Search Results (27)

Frequency-Modulated Continuous-Wave (FMCW) Laser Detection and Ranging (LiDAR) systems are widely used due to their high accuracy and resolution. Nevertheless, conventional distance extraction methods often lack robustness in noisy and complex environments. To address this limitation, we propose a deep learning-based signal extraction framework that integrates a Dual Convolutional Neural Network (DCNN) with a Transformer model. The DCNN extracts multi-scale spatial features through multi-layer and pointwise convolutions, while the Transformer employs a self-attention mechanism to capture global temporal dependencies of the beat-frequency signals. The proposed DCNN–Transformer network is evaluated through beat-frequency signal inversion experiments across distances ranging from 3 m to 40 m. The experimental results show that the method achieves a mean absolute error (MAE) of 4.1 mm and a root-mean-square error (RMSE) of 3.08 mm. These results demonstrate that the proposed approach provides stable and accurate predictions, with strong generalization ability and robustness for FMCW LiDAR systems. Full article

Frequency-modulated continuous-wave (FMCW) LiDAR systems frequently experience noise interference during multi-target measurements in real-world applications, resulting in target overlapping and diminished detection accuracy. Conventional denoising approaches—such as Empirical Mode Decomposition (EMD) and wavelet thresholding—are often constrained by challenges like mode mixing and the attenuation of weak target signals, which limits their detection precision. To address these limitations, this study presents a novel denoising framework that integrates an optimized Complete Ensemble Empirical Mode Decomposition with Adaptive Noise (CEEMDAN) algorithm and singular value decomposition (SVD). The CEEMDAN algorithm’s two critical parameters—the noise standard deviation and the number of noise additions—are optimally determined using particle swarm optimization (PSO), with the envelope entropy of the intrinsic mode functions (IMFs) serving as the fitness criterion. IMFs are subsequently selected based on spectral and amplitude comparisons with the original signal to facilitate initial signal reconstruction. Following CEEMDAN-based decomposition, SVD is employed with a normalized soft thresholding technique to further suppress residual noise. Validation using both synthetic and experimental datasets demonstrates the superior performance of the proposed approach over existing methods in multi-target scenarios. Specifically, it reduces the root mean square error (RMSE) by 45% to 59% and the mean square error (MSE) by 34% to 69%, and improves the signal-to-noise ratio (SNR) by 1.85–4.38 dB and the peak signal-to-noise ratio (PSNR) by 1.18–6.94 dB. These results affirm the method’s effectiveness in enhancing signal quality and target distinction in noisy FMCW LiDAR measurements. Full article

Light detection and ranging (LiDAR) sensors are essential for applications where high-resolution distance and velocity measurements are required. In particular, frequency-modulated continuous wave (FMCW) LiDAR, compared with other LiDAR implementations, provides superior receiver sensitivity, enhanced range resolution, and the capability to measure velocity. Integrating LiDARs into electronic and photonic semiconductor chips can lower their cost, size, and power consumption, making them affordable for cost-sensitive applications. Additionally, simple designs are required, such as FMCW signal generation by the direct modulation of the current of a semiconductor laser. However, semiconductor lasers are inherently nonlinear, and the driving waveform needs to be optimized to generate linear FMCW signals. In this paper, we employ pre-distortion techniques to compensate for chirp nonlinearity, achieving frequency nonlinearities of 0.0029% for the down-ramp and the up-ramp at 55 kHz. Experimental results demonstrate a highly accurate LiDAR system with a resolution of under 5 cm, operating over a 210-m range through single-mode fiber, which corresponds to approximately 308 m in free space, towards meeting the requirements for long-range autonomous driving. Full article

