In this study, a terahertz microfluidic multi-band sensor was designed. Unlike previous microfluidic absorption sensors that rely on dipole resonance, the proposed sensor uses a physical mechanism for absorption by exciting higher-order lattice resonances in microfluidic structures. With a Fabry–Perot cavity, the sensor can form an absorption peak with a high quality factor (Q) and narrow full width at half maximum (FWHM). A high Q value and a narrow FWHM are valuable in the field of sensing and provide strong support for high-precision sensing. On this basis, the sensing performance of the device was investigated. The simulation results clearly show that the absorption sensor has ultra-high sensitivity, which reaches 400 GHz/Refractive Index Unit (RIU). In addition, the sensor generates three absorption peaks, overcoming the limitations of a single frequency band in a composite resonance mode and multidimensional frequency response, which has potential application value in the field of volatile organic compound (VOC) sensing. Full article

Optically pumped gas terahertz (THz) lasers (OPGTLs) as reliable sources of THz radiation have been extensively utilized within THz application areas. In this paper, a substrate-free metal mesh coupler based on the metasurfaces principle was designed for continuous wave OPGTL, which is suitable for the Fabry–Perot (FP) THz resonator. The parameters of substrate-free metal mesh are calculated by the Ulrich equivalent circuit model, and the influence of metal mesh period and linewidth on its transmittance is analyzed quantitatively. Taking the THz laser with the 118.8 µm of CH₃OH optically pumped by the 9.6 µm CO₂ laser line for instance, two kinds of metal mesh were devised as input and output couplers of the resonator, and the transmittance and reflectance of the metal meshes are verified by the finite-difference time-domain (FDTD) method. Furthermore, the transmitted and reflected light fields of the FP resonant cavity metal mesh mirrors were simulated by using the FDTD method under the vertical incidence of both pump light and THz waves. Validation of the optical field characteristics of the substrate-free metal meshes confirmed their suitability as ideal input and output coupling cavity mirrors for FP resonant cavities in optically pumped gas THz lasers. Full article

Quasibound states in the continuum (qBICs) have aroused much attention as a feasible stage to investigate optical strong coupling due to their extremely high-quality factors (Q-factors) and extraordinary electromagnetic field enhancement. However, current demonstrations of strong coupling based on qBICs have primarily focused on the visible spectral range, while research in the near-infrared (NIR) regime remains scarce. In this work, we design a nanograting metasurface supporting Friedrich–Wintgen bound states in the continuum (FW BICs). We demonstrate that FW BIC formation stems from destructive interference between Fabry–Pérot cavity modes and metal–dielectric hybrid guided-mode resonances. To investigate the qBIC–exciton coupling system, we simulated the interaction between MoTe₂ excitons and nanograting metasurfaces. A Rabi splitting of 55.4 meV was observed, which satisfies the strong coupling criterion. Furthermore, a chiral medium layer is modeled inside the nanograting metasurface by rewriting the weak expression and boundary conditions. A mode splitting of the qBIC–chiral medium system in the circular dichroism (CD) spectrum demonstrates that the chiral response successfully transferred from the chiral medium layer to the exciton–polaritons systems through strong coupling. In comparison to the existing studies, our work demonstrates a significantly larger CD signal under the same Pascal parameters and with a thinner chiral dielectric layer. Our work provides a new ideal platform for investigating the strong coupling based on quasibound states in the continuum, which exhibits promising applications in near-infrared chiral biomedical detection. Full article

To address the inherent contradiction between low-profile design and high gain in traditional omnidirectional antennas, as well as the narrow bandwidth constraints of ENZ antennas, this study presents a dual-mode ENZ-FP collaborative resonant antenna array design utilizing a substrate-integrated waveguide (SIW). Through systematic analysis of ENZ media’s quasi-static field distribution, we innovatively integrated it with Fabry–Perot (F–P) resonance, achieving unprecedented dual-band omnidirectional radiation at 5.18 GHz and 5.72 GHz within a single ENZ antenna configuration for the first time. The directivity of both frequencies reached 12.0 dBi, with a remarkably low profile of only 0.018λ. We then extended this design to an ENZ-FP dual-mode beam-scanning array. By incorporating phase control technology, we achieved wide-angle scanning despite low-profile constraints. The measured 3 dB beam coverage angles at the dual frequencies were ±63° and ±65°, respectively. Moreover, by loading the impedance matching network, the −10 dB impedance bandwidth of the antenna array was further extended to 2.4% and 2.7%, respectively, thus overcoming the narrowband limitations of the ENZ antenna and enhancing practical applicability. The antennas were manufactured using PCB (Printed Circuit Board) technology, offering high integration and cost efficiency. This provides a new paradigm for UAV (Unmanned Aerial Vehicle) communication and radar detection systems featuring multi-band operation, a low-profile design, and flexible beam control capabilities. Full article

