Search Results (28)

Long-strip imaging is an important way of improving the coverage and acquisition efficiency of remote sensing satellite data. During the agile maneuver imaging process of the satellite, the LuoJia3-01 satellite can obtain a sequence of array long-strip images with a certain degree of overlap. Limited by the relative accuracy of satellite attitude, there will be relative misalignment between the sequence frame images, requiring high-precision geometric processing to meet the requirements of large-area remote sensing applications. Therefore, this study proposes a new method for the geometric correction of long-strip images without ground control points (GCPs) through GPU acceleration. Firstly, through the relative orientation of sequence images, the relative geometric errors between the images are corrected frame-by-frame. Then, block perspective transformation and image point densified filling (IPDF) direct mapping processing are carried out, mapping the sequence images frame-by-frame onto the stitched image. In this way, the geometric correction and image stitching of the sequence frame images are completed simultaneously. Finally, computationally intensive steps, such as point matching, coordinate transformation, and grayscale interpolation, are processed in parallel using GPU to further enhance the program’s execution efficiency. The experimental results show that the method proposed in this study achieves a stitching accuracy of less than 0.3 pixels for the geometrically corrected long-strip images, an internal geometric accuracy of less than 1.5 pixels, and an average processing time of less than 1.5 s per frame, meeting the requirements for high-precision near-real-time processing applications. Full article

Since the data generation rate of high-resolution satellites is increasing rapidly, to relieve the stress of data downloading and processing systems while enhancing the time efficiency of information acquisition, it is important to deploy on-board edge computing on satellites. However, the volume, weight, and computability of on-board systems are strictly limited by the harsh space environment. Therefore, it is very difficult to match the computability and the requirements of diversified intelligent applications. Currently, this problem has become the first challenge of the practical deployment of on-board edge computing. To match the actual requirements of the Luojia3 satellite of Wuhan University, this manuscript proposes a three-level edge computing architecture based on a System-on-Chip (SoC) for low power consumption and expandable on-board processing. First, a transfer level is designed to focus on hardware communications and Input/Output (I/O) works while maintaining a buffer to store image data for upper levels temporarily. Second, a processing framework that contains a series of libraries and Application Programming Interfaces (APIs) is designed for the algorithms to easily build parallel processing applications. Finally, an expandable level contains multiple intelligent remote sensing applications that perform data processing efficiently using base functions, such as instant geographic locating and data picking, stream computing balance model, and heterogeneous parallel processing strategy that are provided by the architecture. It is validated by the performance improvement experiment that following this architecture, using these base functions can help the Region of Interest (ROI) system geometric correction fusion algorithm to be 257.6 times faster than the traditional method that processes scene by scene. In the stream computing balance experiment, relying on this architecture, the time-consuming algorithm ROI stabilization production can maintain stream computing balance under the condition of insufficient computability. We predict that based on this architecture, with the continuous development of device computability, the future requirements of on-board computing could be better matched. Full article

The extraction of a road network is critical for city planning and has been widely studied in previous research using high resolution images, whereas the high cost of high-resolution remote sensing data and the complexity of its analysis also cause huge challenges for the extraction. The successful launch of a high resolution (130 m) nighttime remote sensing satellite, Luojia 1-01, provides great potential in the study of urban issues. This study attempted to extract city roads using a Luojia 1-01 nighttime lighting image. The urban regions were firstly distinguished through a threshold method. Then, an unsupervised PCNN (pulse coupled neural network) was established to extract the road networks in urban regions. A series of optimizing methods was proposed to enhance the image contrast and eliminate the residential regions along the roads. The final extraction results after optimizing were compared with OSM (OpenStreetMap) data, showing the high precision of the proposed approach with the accuracy rate reaching 83.2%. We also found the precision of city centers to be lower than suburban regions due to the influence of intensive human activities. Our study confirms the potential of Luojia 1-01 data in the extraction of city roads and provides new thought for more complex and microscopic study of city issues. Full article

