Search Results (49)

Nowadays, hydrodynamic noise reduction in hydrofoils is of great importance due to their wide applications in marine industries, submarines and water systems. One of the modern methods for reducing this noise is the use of longitudinal grooves on the surface of the hydrofoil. In this study, the effect of longitudinal grooves on the reduction in noise generated around a NACA0015 hydrofoil was investigated. For this purpose, numerical methods based on computational fluid dynamics (CFD) and acoustic analysis using ANSYS Fluent 2024 R1 software were used. The Fuchs–Williams and Hawkings (FW-H) acoustic model was used for acoustic analysis. The results obtained from the hydrofoil without grooves and the hydrofoil equipped with longitudinal grooves were compared. In total, 11 numerical noise reading stations were installed around the hydrofoil to calculate the noise in two modes with and without grooves. The results show that the use of longitudinal grooves reduces the flow turbulence in the area near the hydrofoil surface and, as a result, prevents the formation of large and unstable vortices. This leads to a significant reduction in hydrodynamic noise, especially at low and medium frequencies. This study shows that the appropriate design of longitudinal grooves on the NACA0015 hydrofoil can be used as an effective solution to reduce hydrodynamic noise. The findings of this research can be the basis for the development of quieter hydrofoils in industrial and military applications. The results show that at low frequencies (up to approximately 10 Hz), the noise intensity of the ungrooved hydrofoil is higher than that of the grooved hydrofoil, but in the frequency range of 10 to 20 Hz, the noise intensity of the grooved hydrofoil increases significantly and exceeds that of the ungrooved hydrofoil. Full article

This study aims to investigate the spatiotemporal evolution of cavitating flow and the associated acoustic responses around a NACA0015 hydrofoil. A coupled fluid–acoustic interaction model is developed by integrating a nonlinear cavitation model with vortex–sound coupling theory. Numerical simulations are conducted within a computational domain established for the hydrofoil to capture the interactions between cavitation dynamics and acoustic radiation. The results indicate that the temporal variations in cavity evolution and pressure fluctuations agree well with experimental observations. The simulations predict a dominant pressure fluctuation frequency of 30.15 Hz, consistent with the cavitation shedding frequency, revealing that the evolution of leading-edge vortex structures governs the periodic variations in the lift-to-drag ratio. Cavitation significantly modifies the development of vortex structures, with vortex stretching effects mainly concentrated near cavitation regions. The dilation–contraction term is closely associated with cavity formation, while the pressure–torque tilting term predominantly affects cloud cavitation collapse. Dynamic mode decomposition (DMD) shows that the coherent structures of the leading modes exhibit morphological similarity to multiscale cavitation and vortex structures. Furthermore, hydrofoil cavitation noise consists mainly of loading noise and cavitation-induced pulsating radiation noise, with surface acoustic sources concentrated in cloud cavitation shedding regions. The dominant frequency of cavitation-induced radiation noise is highly consistent with experimental measurements. Full article

This study examines the hydrodynamic and acoustic performance of plain NACA0018 hydrofoil and modified NACA0018 hydrofoils (foil with a cavity on suction surface) at a Reynolds number ($Re$) of $40,000$, which is indicative of small-scale turbines and marine applications. A cavity was created on suction side surface at 40–50% of the chord length, which is chosen for its efficacy in cavitation control. The present analysis examines the impact of the cavity on lift-to-drag-ratio ($L/D$) and cavity length at three cavitation numbers ($1.7$, $1.2$, and $0.93$) for plain and modified hydrofoils. Simulations demonstrate a significant enhancement of 7% in the lift-to-drag ratio relative to traditional designed foils. Contrary to earlier observations, the cavity length increases instead of decreasing for the modified hydrofoil. Both periodic steady and turbulent inflow conditions are captured that simulate the complex cavity dynamics and flow–acoustic interactions. It is found that a reduction in RMS velocity with modified blade suggests flow stabilization. Spectral analysis using Mel-frequency techniques confirms the cavity’s potential to reduce low-frequency flow-induced noise. These findings offer new insights for designing quieter and more efficient hydrofoils and turbine blades. Full article