Frequency tuning nonlinearities in semiconductor lasers constitute a critical factor that degrades measurement precision and spectral resolution in frequency-modulated continuous-wave (FMCW) LiDAR systems. This study systematically investigates the influence of nonlinear beat signal phase distortions on spectral peak broadening and develops a phase-fitting-based pre-correction algorithm. To further enhance system performance, an electro-optic phase-locked loop architecture combined with non-uniform discrete Fourier transform signal processing is implemented, establishing a comprehensive solution for tuning nonlinearity suppression. Experimental validation demonstrates a sub-18 µm standard deviation in absolute distance measurements at a 19 m target range. This integrated approach represents a significant advancement in coherent frequency-sweep detection methodologies, offering considerable potential for high-precision photonic radar applications. Full article

For Advanced Driver Assistance Systems (ADASs), lots of researchers have been constantly researching various devices that can become the eyes of a vehicle. Currently represented devices are LiDAR, camera, and radar. This paper suggests one of the operation processes to study radar, which can be used regardless of climate change or weather, day or night. Thus, we propose a simple and easy calibration method for Multi-Input Multi-Output (MIMO) radar to guarantee performance with initial calibration parameters. Based on a covariance matrix, the modified signals of all channels improve performance, reducing unexpected interferences. Therefore, using the proposed coupling matrix, we can reduce unexpected interference and generate accurately calibrated results. To prove and verify the improvement in our method, a practical experiment is conducted with Frequency-Modulated Continuous-Wave (FMCW) MIMO radar, mounted on an automotive. Full article

Frequency sweeping linearity is essential for Frequency-Modulated Continuous Wave (FMCW) Light Detection and Ranging (LIDAR), as it impacts the ranging resolution and accuracy of the system. Pre-distortion methods can correct for frequency sweeping nonlinearity; however, residual minor nonlinearities can still degrade the system ranging resolution, especially at far distances. Therefore, the precise measurement of minor nonlinearities is particularly essential for long-range FMCW LIDAR. This paper proposes a calibration-free MZI for measuring optical frequency sweeping nonlinearity, which involves alternately inserting two short polarization-maintaining fibers with different delays into one arm of an MZI, and after two rounds of beat collection, the optical frequency sweep curve of the light source is accurately measured for nonlinearity evaluation. Using the proposed method, the nonlinearity of a frequency-swept laser source is measured to be 0.2113%, and the relative nonlinearity is 5.3560 × 10⁻⁵. With the measured frequency sweep curve, we simulate the beat signal and compare it with the collected beat signal in time and frequency domain, to verify the accuracy of the proposed method. A test conducted at 24.1 °C, 30.4 °C, 39.5 °C and 44.0 °C demonstrate the method’s insensitivity to temperature fluctuations. Based on the proposed MZI, a tunable laser is pre-distorted and then used as light source of a FMCW lidar. A wall at 45 m and a building at 1.2 km are ranged by the lidar respectively. Before and after laser pre-distortion, the FWHM of echo beat spectrum are 25.635 kHz and 9.736 kHz for 45 m, 747.880 kHz and 22.012 kHz for 1.2 km. Full article

A stable and robust odometry system is essential for autonomous robot navigation. The 4D millimeter-wave radar, known for its resilience in harsh weather conditions, has attracted considerable attention. As the latest generation of FMCW radar, 4D millimeter-wave radar provides point clouds with both position and Doppler velocity information. However, the increased uncertainty and noise in 4D radar point clouds pose challenges that prevent the direct application of LiDAR-based SLAM algorithms. To address this, we propose a SLAM framework that fuses 4D radar data with gyroscope readings using graph optimization techniques. Initially, Doppler velocity is employed to estimate the radar’s ego velocity, with dynamic points being removed accordingly. Building on this, we introduce a pre-integration factor that combines ego-velocity and gyroscope data. Additionally, leveraging the stable RCS characteristics of radar, we design a corresponding point selection method based on normal direction and propose a scan-to-submap point cloud registration technique weighted by RCS intensity. Finally, we validate the reliability and localization accuracy of our framework using both our own dataset and the NTU dataset. Experimental results show that the proposed DGRO system outperforms traditional 4D radar odometry methods, especially in environments with slow speeds and fewer dynamic objects. Full article

