Landsat 8 Level 2 Collection 2 (L2C2) surface reflectance (SR) products are widely used in various scientific applications by the remote sensing community, where their accuracy is vital for reliable analysis. However, discrepancies have been observed at shorter wavelength bands, which can affect certain applications. This study investigates the root cause of these differences by analyzing the assumptions made in the Land Surface Reflectance Code (LaSRC), the atmospheric correction algorithm of Landsat 8, as currently implemented at United States Geological Survey Earth Resources Observation and Science (USGS EROS), and proposes a correction method. To quantify these discrepancies, ground truth SR measurements from the Radiometric Calibration Network (RadCalNet) and Arable Mark 2 sensors were compared with the Landsat 8 SR. Additionally, the surface pressure measurements from RadCalNet and the National Centers for Environmental Information (NCEI) were evaluated against the LaSRC-calculated surface pressure values. The findings reveal that the discrepancies arose from using a single scene center surface pressure for the entire Landsat 8 scene pixels. The pressure-related discrepancies were most pronounced in the coastal aerosol and blue bands, with greater deviations observed in regions where the elevation of the study area differed substantially from the scene center, such as Railroad Valley Playa (RVUS) and Baotao Sand (BSCN). To address this issue, an exponential correction model was developed, reducing the mean error in the coastal aerosol band for RVUS from 0.0226 to 0.0029 (about two units of reflectance), which can be substantial for dark vegetative and water targets. In the blue band, there is a smaller improvement in the mean error, from 0.0095 to −0.0032 (about half a unit of reflectance). For the green band, the reduction in error was much less due to the significantly lesser impact of aerosol on this band. Overall, this study underscores the need for a more precise estimation of surface pressure in LaSRC to enhance the reliability of Landsat 8 SR products in remote sensing applications. Full article

The reflectance-based vicarious calibration approach uses measurements at well-understood test sites to provide top-of-atmosphere reference reflectance values suitable for inter-calibration approaches and does not require coincident views. The challenge is that results from such data may suffer from high variability from day to day. Data from high-quality sensors, such as the imaging spectrometers on the International Space Station (ISS) platform, provide an opportunity to use improved fine spectral information about the test sites with various sun/sensor geometries and site surface and atmospheric conditions to improve the test sites’ characterization. The results here are based on data from the DLR Earth Sensing Imaging Spectrometer (DESIS) instrument installed on the ISS since 2018 combined with output from the Radiometric Calibration Network (RadCalNet) site at Railroad Valley Playa (RRV) to decouple the effects of sun/sensor geometry from the RadCalNet predictions. The approach here uses the precessing orbit of the ISS to allow similar sensor view zenith angles at varying sun angles over short periods that limit the impact of any sensor changes and highlight the bi-directional effects of the surface reflectance and atmospheric conditions. DESIS data collected at (i) similar solar angles but varying view angles, (ii) similar sensor angles and varying solar angles, and (iii) similar scatter angles are compared. The DESIS results indicate that the top-of-atmosphere reflectance spectra for RRV at similar solar zenith angles but with varying sensor viewing angles provide more consistent data than those with varying solar zenith but with similar sensor viewing angles. In addition, comparisons of reflectance spectra of the site performed in terms of the sensor view scatter angle show good agreement, indicating that a directional reflectance correction would be straightforward and could offer a significant improvement in the use of RadCalNet data. The work shows that observations from imaging spectroscopy data from DESIS, and eventually Earth Surface Mineral Dust Source Investigation (EMIT), Surface Biology and Geology (SBG), and the climate-quality sensor CLARREO Pathfinder (CPF), provide the opportunity for the development of a model-based, SI-traceable prediction of at-sensor radiance over the RRV site that would serve as the basis for similar site characterizations with error budgets valid for arbitrary view and illumination angles. Full article

This paper presents a comprehensive intercomparison study investigating the radiometric performance of and concurrence among the Advanced Spaceborne Thermal Emission and Reflection Radiometer (ASTER), Landsat 8 Operational Land Imager (L8 OLI), and Landsat 9 OLI (L9 OLI) instruments. This study leverages data sourced from the Radiometric Calibration Network (RadCalNet) and focuses on spectral bands relevant for vegetation analysis and land cover classification, encompassing a thorough assessment of data quality, uncertainties, and underlying influencing factors. This study’s outcomes underscore the efficacy of RadCalNet in evaluating the precision and reliability of remote sensing data, offering valuable insights into the strengths and limitations of ASTER, L8 OLI, and L9 OLI. These insights serve as a foundation for informed decision making in environmental monitoring and resource management, highlighting the pivotal role of RadCalNet in gauging the radiometric performance of remote sensing sensors. Results from RadCalNet sites, namely Railroad Valley Playa and Gobabeb, show their possible suitability for sensors with spatial resolutions down to 15 m. The results indicate that the measurements from both ASTER and OLI closely align with the data from RadCalNet, and the observed agreement falls comfortably within the total range of potential errors associated with the sensors and the test site information. Full article