A unique flow control approach, blow suction combined jet (BSCJ), was presented to enhance the hydrodynamic performance of hydrofoils without the need of external energy resources. Utilizing the three-dimensional (3D) NACA0015 (National Advisory Committee for Aeronautics, NACA) foil as a case study, the orthogonal design methodology is employed to enhance the design of geometric and flow parameters, including the suction/blow point and the jet momentum coefficient. The fluid dynamics of the BSCJ foil at various angles of attack were numerically assessed using the large eddy simulation (LES) approach. The flow structures, encompassing vortex formations, pressure coefficients, and the impact of boundary layer velocity, were presented and evaluated to elucidate the control mechanism and influence of BSCJ. The simulation results indicate that the BSCJ primarily enhances the separation point of the rear wing surface by eliminating low-momentum fluid from the hydrofoil’s suction surface, thereby substantially augmenting the pressure differential across the hydrofoil and ultimately enhancing its hydrodynamic performance. The jet momentum coefficient is the primary determinant influencing the hydrodynamic performance of the hydrofoil, with best conditions attained when the suction slot is positioned at 0.25 C from the leading edge, the blowing slot at 0 C from the trailing edge, and the jet momentum coefficient is 0.1. The conclusions derived from the current study can offer theoretical advice for the future application of the BSCJ approach in underwater vehicles. Full article

This paper investigated the optimization of the hardness and oscillation mode of flexible hydrofoils using bidirectional fluid–structure interaction (FSI) to address the issue of insufficient guidance in engineering applications. A two-dimensional flexible symmetric hydrofoil model of NACA0012 with a chord length of 1 m was constructed for this research. The hydrodynamic characteristics of low-frequency flexible hydrofoils with varying hardness and oscillation modes were analyzed through numerical simulation. The results indicated that the flexible hydrofoil with a Shore hardness of D50 exhibited the most optimal hydrodynamic performance under low-frequency conditions across the five groups of hardness tests. Among the three commonly utilized oscillation modes, the inboard oscillation mode demonstrated the most favorable performance. The hydrodynamic performance of the flexible hydrofoil surpassed that of the rigid hydrofoil in both inward and outward oscillation motions; however, it was inferior in pure pitching motions. Comparative analysis of the vortex structure and velocity distribution in the flow field revealed that the inward oscillation motion effectively enhanced the kinetic energy of the wake vortex and slowed down vortex dissipation, thereby improving the overall flow velocity. These findings provide theoretical support for the study of flexible hydrofoils and contribute to their advancement in pumping applications under actual ultra-low head conditions. Full article

A series of experiments were performed using multiple configurations of hydrofoils to assess the energy harvesting capabilities present within the wake of streamlined bodies. The experiments were performed in a low-speed water tunnel, with energy harvesting assessed using a piezoelectric eel and imaging equipment. Half-sinusoidal undulations were introduced in different combinations on the leading and trailing edges of the hydrofoil. All hydrofoils utilized a NACA 0012 cross-sectional profile. A piezoelectric eel was placed at a variable distance downstream of the hydrofoil’s trailing edge, and the hydrofoil’s angle of attack (α) was varied in order to assess the variation in power generation. The maximum power output was achieved at x/c = 1–1.5 downstream of the trailing edge in all configurations. It was observed that harvested energy is dependent on the oscillation of the eel, α, the streamwise distance between the trailing edge of the hydrofoils and the eel, as well as the geometry of the hydrofoils. Particle image velocimetry was also performed on selected cases for which the recorded energy harvest was high. The results showed that the NACA 0012 base profile has a higher extractable energy capacity in its wake than do the serrated hydrofoils, which confirms the results found in the literature. Full article

