Search Results (18)

This paper analyzes a surface plasmon resonance (SPR) sensor utilizing silver (Ag) and Zirconium Nitride (ZrN) for glucose concentration detection in urine samples by the transfer matrix method (TMM). For effective SP excitation, a high-RI BAF10 prism is thought to be used as the coupling layer in the suggested theoretical design. The performance of the proposed SPR biosensor is theoretically evaluated using the wavelength interrogation technique by analyzing wavelength sensitivity (WS), detection accuracy (DA), figure of merit (FoM), and penetration depth (PD) parameters. Glucose in urine samples serves as the sensing medium (SM) in this biosensor configuration. The sensor achieves a maximum wavelength sensitivity of 6416.66 nm/RIU with a penetration depth of 297.53 nm. The ZrN structure incorporated in the biosensor demonstrates enhanced wavelength sensitivity through its molecular recognition sites that provide strong binding with glucose molecules. The improved wavelength sensitivity is attributed to the greater resonance wavelength shift produced by ZrN, resulting in significant performance enhancement of the biosensor for glucose detection. Benefits of the proposed SPR biosensor include very small urine sample concentration requirements (usually 0 mg/dL to 10 g/dL), compatibility with compact prism-based configurations that support the development of portable and affordable point-of-care devices, and quick detection within a few seconds due to real-time plasmonic response. These features make the sensor ideal for rapid, minimally invasive, and field-deployable glucose monitoring in both home and clinical relevance. Full article

In this work, we analyze how the coupling prism governs the performance of reduced-graphene-oxide (rGO)-assisted surface plasmon resonance (SPR) sensors for trace heavy-metal detection in water. A Kretschmann multilayer at 633 nm with a fixed Cu/Si₃N₄/rGO stack (45.0/5.00/1.41 nm) is modeled by transfer-matrix methods while varying the prism material among CaF₂, BK7, SiO₂, and SF₆. Performance optimization is carried out using angular sensitivity, full width at half maximum (FWHM), figure of merit (FoM), detection accuracy (DA), quality factor (QF), and a practical limit of detection (LoD). The analyte is represented by refractive-index typical of clean and contaminated water (n = 1.330 and 1.340). SF₆ yields the narrowest angular resonances but compresses analyte-induced angle spacing; CaF₂ provides larger analyte separations and consequently higher FoM and lower LoD under angle-encoded readout. The rGO interlayer enhances surface interaction across all prisms when co-tuned with the Cu and Si₃N₄ thicknesses. The sensitivity peaks around 310–320°·RIU⁻¹ for CaF₂. These results highlight the prism as a primary design variable in rGO-enhanced SPR sensing and position CaF₂-coupled architectures as promising for compact water-quality monitoring. Full article

The biomarker carcinoembryonic antigen (CEA) plays an important role in the diagnosis and monitoring of cancer, like breast, surveillance, colon, and liver cancer. The highly sensitive surface plasmon resonance (SPR) sensor presented in this work uses two-dimensional (2D) materials: BP/graphene, and the franckeite layer integrated in a Kretschmann configuration. The sensor structure, which includes a copper (Cu) layer and a CaF₂ prism, is intended to detect CEA in aqueous solutions with high accuracy. The proposed sensor’s performance was assessed using the transfer matrix method (TMM), with particular attention paid to important metrics like sensitivity, figure of merit (FoM), detection accuracy (DA), and penetration depth (PD). The proposed sensor achieved a sensitivity of 307.50 deg/RIU and a FoM of 61.62/RIU at a R_min value of 4.20 × 10⁻⁵ a.u. at a 40 nm Cu thickness, operating at a wavelength of 633 nm. The maximum sensitivity of 348.07 deg/RIU was achieved at 47 nm Cu thickness with BP layer, while the graphene layer yielded maximum sensitivity of 314.32 deg/RIU at the same Cu thickness. The results show that adding 2D layered materials to symmetric SPR sensors greatly improves detection performance, providing a promising foundation for the detection of clinical biomarkers in the future. Full article

This study presents the optimization of two SPR biosensors, Sys₃ and Sys₅, for SARS-CoV-2 detection at concentrations of 0.01–100 nM. Sys₃, with a 55 nm silver layer, a 13 nm silicon nitride layer, and a 10 nm ssDNA layer, achieved a figure of merit (FoM) of 571.24 RIU⁻¹, a signal-to-noise ratio (SNR) of 0.12, and a detection accuracy (DA) of 48.93 × 10⁻². Sys₅, incorporating a 50 nm silver layer, a 10 nm silicon nitride layer, a 10 nm ssDNA layer, and a 1.6 nm tungsten disulfide layer (L = 2), demonstrated a higher sensitivity of 305.33 °/RIU and a lower limit of detection (LoD) of 1.65 × 10⁻⁵. Sys₃ outshined in precision with low attenuation (<1%), while Sys₅ provided enhanced sensitivity and lower detection limits, crucial for early-stage viral detection. These configurations align with the refractive index ranges of clinical SARS-CoV-2 samples, showcasing their diagnostic potential. Future work will focus on experimental validation and integration into point-of-care platforms. Full article