As LiDAR technology progressively advances, the capability of radar in detecting targets has become increasingly vital across diverse domains, including industrial, military, and automotive sectors. Frequency-modulated continuous-wave (FMCW) LiDAR in particular has garnered substantial interest due to its efficient direct velocity measurement and excellent anti-interference characteristics. It is widely recognized for its significant potential within radar technology. This study begins by elucidating the operational mechanism of FMCW LiDAR and delves into its basic principles. It discuss, in depth, the influence of various parameters on FMCW LiDAR’s performance and reviews the latest progress in the field. This paper proposes that future studies should focus on the synergistic optimization of key parameters to promote the miniaturization, weight reduction, cost-effectiveness, and longevity of FMCW LiDAR systems. This approach aims at the comprehensive development of FMCW LiDAR, striving for significant improvements in system performance. By optimizing these key parameters, the goal is to promote FMCW LiDAR technology, ensuring more reliable and accurate applications in automated driving and environmental sensing. Full article

Light Detection and Ranging (LiDAR) sensors can precisely determine object distances using the pulsed time of flight (TOF) or amplitude-modulated continuous wave (AMCW) TOF methods and velocity using the frequency-modulated continuous wave (FMCW) approach. In this paper, we focus on modelling and analysing the reflection of vector beams (VBs) and vector vortex beams (VVBs) for optical sensing in LiDAR applications. Unlike traditional TOF and FMCW methods, this novel approach uses VBs and VVBs as detection signals to measure the orientation of reflecting surfaces. A key component of this sensing scheme is understanding the relationship between the characteristics of the reflected optical fields and the orientation of the reflecting surface. To this end, we develop a computational model for the reflection of VBs and VVBs. This model allows us to investigate critical aspects of the reflected field, such as intensity distribution, intensity centroid offset, reflectance, and the variation of the intensity range measured along the azimuthal direction. By thoroughly analysing these characteristics, we aim to enhance the functionality of LiDAR sensors in detecting the orientation of reflecting surfaces. Full article

To improve the accuracy of signal recognition in delay-based optical reservoir computing (RC) systems, this paper proposes the use of nonlinear algorithms at the output layer to replace traditional linear algorithms for training and testing datasets and apply them to the identification of frequency-modulated continuous wave (FMCW) LiDAR signals. This marks the inaugural use of the system for the identification of FMCW LiDAR signals. We elaborate on the fundamental principles of a delay-based optical RC system using an optical-injected distributed feedback laser (DFB) laser and discriminate four FMCW LiDAR signals through this setup. In the output layer, three distinct training algorithms—namely linear regression, support vector machine (SVM), and random forest—were employed to train the optical reservoir. Upon analyzing the experimental results, it was found that regardless of the size of the dataset, the recognition accuracy of the two nonlinear training algorithms was superior to that of the linear regression algorithm. Among the two nonlinear algorithms, the Random Forest algorithm had a higher recognition accuracy than SVM when the sample size was relatively small. Full article

Micro-Doppler time–frequency analysis has been regarded as an important parameter extraction method for conical micro-motion objects. However, the micro-Doppler effect caused by micro-motion can modulate the frequency of lidar echo, leading to coupling between structure and micro-motion parameters. Therefore, it is difficult to extract parameters for micro-motion cones. We propose a new method for parameter extraction by combining the range profile of a micro-motion cone and the micro-Doppler time–frequency spectrum. This method can effectively decouple and accurately extract the structure and the micro-motion parameters of cones. Compared with traditional time–frequency analysis methods, the accuracy of parameter extraction is higher, and the information is richer. Firstly, the range profile of the micro-motion cone was obtained by using an FMCW (Frequency Modulated Continuous Wave) lidar based on simulation. Secondly, quantitative analysis was conducted on the edge features of the range profile and the micro-Doppler time–frequency spectrum. Finally, the parameters of the micro-motion cone were extracted based on the proposed decoupling parameter extraction method. The results show that our method can effectively extract the cone height, the base radius, the precession angle, the spin frequency, and the gravity center height within the range of a lidar LOS (line of sight) angle from 20° to 65°. The average absolute percentage error can reach below 10%. The method proposed in this paper not only enriches the detection information regarding micro-motion cones, but also improves the accuracy of parameter extraction and establishes a foundation for classification and recognition. It provides a new technical approach for laser micro-Doppler detection in accurate recognition. Full article