Cavitation is a common phenomenon in naval and ocean engineering, typically occurring in the wakes of high-speed rotating propellers and on the surfaces of fast-moving underwater vehicles. To investigate cavitation phenomena, computational fluid dynamics (CFD) simulations are indispensable. Nevertheless, the inherently complex nature of cavitation, which involves phase transitions, heat transfer, and significant pressure fluctuations, often results in high computational costs for these simulations. To address the computational challenges associated with cavitation simulations, a DeepCFD model, which leverages convolutional neural networks (CNNs), was employed to accurately predict cavitation around hydrofoils. Through specific modifications, the DeepCFD model was trained on 400 hydrofoil configurations, learned from CFD simulations. The numerical methods were validated against a modified NACA66 hydrofoil. It was found that the model could accurately predict cavitation shapes under various flow conditions, although it showed some discrepancies in velocity predictions, especially for detached cavitating flows. The significance of this study lies in its potential to simply predict cavitating flows and expedite marine vehicle design through the application of CNNs in cavitation prediction, offering a novel and impactful approach to computational fluid dynamics in the field. Full article

In the realm of marine science and engineering, hydrofoils play a pivotal role in the efficiency and performance of marine turbines and water-jet pumps. In this investigation, the boundary layer characteristics of an NACA0009 hydrofoil with a blunt trailing edge are focused on. The effectiveness of both the two-equation gamma theta (γ-Re_θt) transition model and the one-equation intermittency (γ) transition model in forecasting boundary layer behavior is evaluated. When considering natural transition, these two models outperform the shear stress transport two-equation (SST k-ω) turbulence model, notably enhancing the accuracy of predicting boundary layer flow distribution for chord-length Reynolds numbers (Re_L) below 1.6 × 10⁶. However, as Re_L increases, both transition models deviate from experimental values, particularly when Re_L is greater than 2 × 10⁶. The results indicate that the laminar separation bubble (LSB) is sensitive to changes in angles of attack (AOA) and Re_L, with its formation observed at AOA greater than 2°. The dimensions of the LSB, including the initiation and reattachment points, are found to contract as Re_L increases while maintaining a constant AOA. Conversely, an increase in AOA at similar Re_L values leads to a reduced size of the LSB. The findings are essential for the design and performance optimization of water-jet pumps, particularly in predicting and flow separation and transition phenomena. Full article

In order to obtain a more detailed and comprehensive relationship between the cavitation phenomenon and energy loss, this paper takes an NACA66 hydrofoil as an example to analyze the specific relationship between the cavitation flow field and energy dissipation by using entropy production theory, a ZGB cavitation model, and k-ε turbulence model which were modified by a Filter-Based Density Correction model (FBDCM). The results show that the modified k-ε model can effectively capture the morphology of cavity evolution in the cavitation flow field. The vortex dilatation term contributes the most to the vorticity transport in cavitation flow. The energy loss of the cavitation flow field is primarily composed of turbulent dissipation, which is primarily distributed in the area below the lifted attached cavity and inside the vortex induced by the cloud cavity. The direct dissipation entropy production is predominantly distributed in the area near the stagnation point of the hydrofoil’s leading edge and inside the cavity. The wall entropy production is chiefly distributed in the area where the cavity is not covered. The cavitation entropy production mainly occurs on the vapor–liquid interface, and the value is negative, indicating that the vapor–liquid conversion in the cavitation process needs to absorb energy from the flow field. Full article

