This manuscript presents the results from the synthesis and characterization of a slag analogue with a nominal composition of 17 wt% LiMnO₂ and 83 wt% Ca₂SiO₄ encountering fairly high cooling rates in order to study the evolution of Mn-species. The Mn species was also simulated from 1223 K to 1773 K using a thermodynamic model, assuming a homogeneous melt. The micro-composition including the Mn species of the solidified slag was determined experimentally, and was used as basis for molecular dynamics (MD) simulation. The MD simulation provides information on structure and viscosity at high temperatures, which are otherwise difficult to access. These parameters significantly influence oxidation state of redox-active elements and the solidified product. The micro-composition analyzed by electron probe micro analysis (EPMA) and synchrotron-based micro-X-ray fluorescence (micro-XRF) showed that Mn-rich and Ca-Si-rich phases are separated. While the Mn-O phases did not contain noticeable Ca, the Ca₂SiO₄ phase had incorporated 0.6 wt% of Mn. The slag solidified into round-shaped and droplet-shaped grains of a Li-Mn-oxide, some Mn₃O₄ and Ca₂SiO₄. The powder X-ray diffraction (PXRD) confirmed the formation of larnite; the identity of the Li-Mn-oxide, however, remained inconclusive. The Mn oxidation state (OS) was identified using synchrotron-based micro-X-ray absorption near edge spectroscopy (micro-XANES). The Mn-O grains matched well with Li-Mn-oxides and a Mn OS: +3, e.g., LiMn³⁺O₂. Small areas matching hausmannite (Mn²⁺Mn₂³⁺O₄) were also identified. The OS of Mn in the silicate phase could not be identified. For comparison, a slowly cooled slag analogue with similar composition, but higher Si content, was also subjected to micro-XANES. The slowly cooled slag formed long Mn-rich needles in a matrix of large calcium silicate crystals. The Mn-rich crystals matched well with the XANES spectrum of a Mn³⁺ Li-oxide like LiMn³⁺O₂. At the rim of the needles, the Mn-spectra matched well the hausmannite (Mn²⁺Mn₂³⁺O₄) reference. In the silicate phases, Mn had an OS: +2, unambiguously. The melt structure at different temperatures of two compositions, i.e., LiMn³⁺O₂ and Ca₂SiO₄, was simulated using molecular dynamics (MD). They serve as model compositions, assuming a heterogeneous melt. The results show significant different degrees of polymerization and viscosity. Information from MD simulations can support the identification of potentially different oxygen permeability and with that prediction of oxidation states. The bulk composition was identified by inductively coupled plasma optical emission spectrometry (ICP-OES), bulk structure by PXRD and bulk species by lab-XANES. The synchrotron micro analysis including micro-XRD were performed at the microfocus beamline I18 at the Diamond Light Source. Pure reference compounds were prepared and characterized with the same multi-modal approach. Full article

The High Intensity Muon Beams (HIMB) project at the Paul Scherrer Institute (PSI) will deliver muon beams with unprecedented intensities of up to ${10}^{10}\mathrm{muons}/\mathrm{s}$ for next-generation particle physics and material science experiments. This represents a hundredfold increase over the current state-of-the-art muon intensities, also provided by PSI. We performed beam dynamics optimisations and studies for the design of the HIMB beamlines MUH2 and MUH3 using Graphics Transport, Graphics Turtle, and G4beamline, the latter incorporating PSI’s own measured ${\pi }^{+}$ cross-sections and variance reduction. We initially performed large-scale beamline optimisations using asynchronous Bayesian optimisation with DeepHyper. We are now developing an island-based evolutionary optimisation code $\mathtt{glyfada}$ based on the Paradiseo framework, where we implemented Message Passing Interface (MPI) islands with OpenMP parallelisation within each island. Furthermore, we implemented an island model that is also suitable for high-throughput computing (HTC) environments with asynchronous communication via a Redis database. The code interfaces with the codes COSY INFINITY and G4beamline. The code $\mathtt{glyfada}$ will provide heterogeneous island model optimisation using evolutionary optimisation and local search methods, as well as part-wise optimisation of the beamline with automatic advancement through stages. We will use the $\mathtt{glyfada}$ for a future large-scale optimisation of the HIMB beamlines. Full article