Kinematic orbit determination (KOD) of low earth orbit (LEO) satellites only using single-frequency global navigation satellite system (GNSS) data is a suitable solution for space applications demanding meter-level orbit precision. For some small LEO satellites with the sun-pointing attitude mode, the rotation of the GNSS antenna radiation pattern changes the observation noise characteristics. Since the rotation angle information of the antenna plane may not be available for most low-cost missions, the true elevation cannot be computed and a general elevation-dependent weighting model remains invalid for the onboard GNSS observations. Furthermore, the low-stability GNSS receiver clock oscillator of the LEO satellite at high speeds makes single-frequency cycle slip detection ineffective and difficult since the clock steering events occur frequently. In this study, we investigated the improved KOD strategy to improve the performance of orbit solution using single-frequency GPS and BeiDou navigation satellite system (BDS) observations collected from the Luojia-1A satellite. The weighting model based on exponential function and signal strength is proposed according to the analysis of satellite attitude impact, and a joint single-frequency detection algorithm of receiver clock jump and cycle slip is investigated as well. Based on the GPS/BDS-combined KOD results, it is demonstrated that the clock jump and cycle slip can be properly detected and observations can be effectively utilized with the proposed weighting model considering satellite attitude, which significantly improves the availability and accuracy of orbit solution. The number of available epochs is increased by 12.9% benefitting from this strategy. The orbital root mean square (RMS) precision improvements in the radial, along-track, and cross-track directions are 22.1%, 16.4%, and 6.5%, respectively. Combining BDS observations also contributes to orbit precision improvement, which reaches up to 28.8%. Full article

The accurate and efficient extraction of urban areas is of great significance for better understanding of urban sprawl, built environment, economic activities, and population distribution. Night-Time Light (NTL) data have been widely used to extract urban areas. However, most of the existing NTL indexes are incapable of identifying non-luminous built-up areas. The high-resolution NTL imagery derived from the Luojia 1-01 satellite, with low saturation and the blooming effect, can be used to map urban areas at a finer scale. A new urban spectral index, named the Modified Normalized Urban Areas Composite Index (MNUACI), improved upon the existing Normalized Urban Areas Composite Index (NUACI), was proposed in this study, which integrated the Human Settlement Index (HSI) generated from Luojia 1-01 NTL data, the Normalized Difference Vegetation Index (NDVI) from Landsat 8 imagery, and the Modified Normalized Difference Water Index (MNDWI). Our results indicated that MNUACI improved the spatial variability and differentiation of urban components by eliminating the NTL blooming effect and increasing the variation of the nighttime luminosity. Compared to urban area classification from Landsat 8 data, the MNUACI yielded better accuracy than NTL, NUACI, HSI, and the EVI-Adjusted NTL Index (EANTLI) alone. Furthermore, the quadratic polynomial regression analysis showed the model based on MNUACI had the best R² and Root-Mean Square Error (RMSE) compared with NTL, NUACI, HSI, and EANTLI in terms of estimation of impervious surface area. It is concluded that MNUACI could improve the identification of urban areas and non-luminous built-up areas with better accuracy. Full article

Nighttime light (NTL) data are increasingly used in urban studies and urban planning owing to their strong connection with human activities, although the detection capacity is limited by the spatial resolution of older data. In the present study, we comparedthe results of extractions of urban built-up areas using data obtained from the first professional NTL satellite Luojia 1-01 with a resolution of 130 m and the Visible Infrared Imaging Radiometer Suite (VIIRS). We applied an analyzing framework combing kernel density estimation (KDE) under different search radii and threshold-based extraction to detect the boundary and spatial structure of urban areas. The results showed that: (1) Benefiting from a higher spatial resolution, Luojia 1-01 data was more sensitive in detecting new emerging urban built-up areas, thus better reflected the spatial structure of urban system, and can achieve a higher extraction accuracy than that of VIIRS data; (2) Combining with a proper threshold, KDE improves the extraction accuracy of NTL data by making use of the spatial autocorrelation of nighttime light, thus better detects the scale of the spatial pattern of urban built-up areas; (3) A proper searching radius for KDE is critical for achieving the optimal result, which was 1000 m for Luojia 1-01 and 1600 m for VIIRS in this study. Our findings indicate the usefulness of the KDE method in applying the upcoming high-resolution NTL data such as Luojia 1-01 data in urban spatial analysis and planning. Full article