Silicon-based Lidar is an ideal way to reduce the volume of the Lidar and realize monolithic integration. It removes the moving parts in the conventional device and realizes solid-state beam steering. The advantages of low cost, small size, and high beam steering speed have attracted the attention of many researchers. In order to facilitate researchers to quickly understand the research progress and direction, this paper mainly describes the research progress of silicon-based integrated Lidar, including silicon-based optical phased array Lidar, silicon-based optical switch array Lidar, and continuous frequency-modulated wave Lidar. In addition, we also introduced the scanning modes and working principles of other kinds of Lidar, such as the Micro-Electro-Mechanical System, mechanical Lidar, etc., and analyzed the characteristics of the Lidars above. Finally, we summarized this paper and put forward the future expectations of silicon-based integrated Lidar. Full article

An FMCW LiDAR (frequency-modulated continuous-wave light detection and ranging) is a sensor that can measure distance using optical interference frequency ($f_b$). This sensor has recently attracted interest because it is robust to harsh environmental conditions and sunlight due to the wave properties of the laser. Theoretically, when the frequency of the reference beam is linearly modulated, a constant $f_b$ is obtained with respect to the distance. However, when the frequency of the reference beam fails to be linearly modulated, the distance measurement is not accurate. In this work, linear frequency modulation control using frequency detection is proposed to improve the distance accuracy. The FVC (frequency to voltage converting) method is used to measure $f_b$ for high-speed frequency modulation control. The experimental results show that linear frequency modulation control using an FVC improves FMCW LiDAR performance in terms of control speed and frequency accuracy. Full article

LiDAR has attracted increasing attention because of its strong anti-interference ability and high resolution. Traditional LiDAR systems rely on discrete components and face the challenges of high cost, large volume, and complex construction. Photonic integration technology can solve these problems and achieve high integration, compact dimension, and low-cost on-chip LiDAR solutions. A solid-state frequency-modulated continuous-wave LiDAR based on a silicon photonic chip is proposed and demonstrated. Two sets of optical phased array antennas are integrated on an optical chip to form a transmitter–receiver interleaved coaxial all-solid-state coherent optical system which provides high power efficiency, in principle, compared with a coaxial optical system using a 2 × 2 beam splitter. The solid-state scanning on the chip is realized by optical phased array without a mechanical structure. A 32-channel transmitter–receiver interleaved coaxial all-solid-state FMCW LiDAR chip design is demonstrated. The measured beam width is 0.4° × 0.8°, and the grating lobe suppression ratio is 6 dB. Preliminary FMCW ranging of multiple targets scanned by OPA was performed. The photonic integrated chip is fabricated on a CMOS-compatible silicon photonics platform, providing a steady path to the commercialization of low-cost on-chip solid-state FMCW LiDAR. Full article

We present a simple iterative pre-distortion algorithm for achieving a rapid linear frequency sweep of semiconductor lasers. The algorithm achieves the desired frequency swept linearity with only four iterations. We derive a general formula for iterative pre-distortion by establishing the relationship between the laser output frequency and the drive current. The linear frequency-swept laser source obtained by this algorithm can be used in FMCW LiDAR systems. Experimentally, we investigated the algorithm using a 1550 nm distributed feedback (DFB) laser, achieving frequency swept excursion of 30.26 GHz, and frequency swept slope of 504 THz/s. We analyzed the linearity of the frequency swept results for the fourth iteration, achieving less than 5 MHz root mean square (RMS) value of frequency swept nonlinearity. Full article
