a reasonable performance, with overall mean TCC biases of 2.1 and 5.2% for CLARA-A2 and ISCCP-H, respectively. This, along with the higher correlation coefficients between CLARA-A2 and ECA&D TCC, indicates the better performance of CLARA-A2 TCC data. Full article

A model based on the known high correlation between photosynthetically active radiation (PAR) and global horizontal irradiance (GHI) was implemented to estimate PAR from GHI measurements in this present study. The model has been developed using satellite-derived GHI and PAR estimations. Both variables can be estimated using Kato bands, provided by Satellite Application Facility on Climate Monitoring (CM-SAF), and its ratio may be used as the variable of interest in order to obtain the model. The study area, which was located in mainland Spain, has been split by cluster analysis into regions with similar behavior, according to this ratio. In each of these regions, a regression model estimating PAR from GHI has been developed. According to the analysis, two regions are distinguished in the study area. These regions belong to the two climates dominating the territory: an Oceanic climate on the northern edge; and a Mediterranean climate with hot summer in the rest of the study area. The models obtained for each region have been checked against the ground measurements, providing correlograms with determination coefficients higher than 0.99. Full article

The CM SAF Cloud Fractional Cover dataset from Meteosat First and Second Generation (COMET, https://doi.org/10.5676/EUM_SAF_CM/CFC_METEOSAT/V001) covering 1991–2015 has been recently released by the EUMETSAT Satellite Application Facility for Climate Monitoring (CM SAF). COMET is derived from the MVIRI and SEVIRI imagers aboard geostationary Meteosat satellites and features a Cloud Fractional Cover (CFC) climatology in high temporal (1 h) and spatial (0.05° × 0.05°) resolution. The CM SAF long-term cloud fraction climatology is a unique long-term dataset that resolves the diurnal cycle of cloudiness. The cloud detection algorithm optimally exploits the limited information from only two channels (broad band visible and thermal infrared) acquired by older geostationary sensors. The underlying algorithm employs a cyclic generation of clear sky background fields, uses continuous cloud scores and runs a naïve Bayesian cloud fraction estimation using concurrent information on cloud state and variability. The algorithm depends on well-characterized infrared radiances (IR) and visible reflectances (VIS) from the Meteosat Fundamental Climate Data Record (FCDR) provided by EUMETSAT. The evaluation of both Level-2 (instantaneous) and Level-3 (daily and monthly means) cloud fractional cover (CFC) has been performed using two reference datasets: ground-based cloud observations (SYNOP) and retrievals from an active satellite instrument (CALIPSO/CALIOP). Intercomparisons have employed concurrent state-of-the-art satellite-based datasets derived from geostationary and polar orbiting passive visible and infrared imaging sensors (MODIS, CLARA-A2, CLAAS-2, PATMOS-x and CC4CL-AVHRR). Averaged over all reference SYNOP sites on the monthly time scale, COMET CFC reveals (for 0–100% CFC) a mean bias of −0.14%, a root mean square error of 7.04% and a trend in bias of −0.94% per decade. The COMET shortcomings include larger negative bias during the Northern Hemispheric winter, lower precision for high sun zenith angles and high viewing angles, as well as an inhomogeneity around 1995/1996. Yet, we conclude that the COMET CFC corresponds well to the corresponding SYNOP measurements, and it is thus useful to extend in both space and time century-long ground-based climate observations. Full article

A method for reducing the impact of noise in the 3.7 micron spectral channel in climate data records derived from coarse resolution (4 km) global measurements from the Advanced Very High Resolution Radiometer (AVHRR) data is presented. A dynamic size-varying median filter is applied to measurements guided by measured noise levels and scene temperatures for individual AVHRR sensors on historic National Oceanic and Atmospheric Administration (NOAA) polar orbiting satellites in the period 1982–2001. The method was used in the preparation of the CM SAF cLoud, Albedo and surface RAdiation dataset from AVHRR data—Second Edition (CLARA-A2), a cloud climate data record produced by the EUMETSAT Satellite Application Facility for Climate Monitoring (CM SAF), as well as in the preparation of the corresponding AVHRR-based datasets produced by the European Space Agency (ESA) Climate Change Initiative (CCI) project ESA-CLOUD-CCI. The impact of the noise filter was equivalent to removing an artificial decreasing trend in global cloud cover of 1–2% per decade in the studied period, mainly explained by the very high noise levels experienced in data from the first satellites in the series (NOAA-7 and NOAA-9). Full article
