Search Results (49)

Reinforced concrete (RC) deep beams constructed with low-strength concrete are susceptible to sudden splitting failures in the strut region due to shear–compression stresses. To mitigate this vulnerability, various strengthening techniques, including steel plates, fiber-reinforced polymer sheets, and cementitious composites, have been explored to confine the strut area. This study investigates the structural performance of RC deep beams with low-strength concrete, strengthened externally using an Engineered Cementitious Composite (ECC) layer. To ensure effective confinement and uniform shear distribution, shear reinforcement was provided at equal intervals with configurations of zero, one, and two vertical shear reinforcements. Four-point bending tests revealed that the ECC layer significantly enhanced the shear capacity, increasing load-carrying capacity by 51.6%, 54.7%, and 46.7% for beams with zero, one, and two shear reinforcements, respectively. Failure analysis through non-linear finite element modeling corroborated experimental observations, confirming shear–compression failure characterized by damage in the concrete struts. The strut-and-tie method, modified to incorporate the tensile strength of ECC and shear reinforcement actual stress values taken from the FE analysis, was used to predict the shear capacity. The predicted values were within 10% of the experimental results, underscoring the reliability of the analytical approach. Overall, this study demonstrates the effectiveness of ECC in improving shear performance and mitigating strut failure in RC deep beams made with low-strength concrete. Full article

This paper reviews the applications and performance advantages of ultra-high-performance concrete (UHPC), engineered cementitious composite (ECC), and recycled aggregate concrete (RAC) in composite flexural members. UHPC is characterized by its ultra-high strength, high toughness, excellent durability, and microcrack self-healing capability, albeit with high costs and complex production processes. ECC demonstrates superior tensile, flexural, and compressive strength and durability, yet it exhibits a lower elastic modulus and greater drying shrinkage strain. RAC, as an eco-friendly concrete, offers cost-effectiveness and environmental benefits, although it poses certain performance challenges. The focus of this review is on how to enhance the load-bearing capacity of composite beams or slabs by modifying the interface roughness, adjusting the thickness of the ECC or UHPC layer, and altering the cross-sectional form. The integration of diverse concrete materials improves the performance of beam and slab elements while managing costs. For instance, increasing the thickness of the UHPC or ECC layer typically enhances the load-bearing capacity of composite beams or plates by approximately 10% to 40%. Increasing the roughness of the interface can significantly improve the interfacial bond strength and further augment the ultimate load-bearing capacity of composite components. Moreover, the optimized design of material mix proportions and cross-sectional shapes can also contribute to enhancing the load-bearing capacity, crack resistance, and ductility of composite components. Nevertheless, challenges persist in engineering applications, such as the scarcity of long-term monitoring data on durability, fatigue performance, and creep effects. Additionally, existing design codes inadequately address the nonlinear behavior of multi-material composite structures, necessitating further refinement of design theories. Full article

This study applied precast engineered cementitious composite (ECC) shells to replace conventional concrete in precast assembled monolithic composite beams to enhance mechanical performance. A new type of precast monolithic ECC composite beam was proposed. Five ECC composite beams and one reinforced concrete (RC) composite beam were designed and fabricated for the experimental study. The failure pattern, failure mechanism, load-bearing capacity, deformability, and stiffness degradation were quantitatively analyzed through the tests. The main findings were as follows: ECC composite beams developed finer and more densely distributed cracks compared to RC composite beams, without significant concrete spalling. The peak load of ECC composite beams was 8.2% higher than that of RC composite beams, while the corresponding displacement at peak load increased by 29.3%. The ECC precast shell delayed crack propagation through the fiber bridging effect. The average load degradation coefficient of the ECC composite beams was 8.2% lower than that of the RC beam. The stiffness degradation curve of ECC composite beams was more gradual than that of RC composite beams, providing an optimization basis for the design of precast beams in structures with high seismic demands. As the shear span ratio increased from 1.5 to 3, the load-bearing capacity decreased by 32.0%. When the stirrup ratio increased from 0.25% to 0.75%, the ultimate load-bearing capacity improved by 28.8%. Furthermore, specimens with higher stirrup ratios showed a 40–50% reduction in stiffness degradation rate, demonstrating that increased stirrup ratio effectively mitigated brittle failure. Full article

This paper proposes a steel-ECC ordinary concrete composite continuous bridge deck structure to address the cracking problem of simply supported beam bridge deck continuity. Through theoretical and experimental research, a high-performance ECC material was developed. The ECC material has a compressive strength of 57.58 MPa, a tensile strain capacity of 4.44%, and significantly enhanced bending deformation ability. Bonding tests showed that the bond strength of the ECC-reinforcing bar interface reaches 22.84 MPa when the anchorage length is 5d, and the splitting strength of the ECC-concrete interface is 3.58 MPa after 4–5 mm chipping treatment, with clear water moistening being the optimal interface treatment method. Full-scale tests indicated that under 1.5 times the design load, the crack width of the ECC bridge deck continuity structure is ≤0.12 mm, the maximum deflection is only 5.345 mm, and the interface slip is reduced by 42%, achieving a unified control of multiple cracks and coordinated deformation. The research results provide a new material system and interface design standards for seamless bridge design. Full article