Modern catalysts are complex systems whose performance depends both on space and time domains and, most importantly, on the operational environment. As a direct consequence, understanding their functionalities requires sophisticated techniques and tools for measurement and simulation, addressing the proper spatial and temporal scale and being capable of mimicking the working conditions of every single component, such as catalyst supports, electrodes, electrolytes, as well as of the entire assembly, e.g., in the case of fuel cells or batteries. Scanning photoelectron spectro-microscopy (SPEM) is one of the approaches that allow combining X-ray photoelectron spectroscopy with sub-micron spatial resolution; in particular, the SPEM hosted at the ESCA Microscopy beamline at Elettra has been upgraded to conduct in situ and operando experiments. Three different case studies are presented to illustrate the capabilities of the SPEM in the investigation of catalytic materials in different conditions and processes. Full article

In many food applications, the mechanical properties of fats play a critical role in determining the processing performance of fat-rich products. In fact, fat crystal networks form a particular class of soft materials that exhibit viscoelastic properties. The uniqueness of the mechanical response is intricately linked to the hierarchical nature of the system, as fats possess a complex architecture encompassing features at different scale levels (i.e., length scales). Since the discovery of crystalline nanoplatelets (CNPs), it has been hypothesized that CNPs are the basic building blocks of lipid networks and that CNPs are the responsible units for the mechanical properties of fats. This hypothesis, however, has only been partially tested. In this article, we examine which units could be responsible (e.g., lamellae, CNP, CNP aggregates) for the mechanical breakdown of fat crystal networks, through Rheo-USAXS in beamline ID02 (ESRF, Grenoble, France). Time-resolved USAXS profiles were acquired during the three steps of a three-interval thixotropy test (3iTT), namely, pre-shear, shear and recovery. The results were then utilized to evidence which specific length scale is arranged (i.e., orientated) during rheological breakdown. The findings suggest that, at the tested shear rates, orientation is only visible from 250 nm onwards, suggesting that the rheological breakdown of triglycerides is primarily driven by the orientation, and possible disruption, of CNP aggregates. These results reveal the critical role of CNP aggregates in the mechanical properties of fats. In the longer term, we believe this study will steer future research toward a more focused understanding of CNP aggregation and disaggregation dynamics. Full article

Beam position uncertainties along the beam trajectory arise from the accelerator, beamline, and scanning magnets (SMs). They can be monitored in real time, e.g., through strip ionization chambers (ICs), and treatments can be paused if needed. Delivery is more reliable and accurate if the beam position is projected from monitored nozzle parameters to the isocenter, allowing for accurate online corrections to be performed. Beam position projection algorithms are also used in post-delivery log file analyses. In this paper, we investigate the four potential algorithms that can be applied to all pencil beam scanning (PBS) nozzles. For some combinations of nozzle configurations and algorithms, however, the projection uses beam properties determined offline (e.g., through beam tuning or technical commissioning). The best algorithm minimizes either the total uncertainty (i.e., offline and online) or the total offline uncertainty in the projection. Four beam position algorithms are analyzed (A1–A4). Two nozzle lengths are used as examples: a large nozzle (1.5 m length) and a small nozzle (0.4 m length). Three nozzle configurations are considered: IC after SM, IC before SM, and ICs on both sides. Default uncertainties are selected for ion chamber measurements, nozzle entrance beam position and angle, and scanning magnet angle. The results for other uncertainties can be determined by scaling these results or repeating the error propagation. We show the propagation of errors from two locations and the SM angle to the isocenter for all the algorithms. The best choice of algorithm depends on the nozzle length and is A1 and A3 for the large and small nozzles, respectively. If the total offline uncertainty is to be minimized (a better choice if the offline uncertainty is not stable), the best choice of algorithm changes to A1 for the small nozzle for some hardware configurations. Reducing the nozzle length can help to reduce the gantry size and make proton therapy more accessible. This work is important for designing smaller nozzles and, consequently, smaller gantries. This work is also important for log file analyses. Full article

