This article presents an integrated framework for robust control and cybersecurity of an industrial robot, combining Quantitative Feedback Theory (QFT), digital twin (DT) technology, and a programmable logic controller–based architecture aligned with the requirements of the NIS2 Directive. The study considers a five-axis industrial manipulator modeled as a set of decoupled linear single-input single-output systems subject to parametric uncertainty and external disturbances. For position control of each axis, closed-loop robust systems with QFT-based controllers and prefilters are designed, and the dynamic behavior of the system is evaluated using predefined key performance indicators (KPIs), including tracking errors in joint space and tool space, maximum error, root-mean-square error, and three-dimensional positional deviation. The proposed architecture executes robust control algorithms in the MATLAB/Simulink environment, while a programmable logic controller provides deterministic communication, time synchronization, and secure data exchange. The synchronized digital twin, implemented in the FANUC ROBOGUIDE environment, reproduces the robot’s kinematics and dynamics in real time, enabling realistic hardware-in-the-loop validation with a real programmable logic controller. This work represents one of the first architectures that simultaneously integrates robust control, real programmable logic controller-based execution, a synchronized digital twin, and NIS2-oriented mechanisms for observability and traceability. The conducted simulation and digital twin-based experimental studies under nominal and worst-case dynamic models, as well as scenarios with externally applied single-axis disturbances, demonstrate that the system maintains robustness and tracking accuracy within the prescribed performance criteria. In addition, the study analyzes how the proposed architecture supports the implementation of key NIS2 principles, including command traceability, disturbance resilience, access control, and capabilities for incident analysis and event traceability in robotic manufacturing systems. Full article

Quantitative Feedback Theory (QFT) enables the control system to guarantee stability and performance in the presence of plant uncertainty, thus offering a quantitative and less conservative framework for designing robust yet practical controllers. The presented work investigates a single-stage constraint optimization-based approach for synthesizing controllers for the ship roll stabilization. The typical QFT loop shaping is a manual two-stage procedure that demands a proficient understanding of loop-shaping principles on Nichols charts. The proposed procedure simplifies the QFT synthesis process by introducing a single-stage method that allows for concurrent synthesis of both the QFT controller and pre-filter. The present work considers the synthesis of fractional order controllers (using the FOMCON toolbox). The proposed method also enables the designer to pre-specify the controller architecture at the beginning of the design procedure. A comparative analysis with the controllers obtained using the QFT toolbox, Ziegler–Nichols, ${\mathcal{H}}_{\infty }$, IMC, and MPC have also been presented in the work. The implementation has been carried out for the ship roll stabilization, which is one of the critical problems in marine engineering, as it directly impacts the vessel safety, operational efficiency, and passenger comfort, wherein excessive roll can lead to reduced propulsion efficiency. The obtained results highlight that the proposed controller performs better than the benchmark controllers, and Monte Carlo simulations have also been included to support the results. Full article

The continuously increasing requirements for product purity and heat exchange efficiency in distillation processes exacerbate the system’s nonlinearity, coupling effects, and uncertainties. To address these challenges, this research proposes an optimized design approach for multivariable active disturbance rejection control (ADRC) that integrates quantitative feedback theory (QFT). An extended state observer is first employed to estimate and compensate for coupling and uncertainties, thus enabling effective decoupling. Under a two-degree-of-freedom equivalent model, QFT performance boundaries are transformed into a fitness function, turning controller parameter tuning into a frequency-domain multi-objective optimization problem. An improved multi-objective grey wolf algorithm is then introduced to optimize the controller parameters. The proposed approach is verified in a toluene–methylcyclohexane (MCH) extractive distillation process and compared with proportional–integral (PI) control and model predictive control (MPC). The simulation results indicate that, under the same feed temperature disturbance, the ADRC–QFT strategy reduces the system settling time by over 67% and lowers the integral of absolute error (IAE) index by more than 53% compared with PI–QFT and MPC, while also exhibiting stronger robustness to model uncertainties. These findings suggest that the proposed method provides an effective solution for achieving high precision and robust control in complex coupled distillation processes. Full article