The radiometric calibration network (RadCalNet) comprises four pseudo-invariant calibration sites (PICS): Gobabeb, Baotou, Railroad Valley Playa, and La Crau. Due to its site stability characteristics, it is widely used for sensor performance monitoring and radiometric calibration, which require high spatiotemporal stability. However, some studies have found that PICS are not invariable. Previous studies used top-of-atmosphere (TOA) data without verifying site data, which could affect the accuracy of their results. In this study, we analyzed the short- and long-term radiometric trends of RadCalNet sites using bottom-of-atmosphere (BOA) data, and verified the trends revealed by the TOA data from Landsat 7, 8, and Sentinel-2. Besides the commonly used methods (e.g., nonparametric Mann–Kendall and sequential Mann–Kendall tests), a more robust Sen’s slope method was used to estimate the magnitude of the change. We found that (1) the trends based on TOA reflectance contrasted with those based on BOA reflectance in certain cases, e.g., the reflectance trends in the red band of BOA data for La Crau in summer and autumn and Baotou were not significant, while the TOA data showed a significant downward trend; (2) the temporal trends showed statistically significant and abrupt changes in all PICS, e.g., the SWIR2 band of La Crau in winter and spring changed by 1.803% per year, and the SWIR1 band of Railroad Valley Playa changed by >0.282% per year, indicating that the real changes in sensor performance are hard to detect using these sites; (3) spatial homogeneity was verified using the coefficient of variation (CV) and Getis statistic (Gi*) for each PICS (CV < 3% and Gi* > 0). Overall, the RadCalNet remains a highly reliable tool for vicarious calibration; however, the temporal stability should be noted for radiometric performance monitoring of sensors. Full article

The Thompson River valley hosts 14 landslides along a 10 km section, which threaten the two major railroads connecting the Port of Vancouver and the interior provinces in Canada. The Ripley landslide is one of the active landslides in this section of the valley. Previous research at this site included an analysis of landslide deformations using satellite radar interferometry focusing on deformations measured in the line of sight between the satellite and the slopes, and average downslope displacement (deformations projected in the average downslope direction). Since then, further stratigraphic interpretation has provided an enhanced understanding of the Ripley landslide. In this update, the new stratigraphic interpretation is supplemented with satellite InSAR data from May 2015 to May 2017 to enhance the current understanding of the landslide kinematics. The results indicate that the Ripley landslide has been moving at a rate between 2 and 82 mm per year, corresponding to a very slow to slow landslide. It is also observed that the movements tend to be near-horizontal on areas closer to the toe of the landslide, while the vertical component of deformation increases near the scarp of the landslide. This, together with the interpreted stratigraphy, indicates the kinematics corresponds to a compound landslide. This is consistent with interpreted landslide kinematics of older, more mature landslides in the area that have shown episodes of retrogression and suggests the possibility of a similar future behaviour of the Ripley landslide. Full article

In contrast to river floods, the enormous erosion potential in catchments contributes significantly to the extent of damage to infrastructure in valleys. This paper investigates the impact of the heavy precipitation event of 14–15 July 2021 on the railroad in the Ahr valley in Rhineland-Palatinate, Germany. In a first step, a detailed overview of the climatological and hydrological drivers using spatially high-resolved precipitation distribution and peak discharge modeling is provided, and the event is placed in a broader context by comparing it to past flash flood events from 1910 and 2016. In a second step, a detailed mapping of damages along the railroad line is performed using aerial photographs. The mapping revealed that bridges are the weakest point during a flood event and that they contribute to an increase and modification of the flood wave through backwater effects. Since flood events are expected to increase in the future, there is an urgent need to increase the resilience of transportation to this hazard and to answer the question of what magnitudes and return periods of events should be used in future sizing of rail infrastructure. Full article