Micro-X-ray fluorescence and X-ray absorption fine structure (µ-XRF-XAFS) is one of the most powerful tools to identify the distribution and speciation of trace elements in natural samples with µm spatial resolution. However, conventional µ-XRF-XAFS studies applied to rare earth elements (REEs: lanthanide elements + Y in this study) are mainly limited to their L-edges and L lines (except for Y) that are subject to strong interferences from other elements (mainly transition metals). In this study, we extend µ-XRF-XAFS to the higher energy region (HE-µ-XRF-XAFS) by using an incident X-ray microbeam (size: ca. 1 × 1 µm²) between 38 and 54 keV to realize K-edge excitation lanthanide analysis without interferences from other elements at the BL37XU beamline, SPring-8 (Japan). This method enables us to simultaneously analyze (i) REE patterns (from La to Dy), (ii) XAFS spectra, and (iii) µm-scale distribution of each REE in the natural sample. The proposed method also realizes the simultaneous application of µ-XAFS at low (e.g., Fe K-edge) and high (lanthanide K-edges) energy at the same spot without changing the setup of the µ-XRF-XAFS system using the detuning technique. Full article

We report on the technological commissioning of the Laser–Plasma Ion Accelerator section of the ELIMAIA user beamline at the ELI Beamlines facility in the Czech Republic. The high-peak, high-average power L3-HAPLS laser system was used with an energy of ~10 J and pulse duration of ~30 fs on target, both in single-pulse and high repetition-rate (~0.5 Hz) mode. The laser pulse was tightly focused to reach ultrahigh intensity on target (~10²¹ W/cm²) and sustain such laser–plasma interaction regime during high repetition-rate operations. The laser beam, ion beam, and laser–plasma emission were monitored on a shot-to-shot basis, and online data analysis at 0.5 Hz was demonstrated through the full set of used diagnostics (e.g., far and near field, laser temporal diagnostics, X- and gamma-ray detectors, Thomson Parabola ion spectrometer, time-of-flight ion detectors, plasma imaging, etc.). The capability and reliability of the ELIMAIA Ion Accelerator was successfully demonstrated at a repetition rate of 0.5 Hz for several hundreds of consecutive laser shots. Full article

ELIMED has been developed and installed at ELI beamlines as a part of the ELIMAIA beamline to transport, monitor, and use laser-driven ion beams suitable for multidisciplinary applications, including biomedical ones. This paper aims to investigate the feasibility to perform radiobiological experiments using laser-accelerated proton beams with intermediate energies (up to 30 MeV). To reach this goal, we simulate a proton source based on experimental data like the ones expected to be available in the first phase of ELIMED commissioning by using the G4-ELIMED application (an application based on the Geant4 toolkit that simulates the full ELIMED beamline). This allows the study of transmission efficiency and the final characteristics of the proton beam at the sample irradiation point. The Energy Selector System is used as an active energy modulator to obtain the desired beam features in a relatively short irradiation time (around 6 min). Furthermore, we demonstrate the capability of the beamline to filter out other ion contaminants, typically co-accelerated in a laser-plasma environment. These results can be considered as a detailed feasibility study for the use of ELIMED for various user applications such as radiobiological experiments with ultrahigh dose rate proton beams. Full article

