The article analyses the hosting capacity of low-voltage (LV) power grids for connecting distributed energy sources (DER), mainly photovoltaic installations (PV), considering technical limitations imposed by power system operating conditions. The main objective of the research was to develop a simple equation that enables the quick estimation of the maximum power of an energy source that can be safely connected at a given point in the network without causing excessive voltage rise or overloading the transformer and line cable. The analysis was performed on the basis of relevant calculation formulas and simulations carried out in DIgSILENT PowerFactory, where a representative low-voltage grid model was developed. The network model included four transformer power ratings (40, 63, 100, and 160 kVA) and four cable cross-sections (25, 35, 50, and 70 mm²), which made it possible to assess the impact of these parameters on grid hosting capacity as a function of the distance from the transformer station. Based on this, the P_HCI indicator was developed to determine the hosting capacity of a low-voltage network, using only the transformer rating and the length and cross-section of the line for the calculations. A comparison of the results obtained using the proposed equation with detailed calculations showed that the approximation error does not exceed 15%, which confirms the high accuracy and practical applicability of the proposed approach. Full article

In recent years, the rapid increase in installed photovoltaic (PV) capacity in Poland has created significant challenges for low-voltage distribution networks. Excess generation during peak solar hours frequently leads to local overvoltage conditions that exceed regulatory limits, causing PV inverters to disconnect from the grid. This phenomenon reduces the efficiency of distributed renewable energy integration and results in direct financial losses for prosumers. The present study quantifies these losses on an annual basis for a single-family household located in southeastern Poland, where overvoltage incidents occurred 614 times over 78 days in 2024. Real operational data from the residential PV installation were analyzed and complemented with detailed PVsyst simulations to determine the amount of energy curtailed due to inverter disconnections. The analysis revealed that daily energy losses can reach up to 22% of potential production, depending on the duration and frequency of overvoltage events. Furthermore, several technical and organizational measures are proposed to mitigate the issue, including grid reinforcement strategies and demand-side management. The findings highlight the necessity of addressing overvoltage in low-voltage distribution networks to ensure system reliability, enhance renewable energy integration, and maintain the economic viability of residential PV investments. Full article

The increasing penetration of distributed energy resources (DERs) such as solar photovoltaic (PV) systems, battery energy storage systems (BESSs), and electric vehicles (EVs) in low-voltage (LV) and medium-voltage (MV) distribution networks is reshaping traditional grid operations. This shift introduces challenges including voltage violations, thermal overloading, and power quality issues due to bidirectional power flows. Hosting capacity (HC) assessment has become essential for quantifying and optimizing DER integration while ensuring grid stability. This paper reviews state-of-the-art HC assessment methods, including deterministic, stochastic, time-series, and AI-based approaches. Techniques for enhancing HC—such as on-load tap changers, reactive power control, and network reconfiguration—are also discussed. A key focus is the emerging concept of dynamic operating envelopes (DOEs), which enable real-time allocation of HC by dynamically adjusting import/export limits for DERs based on operational conditions. The paper examines the benefits, challenges, and implementation of DOEs, supported by insights from Australian projects. Technical, regulatory, and social aspects are addressed, including network visibility, DER uncertainty, scalability, and cybersecurity. The study highlights the potential of integrating DOEs with other HC enhancement strategies to support efficient, reliable, and scalable DER integration in modern distribution networks. Full article

The surge in electric vehicles (EVs) in Denmark challenges the country’s residential low-voltage (LV) distribution system. In particular, it increases the demand for home EV charging significantly and possibly overloads the LV grid. This study analyzes the impact of EV charging integration on Denmark’s residential distribution networks. A residential grid comprising 67 households powered by a 630 kVA transformer is studied using DiGSILENT PowerFactory. With the assumption of simultaneous charging of all EVs, the transformer can be heavily loaded up to 147.2%. Thus, a voltage-droop based autonomous control approach is adopted, where the EV charging power is dynamically adjusted based on the point-of-connection voltage of each charger instead of the fixed rated power. This strategy eliminates overloading of the transformers and cables, ensuring they operate within a pre-set limit of 80%. Voltage drops are mitigated within the acceptable safety range of ±10% from normal voltage. These results highlight the effectiveness of the droop control strategy in managing EV charging power. Finally, it exemplifies the benefits of intelligent EV charging systems in Horizon 2020 EU Projects like SERENE and SUSTENANCE. The findings underscore the necessity to integrate smart control mechanisms, consider reinforcing grids, and promote active consumer participation to meet the rising demand for a low-carbon future. Full article

During the energy transition, new types of electrical equipment, especially power electronic devices, are proposed to increase the flexibility of electricity distribution grids. One type is the solid-state transformer (SST), which offers excellent possibilities to improve the voltage quality in electricity distribution grids and integrate hybrid AC/DC grids. This paper compares SST to conventional copper-based power transformers (CPT) with and without an on-load tap changer (OLTC) and with additional downstream converters. For this purpose, a corresponding electricity distribution grid is set up in the power system analysis tool DIgSILENT PowerFactory 2022. A DC generator like a photovoltaic system, a DC load like an electric vehicle fast charging station, and an AC load are connected. Based on load flow simulations, the four power transformers are compared concerning voltage stability during a generator-based and a load-based scenario. The results of load flow simulations show that SSTs are most valuable when additional generators and loads are to be connected to the infrastructure, which would overload the existing grid equipment. The efficiency of using SSTs also depends on the parameters of the electrical grid, especially the lengths of the low-voltage (LV) lines. In addition, a flowchart-based decision process is proposed to support the decision-making process for the appropriate power transformer from an electrical perspective. Beyond these electrical properties, an evaluation matrix lists other relevant criteria like characteristics of the installation site, noise level, expected lifetime, and economic criteria that must be considered. Full article