The DLR Earth Sensing Imaging Spectrometer (DESIS) is the first hyperspectral imaging spectrometer installed in the Multi-User System for Earth Sensing (MUSES) on the International Space Station (ISS) for acquiring routine science grade images from orbit. It was launched on 29 June 2018 and integrated into MUSES. DESIS measures energy in the spectral range of 400 to 1000 nm with high spatial and spectral resolution: 30 m and 2.55 nm, respectively. DESIS data should be sufficiently quantitative and accurate to use it for different applications and research. This work performs a radiometric evaluation of DESIS Level 1 product (Top of Atmosphere (TOA) reflectance) by comparing it with coincident Radiometric Calibration Network (RadCalNet) measurements at Railroad Valley Playa (RVUS), Gobabeb (GONA), and La Crau (LCFR). RVUS, GONA, and LCFR offer 4, 15, and 5 coincident datasets between DESIS and RadCalNet measurements, respectively. The results show an agreement between DESIS and RadCalNet TOA reflectance within ~5% for most spectral regions. However, there is an additional ~5% disagreement across the wavelengths affected by water vapor absorption and atmospheric scattering. Among the three RadCalNet sites, RVUS and GONA show a similar measurement disagreement with DESIS of ~5%, while LCFR differs by ~10%. Agreement between DESIS and RadCalNet measurements is variable across all three sites, likely due to surface type differences. DESIS and RadCalNet agreement show a precision of ~2.5%, 4%, and 7% at RVUS, GONA, and LCFR, respectively. RVUS and GONA, which have a similar surface type, sand, have a similar level of radiometric accuracy and precision, whereas LCFR, which consists of sparse vegetation, has lower accuracy and precision. The observed precision of DESIS Level 1 products from all the sites, especially LCFR, can be improved with a better Bidirectional Reflection Distribution Function (BRDF) characterization of the RadCalNet sites. Full article

Vicarious calibration, as one on-orbit calibration method, is a supplement to onboard calibration of sensors. The application of vicarious calibration, however, is greatly limited due to the time- and effort-consuming field measurements of atmosphere and surface. Fortunately, the Radiometric Calibration Network (RadCalNet) provides automated in situ data at multiple sites, thus increasing the opportunities to achieve ongoing ground-reference calibration of in-orbit instruments. The MEdium Resolution Spectrum Imager-II (MERSI-II) onboard FengYun-3D (FY) has the temporal, spectral, spatial, and radiometric capacity for image capture at a level on par with other sensors used worldwide, such as the Moderate Resolution Imaging Spectroradiometer (MODIS). Its on-orbit radiometric performance, however, is assessed in a limited manner. In this study, the reflectance-based vicarious calibration method was employed to calibrate the MERSI-II sensor using ground measurements from RadCalNet at the Railroad Valley Playa site. The calibration of the MERSI-II sensor with large view angles presents difficulties due to the uncertainties introduced by surface bidirectional reflectance distribution function (BRDF) effects. Thus, we performed BRDF correction to harmonize the sensor and ground measurements to consistent observation geometries, before the in-situ measurements were taken as inputs for the 6SV radiative transfer model to predict at-sensor radiance. The calibration results were comprehensively validated with ground data and MODIS benchmark datasets. The results show that accounting for BRDF correction could improve the accuracy of vicarious calibration and ensure inter-consistency between different sensors. An analysis of the vicarious calibration of FY-3D MERSI-II yielded uncertainties of <5% for solar reflective bands, which meets the radiometric accuracy requirements typical for land-monitoring space missions. The proposed approach is also applicable to the calibration of other large footprint sensors. Full article

Radiometric calibration utilizing the Moon as a reference source is termed as lunar calibration. It is a useful method for evaluating the performance of optical sensors onboard satellites orbiting the Earth. Lunar calibration provides sufficient radiometric calibration opportunities without requiring any special equipment, and is suitable for nano/microsatellites. This study applies lunar calibration to a multispectral sensor, Ocean Observation Camera (OOC), on board a microsatellite named Rapid International Scientific Experiment Satellite. Simulating the brightness of the Moon based on the RObotic Lunar Observatory and SELENE/Spectrum Profiler models, sensitivity degradation was proven to be negligible in any of the four spectral bands of the OOC with the sensor temperature correction. A bluing trend in the OOC’s sensor sensitivity was revealed, indicating a shorter observation wavelength shows larger irradiance. Comparing the top-of-atmosphere reflectance of Railroad Valley Playa with the Radiometric Calibration Network dataset revealed that the derived calibration parameter from the lunar calibration was valid for correcting the bluing trend in the visible range. Although the lunar and vicarious calibration parameters for the infrared band were unexpectedly inconsistent, lunar calibration could potentially contribute toward estimating the contaminated background radiance in the Earth observation images. Full article

