Various short-range radars, such as impulse-radio ultra-wideband (IR-UWB) and frequency-modulated continuous-wave (FMCW) radars, are currently employed to monitor vital signs, including respiratory and cardiac rates (RRs and CRs). However, these methods do not consider the motion of an individual, which can distort the phase of the reflected signal, leading to inaccurate estimation of RR and CR because of a smeared spectrum. Therefore, motion compensation (MOCOM) is crucial for accurately estimating these vital rates. This paper proposes an efficient method incorporating MOCOM to estimate RR and CR with super-resolution accuracy. The proposed method effectively models the radar signal phase and compensates for motion. Additionally, applying the super-resolution technique to RR and CR separately further increases the estimation accuracy. Experimental results from the IR-UWB and FMCW radars demonstrate that the proposed method successfully estimates RRs and CRs even in the presence of body movement. Full article

Impulse radio ultra-wideband (IR-UWB) radar, operating in the low-frequency band, can penetrate walls and utilize its high range resolution to recognize different human activities. Complex deep neural networks have demonstrated significant performance advantages in classifying radar spectrograms of various actions, but at the cost of a substantial computational overhead. In response, this paper proposes a lightweight model named TG2-CAFNet. First, clutter suppression and time–frequency analysis are used to obtain range–time and micro-Doppler feature maps of human activities. Then, leveraging GhostV2 convolution, a lightweight feature extraction module, TG2, suitable for radar spectrograms is constructed. Using a parallel structure, the features of the two spectrograms are extracted separately. Finally, to further explore the correlation between the two spectrograms and enhance the feature representation capabilities, an improved nonlinear fusion method called coordinate attention fusion (CAF) is proposed based on attention feature fusion (AFF). This method extends the adaptive weighting fusion of AFF to a spatial distribution, effectively capturing the subtle spatial relationships between the two radar spectrograms. Experiments showed that the proposed method achieved a high degree of model lightweightness, while also achieving a recognition accuracy of 99.1%. Full article

Mental distress-induced imbalances in autonomic nervous system activities adversely affect the electrical stability of the cardiac system, with heart rate variability (HRV) identified as a related indicator. Traditional HRV measurements use electrocardiography (ECG), but impulse radio ultra-wideband (IR-UWB) radar has shown potential in HRV measurement, although it is rarely applied to psychological studies. This study aimed to assess early high levels of mental distress using HRV indices obtained using radar through modified signal processing tailored to reduce phase noise and improve positional accuracy. We conducted 120 evaluations on 15 office workers from a software startup, with each 5 min evaluation using both radar and ECG. Visual analog scale (VAS) scores were collected to assess mental distress, with evaluations scoring 7.5 or higher classified as high-mental distress group, while the remainder formed the control group. Evaluations indicating high levels of mental distress showed significantly lower HRV compared to the control group, with radar-derived indices correlating strongly with ECG results. The radar-based analysis demonstrated a significant ability to differentiate high mental distress, supported by receiver operating characteristic (ROC) analysis. These findings suggest that IR-UWB radar could be a supportive tool for distinguishing high levels of mental stress, offering clinicians complementary diagnostic insights. Full article

Against the backdrop of rapidly advancing Artificial Intelligence of Things (AIOT) and sensing technologies, there is a growing demand for indoor location-based services (LBSs). This paper proposes a through-the-wall localization and tracking (TWPT) system based on an improved ultra-wideband (IR-UWB) radar to achieve more accurate localization of indoor moving targets. The TWPT system overcomes the limitations of traditional localization methods, such as multipath effects and environmental interference, using the high penetration and high accuracy of IR-UWB radar based on multi-sensor fusion technology. In the study, an improved Kalman filter (KF) algorithm is used for clutter reduction, while the CLEAN algorithm, combined with a compensation mechanism, is utilized to increase the target detection probability. Finally, a three-point localization estimation algorithm based on multi-IR-UWB radar is applied for the precise position and trajectory estimation of the target. Experimental validation indicates the TWPT system achieves a high positioning accuracy of 96.91%, with a root mean square error (RMSE) of 0.082 m and a Maximum Position Error (MPE) of 0.259 m. This study provides a highly accurate and precise solution for indoor TWPT based on IR-UWB radar. Full article

This paper presents a real-time and non-contact dual-mode embedded impulse-radio (IR) ultra-wideband (UWB) radar system designed for microwave imaging and vital sign applications. The system is fully customized and composed of three main components, an RF front-end transmission block, an analog signal processing (ASP) block, and a digital processing block, which are integrated in an embedded system. The ASP block enables dual-path receiving for image construction and vital sign detection, while the digital part deals with the inverse scattering and direct current (DC) offset issues. The self-calibration technique is also incorporated into the algorithm to adjust the DC level of each antenna for DC offset compensation. The experimental results demonstrate that the IR-UWB radar, based on the proposed algorithm, successfully detected the 2D image profile of the object as confirmed by numerical derivation. In addition, the radar can wirelessly monitor vital sign behavior such as respiration and heartbeat information. Full article