Graphene-enhanced surface plasmon resonance (SPR) biosensors offer promising advancements in viral detection, particularly for SARS-CoV-2. This study presents the design and optimization of a multilayer SPR biosensor incorporating silver, silicon nitride, single-layer graphene, and thiol-tethered ssDNA to achieve high sensitivity and specificity. Key metrics, including SPR angle shift (Δθ), sensitivity (S), detection accuracy (DA), and figure of merit (FoM), were assessed across SARS-CoV-2 concentrations from 150 to 525 mM. The optimized biosensor achieved a sensitivity of 315.91°/RIU at 275 mM and a maximum Δθ of 4.2° at 400 mM, demonstrating strong responsiveness to virus binding. The sensor maintained optimal accuracy and figure of merit at lower concentrations, with a linear sensitivity response up to 400 mM, after which surface saturation limited further responsiveness. These results highlight the suitability of the optimized biosensor for real-time, point-of-care SARS-CoV-2 detection, particularly at low viral loads, supporting its potential in early diagnostics and epidemiological monitoring. Full article

Timely detection of highly infectious pathogens is essential for preventing and controlling public health risks. However, most traditional testing instruments require multiple tedious steps and ultimately testing in hospitals and third-party laboratories. The sample transfer process significantly prolongs the time to obtain test results. To tackle this aspect, a portable fiber optic surface plasmon resonance (FO-SPR) device was developed for the real-time detection of infectious pathogens. The portable device innovatively integrated a compact FO-SPR sensing component, a signal acquisition and processing system, and an embedded power supply unit. A gold-plated fiber is used as the FO-SPR sensing probe. Compared with traditional SPR sensing systems, the device is smaller size, lighter weight, and higher convenience. To enhance the detection capacity of pathogens, a monolayer graphene was coated on the sensing region of the FO-SPR sensing probe. Severe acute respiratory syndrome coronavirus 2 (SARS-CoV-2) was used to evaluate the performance of the portable device. The device can accurately detect the SARS-CoV-2 spike S1 protein in phosphate-buffered saline (PBS) and artificial saliva within just 20 min, and the device successfully detected cultured SARS-CoV-2 virus. Furthermore, the FO-SPR probe has long-term stability, remaining stable for up to 8 days. It could distinguish between the SARS-CoV-2 spike protein and the MERS-CoV spike protein. Hence, this FO-SPR device provides reliable, rapid, and portable access to test results. It provides a promising point-of-care testing (POCT) tool for on-site screening of infectious pathogens. Full article

Concrete is the most commonly used construction material nowadays. With emerging cutting-edge technologies such as nanomaterials (graphene, carbon nanotubes, etc.), advanced sensing (fiber optics, computer tomography, etc.), and artificial intelligence, concrete can now achieve self-sensing, self-healing, and ultrahigh performance. The concept and functions of smart concrete have thus been partially realized. However, due to the wider application location (coastal areas, cold regions, offshore, and deep ocean scenarios) and changing climate (temperature increase, more CO₂ emissions, higher moisture, etc.), durability monitoring (pH, ion penetration, carbonation, corrosion, etc.) becomes an essential component for smart concrete. Fiber optic sensors (FOS) have been widely explored in recent years for concrete durability monitoring due to their advantages of high sensitivity, immunity to harsh environments, small size, and superior sensitivity. The purpose of this review is to summarize FOS development and its application in concrete durability monitoring in recent years. The objectives of this study are to (1) introduce the working principle of FOS, including fiber Bragg grating (FBG), long-period fiber grating (LPFG), surface plasmon resonance (SPR), fluorescence-based sensors, and distributed fiber optic sensors (DFOS); (2) compare the sensitivity, resolution, and application scenarios of each sensor; and (3) discuss the advantages and disadvantages of FOS in concrete durability monitoring. This review is expected to promote technical development and provide potential research paths in the future for FOS in durability monitoring in smart concrete. Full article