Surface reflectance products obtained through the absolute atmospheric correction of multispectral satellite images are useful for precise scientific applications. For broader applications, the reflectance products computed using high-resolution images need to be validated with field measurement data. This study dealt with 2.2-m resolution Korea Multi-Purpose Satellite (KOMPSAT)-3A images with four multispectral bands, which were used to obtain top-of-atmosphere (TOA) and top-of-canopy (TOC) reflectance products. The open-source Orfeo Toolbox (OTB) extension was used to generate these products. Next, these were subsequently validated by considering three sites (i.e., Railroad Valley Playa, NV, USA (RVUS), Baotou, China (BTCN), and La Crau, France (LCFR)) in RadCalNet, as well as a calibration and validation portal for remote sensing. We conducted the validations comparing satellite image-based reflectance products and field measurement reflectance based on data sets acquired at different times. The experimental results showed that the overall trend of validation accuracy of KOPSAT-3A was well fitted in all the RadCalNet sites and that the accuracy remained quite constant. Reflectance bands showing the minimum and maximum differences between the sets of experimental data are presented in this paper. The vegetation indices (i.e., the atmospherically resistant vegetation index (ARVI) and the structure insensitive pigment index (SIPI)) and three TOC reflectance bands obtained from KOMPSAT-3A were computed as a case study and used to achieve a detailed vegetation interpretation; finally, the correspondent results were compared with those obtained from Landsat-8 images (downloaded from the Google Earth Engine (GEE)). The validation and the application scheme presented in this study can be potentially applied to the generation of analysis ready data from high-resolution satellite sensor images. Full article

This paper aims to assess the relationship between the surface reflectance derived from ground based and aircraft measurements. The parameters of the Rahman–Pinty–Verstraete (RPV) and Ross Thick-LiSparse (RTLS) kernel based bi-directional reflectance distribution functions (BRDF), have been derived using actual measurements of the hemispherical-directional reflectance factor (HDRF), collected during different campaigns over the Railroad Valley Playa. The effect of the atmosphere, including that of the diffuse radiation on bi-directional reflectance factor (BRF) parameter retrievals, assessed using 6S model simulations, was negligible for the low turbidity conditions of the site under investigation (${\tau }_{550}\le 0.05$). It was also shown that the effects of the diffuse radiation on RPV spectral parameters retrieval is linear for the isotropic parameter ${\rho }_0$ and the scattering parameter $\mathrm{\Theta }$, and can be described with a second order polynomial for the k-Minnaert parameter. In order to overcome the lack of temporal collocations between aircraft and in-situ measurements, Monte Carlo 3-D radiative transfer simulations mimicking in-situ and remote sensing techniques were performed on a synthetic parametric meshed scene defined by merging Landsat and Multianglhe Imaging Spectroradiometer (MISR) remote sensing reflectance data. We simulated directional reflectance measurements made at different heights for PARABOLA and CAR, and analyzed them according to practices adopted for real measurements, consisting of the inversion of BRF functions and the calculation of the bi-hemispherical reflectance (BHR). The difference of retrievals against the known benchmarks of kernel parameters and BHR is presented. We associated an uncertainty of up to 2% with the retrieval of area averaged BHR, independently of flight altitudes and the BRF model used for the inversion. As expected, the local nature of PARABOLA data is revealed by the difference of the anisotropic kernel parameters with the corresponding parameters retrieved from aircraft loops. The uncertainty of the resultant BHR fell within $\pm 3\%$. Full article

Recently, the growing number of hyperspectral satellite sensors have increased the demand for a flexible and robust approach to their calibration. This paper proposes an operational method for the simultaneous correction of inter-sensor and inter-band biases in hyperspectral sensors via the soil line concept for spectral band adjustment. Earth Observing-1 Hyperion was selected as an example, with the Terra Moderate Resolution Imaging Spectroradiometer (MODIS) as a reference. The results over the Railroad Valley Playa calibration site indicated that the discrepancy in the analogous bands between Hyperion and MODIS during 2001–2008 was approximately 4–6% and 7–9% of the root-mean-square error in the top-of-atmosphere (TOA) radiance at the visible and near-infrared region and shortwave infrared region, respectively. For all Hyperion bands, the relative cross-calibration coefficients during this period were calculated (typically ranging from 0.9 to 1.1) to correct the Hyperion TOA radiance to be consistent with the MODIS and the other Hyperion bands. The application of the proposed approach could allow for more flexible cross-calibration of irregular-orbit sensors aboard the International Space Station. Full article

