Geotechnical field testing evaluates soil, rock, and groundwater conditions in their natural states, offering critical information about subsurface properties such as the density, strength, permeability, and groundwater flow. These tests are essential in ensuring the safety, reliability, and performance of civil engineering projects and are increasingly used for 3D geographical visualization and subsurface modeling. While point-based tests like the cone penetration test (CPT) and standard penetration test (SPT) are widely used, area-based methods such as the spectral analysis of surface waves (SASW) and electrical resistivity testing significantly enhance the accuracy of such models by providing broader coverage. Furthermore, these non-destructive techniques are particularly effective in identifying subsurface defects. This study focuses on analyzing the data acquisition areas of various field seismic tests, including SASW, downhole, crosshole, and suspension logging (PS logging). While other tests clearly define data acquisition areas based on their array paths, the SASW test posed challenges due to the complexity of data reconstruction. To address this, 69 datasets from four different sites were analyzed to predict the data acquisition areas for SASW as a function of depth. Moreover, a case study demonstrates the practical application of the SASW method in detecting cavities near a dam spillway. The findings of this research improve the understanding and interpretation of geotechnical seismic test data, enabling more precise geotechnical investigations and advancing the detection of subsurface defects using non-destructive methods. Full article

The nondestructive spectral analysis of surface waves (SASW) technique determines the shear wave velocities along the wide wavelength range using Rayleigh-type surface waves that propagate along pairs of receivers on the surface. The typical configuration of source-receivers consists of a vertical source and three vertical receivers arranged in a linear array. While this approach allows for effective site characterization, laterally variable sites are often challenging to characterize. In addition, in a traditional SASW test configuration system, where sources are placed in one direction, the data are collected more on one side, which can cause an imbalance in the interpretation of the data. Data interpretation issues can be resolved by moving the source to opposite ends of the original array and relocating receivers to perform a second complete set of tests. Consequently, two different Vs profiles can be provided with only a small amount of additional time at sites where lateral variability exists. Furthermore, the testing procedure can be modified to enhance the site characterization during data collection. The advantages of performing SASW testing in both directions are discussed using a real case study. Full article

This paper introduces an efficient computational procedure for analyzing the propagation of harmonic waves in layered elastic media. This offers several advantages, including the ability to handle arbitrary frequencies, depths, and the number of layers above an elastic half-space, and efforts to follow dispersion curves and flag up possible singularities are investigated. While there are inherent limitations in terms of computational accuracy and capacity, this methodology is straightforward to implement for studying free or forced vibrations and obtaining relevant response data. We present computations of wavenumber dispersion diagrams, phase velocity plots, and response data in both the frequency and time domains. These computational results are provided for two example cases: plane strain and axisymmetry. Our methodology is grounded in a well-conditioned dynamic stiffness approach specifically tailored for deep-layered strata analysis. We introduce an innovative method for efficiently computing wavenumber dispersion curves. By tracking the slope of these curves, users can effectively manage continuation parameters. We illustrate this technique through numerical evidence of a layer resonance in a real-life case study characterized by a fold in the dispersion curves. Furthermore, this framework is particularly advantageous for engineers addressing problems related to ground-borne vibrations. It enables the analysis of phenomena such as zero group velocity (ZGV), where a singularity occurs, both in the frequency and time domains, shedding light on the unique characteristics of such cases. Given the reduced dimension of the problem, this formulation can considerably aid geophysicists and engineers in areas such as MASW or SASW techniques. Full article

Before conducting pavement rehabilitation, the concrete pavement performance evaluation is more than necessary to assess the strength and analyze the internal condition. To evaluate the modulus performance of concrete pavement and provide theoretical support for subsequent maintenance and rehabilitation, the SASW (Spectral-Analysis-of-Surface-Waves) method, a non-destructive testing method based on surface waves, was used to determine the modulus of three in-service concrete pavements. At the same time, FWD (Falling Weight Deflectometer) testing and on-site coring were carried out at the measuring points. Through the analysis of modulus results measured in the field, it was found that the SASW method can accurately obtain the elastic modulus of the concrete layer and base layer. Compared with the concrete modulus measured by FWD, the modulus measured by the SASW method was closer to the uniaxial compressive modulus. Moreover, since the SASW method has the ability to provide gradient modulus varying with depth and determine the pavement thicknesses, it is reasonable to recognize the location of the inherent distress based on the region where the modulus suddenly decreases within one layer. The comprehensive evaluation of concrete pavement condition, including the modulus value and internal distress recognition, has the capability to assist in determining the design of overlay asphalt thickness and material. Full article

