Search Results (18)

This paper presents an accurate analysis of the power losses of an interior permanent magnet synchronous motor fed by a cascaded H-bridge multilevel inverter. The main goal of this study is to investigate the impact of the cascaded h-bridge inverter, multicarrier PWM strategies, and inverter switching frequency on the synchronous motor power losses. With this aim in mind, a detailed frequency domain power analysis was carried out on motor power losses at different operating points in the frequency–torque plane. Motor power losses were further categorized into fundamental and harmonic power losses. This evaluation involved driving the power converter using six distinct multicarrier PWM strategies at four different switching frequencies. Additionally, a comparison was conducted with a conventional two-level PWM inverter to quantify the reduction in motor power losses. The experimental results show that the cascaded h-bridge inverter guarantees a notable increase in the motor efficiency, up to 7%, and losses in segregation at the fundamental frequency, if compared to the standard two-level PWM inverter, especially at low speed and with partial-load conditions. Such results mark out the cascaded H-bridge inverter as a valuable choice, also with regard to low-voltage drive applications. Full article

The partial discharge (PD) measurement under pulse width modulation (PWM) voltage is a critical measurement of quality assessment for inverter-fed motors, as outlined in IEC 60034-18-41 and IEC 60034-18-42. One of the key parameters in PD measurement is the repetitive partial discharge inception voltage (RPDIV). This paper examines factors that influence the ageing process of hairpin windings in motors, with ageing tests designed using the Design of Experiment (DoE) method. The study focuses on the effects of electrical and thermal stresses on the ageing process. To achieve this, the failure rate, the RPDIV data, and the lifetime data are selected as the output responses. The findings highlights that RPDIV measurements alone cannot accurately predict the degree of ageing of hairpin windings. Specifically, RPDIV results are influenced not only by the quality of the hairpin windings under PWM voltage but also by other contributing factors. Furthermore, the change in RPDIV during the ageing process showed that the RPDIV measurement cannot predict the ageing degree of the hairpin winding. Experimental data on failure rates and lifetimes reveal that both electrical and thermal stresses significantly influence the ageing process, with a notable interaction between these factors. Among the three output responses, the failure rate provides a more accurate reflection of this interaction. To reliably estimate the lifetime of hairpin windings, more precise parameters are necessary. Further research is required to deepen the understanding of the underlying PD mechanisms under PWM voltage, which could enhance diagnostic and predictive capabilities for hairpin winding performance. Full article

This article presents a harmonic analysis of the stator currents of a squirrel-cage induction motor fed by a voltage source inverter with PWM space vector control (SVPWM). The influence of PWM switching frequency and dead time (dead band) of controlled transistors on THD and electromagnetic torque ripple is shown. The aim is to determine the lowest switching frequency of the transistors for which the drive will operate correctly. Characteristics were determined as functions in the form of THD ($f_{PWM}$), where the least square approximation was used for stator current measurements when the PWM switching frequency was changed. The approximations were realized for simulation and experimental results. To clarify the results, the operation of hardware PWM circuits in microcontrollers is analyzed. Full article

This paper undertakes the thermal and electrical characterization of three commercial unsaturated polyester imide resins (UPIR) to identify which among them could better perform the insulation function of electric motors (high-power induction motors fed by pulse-wide modulation (PWM) inverters). The process foreseen for the motor insulation using these resins is Vacuum Pressure Impregnation (VPI). The resin formulations were specially selected because they are one-component systems; hence, before the VPI process, they do not require mixing steps with external hardeners to activate the curing process. Furthermore, they are characterized by low viscosity and a thermal class higher than 180 °C and are Volatile Organic Compound (VOC)-free. Thermal investigations using Thermogravimetric Analysis (TGA) and Differential Scanning Calorimetry (DSC) techniques prove their excellent thermal resistance up to 320 °C. Moreover, impedance spectroscopy in the frequency range of 100 Hz–1 MHz was analyzed to compare the electromagnetic performance of the considered formulations. They manifest an electrical conductivity starting from 10⁻¹⁰ S/m, a relative permittivity around 3, and a loss tangent value lower than 0.02, which appears almost stable in the analyzed frequency range. These values confirm their usefulness as impregnating resins in secondary insulation material applications. Full article