The Compact Infrared Camera (CIRC) instruments onboard the Advanced Land Observing Satellite-2 (ALOS-2) and the Calorimetric Electron Telescope (CALET) attached to the International Space Station are satellite-borne 2D-array thermal infrared cameras for technical demonstrations in fields such as forest fire monitoring, volcano monitoring, and heat island analysis. Since they have the characteristics of low cost and low power consumption and have no onboard calibrator such as a blackbody or shutter, in-flight calibration should be performed by vicarious calibration (VC) and cross-calibration (CC). In this study, we determined the recalibration coefficients for both of the CIRC instruments as a function of time based on VC experiments in Lake Kasumigaura (Japan) and Railroad Valley Playa (USA), VC with telemetry data from three lakes in Japan and the USA, and CC with imagers onboard two geostationary satellites (MTSAT-2 and Himawari-8). As a result, the derived recalibration coefficients improved the accuracy of the ground-testing-based radiance remarkably in both of the CIRC instruments, suggesting that the recalibrated radiance can satisfy the target accuracy of CIRC, given as 2 K at 300 K. These coefficients, as a function of time, will be applied to all CIRC images by reprocessing planned in the near future. Full article

A new Taiwanese satellite, FORMOSAT-5 (FS-5), with a payload remote sensing instrument (RSI) was launched in August 2017 to continue the mission of its predecessor FORMOSAT-2 (FS-2). Similar to FS-2, the RSI provides 2-m resolution panchromatic and 4-m resolution multi-spectral images as the primary payload on FS-5. However, the radiometric properties of the optical sensor may vary, based on the environment and time after being launched into the space. Thus, maintaining the radiometric quality of FS-5 RSI imagery is essential and significant to scientific research and further applications. Therefore, the objective of this study aimed at the on-orbit absolute radiometric assessment and calibration of on-orbit FS-5 RSI observations. Two renowned approaches, vicarious calibrations and cross-calibrations, were conducted at two calibration sites that employ a stable atmosphere and high surface reflectance, namely, Alkali Lake and Railroad Valley Playa in North America. For cross-calibrations, the Landsat-8 Operational Land Imager (LS-8 OLI) was selected as the reference. A second simulation of the satellite signal in the solar spectrum (6S) radiative transfer model was performed to compute the surface reflectance, atmospheric effects, and path radiance for the radiometric intensity at the top of the atmosphere. Results of vicarious calibrations from 11 field experiments demonstrated high consistency with those of seven case examinations of cross-calibration in terms of physical gain in spectra, implying that the practicality of the proposed approaches is high. Moreover, the multi-temporal results illustrated that RSI decay in optical sensitivity was evident after launch. The variation in the calibration coefficient of each band showed no obvious consistency (6%–24%) in 2017, but it tended to be stable at the order of 3%–5% of variation in most spectral bands during 2018. The results strongly suggest that periodical calibration is required and essential for further scientific applications. Full article

Vicarious calibration is the determination of an on-orbit sensor’s radiometric response using measurements over test sites such as Railroad Valley (RRV), Nevada. It has the highest accuracy when a remote sensor’s view angle is aligned with that of the surface measurements, namely at a nadir view. For view angles greater than 10°, the dominant error is the uncertainty in the off-nadir correction factor. The factor is largest in the back-scatter principal plane and can reach 20%. The Orbiting-Carbon Observatory has access to a number of datasets to determine this deviation. These include measurements from field instruments such as the Portable Apparatus for Rapid Acquisition of Bidirectional Observation of the Land and Atmosphere (PARABOLA), as well as satellite measurements from Multi-angle Imaging SpectroRadiometer (MISR) and MODerate resolution Imaging Spectroradiometer (MODIS). The correction factor derived from PARABOLA is consistent in time and space to within 2% for view angles as large as 30°. Field spectrometer data show that the correction term is spectrally invariant. For this reason, a time-invariant model of RRV surface reflectance, along with empirically derived coefficients, is sufficient to use in the calibration of off-nadir sensors, provided there has been no recent rainfall. With this off-nadir correction, calibrations can be expected to have uncertainties within 5%. Full article