CrN coatings are widely used in the industry due to their excellent mechanical features and outstanding wear and corrosion resistance. Using scratch and ball-on-disk wear tests, the current study deals with the tribological characterisation of CrN coatings deposited onto an X42Cr13 plastic mould tool steel. Two surface conditions of the secondary-hardened substrate are compared—the plasma nitrided (duplex treated) and the un-nitrided (simply coated) states. The appropriate combination of secondary hardening providing the maximum toughness and the high-temperature nitriding of this high Cr steel is a great challenge due to the nitrogen-diffusion-inhibiting effect of Cr. The beneficial effect of the applied duplex treatment is proven by the 34% improvement of the adhesion strength and the 43% lower wear rate of the investigated duplex coatings. Detailed morphological analyses give insight into the characteristic damage mechanisms controlling the coating failure processes during scratching and wearing. For the simply CrN-coated sample, a new type of scratch damage mechanism, named “SAS-wings”, is identified, providing useful information in predicting the final failure of the coating. The tribological results obtained on tribosystems with the investigated high Cr steel/CrN constituents represent a novelty in the given field. Full article

One of the complex processes in spectral analysis of surface waves (SASW) data analysis is the inversion procedure. An initial soil profile needs to be assumed at the beginning of the inversion analysis, which involves calculating the theoretical dispersion curve. If the assumption of the starting soil profile model is not reasonably close, the iteration process might lead to nonconvergence or take too long to be converged. Automating the inversion procedure will allow us to evaluate the soil stiffness properties conveniently and rapidly by means of the SASW method. Multilayer perceptron (MLP), random forest (RF), support vector regression (SVR), and linear regression (LR) algorithms were implemented in order to automate the inversion. For this purpose, the dispersion curves obtained from 50 field tests were used as input data for all of the algorithms. The results illustrated that SVR algorithms could potentially be used to estimate the shear wave velocity of soil. Full article

In Bangkok, the demand for housing is extensively high due to the city growing rapidly, so some swampy areas are filled with soil. A Prefabricated Vertical Drain (PVD) with the Vacuum Consolidation Method (VCM) is required to make the soil applicable for construction. However, it is difficult to monitor the soil strength during the process because the airtight sheet will be broken. This research aims to study the possibility of using the Spectral Analysis of Surface Waves (SASW) test to monitor the effectiveness of the VCM method and to study the development of shear-wave velocity over the consolidation period. Multiple instruments were installed on site, namely, vacuum gauges, settlement plates, and a piezometer, as well as a borehole to monitor the pump pressure, settlement, porewater pressure, and soil properties. Ten SASW tests were taken to measure the change in shear-wave velocity (Vs) over 7 months. The results showed an increment in the Vs along with increments in the settlement and undrained shear strength (Su), as well as a decrement in pore pressure during the consolidation period. The correlation between Vs and soil settlement was developed to predict the amount of settlement using Vs. These all indicated the potential of using the SASW method for soil improvement monitoring purposes. Full article

This research aims to propose the use of spectral analysis of surface wave (SASW) tests along with in-situ suction measurements for non-destructive determination of shrinkage cracks. The underlying principle behind this proposed method is that, while suction and the small-strain shear modulus are positively correlated for intact samples, this is not the case for cracked ground. A series of SASW tests were performed on a clay embankment at different periods, during which the suction, modulus, and shrinkage crack depth varied seasonally. The soil water retention curve (SWRC) of the undisturbed sample collected from the cracked zone was determined, which related the suction-to-moisture content and void ratio of the soil. A free-free resonant frequency (FFR) test in the lab was conducted to determine the small-strain shear modulus (G₀) at various moisture contents. The small-strain moduli from the SASW tests on the intact ground were generally higher than those from the FFR tests due to the effect of confining stress. A drop in the small-strain modulus determined using the SASW test was observed as an increase in suction-induced cracks and it relieved the horizontal stress. The crack depth measured in the field was then modelled using a semi-empirical procedure that can be used to predict crack depth relative to suction. Full article