This study investigates cloud cavitation suppression around a model-scale NACA66 hydrofoil using active water injection and explores the effect of multiple injection parameters. Numerical simulations and a mixed-level orthogonal test method are employed to systematically analyze the impact of jet angle α_jet, jet location L_jet, and jet velocity U_jet on cavitation suppression efficiency and hydrofoil energy performance. The study reveals that jet location has the greatest influence on cavitation suppression, while jet angle has the greatest influence on hydrofoil energy performance. The optimal parameter combination (L_jet = 0.30C, α_jet = +60 degrees, U_jet = 3.25 m/s) effectively balances energy performance and cavitation suppression, reducing cavitation volume by 49.34% and improving lift–drag ratio by 8.55%. The study found that the jet’s introduction not only enhances vapor condensation and reduces the intensity of the vapor–liquid exchange process but also disrupts the internal structure of cavitation clouds and elevates pressure on the hydrofoil suction surface, thereby effectively suppressing cavitation. Further analysis shows that positive-going horizontal jet components enhance the lift–drag ratio, while negative-going components have a detrimental effect. Jet arrangements near the trailing edge negatively impact both cavitation suppression and energy performance. These findings provide a valuable reference for selecting optimal injection parameters to achieve a balance between cavitation suppression and energy performance in hydrodynamic systems. Full article

Biomimetic pumps can effectively enhance the hydrodynamics of plain river networks, improve the water environment, and facilitate the transport of sticky bottom sediment. In this paper, a biomimetic pump equipped with an NACA0012 wing profile was used as the research subject, and a commercial CFD package was employed to investigate the impact of the pump’s installation height (the vertical distance from the hydrofoil’s pivot to the riverbed) and operating frequency on the incipient motion of riverbed sediment. The results indicate that the lowest maximum near-bed velocity is obtained at an installation height of 3 times the chord length (3 c) and operating frequency of 0.5 Hz, while the highest is reached at 4 c and 5 Hz. The maximum near-bed velocity point is the furthest from the biomimetic pump when the installation height is 3 c and the operating frequency is 0.5 Hz and the closest at 4 c and 0.5 Hz. At a fixed installation height, a quadratic relationship is found between the maximum near-bed velocity and the operating frequency. At installation heights of c, 2 c, and 4 c, the effect of operating frequency on the point of action is minimal, with only a sudden change followed by stability at 3 c as the frequency increases. When the operating frequency is fixed and the installation height is increased, the maximum near-bed velocity initially decreases and then rises, being the smallest at 3 c. The distance between the point of maximum near-bed velocity and the biomimetic pump initially increases and then decreases with increasing installation height, being the farthest at 3 c. Furthermore, in this paper, we fitted mathematical expressions for the maximum near-bed velocity relative to the operating frequency under different installation heights of the biomimetic pump and calculated the threshold frequencies for the incipient motion of sediment at installation heights of c, 2 c, 3 c, and 4 c to be 1.15 Hz, 1.64 Hz, 2.85 Hz, and 1.06 Hz, respectively, providing scientific guidance for the application of biomimetic pumps in various scenarios. Full article

The resistance performance of amphibious vehicles can be improved by installing underwater tail hydrofoils. The research on the impact of different hydrofoil profiles on the resistance characteristics of amphibious vehicles can provide a reference for the vehicle’s design. For an amphibious vehicle model, five shapes of symmetrical hydrofoils, NACA0012, NACA0015, NACA0016, and asymmetric hydrofoils NACA23012, NACA66-209, were selected as the underwater tail wing of the vehicle body, respectively. Based on the RANS method and overset grid technology, the resistance performance of the vehicle body was numerically calculated, and the resistance variation in the amphibious vehicle equipped with different tail hydrofoils at 0.43 < Fr_∇ < 1.3 speed was obtained. The basic shape of amphibious vehicle tail wings can be determined by comparing the effects of symmetrical hydrofoils and asymmetric hydrofoils on body resistance. The results show that the asymmetric hydrofoils have a better resistance reduction effect on amphibious vehicles than the symmetrical ones. Among them, an amphibious vehicle installing the asymmetric hydrofoil NACA66-209 as an underwater tail wing can reduce resistance by 44.3%. Chord length is an important factor affecting the resistance reduction performance of tail wings. When Fr_∇ = 1.3, the asymmetric hydrofoil optimized based on chord length has a 21.2% higher resistance reduction effect on amphibious vehicles. Full article