The distribution grid comprises cables with diverse constructions. The insulating material used in low-voltage (LV) distribution cables is predominantly PVC. Furthermore, the presence of cables with different structures in the grid poses challenges in detecting the aging of the cable network. Finding a universal and dependable condition-monitoring technique that can be applied to various types of cables is indeed a challenge. The diverse construction and materials used in different cables make it difficult to identify a single monitoring approach that can effectively assess the condition of all cables. To address this issue, this study aims to compare the thermal aging behavior of different LV distribution cables with various structures, i.e., one cable contains a PVC belting layer, while the other contains filler material. The growing adoption of distributed generation sources, electric vehicles, and new consumer appliances in low-voltage distribution grids can lead to short, repetitive overloads on the low-voltage cable network. Hence, these cable samples were exposed to short-term cyclic accelerated aging in the climate chamber at 110 °C. The cable’s overall behavior under thermal stress was evaluated through frequency and time domain electrical measurements (including tan $\delta$ and extended voltage response) and a mechanical measurement (Shore D). The tan $\delta$ was measured in the frequency range of 20 Hz–500 kHz by using the Wayne-Kerr impedance analyzer. The extended voltage response measurement was conducted using a C# application developed in-house specifically for laboratory measurements in the .NET environment. The study observed a strong correlation between the different measurement methods used, indicating that electrical methods have the potential to be adopted as a non-destructive condition-monitoring technique. Full article

High Photovoltaic (PV) and Electric Vehicle (EV) Charging Penetration challenges the grid’s Low-Voltage (LV) Distribution Network’s stability due to voltage variations and the overloading of feeders. This research paper investigates the potential of combined PV and Electric Vehicle (EV) charging integration within LV DN, using a representative DN in Malta as a case study. The European Union (EU) has set forth objectives and guidelines that suggest a high likelihood of Distributed Networks (DNs) incorporating a significant number of Photovoltaic Systems (PVs), resulting in overvoltage occurrences, as well as a substantial number of Electric Vehicles (EVs), which may charge in an erratic manner, leading to undervoltage and overloading events. A distribution network (DN) may experience unfavorable situations concurrently due to the simultaneous occurrence of photovoltaic (PV) generation and electric vehicle (EV) charging, particularly in residential case studies. Effectively employing either dispersed or centralized storage is a viable approach to tackle these issues. However, this strategy may defer the requirement for expensive DN investments. The study showcases the extent of automated mitigation attained in the urban zones of Malta. The data presented primarily comprises empirical measurements obtained at the onset of the LV feeder. Full article

In this paper, we determine the maximum number of battery electric vehicles (BEVs) that can be charged simultaneously at full power during peak load hour without overloading transformer and lines or causing an unacceptable voltage drop in the low-voltage (LV) grid. In order to predict the BEVs charging demand, an application that takes into account the random user’s arrival time and the initial battery state of charge (SOC) was developed using the C++ programming language and the Qt toolkit. The network analysis was then carried out using the Quasi-Dynamic Simulation (QDS) toolbox in DIgSILENT PowerFactory on a typical German LV grid for a metropolitan urban area. The simulation findings indicate that the value of simultaneity factor (SF) plays an important role in identifying the most robust and weakest grid’s bottlenecks. There is currently no immediate threat of electromobility pushing the parameters of the grid to their unacceptable limits; however, it is essential to examine the LV grid’s bottlenecks and gradually prepare them for the ramp-up of BEVs. In the short term, the bottlenecks can be removed using conservative planning and operating principles; however, employing novel approaches will be crucial in the longer term. Full article

Integration of PV power generation systems at distribution grids, especially at low-voltage (LV) grids, brings in operational challenges for distribution system operators (DSOs). These challenges include grid over-voltages and overloading of cables during peak PV power production. Battery energy storage systems (BESS) are being installed alongside PV systems by customers for smart home energy management. This paper investigates the utilization of those BESS by DSOs for maintaining the grid voltages within limits. In this context, an incentive price based demand response (IDR) method is proposed for indirect control of charging/discharging power of the BESS according to the grid voltage conditions. It is shown that the proposed IDR method, which relies on a distributed computing application, is able to maintain the grid voltages within limits. The advantage of the proposed distributed implementation is that the DSOs can compute and communicate the incentive prices thereby encouraging customers to actively participate in the demand response program. An iterative distributed algorithm is used to compute the incentive prices of individual BESS to minimize the costs of net power consumption of the customer. The proposed IDR method is tested by conducting simulation studies on the model of a Danish LV grid for few study cases. The simulation results show that by using the proposed method for the control of BESS, node voltages are maintained within limits as well as the costs of net power consumption of BESS owners are minimized. Full article