The current study investigated the associations between female football players’ training loads and their sleep variations. The sample included 21 female elite football players from a Norwegian top-league club with a mean age of 24 years (±2.8). Sleep duration, sleep quality, and training load were monitored every day over 273 consecutive days with a Somnofy sleep monitor based on ultra-wideband (IR-UWB) pulse radar and Doppler technology, and a FIFA-approved STATSports APEX 10 Hz GPS tracking system monitoring players’ training loads. A multivariate analysis of variance (MANOVA) was conducted to investigate the relationships between the players’ training loads and sleep. It was revealed that very high training loads were associated with reduced time in bed (p = 0.005), total sleep time (p = 0.044)), and rapid eye movement (p < 0.001). The present findings show that the female football players’ sleep was disrupted when the training load, based on total distance (TDI), was very high. It appears to be a point where their sleep is somewhat consistent through low, medium, and high training loads, but with disrupted sleep when the training load reaches a very high level. Considering the reduced TIB after a very high training load, there should be suggested strategies to improve their sleep, such as extended TIB, to aid in longer TST and improved recovery. Full article

Contactless continuous blood pressure (BP) monitoring is of great significance for daily healthcare. Radar-based continuous monitoring methods typically extract time-domain features manually such as pulse transit time (PTT) to calculate the BP. However, breathing and slight body movements usually distort the features extracted from pulse-wave signals, especially in long-term continuous monitoring, and manually extracted features may have limited performance for BP estimation. This article proposes a Transformer network for Radar-based Contactless Continuous Blood Pressure monitoring (TRCCBP). A heartbeat signal-guided single-beat pulse wave extraction method is designed to obtain pure pulse-wave signals. A transformer network-based blood pressure estimation network is proposed to estimate BP, which utilizes convolutional layers with different scales, a gated recurrent unit (GRU) to capture time-dependence in continuous radar signal and multi-head attention modules to capture deep temporal domain characteristics. A radar signal dataset captured in an indoor environment containing 31 persons and a real medical situation containing five persons is set up to evaluate the performance of TRCCBP. Compared with the state-of-the-art method, the average accuracy of diastolic blood pressure (DBP) and systolic blood pressure (SBP) is 4.49 mmHg and 4.73 mmHg, improved by 12.36 mmHg and 8.80 mmHg, respectively. The proposed TRCCBP source codes and radar signal dataset have been made open-source online for further research. Full article

As the Artificial Intelligence of Things (AIOT) and ubiquitous sensing technologies have been leaping forward, numerous scholars have placed a greater focus on the use of Impulse Radio Ultra-Wide Band (IR-UWB) radar signals for Region of Interest (ROI) population estimation. To address the problem concerning the fact that existing algorithms or models cannot accurately detect the number of people counted in ROI from low signal-to-noise ratio (SNR) received signals, an effective 1DCNN-LSTM model was proposed in this study to accurately detect the number of targets even in low-SNR environments with considerable people. First, human-induced excess kurtosis was detected by setting a threshold using the optimized CLEAN algorithm. Next, the preprocessed IR-UWB radar signal pulses were bundled into frames, and the resulting peaks were grouped to develop feature vectors. Subsequently, the sample set was trained based on the 1DCNN-LSTM algorithm neural network structure. In this study, the IR-UWB radar signal data were acquired from different real environments with different numbers of subjects (0–10). As indicated by the experimental results, the average accuracy of the proposed 1DCNN-LSTM model for the recognition of people counting reached 86.66% at ROI. In general, a high-accuracy, low-complexity, and high-robustness solution in IR-UWB radar people counting was presented in this study. Full article

Radar-based personal identification and fall detection have received considerable attention in smart healthcare scenarios. Deep learning algorithms have been introduced to improve the performance of non-contact radar sensing applications. However, the original Transformer network is not suitable for multi-task radar-based applications to effectively extract temporal features from time-series radar signals. This article proposes the Multi-task Learning Radar Transformer (MLRT): a personal Identification and fall detection network based on IR-UWB radar. The proposed MLRT utilizes the attention mechanism of Transformer as its core to automatically extract features for personal identification and fall detection from radar time-series signals. Multi-task learning is applied to exploit the correlation between the personal identification task and the fall detection task, enhancing the performance of discrimination for both tasks. In order to suppress the impact of noise and interference, a signal processing approach is employed including DC removal and bandpass filtering, followed by clutter suppression using a RA method and Kalman filter-based trajectory estimation. An indoor radar signal dataset is generated with 11 persons under one IR-UWB radar, and the performance of MLRT is evaluated using this dataset. The measurement results show that the accuracy of MLRT improves by 8.5% and 3.6% for personal identification and fall detection, respectively, compared to state-of-the-art algorithms. The indoor radar signal dataset and the proposed MLRT source code are publicly available. Full article