Since the 1970s various decentralized control methodologies have been developed to deal with the challenge of controlling complex and/or spatially distributed systems with multiple inputs and multiple outputs (MIMO), e.g., chemical plants, power systems, water systems, etc. In general, the use of distributed information and control structures requires the synthesis of control laws in a constrained (decentralized) information structure. The article presents a novel frequency domain robust decentralized controller design method that is appropriate for uncertain dynamic MIMO systems with equal numbers of input and output variables, which consist of interconnected physical subsystems and are given as a set of square transfer function matrices. The main framework of the proposed method provides the Equivalent Subsystems Method (ESM), whereby the overall closed-loop system under a decentralized controller is stable if, and only if, all the individual closed-loop equivalent subsystems are stable. By generating equivalent subsystems for all transfer matrices, which describe the uncertain MIMO system, the individual uncertain equivalent subsystems are obtained as sets of respective frequency responses. Such representation allows the application of the QFT (quantitative feedback theory) approach to independently design local single-input single-output (SISO) robust controllers which constitute the resulting decentralized controller implemented in real subsystems. The designed controller ensures robust stability of the overall closed-loop system and the required performance as specified by the standard QFT performance specification types in both the equivalent subsystems and the overall closed-loop system. Compared to the existing method and references therein, the proposed method reduces the conservatism of the robust stability conditions and enables the exploitation of the benefits by the SISO QFT approach in the independent design of the robust decentralized controller. The developed design procedure is verified and illustrated in a case study on the robust decentralized level controller design of the quadruple tank process. Full article

Whenever additional states of a plant can be measured, closing nested feedback loops can be exploited in a variety of ways. The goal here is to reduce the bandwidth of feedback controllers and thus reduce the amplification of sensor noise that can otherwise spoil the expected performance when the actuator saturates. This can be particularly relevant for demanding tracking specifications and large plant uncertainties. In this context, the current work proposes a novel model-matching control architecture with a feedforward controller and two feedback controllers, which is accompanied by a new robust design method in the frequency domain of Quantitative Feedback Theory (QFT). The use of a feedforward controller reduces the amount of feedback to the minimum necessary to constrain the spread of the tracking error responses as specified. Furthermore, this amount of feedback is quantitatively distributed along the frequency between the inner and outer loops to reduce the total sensor noise at the control input as much as possible. A theoretical example illustrates the method and highlights the advantages of the new architecture over two other previously feasible QFT solutions: one with double feedback and another with single feedback plus feedforward. The importance of choosing the correct switching frequency between loops is also demonstrated. Finally, the angle of rotation of a commercial servo motor is successfully controlled using the motor speed as an internal measure. Full article

This paper suggests and develops a new methodology of estimation for a multivariable reachability region of a plasma separatrix shape on the divertor phase of a plasma discharge in D-shaped tokamaks. The methodology is applied to a spherical Globus-M/M2 tokamak, including the estimation of a controllability region of a vertical unstable plasma position on the basis of the experimental data. An assessment of the controllability region and the reachability region of the plasma is important for the design of tokamak poloidal field coils and the synthesis of a plasma magnetic control system. When designing a D-shaped tokamak, it is necessary to avoid the small controllability region of the vertically unstable plasma, because such cases occur in practice at a restricted voltage on a horizon field coil. To make the estimations mentioned above robust, PID-controllers for vertical and horizontal plasma position control were designed using the Quantitative Feedback Theory approach, which stabilizes the system and provides satisfactory control indexes (stability margins, setting time, overshoot) during plasma discharges. The controllers were tested on a series of plasma models and nonlinear models of current inverters in auto-oscillation mode as actuators for plasma position control. The estimations were made on these models, taking into account limitations on control actions, i.e., voltages on poloidal field coils. This research is the first step in the design of the plasma shape feedback control system for the operation of the Globus-M2 spherical tokamak. The developed methodology may be used in the design of poloidal field coil systems in tokamak projects in order to avoid weak achievability and controllability regions in magnetic plasma control. It was found that there is a strong cross-influence from the PF-coils currents and the CC current on the plasma shape; hence, these coils should be used to control the plasma shape simultaneously. Full article