Artificial intelligence (AI) techniques are widely used in fault diagnosis because they are superior in detection and prediction. The detection of faults in power systems containing electronic components is critical. The switch faults of the voltage source inverter (VSI) have a severe impact on the driving system. Short-circuit switches increase the thermal stress due to their fast and high stator currents. Additionally, open-circuit switches cause unstable motor operation. However, these issues are not sufficiently addressed or accurately predicted for VSI switch faults in the literature. Thus, this paper investigates the use of different AI classifiers for three-phase VSI fault diagnosis. Various AI methods are used, such as naïve Bayes, support vector machine (SVM), artificial neural network (ANN), and decision tree (DT) techniques. These methods are applied to a VSI-fed permanent magnet synchronous motor (PMSM) to detect the faults in the inverter switches. These methods use the drain–source voltage and PWM signals to decide whether the switch is healthy or unhealthy. In addition, they are compared in terms of their detection accuracy. In this regard, the comparative results show that the DT method has the highest accuracy as compared to other methods in the fault diagnosis process. Moreover, this paper proposes a novel and universal voltage compensation loop to compensate for the absence of the voltage portion due to the open switch fault. Thus, the driving system is assisted in operating under its normal operating conditions. The universal term is used because the proposed voltage compensation loop can be implemented in any type of inverter. To validate the results, the proposed system is implemented using two software programs, LTSPICE XVII-USA, WEKA 3.9-New Zealand. Full article

A common-mode voltage (CMV) suppression strategy, namely double zero-sequence injection common-mode voltage (DZICMV), is proposed in this paper for an asymmetrical six-phase induction motor fed by two-level dual three-phase voltage source inverters (VSIs). In this strategy, the sinusoidal waveforms injected by double zero-sequence signals are employed as modulation signals, and two opposite triangular waveforms are used as carriers. The fundamental period is divided into 24 sectors. In each sector, the carrier used by the medium amplitude phase is distinct from the carriers used by the other two phases in each set of three-phase windings. Using this method, the zero vectors (000) and (111) in each set of three-phase windings can be eliminated, and the peak values of sub-CMV and total CMV can be reduced from ±U_dc/2 to ±U_dc/6. The experiment results show that the root mean square (RMS) value of common-mode leakage current in DZICMV can be reduced by 51.83% compared with the double zero-sequence injection PWM (DZIPWM) strategy. It is also found in the other four existing benchmark CMV suppression strategies that the peak values of sub-CMV therein are nearly all ±U_dc/2, and only in the low linear modulation region could one of these strategies suppress sub-CMV peak values to ±U_dc/6. However, the proposed DZICMV can suppress the sub-CMV peak values to ±U_dc/6 in the whole linear modulation range. Moreover, the maximum linear modulation index of the DZICMV is 1.15, which is larger than that of the four benchmark strategies, whose maximum modulation index is 1. Full article

Among the existing harmonic current suppression methods, it is difficult and complicated to suppress any n^th harmonic current accurately for multi-phase permanent magnet synchronous motors (PMSMs). To solve this problem, this paper takes a five-phase dual-rotor PMSM fed with a current source inverter (CSI) as an example, and proposes an n^th harmonic current suppression method based on the impulse current PWM algorithm. Firstly, the analysis is conducted and presented for the n^th harmonic current in the m^th harmonic space. Then, based on the Sliding Discrete Fourier Transformation (SDFT), a low-pass filter (LPF) named SDFT-LPF is designed. Additionally, the impulse current PWM technique for the five-phase CSI is realized. In this paper, the experiments have confirmed that the SDFT-LPF has good filter performance. Compared with the SVPWM, the impulse current PWM technique has the same DC-link current utilization rate, but it is easier to implement. Moreover, the proposed harmonic current control method can accurately control any n^th harmonic current without changing the PWM technique, which has significantly reduced the complexity of the harmonic current control. Additionally, the proposed scheme is easy to implement and can be directly extended to the multiple harmonic current’s control. Full article

The reduction or elimination of selected torque and current harmonics is widely used in multilevel inverter fed induction motor drives. A wide range of methods are employed to achieve this goal. Those modes of operation allow the avoidance of certain torque and current harmonics that may lead to disturbance and even mechanical and electrical resonance. In this paper, the selective harmonic elimination technique (SHE-PWM) is employed to reduce the chosen torque harmonics in a three-level NPC inverter-fed induction motor drive. The proposed method is compared with the synchronized carrier pulse width modulation technique (SCPWM). For both schemes of control simulation, a model is proposed using Simulink software. Furthermore, laboratory stand experiments are carried out to verify the correctness of torque harmonics formation. Full article