The current methods for evaluating the contact condition between concrete and lining were the ground penetrating radar (GPR) and the coring method. The penetration of radar electromagnetic waves was greatly affected by steel reinforcement and water, which often made the detection results of GPR unsatisfactory. A spectral analysis of the surface wave (SASW) method was used to evaluate the concrete-bedrock interface condition for hydraulic tunnel linings in this paper, since the impact elastic wave is less affected by steel bars and water content. An SASW implementation program based on fast Fourier transformation (FFT) was developed to analyze data from numerical simulations and field tests. Various models were studied to investigate the feasibility of using numerical analysis. For the first time, the study was employed to find out the influences of different receiver spacings and impact duration on the efficiency of detecting the existence of a weak layer underneath the concrete using the SASW method. On this basis, in-situ tests were carried out to verify the applicability in the field and results were verified by coring. In the research, the following results were found: (1) The finite element analysis results of different uniform or layered models showed that the SASW method could accurately identify the interface contact condition between the concrete lining and bedrock, especially the existence of voids; (2) when the receiver spacing was 1.0–1.5 times the thickness of the target object to be inspected, the quality of the collected signal data was the best; (3) under a certain reasonable range, the impact duration had an insignificant effect on the phase spectra and dispersion curves of a concrete-weak layer model; (4) in-situ SASW inspection could accurately tell whether the voids exist at the concrete-bedrock interface; and (5) the data processing program of the SASW method based on the MATLAB platform was accurate, convenient, and worth promoting. Full article

Spectral Analysis of Surface Wave (SASW) is widely used in nondestructive subsurface profiling for geological sites. The air-coupled SASW is an extension from conventional SASW methods by replacing ground-mounted accelerometers with non-contact microphones, which acquire a leaky surface wave instead of ground vibration. The air-coupled SASW is a good candidate for fast inspection in shallow geological studies. Especially for pavement maintenance, minimum traffic interference might be induced. One issue that restrains SASW from fast inspection is the traditional slow inversion which relies on guess-and-check iteration techniques including a forward analysis. In this article, a fast inversion analysis algorithm is proposed to estimate the shear velocity profile without performing conventional forward simulation. By investigating the attenuation of particle displacement along penetrating depths, a weighted combination relationship is derived to connect the dispersion curve with the shear velocity profile directly. Using this relationship, the shear velocity profile could be estimated from a given/measured dispersion curve. The proposed procedure allows the surface wave-based method to be fully automatic and even operated in real-time for geological site and pavement assessment. The method is verified by the forward analysis with stiffness matrix method. It is also proved by comparing with other published results using various inversion methods. Full article

Surface waves are commonly used for vibration-based nondestructive testing for infrastructure. Spectral Analysis of Surface Waves (SASW) has been used to detect subsurface properties for geologic inspections. Recently, efforts were made to scale down these subsurface detection approaches to see how they perform on small-scale structures such as concrete slabs and pavements. Additional efforts have been made to replace the traditional surface-mounted transducers with non-contact acoustic transducers. Though some success has been achieved, most of these new approaches are inefficient because they require point-to-point measurements or off-line signal analysis. This article introduces a Mobile Acoustic Subsurface Sensing system as MASS, which is an improved surface wave based implementation for measuring the subsurface profile of roadways. The compact MASS system is a 3-wheeled cart outfitted with an electromagnetic impact source, distance register, non-contact acoustic sensors and data acquisition/ processing equipment. The key advantage of the MASS system is the capability to collect measurements continuously at walking speed in an automatic way. The fast scan and real-time analysis advantages are based upon the non-contact acoustic sensing and fast air-coupled surface wave analysis program. This integration of hardware and software makes the MASS system an efficient mobile prototype for the field test. Full article