With the rapid process of urbanization, anthropogenic heat generated by human activities has become an important factor that drives the changes in urban climate and regional environmental quality. The nighttime light (NTL) data can aptly reflect the spatial distribution of social-economic activities and energy consumption, and quantitatively estimate the anthropogenic heat flux (AHF) distribution. However, the commonly used DMSP/OLS and Suomi-NPP/VIIRS NTL data are restricted by their coarse spatial resolution and, therefore, cannot exhibit the spatial details of AHF at city scale. The 130 m high-resolution NTL data obtained by Luojia 1-01 satellite launched in June 2018 shows a promise to solve this problem. In this paper, the gridded AHF spatial estimation is achieved with a resolution of 130 m using Luojia 1-01 NTL data based on three indexes, NTL_nor (Normalized Nighttime Light Data), HSI (Human Settlement Index), and VANUI (Vegetation Adjusted NTL Urban Index). We chose Jiangsu, a fast-developing province in China, as an example to determine the best AHF estimation model among the three indexes. The AHF of 96 county-level cities of the province was first calculated using energy-consumption statistics data and then correlated with the corresponding data of three indexes. The results show that based on a 5-fold cross-validation approach, the VANUI power estimation model achieves the highest R² of 0.8444 along with the smallest RMSE of 4.8277 W·m⁻² and therefore has the highest accuracy among the three indexes. According to the VANUI power estimation model, the annual mean AHF of Jiangsu in 2018 was 2.91 W·m⁻². Of the 96 cities, Suzhou has the highest annual mean AHF of 7.41 W·m⁻², followed by Wuxi, Nanjing, Changzhou and Zhenjiang, with the annual mean of 3.80–5.97 W·m⁻², while the figures of Suqian, Yancheng, Lianyungang, and Huaian, the cities in northern Jiangsu, are relatively low, ranging from 1.41 to 1.59 W·m⁻². This study has shown that the AHF estimation model developed by Luojia 1-01 NTL data can achieve higher accuracy at city-scale and discriminate the spatial detail of AHF effectively. Full article

Luojia-1A is a scientific experimental satellite operated by Wuhan University, which is the first low earth orbiter (LEO) navigation signal augmentation experimental satellite. The precise orbit is the prerequisite of augmenting existing Global Navigation Satellite System (GNSS) performance and improves users’ positioning accuracy. Meanwhile, LEO precise orbit determination (POD) with BeiDou-2 observations is particularly challenging since it only provides regional service. In this study, we investigated the method of precise orbit determination (POD) for Luojia-1A satellite with the onboard BeiDou observation to establish the high-precision spatial datum for the LEO navigation augmentation (LEO-NA) system. The multipath characteristic of the BeiDou System (BDS) observations from Luojia-1A satellite is analyzed, and the elevation-dependent BeiDou code bias is estimated with the LEO onboard observations. A weight reduction strategy is adopted to mitigate the negative effect of poor BeiDou-2 geostationary earth orbit (GEO) satellites orbit quality, and the Luojia-1A orbit precision can be improved from 6.3 cm to 2.3 cm with the GEO weighting strategy. The precision improvement of the radial direction, along-track, and out-of-plane directions are 53.47%, 47.29%, and 76.2%, respectively. Besides, tuning the pseudo-stochastic parameters is also beneficial for improving orbit precision. The experiment results indicate that about 2 cm overlapping orbit accuracy are achievable with BeiDou observations from Luojia-1A satellite if proper data processing strategies are applied. Full article