The insulation system’s dielectric of the electric motor is very often subjected to severe electrical stress generated by the high $dv/dt$ seen at the machine’s terminals. The electrical stress and high reflected wave transient overvoltage are even more evident in case of high-speed machines fed by high-frequency (HF) converters featuring very fast wide-bandgap devices. They are promoting the occurrence of partial discharges and consequently accelerate ageing. As this is serious issue and the main cause of the drive failure, it is important to analyse and characterise the surges at the motor terminals. Several HF models of motors have been proposed in the literature for this purpose. This article presents a survey on HF motor models, which is crucial in understanding and studying the most critical parameter identification and overvoltage mitigation techniques. Moreover, it offers a comparison of the models’ main features as well as a comparison with the experimental voltage waveform at motor terminals. A general overview of the partial discharge (PD) phenomenon is also provided, as it is favoured by HF operation and together with HF motor modelling provides key insights to the insulation ageing issue. In particular, an analysis of the effects of PWM waveform affecting insulation is given, as well as useful methods for developing strategies for the inspection and maintenance of winding insulation. Full article

An appropriate modulation scheme selection ensures inverter performance. Thus, space vector modulation (SVM) is more efficient and has its own distinct advantages compared to other pulse width modulation (PWM) techniques. This work deals with the development of an advanced space vector pulse width modulation (SVM) technique for two-phase inverter control using an XSG library to ensure rapid prototyping of the controller FPGA implementation. The proposed architecture is applied digitally and in real time to drive a two-phase induction motor (TPIM) for small-scale wind turbine emulation (WTE) profiles in laboratories with minimum current ripple and torque oscillation. Four space voltage vectors generated for the used SVM technique do not contain a zero vector. Hence, for an adequate adjustment of these four vectors, a reference voltage vector located in the square locus is determined. Considering the asymmetry between the main and auxiliary windings, the TPIM behavior, which is fed through the advanced SVM controlled-two-phase inverter (2ϕ-inverter), is studied, allowing us to control the speed and the torque under different conditions for wind turbine emulation. Several quantities, such as electromagnetic torque, rotor fluxes, stator currents and speed, are analyzed. To validate the obtained results using both Simulink and XSG interfaces, the static and dynamic characteristics of the WTE are satisfactorily reproduced. The collected speed and torque errors between the reference and actual waveforms show low rates, proving emulator controller effectiveness. Full article

Most power quality problems for electrical grids connected to Doubly-Fed Induction Generators (DFIGs) include flicker, variations of the RMS voltage profile, and injected harmonics because of switching in power converters. These converters have different topologies with the back-to-back (B2B) topology being the most exploited in high-powered three-phase systems. Therefore, in this article a model of a DFIG connected to the B2B power converter is proposed to which different switching techniques are implemented for interharmonic propagation studies. The switching techniques that are implemented include the Sinusoidal PWM (SPWM), the third harmonic injection PWM (THIPWM), and the space vector PWM (SVPWM), to reduce the Total Harmonic Distortion (THD) index of voltage and current in both windings of the machine. MATLAB-Simulink^® software is used for modeling and simulating the B2B power converter and the switching techniques. The proposed model is validated with an experimental prototype that includes a 3-kW DFIG, a 10 HP motor, a gear-box with a transmission ratio of 4.5: 1, a B2B power converter, and a three-phase transformer connecting the system to the electrical grid. Finally, it is shown that the results obtained from the experimental tests corroborate the correct operation of the proposed model. Full article

A novel induction motor direct torque control (DTC) algorithm with synchronous modulation is presented. Compared to the traditional DTC method, whose main drawback is the presence of low-frequency torque harmonics (sub-harmonics), in the proposed method, the PWM switching frequency is imposed to be an integer multiple of the main supply frequency. This is achieved by continuously adjusting the PWM switching period to significantly reduce low-frequency harmonics. The devised algorithm has been tested on an inverter-fed induction motor drive system, and the obtained results show an important reduction of the sub-harmonic spectral content of the developed torque with respect to a conventional direct torque control while maintaining at the same time a high dynamic response. Full article