The flapping hydrofoil bionic pump is an innovative hydrodynamic device that utilizes flapping hydrofoil technology. Flapping hydrofoil bionic pumps are crucial in addressing issues like inadequate river hydropower and limited water purification capabilities in flat river network regions. Optimizing the foil characteristics is essential for enhancing the hydrodynamic efficiency of the flapping hydrofoil bionic pump. This study investigates the impact of foil camber parameters on the hydrodynamic performance of swing-type asymmetric flapping bionic pumps. The NACA series standard foils with varying cambers are analyzed using the overlapping grid technology and finite volume method. The thrust coefficient, flow rate, pumping efficiency, and flow field structure of the flapping hydrofoil bionic pump are examined under pressure inlet conditions with the foil camber. The findings indicate that increasing the foil’s curvature within a specific range can greatly enhance the maximum values of thrust coefficient, propulsive efficiency, and pumping efficiency of the flapping hydrofoil bionic pump. Specifically, when the foil curvature is 6%c, the maximum value of the instantaneous thrust coefficient of the flapping hydrofoil bionic pump is significantly improved by 31.25% compared to the symmetric foil type under the condition of an oscillating frequency of f = 1 HZ. The flapping hydrofoil bionic pump achieves its maximum pumping efficiency when the oscillation frequency is within the range of f ≤ 2.5 Hz. This efficiency is 11.7% greater than that of the symmetric foil, and it occurs when the foil curvature is 8%c. Within the frequency range of f > 2.5 Hz, the flapping hydrofoil bionic pump that has a foil curvature of 6%c exhibits the highest enhancement in pumping efficiency. It achieves a maximum increase of 12.8% compared to the symmetric foil type. Nevertheless, the average head was less than 0.4 m, making it suitable for ultra-low-head applications. Full article

This research investigates cavitation around a marine propeller, employing computational fluid dynamic (CFD) solvers, including an incompressible, isothermal compressible, and fully compressible flow. The investigation commenced with simulations utilizing an incompressible flow solver, subsequently extending to the two compressible flow solvers. In the compressible flow, there is a close interrelation between density, pressure, and temperature, which significantly influences cavitation dynamics. To verify computational methods, verification tests were conducted for leading-edge cavitating flows over a two-dimensional (2D)-modified NACA66 hydrofoil section at various cavitation numbers. The computational results were validated against the experimental data, with the solvers’ capability to predict cavitation forming the basis for comparison. The results demonstrate consistent predictions among the solvers; however, the fully compressible flow solver demonstrated a superior performance in capturing re-entrant jets and accurately modeling cavity closure regions. Furthermore, the fully compressible flow solver precisely estimated propeller hydrodynamic performance, yielding results closely aligned with experimental observations. Full article

The strong increase in anthropogenic underwater noise has caused a growing intention to design quieter ships given that ship propellers are one of the dominating noise sources along the worldwide shipping routes. This creates an imminent demand for deeper knowledge on the noise generation mechanisms of propeller cavitation. A cavitating, oscillating two-dimensional NACA0015 hydrofoil is analyzed with hydrophone and high-speed video recording as a simplified and manipulatable representative of a propeller blade in a ship’s wake field for the identification of major influencing parameters on the radiated noise. A pneumatic drive allows the application of asymmetrical temporal courses of the angle of attack, a novel amendment to the widely reported sinusoidal setups. Three different courses are tested with various cavitation numbers. The combination of a moderate angle increase and a rapid decrease is found to generate significantly higher pressure peaks compared to symmetrical angular courses. Considering that the rapid change of the angle of attack caused by the inhomogeneous wake field behind the hull is the core of the cavitation occurrence, the understanding of its influence may contribute to the design of quieter ships in the future while still allowing for the necessary high propeller efficiency. Full article