The availability of multiple inputs (plants) can improve output performance by conveniently allocating the control bandwidth among them. Beyond that, the intervention of only the useful plants at each frequency implies the minimum control action at each input. Secondly, in single input control, the addition of feedforward loops from measurable external inputs has been demonstrated to reduce the amount of feedback and, subsequently, palliate its sideband effects of noise amplification. Thus, one part of the action calculated by feedback is now provided by feedforward. This paper takes advantage of both facts for the problem of robust rejection of measurable disturbances by employing a set of control inputs; a previous work did the same for the case of robust reference tracking. Then, a control architecture is provided that includes feedforward elements from the measurable disturbance to each control input and feedback control elements that link the output error to each control input. A methodology is developed for the robust design of the named control elements that distribute the control bandwidth among the cheapest inputs and simultaneously assures the prescribed output performance to correct the disturbed output for a set of possible plant cases (model uncertainty). The minimum necessary feedback gains are used to fight plant uncertainties at the control bandwidth, while feedforward gains achieve the nominal output response. Quantitative feedback theory (QFT) principles are employed. An example illustrates the method and its benefits versus a control architecture with only feedback control elements, which have much more gain beyond the control bandwidth than when feedforward is employed. Full article

Two robust mutlivariable controllers, H_∞ and a decentralized quantitative feedback theory (QFT), are designed in the frequency domain for the 2 × 2 looper system in a steel hot rolling mill to keep stability in the presence of parametric uncertainties. The H_∞ controller is designed by using the mixed sensitivity approach, while the multivariable decentralized QFT is designed by the extension of the sequential loop closing method presented elsewhere. Stability robustness conditions are verified in the frequency domain, while simulations in time domain are carried out to evaluate the controllers and compare their performance along with that of proportional + integral (PI) and single input single output (SISO) QFT controllers designed earlier. The QFT controller shows the best balance among the performance indicators analyzed here; however, at the expenses of using higher power in one of the control inputs. Full article

This paper devotes to the robust stability problem for an uncertain linear time invariant (LTI) feedback system with actuator saturation nonlinearity. Based on a three degree of freedom (DOF) non-interfering control structure, the robust stability is enforced with the describing function (DF) approach for an uncertain LTI system to avoid the limit cycle. A new type of anti-windup (AW) compensator is designed using the quantitative feedback theory (QFT) graphical method, which results in a simple design procedure and low-order AW control system. One of the most significant benefits of the proposed method is free of the non-convexity (intractable) drawback of the linear matrix inequality (LMI)-based approach. The analysis conducted on the benchmark problem clearly reveals that the proposed QFT-based anti-windup design is able to handle both saturation and uncertainty in a very effective manner. Full article

This paper proposes a systematic feedback controller design methodology for multi-input multi-output (MIMO) uncertain systems using the quantitative feedback theory (QFT). To achieve this goal, the model matching problem was considered and the inversion feedforward controller was designed to improve control performance while reducing the demand on feedback control alone. The proposed method is formulated based on the concept of equivalent disturbance attenuation (EDA) approach in which the uncertain system problem is converted into an external disturbance rejection problem based on a nominal system. This proposed approach exhibiting non-sequential design method result in the suboptimal solution showing design simplicity and computational efficiency compared to the existing method. In order to validate the effectiveness of the proposed control methodology, the MIMO magnetic levitation system as adopted and control performances such as time response were presented in both time and frequency domains. Full article

Autothermal thermophilic aerobic digestion (ATAD) is an advanced sewage sludge treatment which allows compliance with increasingly demanding regulations. Concerning sludge pasteurization, a certain average temperature must be assured in the digester during batch treatment. Aeration flow is the variable most manipulated to regulate the digester temperature. Additionally, the manipulation of the batch sludge flow—which is related to the solid-retention-time—is considered to improve temperature regulation despite variations in air and sludge temperatures and the variability of raw sludge organic content. Thus, a dual-input control structure was provided where the aeration and solid-retention-time contributed as faster and slower inputs, respectively. Two controllers intervened, and the set-point for the batch average temperature was chosen to meet the minimum effluent quality established by the US regulations or European recommendations, considering that lower set point temperatures save aeration costs. A set-point for the aeration allowed us to achieve an extra goal, which aimed at either reducing operation costs or increasing production rates. The two feedback controllers were designed following the robust control methodology known as quantitative feedback theory (QFT). Improvements were compared with single-input (aeration-flow) control strategy and open-loop control strategy. Simulations were performed on a benchmark non-linear simulation model for ATAD. Full article