The pulse width modulation (PWM) inverter is an obvious choice for any industrial and power sector application. Particularly, industrial drives benefit from the higher DC-link utilization, acoustic noise, and vibration industrial standards. Many PWM techniques have been proposed to meet the drives’ demand for higher DC-link utilization and lower harmonics suppression and noise reductions. Still, random PWM (RPWM) is the best candidate for reducing the acoustic noises. Few RPWM (RPWM) methods have been developed and investigated for the AC drive’s PWM inverter. However, due to the lower randomness of the multiple frequency harmonics spectrum, reducing the drive noise is still challenging. These PWMs dealt with the spreading harmonics, thereby decreasing the harmonic effects on the system. However, these techniques are unsuccessful at maintaining the higher DC-link utilizations. Existing RPWM methods have less randomness and need complex digital circuitry. Therefore, this paper mainly deals with a combined RPWM principle in space vector PWM (SVPWM) to generate random PWM generation using an asymmetric frequency multicarrier called multicarrier random space vector PWM (MCRSVPWM). he SVPWM switching vectors with different frequency carrier are chosen with the aid of a random bi-nary bit generator. The proposed MCRSVPWM generates the pulses with a randomized triangular carrier (1 to 4 kHz), while the conventional RPWM method contains a random pulse position with a fixed frequency triangular carrier. The proposed PWM is capable of eradicating the high-frequency unpleasant acoustic noise more effectually than conventional RPWM with a shorter random frequency range. The simulation study is performed through MATLAB/Simulink for a 2 kW asynchronous induction motor drive. Experimental validation of the proposed MCRSVPWM is tested with a 2 kW six-switch (Power MOSFET–SCH2080KE) inverter power module-fed induction motor drive. Full article

A minimum root mean square (RMS) torque ripple-remote-state pulse-width modulation (MTR-RSPWM) technique is proposed for minimizing the RMS torque ripple under reduced common-mode voltage (CMV) condition of three-phase voltage source inverters (VSI)-fed brushless alternating current (BLAC) motor drives. The q-axis current ripple due to an error voltage vector generated between the reference voltage vector and applied voltage vector is analyzed for all pulse patterns with reduced CMV of the RSPWM. From the analysis result, in the MTR-RSPWM, a sector is divided into five zones, and within each zone, pulse patterns with the lowest RMS torque ripple and reduced CMV are employed. To verify the validity of the MTR-RSPWM, theorical analysis, simulation, and experiments are performed, where the MTR-RSPWM is thoroughly compared with RSPWM3 that generates the minimum RMS current ripple. From the analytical, simulation, and experimental results, it is shown that the MTR-RSPWM significantly reduces the RMS torque ripple under a reduced CMV condition at the expense of an increase in the RMS current ripple, compared to the RSPWM3. Full article

In this paper, a single-phase photovoltaic (PV) inverter fed by a boost converter to supply a freezer motor with variable DC input is investigated. The proposed circuit has two stages. Firstly, the DC output of the PV panel that varies between 150 and 300 V will be applied to the boost converter. The boost converter will boost the input voltage to a fixed 300 V DC. Next, this voltage is supplied to the single-phase full bridge inverter to obtain 230 V AC. In the end, The output of the inverter will feed a freezer motor. The PV panels can be stand-alone or grid-connected. The grid-connected PV is divided into two categories, such as with a transformer and without a transformer, a transformer type has galvanic isolation resulting in increasing the security and also provides no further DC current toward the grid, but it is expensive, heavy and bulky. The transformerless type holds high efficiency and it is cheaper, but it suffers from leakage current between PV and the grid. This paper proposes a stand-alone direct use of PV to supply a freezer; therefore, no grid connection will result in no leakage current between the PV and Grid. The proposed circuit has some features such as no filtering circuit at the output of the inverter, no battery in the system, DC-link instead of AC link that reduces no-loads, having a higher efficiency, and holding enough energy in the DC-link capacitor to get the motor started. The circuit uses no transformers, thus, it is cheaper and has a smaller size. In addition, the system does not require a complex pulse width modulation (PWM) technique, because the motor can operate with a pulsed waveform. The control strategy uses the PWM signal with the desired timing. With this type of square wave, the harmonics (5th and 7th) of the voltage are reduced. The experimental and simulation results are presented to verify the feasibility of the proposed strategy. Full article