Acoustic temperature measurement (ATM) and sound source localization (SSL) are two important applications of acoustic sensors. The development of novel acoustic sensors capable of both ATM and SSL is an innovative research topic with great interest. In this work, an acoustic Fabry-Perot resonance detector (AFPRD) and its cross-shaped array were designed and fabricated, and the passive ATM function of the AFPRD and the SSL capability of the AFPRD array were simulated and experimentally verified. The AFPRD consists of an acoustic waveguide and a microphone with its head inserted into the waveguide, which can significantly enhance the microphone’s sensitivity via the FP resonance effect. As a result, the frequency response curve of AFPRD can be easily measured using weak ambient white noise. Based on the measured frequency response curve, the linear relationship between the resonant frequency and the resonant mode order of the AFPRD can be determined, the slope of which can be used to calculate the ambient sound velocity and air temperature. The AFPRD array was prepared by using four bent acoustic waveguides to expand the array aperture, which combined with the multiple signal classification (MUSIC) algorithm can be used for distant multi-target localization. The SSL accuracy can be improved by substituting the sound speed measured in real time into the MUSIC algorithm. The AFPRD’s passive ATM function was verified in an anechoic room with white noise as low as 17 dB, and the ATM accuracy reached 0.4 °C. The SSL function of the AFPRD array was demonstrated in the outdoor environment, and the SSL error of the acoustic target with a sound pressure of 35 mPa was less than 1.2°. The findings open up a new avenue for the development of multifunctional acoustic detection devices and systems. Full article

In this study, we present a novel ultra-wideband passive polarization conversion metasurface (PCM) that integrates double V-shaped patterns with circular split-ring resonators. Operating without any external power supply or active components, this design effectively manipulates the polarization state of incident electromagnetic waves. Numerical and experimental results demonstrate that the proposed PCM can convert incident linear polarization into orthogonal states across a wide frequency range of 7.1–22.3 GHz, encompassing the C-, X-, Ku-, and K-bands. A fabricated prototype confirms that the polarization conversion ratio (PCR) exceeds 90% throughout the specified band. Furthermore, we explore an additional application of this passive metasurface for electromagnetic stealth, wherein it achieves over 10 dB of monostatic radar cross-section (RCS) reduction from 7.6 to 21.5 GHz. This broad effectiveness is attributed to strong electromagnetic resonances between the top and bottom layers, as well as the Fabry–Pérot cavity effect, as evidenced by detailed analyses of the underlying physical mechanisms and induced surface currents. These findings confirm the effectiveness of the proposed design and highlight its potential for future technological applications, including 6G communications, radar imaging, anti-interference measures, and electromagnetic stealth. Full article

The main characteristic of a reflective semiconductor optical amplifier chip (RSOA) is that it does not generate optical resonance under electric pumping and maintains the operation state of spontaneous emission. In this paper, a Nb₂O₅/SiO₂/Nb₂O₅/SiO₂ (four-layer Nb₂O₅/SiO₂) film system is employed as the coating material for the output facet of the RSOA. The 3 dB spectral width of the spontaneous emission spectrum from this RSOA reaches 79.4 nm, with a ripple of less than 1 dB occurring across this wavelength range. Notably, around the 1550 nm wavelength, the ripple is as low as 0.5 dB. This represents the best performance reported for this type of chip. The RSOA is packaged as a narrow-linewidth external cavity laser. Under test conditions of 25 °C and 180 mA, the external cavity laser produces an output power of 12.6 mW and achieves a linewidth of 299.8 Hz. Furthermore, by adjusting the Fabry–Pérot (FP) standard cavity, filtering, and other external cavity parameters, the lasing spectrum of the narrow-linewidth external cavity laser based on the RSOA is tunable across a wavelength range from 1535.83 nm to 1561.42 nm, which shows the usability of the proposed ROSA for a C-band external cavity narrow-linewidth laser. Full article