Synchrotron X-ray µ- and nano-probes are increasingly affirming their relevance in cultural heritage applications, especially in material characterization of tiny and complex micro-samples which are typical from archaeological and artistic artifacts. For such purposes, synchrotron radiation facilities are tailoring and optimizing beamlines and set-ups for CH, taking also advantages from the challenges offered by the third-generation radiation sources. In ancient ceramics studies, relevant information for the identification of production centers and manufacture technology can be obtained in a non-invasive and non-destructive way at the micro-sample level by combining different SR based methods. However, the selection of appropriate beamlines, techniques and set-ups are critical for the success of the experiments. Fine and varnished wares (e.g., Attic and western-Greek colonial products) are an excellent case study for exploring challenges offered by synchrotron X-ray microprobes optimized to collect microchemical and phase-distribution maps. The determination of provenance and/or technological tracers is relevant in correctly classifying productions, often based only on ceramic paste, gloss macroscopic features or style. In addition, when these vessels are preserved in Museums as masterpieces or intact pieces the application of non-invasive approach at the micro sample is strictly required. Well-designed synchrotron µXRF and µXANES mapping experiments are able providing relevant clues for discriminating workshops and exploring technological aspects, which are fundamental in answering the current archaeological questions on varnished Greek or western-Greek colonial products. Full article

The Imaging and Medical Beamline (IMBL) is a superconducting multipole wiggler-based beamline at the 3 GeV Australian Synchrotron operated by the Australian Nuclear Science and Technology Organisation (ANSTO). The beamline delivers hard X-rays in the 25–120 keV energy range and offers the potential for a range of biomedical X-ray applications, including radiotherapy and medical imaging experiments. One of the imaging modalities available at IMBL is propagation-based X-ray phase-contrast computed tomography (PCT). PCT produces superior results when imaging low-density materials such as soft tissue (e.g., breast mastectomies) and has the potential to be developed into a valuable medical imaging tool. We anticipate that PCT will be utilized for medical breast imaging in the near future with the advantage that it could provide better contrast than conventional X-ray absorption imaging. The unique properties of synchrotron X-ray sources such as high coherence, energy tunability, and high brightness are particularly well-suited for generating PCT data using very short exposure times on the order of less than 1 min. The coherence of synchrotron radiation allows for phase-contrast imaging with superior sensitivity to small differences in soft-tissue density. Here we also compare the results of PCT using two different detectors, as these unique source characteristics need to be complemented with a highly efficient detector. Moreover, the application of phase retrieval for PCT image reconstruction enables the use of noisier images, potentially significantly reducing the total dose received by patients during acquisition. This work is part of ongoing research into innovative tomographic methods aimed at the introduction of 3D X-ray medical imaging at the IMBL to improve the detection and diagnosis of breast cancer. Major progress in this area at the IMBL includes the characterization of a large number of mastectomy samples, both normal and cancerous, which have been scanned at clinically acceptable radiation dose levels and evaluated by expert radiologists with respect to both image quality and cancer diagnosis. Full article

We present the initial design studies and specifications for an accelerator and conveyor system to irradiate collagen samples, modifying properties such as the putrescibility and mechanical behaviours in a paradigm shift from existing, widely used technology. We show the integrated design requirements for a magnetic rastering scheme to move the beam position in order to ensure a uniform dose distribution over the full surface of the hide and discuss its dependence on factors such as the size of the hide, the beam current and conveyor speed. We also present initial energy deposition studies using beam particle interaction simulation program G4beamline, in order to determine the numerical beam parameters and angle of incidence needed to ensure a uniform depth-dose distribution throughout the hide thickness. Full article

The macroscopic properties of novel liquid crystal (LC) systems—LCs with unconventional molecular structure as well as conventional LCs in unconventional geometries—directly descend from their mesoscopic structural organization. While X-ray diffraction (XRD) is an obvious choice to investigate their nanoscale structure, conventional diffractometry is often hampered by experimental difficulties: the low scattering power and short-range positional order of the materials, resulting in weak and diffuse diffraction features; the need to perform measurements in challenging conditions, e.g., under magnetic and/or electric fields, on thin films, or at high temperatures; and the necessity to probe micron-sized volumes to tell the local structural properties from their macroscopic average. Synchrotron XRD allows these problems to be circumvented thanks to the superior diffraction capabilities (brilliance, q-range, energy and space resolution) and advanced sample environment available at synchrotron beamlines. Here, we highlight the potentiality of synchrotron XRD in the field of LCs by reviewing a selection of experiments on three unconventional LC systems: the potentially biaxial and polar nematic phase of bent-core mesogens; the very high-temperature nematic phase of all-aromatic LCs; and polymer-dispersed liquid crystals. In all these cases, synchrotron XRD unveils subtle nanostructural features that are reflected into macroscopic properties of great interest from both fundamental and technological points of view. Full article