Nighttime light (NTL) images have been broadly applied to extract urban built-up areas in recent years. However, the typical NTL images provided by Defense Meteorological Satellite Program/Operational Linescan System (DMSP/OLS) and National Polar-Orbiting Partnership’s Visible Infrared Imaging Radiometer Suite (NPP/VIIRS) have the drawbacks of low resolution and blooming effect, which bring difficulty for the application of them in urban built-up area extraction. Therefore, this paper proposes the POI (point of interest) and LST (land surface temperature) adjusted NTL urban index (PLANUI) to extract the urban built-up areas with high accuracy. PLANUI is the first urban index to integrate POI and NTL for urban built-up area extraction. In this paper, NPP/VIIRS and Luojia 1-01 images were introduced as the original NTL data and the vegetation adjusted NTL urban index (VANUI) was selected as the comparison item. The threshold method was utilized to extract urban built-up areas from these data. The results show that: (1) Based on the comparison with the reference data, the PLANUI can make up the shortcoming of low resolution and the blooming effect of NTL effectively. (2) Compared with the VANUI, the PLANUI can significantly improve the accuracy of the urban built-up areas extracted and characterize urban features. (3) According to the results based on NPP/VIIRS and Luojia 1-01 images, the PLANUI has extensive applicability, both for regions with different degrees of economic development and NTL data with different resolutions. PLANUI can enhance the features of urban built-up areas with social sensing data and natural remote sensing data, which helps to weaken the NTL blooming effect and improve the extraction accuracy. PLANUI can provide an effective approach for urban built-up area extraction, which plays a certain guiding role for the study of urban structure, urban expansion, and urban planning and governance. Full article

Most studies on light pollution are based on light intensity retrieved from nighttime light (NTL) remote sensing with less consideration of the population factors. Furthermore, the coarse spatial resolution of traditional NTL remote sensing data limits the refined applications in current smart city studies. In order to analyze the influence of light pollution on populated areas, this study proposes an index named population exposure to light pollution (PELP) and conducts a street-scale analysis to illustrate spatial variation of PELP among residential areas in cites. By taking Shenzhen city as a case, multi-source data were combined including high resolution NTL remote sensing data from the Luojia 1-01 satellite sensor, high-precision mobile big data for visualizing human activities and population distribution as well as point of interest (POI) data. Results show that the main influenced areas of light pollution are concentrated in the downtown and core areas of newly expanded areas with obvious deviation corrected like traditional serious light polluted regions (e.g., ports). In comparison, commercial–residential mixed areas and village-in-city show a high level of PELP. The proposed method better presents the extent of population exposure to light pollution at a fine-grid scale and the regional difference between different types of residential areas in a city. Full article

In recent years, the number of artificial light sources has tremendously increased with the development of lighting technology and the economy. Nighttime light pollution has been an increasing environmental problem, resulting in negative impacts on human health and the ecological environment. Detailed knowledge of light pollution is important for the planning and management of urban lighting. In this study, light pollution in Nanjing, China was monitored and analyzed using field observations and a 130-m resolution Luojia 1-01 nighttime light imagery. Combined with in situ observations and satellite imagery, a variety of empirical models were established for estimating ambient illuminance at night. Cross-validation was employed to assess the performance of these models, indicating that the third-degree polynomials model had the best performance (MAE = 5.06 lx, R² = 0.81). The developed third-degree polynomial model was then applied to the Luojia 1-01 image to map the nighttime illuminance in Nanjing. The nighttime illuminance depicted the spatial pattern of the light environment over Nanjing and also indicated some heavily light-polluted areas. Some lit areas were residential areas, whose high brightness had negative effects on residents and need particular attention. This study provides a quantitative and objective reference for the light pollution management in Nanjing, and also a reference for light pollution survey in other regions. Full article