We propose a highly efficient broadband tunable metamaterial infrared absorption device. The design is modeled using the three-dimensional finite element method for the absorption device. The results show that the absorption device captures over 90% of the light in the wavelength range from 6.10 μm to 17.42 μm. We utilize VO₂’s phase change property to adjust the absorption device, allowing the average absorption level to vary between 20.61% and 94.88%. In this study, we analyze the electromagnetic field distribution of the absorption device at its peak absorption point and find that the high absorption is achieved through both surface plasmon resonance and Fabry–Perot cavity resonance. The structural parameters of the absorption device are fine-tuned through parameter scanning. By comparing our work with previous studies, we demonstrate the superior performance of our design. Additionally, we investigate the polarization angle and incident angle of the absorption device and show that it is highly insensitive to these factors. Importantly, the simple structure of our absorption device broadens its potential uses in photodetection, electromagnetic stealth, and sensing. Full article

This study addresses the challenges of electromagnetic interference and unstable signal transmission encountered by traditional sensors in detecting partial discharge (PD) within stator slots of large motors. A novel Extrinsic Fabry–Perot Interferometer (EFPI) sensor with a vibration-coupling air gap was designed to enhance the narrowband resonant detection sensitivity for PD ultrasonic signals by optimizing the diaphragm structure and coupling interface. The sensor features a quartz diaphragm with a thickness of 20 μM, an effective constrained radius of 0.9 mm, a vibration-coupling air gap depth of 100 μM, and a first-order natural resonant frequency of 66 kHz. Simulation and experimental analyses revealed the distribution characteristics and propagation paths of ultrasonic signals within stator slots. The results demonstrate that the EFPI sensor effectively detects PD ultrasonic signals at its resonant frequency of 66 kHz with a localization error of less than 5 mm, meeting engineering requirements. This study provides theoretical and practical insights into the efficient detection and precise localization of insulation faults in large motor stators. Full article

In this paper, we report the growth of high-quality ${\mathrm{In}}_{0.59}{\mathrm{Ga}}_{0.41}\mathrm{As}/{\mathrm{In}}_{0.37}{\mathrm{Al}}_{0.63}\mathrm{As}$ strain-balanced quantum cascade lasers (QCLs) in the low-pressure MOCVD production type multi-wafer planetary reactor addressing, in particular, quality and scaled manufacturing issues. Special attention was given to achieving the sharp interfaces (IFs), by optimizing the growth interruptions time and time of exposure of InAlAs layer to oxygen contamination in the reactor, which all result in extremely narrow IFs width, below 0.5 nm. The lasers were designed for emission at $7.7\mu$m. The active region was based on diagonal two-phonon resonance design with 40 cascade stages. For epitaxial process control, the High Resolution X-Ray Diffraction (HR XRD) and Transmission Electron Microscopy (TEM) were used to characterize the structural quality of the QCL samples. The grown structures were processed into mesa Fabry-Perot lasers using dry etching RIE ICP processing technology. The basic electro-optical characterization of the lasers is provided. We also present results of Green’s function modeling of QCLs and demonstrate the capability of non-equilibrium Green’s function (NEGF) approach for sophisticated, but still computationally effective simulation of laser’s characteristics. The sharpness of the grown IFs was confirmed by direct measurements of their chemical profiles and as well as the agreement between experimental and calculated wavelength obtained for the bandstructure with ideally abrupt (non-graded) IFs. Full article

In this paper, a design of vanadium dioxide for dynamic color gamut modulation based on Fano resonance is proposed. This approach facilitates color modulation by manipulating the phase transition state of vanadium dioxide. The device integrates both broadband and narrowband filters, featuring a structure consisting of a top silver mesh, a layer of vanadium dioxide, and a Fabry–Pérot cavity, which allows for effective modulation of the reflectance spectrum. Simulation results demonstrate that when vanadium dioxide is in its insulating state, the maximum reflectivity observed in the device spectrum, reaching 43.1%, appears at 475 nm. Conversely, when vanadium dioxide transitions to its metallic state, the peak wavelength shifts to 688 nm, accompanied by an increased reflectance peak of 59.3%. Analysis of electric field distributions reveals that the intensity caused by surface plasmonic resonance dominates over the excited Fano resonance while vanadium dioxide is in its insulating state, which is the opposite of when vanadium dioxide transitions to its metallic state. This behavior exhibits an excellent dynamic color-tuning capability. Specifically, the phase transition of vanadium dioxide results in a color difference ∆E₂₀₀₀ of up to 36.7, while maintaining good color saturation. This technique holds significant potential for applications such as dynamic color display and anti-counterfeit labeling. Full article