Vital signs provide important biometric information for managing health and disease, and it is important to monitor them for a long time in a daily home environment. To this end, we developed and evaluated a deep learning framework that estimates the respiration rate (RR) and heart rate (HR) in real time from long-term data measured during sleep using a contactless impulse radio ultrawide-band (IR-UWB) radar. The clutter is removed from the measured radar signal, and the position of the subject is detected using the standard deviation of each radar signal channel. The 1D signal of the selected UWB channel index and the 2D signal applied with the continuous wavelet transform are entered as inputs into the convolutional neural-network-based model that then estimates RR and HR. From 30 recordings measured during night-time sleep, 10 were used for training, 5 for validation, and 15 for testing. The average mean absolute errors for RR and HR were 2.67 and 4.78, respectively. The performance of the proposed model was confirmed for long-term data, including static and dynamic conditions, and it is expected to be used for health management through vital-sign monitoring in the home environment. Full article

The knowledge of heart and respiratory rates (HRs and RRs) is essential in assessing human body static. This has been associated with many applications, such as survivor rescue in ruins, lie detection, and human emotion detection. Thus, the vital signal extraction from radar echoes after pre-treatments, which have been applied using various methods by many researchers, has exceedingly become a necessary part of its further usage. In this review, we describe the variety of techniques used for vital signal extraction and verify their accuracy and efficiency. Emerging approaches such as wavelet analysis and mode decomposition offer great opportunities to measure vital signals. These developments would promote advancements in industries such as medical and social security by replacing the current electrocardiograms (ECGs), emotion detection for survivor status assessment, polygraphs, etc. Full article

This paper presents the design of an H-band planar antenna array with broad bandwidth and narrow beam width for an IR-UWB radar application. The basic single wideband microstrip antenna is achieved by adding slots and the inset-fed technique. Then, we proposed a planar antenna array on a limited area that obtains an essential narrow beamwidth for the radar of a Non-Contact Human Vital Signs Detection application. The experimental and simulated results of the microstrip antenna array are in good agreement. The measured results show that the proposed antenna array exhibits a wide impedance bandwidth of 10.7% at around 7.5 GHz and a narrow beamwidth of 40 degrees vertically and 50 degrees horizontally, respectively. Full article

With the vigorous development of ubiquitous sensing technology, an increasing number of scholars pay attention to non-contact vital signs (e.g., Respiration Rate (RR) and Heart Rate (HR)) detection for physical health. Since Impulse Radio Ultra-Wide Band (IR-UWB) technology has good characteristics, such as non-invasive, high penetration, accurate ranging, low power, and low cost, it makes the technology more suitable for non-contact vital signs detection. Therefore, a non-contact multi-human vital signs detection method based on IR-UWB radar is proposed in this paper. By using this technique, the realm of multi-target detection is opened up to even more targets for subjects than the more conventional single target. We used an optimized algorithm CIR-SS based on the channel impulse response (CIR) smoothing spline method to solve the problem that existing algorithms cannot effectively separate and extract respiratory and heartbeat signals. Also in our study, the effectiveness of the algorithm was analyzed using the Bland–Altman consistency analysis statistical method with the algorithm’s respiratory and heart rate estimation errors of 5.14% and 4.87%, respectively, indicating a high accuracy and precision. The experimental results showed that our proposed method provides a highly accurate, easy-to-implement, and highly robust solution in the field of non-contact multi-person vital signs detection. Full article

This paper deals with robust heart rate detection intended for the in-car monitoring of people. There are two main problems associated with radar-based heart rate detection. Firstly, the signal associated with the human heart is difficult to separate from breathing harmonics in the frequency domain. Secondly, the vital signal is affected by any interference signal from hand gestures, lips motion during speech or any other random body motions (RBM). To handle the problem of the breathing harmonics, we propose a novel algorithm based on time series data instead of the conventionally used frequency domain technique. In our proposed method, a deep learning classifier is used to detect the pattern of the heart rate signal. To deal with the interference mitigation from the random body motions, we identify an optimum location for the radar sensor inside the car. In this paper, a commercially available Novelda Xethru X4 radar is used for signal acquisition and vital sign measurement of 5 people. The performance of the proposed algorithm is compared with and found to be superior to that of the conventional frequency domain technique. Full article

Ultra-wideband radar application for sleep breathing monitoring is hampered by the difficulty of obtaining breathing signals for non-stationary subjects. This occurs due to imprecise signal clutter removal and poor body movement removal algorithms for extracting accurate breathing signals. Therefore, this paper proposed a Sleep Breathing Detection Algorithm (SBDA) to address this challenge. First, SBDA introduces the combination of variance feature with Discrete Wavelet Transform (DWT) to tackle the issue of clutter signals. This method used Daubechies wavelets with five levels of decomposition to satisfy the signal-to-noise ratio in the signal. Second, SBDA implements a curve fit based sinusoidal pattern algorithm for detecting periodic motion. The measurement was taken by comparing the R-square value to differentiate between chest and body movements. Last but not least, SBDA applied the Ensemble Empirical Mode Decomposition (EEMD) method for extracting breathing signals before transforming the signal to the frequency domain using Fast Fourier Transform (FFT) to obtain breathing rate. The analysis was conducted on 15 subjects with normal and abnormal ratings for sleep monitoring. All results were compared with two existing methods obtained from previous literature with Polysomnography (PSG) devices. The result found that SBDA effectively monitors breathing using IR-UWB as it has the lowest average percentage error with only 6.12% compared to the other two existing methods from past research implemented in this dataset. Full article