Fiber-optic surface plasmon resonance (FOSPR) sensing technology has become an appealing candidate in biochemical sensing applications due to its distinguished capability of remote and point-of-care detection. However, FOSPR sensing devices with a flat plasmonic film on the optical fiber tip are seldom proposed with most reports concentrating on fiber sidewalls. In this paper, we propose and experimentally demonstrate the plasmonic coupled structure of a gold (Au) nanodisk array and a thin film integrated into the fiber facet, enabling the excitation of the plasmon mode on the planar gold film by strong coupling. This plasmonic fiber sensor is fabricated by the ultraviolet (UV) curing adhesive transferring technology from a planar substrate to a fiber facet. The experimental results demonstrate that the fabricated sensing probe has a bulk refractive index sensitivity of 137.28 nm/RIU and exhibits moderate surface sensitivity by measuring the spatial localization of its excited plasmon mode on Au film by layer-by-layer self-assembly technology. Furthermore, the fabricated plasmonic sensing probe enables the detection of bovine serum albumin (BSA) biomolecule with a detection limit of 19.35 μM. The demonstrated fiber probe here provides a potential strategy to integrate plasmonic nanostructure on the fiber facet with excellent sensing performance, which has a unique application prospect in the detection of remote, in situ, and in vivo invasion. Full article

Extracellular vesicles (EVs) have attracted great attention as potential biomarkers for cancer diagnostics. Although several technologies have been developed for EV detection, many of them are still not applicable to clinical settings as they rely on complex EV isolation processes, while lacking sensitivity, specificity or standardization. To solve this problem, we have developed a sensitive breast cancer-specific EV detection bioassay directly in blood plasma using a fiber-optic surface plasmon resonance (FO-SPR) biosensor, previously calibrated with recombinant EVs. First, we established a sandwich bioassay to detect SK-BR-3 EVs by functionalizing the FO-SPR probes with anti-HER2 antibodies. A calibration curve was built using an anti-HER2/^Banti-CD9 combination, resulting in an LOD of 2.1 × 10⁷ particles/mL in buffer and 7 × 10⁸ particles/mL in blood plasma. Next, we investigated the potential of the bioassay to detect MCF7 EVs in blood plasma using an anti-EpCAM/^Banti-mix combination, obtaining an LOD of 1.1 × 10 ⁸ particles/mL. Finally, the specificity of the bioassay was proven by the absence of signal when testing plasma samples from 10 healthy people unknown to be diagnosed with breast cancer. The remarkable sensitivity and specificity of the developed sandwich bioassay together with the advantages of the standardized FO-SPR biosensor highlight outstanding potential for the future of EV analysis. Full article

In this study, we report on the synthesis of L-Cysteine (L-Cys)-coated magnetic iron oxide nanoparticles (NPs) loaded with doxorubicin (Dox). The Fe₃O₄-L-Cys-Dox NPs were extensively characterized for their compositional and morpho-structural features using EDS, SAED, XRD, FTIR and TEM. XPS, Mӧssbauer spectroscopy and SQUID measurements were also performed to determine the electronic and magnetic properties of the Fe₃O₄-L-Cys-Dox nanoparticles. Moreover, by means of a FO-SPR sensor, we evidenced and confirmed the binding of Dox to L-Cys. Biological tests on mouse (B16F10) and human (A375) metastatic melanoma cells evidenced the internalization of magnetic nanoparticles delivering Dox. Half maximum inhibitory concentration IC50 values of Fe₃O₄-L-Cys-Dox were determined for both cell lines: 4.26 µg/mL for A375 and 2.74 µg/mL for B16F10, as compared to 60.74 and 98.75 µg/mL, respectively, for unloaded controls. Incubation of cells with Fe₃O₄-L-Cys-Dox modulated MAPK signaling pathway activity 3 h post-treatment and produced cell cycle arrest and increased apoptosis by 48 h. We show that within the first 2 h of incubation in physiological (pH = 7.4) media, ~10–15 µM Dox/h was released from a 200 µg/mL Fe₃O₄-L-Cys-Dox solution, as compared to double upon incubation in citrate solution (pH = 3), which resembles acidic environment conditions. Our results highlight the potential of Fe₃O₄-L-Cys-Dox NPs as efficient drug delivery vehicles in melanoma therapy. Full article