In situ dilatometry experiments using high energy synchrotron X-ray diffraction in transmission mode were carried out at the high energy material science beamline P07@PETRAIII at DESY (Deutsches Elektronen Synchrotron) for the tempering steel AISI 4140 at defined mechanical loading. The focus of this study was on the initial tempering state ( $ferrite$ ) and the hardened state ( $martensite$ ). Lattice strains were calculated from the 2D diffraction data for different $hkl$ planes and from those temperature-dependent lattice plane specific diffraction elastic constants ( $DECs$ ) were determined. The resulting coupling terms allow for precise stress analysis for typical hypoeutectoid steels using diffraction data during heat treatment processes, that is, for in situ diffraction studies during thermal exposure. In addition, by averaging $hkl$ specific $Youn{g}^{\prime }smoduli$ and $Poissonratios$ macroscopic temperature-dependent elastic constants were determined. In conclusion a novel approach for the determination of phase-specific temperature-dependent DECs was suggested using diffraction based dilatometry that provides more reliable data in comparison to conventional experimental procedures. Moreover, the averaging of lattice plane specific results from in situ diffraction analysis supply robust temperature-dependent macroscopic elastic constants for martensite and ferrite as input data for heat treatment process simulations. Full article

Zone plates are diffractive optics commonly used in X-ray microscopes. Here, we present a wet-chemical approach for fabricating high aspect ratio Pd/Si zone plate optics aimed at the hard X-ray regime. A Si zone plate mold is fabricated via metal-assisted chemical etching (MACE) and further metalized with Pd via electroless deposition (ELD). MACE results in vertical Si zones with high aspect ratios. The observed MACE rate with our zone plate design is 700 nm/min. The ELD metallization yields a Pd density of 10.7 g/cm ${}^3$ , a value slightly lower than the theoretical density of 12 g/cm ${}^3$ . Fabricated zone plates have a grid design, 1:1 line-to-space-ratio, 30 nm outermost zone width, and an aspect ratio of 30:1. At 9 keV X-ray energy, the zone plate device shows a first order diffraction efficiency of 1.9%, measured at the MAX IV NanoMAX beamline. With this work, the possibility is opened to fabricate X-ray zone plates with low-cost etching and metallization methods. Full article

Nanoparticles (NPs) are currently under intensive research for their application in tumor diagnosis and therapy. X-ray fluorescence computed tomography (XFCT) is considered a promising non-invasive imaging technique to obtain the bio-distribution of nanoparticles which include high-Z elements (e.g., gadolinium (Gd) or gold (Au)). In the present work, a set of experiments with quantitative imaging of GdNPs in mice were performed using our benchtop XFCT device. GdNPs solution which consists of 20 mg/mL NaGdF4 was injected into a nude mouse and two tumor-bearing mice. Each mouse was then irradiated by a cone-beam X-ray source produced by a conventional X-ray tube and a linear-array photon counting detector with a single pinhole collimator was placed on one side of the beamline to record the intensity and spatial information of the X-ray fluorescent photons. The maximum likelihood iterative algorithm with scatter correction and attenuation correction method was applied for quantitative reconstruction of the XFCT images. The results show that the distribution of GdNPs in each target slice (containing liver, kidney or tumor) was well reconstructed and the concentration of GdNPs deposited in each organ was quantitatively estimated, which indicates that this benchtop XFCT system provides convenient tools for obtaining accurate concentration distribution of NPs injected into animals and has potential for imaging of nanoparticles in vivo. Full article