Minimizing optical losses in resonant cavities is crucial for improving photonic device performance. This study focuses on the development of a simulation tool to analyze scattering losses in Fabry–Pérot interferometers (FPIs), offering precise modeling of waveguide dynamics and contributing to accurate loss predictions across various platforms. Optical cavities often suffer from scattering losses due to surface roughness and material defects. Our approach integrates theoretical models and simulations to quantify these losses, utilizing the FPI as a model system. We identified upper and lower reflectivity thresholds, beyond which accurate measurement of losses becomes unreliable. For reflectivity below a certain threshold, measurement errors arise, while excessively high reflectivity can reduce fringe visibility and introduce detector sensitivity issues. Simulations were used to validate the model’s ability to predict reflectivity and attenuation in waveguides with varying loss levels. The software’s flexibility to adjust transmission parameters for different cavity configurations enhances its utility for a broad range of photonic systems. Our study offers a novel methodology for optical loss analysis, with practical applications in optimizing photonic devices. By providing a reliable tool for precise loss measurement, this work supports advancements in optical technologies, enabling the design of more efficient, high-performance devices across various applications. Full article

The method of laser far-detuned frequency locking is proposed based on a fiber Fabry–Perot cavity which transfers the ultra-stable atomic reference frequency stability to the target laser utilized for atomic sensors. The control transfer function of the closed-loop system is established to elucidate the process of perturbation suppression. It is illustrated that this method is robust against the disturbance to the laser and cavity by controlling the cavity with different parameters. After the long-term experimental test, the stability of the laser frequency locked on the fiber cavity achieves an Allan deviation of $9.9\times {10}^{-11}$ and the detuning of the nearest atomic frequency resonance point is more than 200 GHz. Its stability and detuning value exceed previous reports. Full article

Tunable filters have many potential applications in diverse fields, including high-capacity communications, dynamic beam shaping and spectral imaging. Although providing a high-performance solution for actively tunable devices, metasurface combined with tunable materials faces the great challenges of limited tuning range and modulation depth. Here, we propose a far-infrared tunable band-stop filter based on Fabry-Perot (FP) resonators and graphene surface plasmons. By switching the wavelength of the critical coupling condition of the filter via the gate voltage applied on graphene, achieving the dynamically tunable band-stop filtering at the central wavelengths from 12.4 μm to 14.1 μm with a modulation depth of more than 99%. Due to the symmetry of the proposed meta-atoms, the filter is insensitive to the polarization direction of the incident light. And it can realize more than 85% filtering efficiency within 60° angle of incidence around the vertical direction. By adjusting the geometry of the meta-atoms structure, it is feasible to move the operational range from the near-infrared to terahertz bands. Full article

We propose and experimentally demonstrate an approach for generating a wideband optical frequency comb (OFC) featuring multiple comb lines and wavelength tunability based on a gain-switched weak-resonant-cavity Fabry–Perot laser diode (WRC-FPLD) under multi-wavelength optical injection. The longitudinal mode interval of the utilized WRC-FPLD is about 0.28 nm (35.0 GHz), and its relaxation oscillation frequency is about 2.0 GHz at 1.15 times the threshold current. Under current modulation with a power of 20.00 dBm and a frequency of 2.0 GHz, the WRC-FPLD is driven into the gain-switched state. By further introducing multi-wavelength injection light (MWIL) containing four power equalization comb lines with an interval of 0.56 nm, a wideband OFC featuring multiple comb lines and wavelength tenability can be obtained. The experimental results demonstrate that by gradually increasing the injection’s optical power, the number of produced OFC lines initially increases and then decreases. By meticulously adjusting the wavelengths of the MWIL and carefully selecting the matched injection power, the broadband OFC can be tuned across an extensive spectral range. Under optimized operation parameters, an OFC with 147 lines, and a bandwidth of approximately 292 GHz within a 10 dB amplitude, variation is achieved. In this case, the measured single-sideband phase noise at the fundamental frequency is about −115 dBc/Hz @ 10 kHz, indicating that the comb lines possess good stability and strong coherence. Full article