Night-light remote sensing imaging technologies have increasingly attracted attention with the development and application of focal plane arrays. On-orbit signal-to-noise ratio (SNR) test is an important link to evaluate night-light camera’s radiometric performance and the premise for quantitative application of remote sensing imageries. Under night-light illumination conditions, the illuminance of ground objects is very low and varies dramatically, the spatial uniformity of each pixel’s output cannot be guaranteed, and thus the traditional on-orbit test methods represented by variance method are unsuitable for low-resolution night-light cameras. To solve this problem, we proposed an effective on-orbit SNR test method based on consecutive time-sequence images that including the same objects. We analyzed the radiative transfer process between night-light camera and objects, and established a theoretical SNR model based on analysis of the generation and main sources of signal electrons and noise electrons. Finally, we took Luojia 1-01 satellite, the world’s first professional night-light remote sensing satellite, as reference and calculated the theoretical SNR and actual on-orbit SNR using consecutive images captured by Luojia 1-01 satellite. The actual results show the similar characteristics as theoretical results, and are higher than the theoretical results within the reasonable error tolerance, which fully guarantee the detection ability of night-light camera and verify the validity of this time-sequence-based method. Full article

The high-resolution nighttime light (NTL) data of the LuoJia1-01 NTL remote sensing satellite has enriched the available data of NTL remote sensing applications. The radiance calibration used as a reference to convert the digital number (DN) recorded by the nighttime sensor into the radiance of the corresponding ground object is the basic premise to the effective application of the NTL data. Owing to the lack of on-board calibration equipment and the absence of an absolute radiometric calibration light source at night, it is difficult for LuoJia1-01 to carry out on-orbit radiance calibration. The moon, as an exoatmospheric stable radiation source, is widely used for the radiometric calibration of remote sensing satellite sensors and to monitor the stability of the visible and near-infrared sensors. This study, based on lunar observation of the LuoJia1-01 NTL sensor, focused on on-orbit radiometric calibration and included monitoring changes in the nighttime sensor radiometric response for nearly a year by using the Robotic Lunar Observatory (ROLO) lunar irradiance model (Version 311 g). The results showed that: (1) the consistency of the radiometric calibration results based on the ROLO model and the laboratory calibration results of LuoJia1-01 exceeded 90%; (2) the nighttime sensor of LuoJia1-01 radiometric response underwent approximately 6% degradation during the observation period of nearly one year (353 days). Full article

The Luojia1-01 satellite provides high-resolution, high-sensitivity nighttime light data at a resolution of 130 m. To effectively use the Luojia1-01 nighttime light data for global applications, the problems of relative and absolute positioning accuracy should be solved. This paper proposes a high accuracy regional geometric processing method of nighttime light imagery. We utilized a nighttime light image matching algorithm to obtain tie points, which are used in the planar block adjustment with ground control points. Then, orthorectification of all images is implemented. Finally, we obtain the nighttime light map of China by mosaicking all the nighttime light orthoimages. According to the experimental results for 275 Luojia1-01 images, the root mean square error of the tie points is 0.983 pixels and the root mean square error of independent checkpoints is 195.491 m (less than 1.5 pixels) after the planar block adjustment. The experimental results prove the validity and feasibility of the proposed method. Full article

Ground control points (GCPs) are generally used to calibrate the installation between the camera and star sensor of a satellite in orbit and improve the geometric positioning accuracy of the satellite. However, the use of GCPs for high-frequency calibration is difficult, and it is particularly difficult to acquire accurate GCPs for the image of a nightlight satellite. In this study, we developed a camera-star sensor installation calibration method that eliminates the need for GCPs. In the proposed method, the camera and star sensor lenses are simultaneously pointed at the star, and the camera-star sensor installation is accurately calibrated by processing the star map obtained by the camera and star sensors. Reference data such as road network and Moon position data were used to verify the proposed method and evaluate its positioning accuracy. The results of the application of the method to the positioning of the Luojia 1-01 satellite indicated an accuracy within 800 m, which is comparable with that of the traditional method. Full article