Aquaculture is an expanding economic sector that nourishes the world’s growing population due to its nutritional significance over the years as a source of high-quality proteins. However, it has faced severe challenges due to significant cases of environmental pollution, pathogen outbreaks, and the lack of traceability that guarantees the quality assurance of its products. Such context has prompted many researchers to work on the development of novel, affordable, and reliable technologies, many based on nanophotonic sensing methodologies. These emerging technologies, such as surface plasmon resonance (SPR), localised SPR (LSPR), and fibre-optic SPR (FO-SPR) systems, overcome many of the drawbacks of conventional analytical tools in terms of portability, reagent and solvent use, and the simplicity of sample pre-treatments, which would benefit a more sustainable and profitable aquaculture. To highlight the current progress made in these technologies that would allow them to be transferred for implementation in the field, along with the lag with respect to the most cutting-edge plasmonic sensing, this review provides a variety of information on recent advances in these emerging methodologies that can be used to comprehensively monitor the various operations involving the different commercial stages of farmed aquaculture. For example, to detect environmental hazards, track fish health through biochemical indicators, and monitor disease and biosecurity of fish meat products. Furthermore, it highlights the critical issues associated with these technologies, how to integrate them into farming facilities, and the challenges and prospects of developing plasmonic-based sensors for aquaculture. Full article

Environmental pollution with cadmium (Cd) is a major concern worldwide, with prolonged exposure to this toxic heavy metal causing serious health problems, such as kidney damage, cancer, or cardiovascular diseases, only to mention a few. Herein, a gold-coated reflection-type fiber optic–-surface plasmon resonance (Au-coated FO-SPR) sensor is manufactured and functionalized with (i) bovine serum albumin (BSA), (ii) chitosan, and (iii) polyaniline (PANI), respectively, for the sensitive detection of cadmium ions (Cd${}^{2+}$) in water. Then, the three sensor functionalization strategies are evaluated and compared one at a time. Out of these strategies, the BSA-functionalized FO-SPR sensor is found to be highly sensitive, exhibiting a limit of detection (LOD) for Cd${}^{2+}$ detection at nM level. Moreover, the presence of Cd${}^{2+}$ on the FO-SPR sensor surface was confirmed by the X-ray photoelectron spectroscopy (XPS) technique and also quantified consecutively for all the above-mentioned functionalization strategies. Hence, the BSA-functionalized FO-SPR sensor is sensitive, provides a rapid detection time, and is cheap and portable, with potential applicability for monitoring trace-level amounts of Cd within environmental or potable water. Full article

Aptamers represent the next frontier as biorecognition elements in biosensors thanks to a smaller size and lower molecular weight with respect to antibodies, more structural flexibility with the possibility to be regenerated, reduced batch-to-batch variation, and a potentially lower cost. Their high specificity and small size are particularly interesting for their application in optical biosensors since the perturbation of the evanescent field are low. Apart from the conventional plasmonic optical sensors, platforms based on silica and plastic optical fibers represent an interesting class of devices for point-of-care testing (POCT) in different applications. The first example of the coupling between aptamers and silica optical fibers was reported by Pollet in 2009 for the detection of IgE molecules. Six years later, the first example was published using a plastic optical fiber (POF) for the detection of Vascular Endothelial Growth Factor (VEGF). The excellent flexibility, great numerical aperture, and the large diameter make POFs extremely promising to be coupled to aptamers for the development of a sensitive platform easily integrable in portable, small-size, and simple devices. Starting from silica fiber-based surface plasmon resonance devices, here, a focus on significant biological applications based on aptamers, combined with plasmonic-POF probes, is reported. Full article

A planar waveguide consisting of a coverslip for a microscope glass slide was deposited in one of its two faces with two materials: silver and indium tin oxide (ITO). The incidence of light by the edge of the coverslip permitted the generation of both surface plasmon and lossy mode resonances (SPRs and LMRs) in the same transmission spectrum with a single optical source and detector. This proves the ability of this optical platform to be used as a benchmark for comparing different optical phenomena generated by both metal and dielectric materials, which can be used to progress in the assessment of different sensing technologies. Here the SPR and the LMR were compared in terms of sensitivity to refractive index and figure of merit (FoM), at the same time it was demonstrated that both resonances can operate independently when silver and ITO coated regions are surrounded by different refractive index liquids. The results were supported with numerical results that confirm the experimental ones. Full article

In this paper, we demonstrate a fiber-optic surface plasmon resonance (FO-SPR) biosensor based on image processing and back propagation (BP) neural network. The transmitted light of the FO-SPR sensor was captured by using visible (VIS) and near-infrared (NIR) CMOS sensors. The optical information related to the SPR effect was extracted from images based on grayscale conversion and an edge detection algorithm. To achieve accurate monitoring of refractive index (RI) changes, the grayscale means of the VIS and NIR images and the RGB summation of the edge-detected images were used as training and test inputs for the BP neural network. We verified the effectiveness and superiority of this sensing system by experiments on sodium chloride solution identification and protein binding detection. This work is promising for practical applications in standardized biochemical sensing. Full article