In order to enhance the durability of concrete frame beams, a U-shaped engineered cementitious composites (ECC) protective layer is applied at the end of the frame beams. The bond between the ECC protective layer and the concrete is reinforced by incorporating notches and grooves in the occupancy plate. The development and resistance to cracking of reinforced concrete (RC) frame beams and frame beams with an ECC protective layer were investigated using monotonic loading tests. The test results show that the average value of crack spacing in the negative moment zone of the RC frame beam specimen is in close agreement with the crack spacing calculated according to the GB50010 Code for Design of Concrete Structures. While the dispersion of crack width in the negative moment zone of the RC frame beam specimens is considerable, the distribution pattern of crack width undergoes a gradual change with increasing load. When the maximum crack width calculation method of GB50010 is employed in the negative moment zone of RC frame beams, the crack width should be increased by approximately 1.25 times. Furthermore, the crack spacing and crack width of the ECC protective layer are markedly smaller than those of RC frame beams. Full article

Engineered Cementitious Composite (ECC) has emerged as a promising solution with which to address the longstanding challenge of cracking in the tensile zone of reinforced concrete beams. This study conducts an experimental and analytical exploration of the flexural performance of ECC-concrete composite beams reinforced with hot-rolled ribbed steel bars. Sixteen beams, featuring diverse reinforcement ratios and ECC layer thicknesses, underwent rigorous testing through a four-point bending setup. The experimental findings underscore a substantial improvement in crack resistance and flexural bearing capacity of ECC-concrete composite beams reinforced with steel bars. Building on these results, a theoretical model was formulated to predict the moment-deflection responses of ECC-concrete composite beams incorporating steel bars. Furthermore, practical and simplified methods were introduced to predict flexural bearing capacity and effective moment of inertia, as well as anticipate failure modes, offering a user-friendly approach for engineering applications. Validation of the proposed approaches was achieved through simulation results, demonstrating a high degree of accuracy when compared with the experimental outcomes. Moreover, the average crack width at serviceability limit states of composite beams was sensitive to specimen size and the yield strength of steel bars, and a size effect was also observed for ductility expressed as deflection. Full article

Engineering Cementitious Composites (ECC) has gained significant attention in civil engineering due to its excellent tensile strength, crack width control capability, and remarkable ductility. This study examines the influence of the ECC strength and reinforcement on the flexural behavior of ECC slabs through four-point flexural tests. The results demonstrate that ECC is well suited for flexural applications. During flexural tests, the fibers within the ECC provide a bridging effect, allowing the ECC in the tensile zone to sustain a load while developing a dense network of fine microcracks at failure. This characteristic significantly enhances the crack resistance of ECC slabs. Despite the relatively low flexural capacity of unreinforced ECC slabs, they achieve 59.2% of the capacity of reinforced ECC slabs with a reinforcement ratio of 1.02%, demonstrating the potential for using unreinforced ECC in low-load-bearing applications. Further findings reveal that high-strength ECC (HSECC) not only improves the flexural capacity of unreinforced ECC slabs but also maintains excellent ductility, enabling a better balance between the load-bearing capacity and deformation ability. However, while reinforcement enhances both the flexural capacity and energy absorption, an excessively high reinforcement ratio significantly compromises ductility. Additionally, this study proposes a simplified calculation method for the flexural capacity of ECC slabs based on the axial force and moment equilibrium, providing theoretical support for their design and application. Due to their excellent flexural behavior, ECC slabs exhibit significant potential for use in flexural components such as bridge deck slabs and link slabs in simply supported beam bridges. With continued research and optimization, their application in engineering practice is expected to become more widespread, thereby improving the cracking resistance and durability of concrete structures. Full article

Acoustic emission (AE) analysis was utilized to assess the cracking behavior of six lightweight self-consolidating concrete (LWSCC)–engineering cementitious composite (ECC) beams under flexural loading. Two control beams were fully cast with ECC containing either polyvinyl alcohol (PVA) fibers or steel fibers (SF). The remaining four beams were ECC-LWSCC composite beams, with the ECC layer containing PVA fibers or SF placed on either the tension or compression side. The results showed that the control beams had the highest ultimate load capacity, followed by beams repaired in tension, and then beams repaired in compression. PVA fibers exhibited higher performance compared to steel fibers at the first crack load, while steel fibers enhanced the beam’s performance at the ultimate load stage. During the flexural testing, AE parameters such as the number of hits, signal amplitude, and cumulative signal strength (CSS) were collected until failure. The analysis of these AE parameters was effective in detecting the first crack and evaluating cracking propagation in all beams. Changing the type of fibers (PVA and SF) in the ECC layer showed a significant effect on AE parameters. Moreover, adding a new ECC layer to an existing LWSCC layer resulted in variations in the signal amplitude. Finally, the flexural failure mode was confirmed with the aid of the rise time/maximum amplitude vs. average frequency analysis. Full article

This study investigates the toughness and load capacity of various innovative beam configurations of cold-formed steel beams (CFSB) using both ordinary concrete slabs and engineered cementitious composite (ECC) slabs. A finite element analysis with ABAQUS 20 was conducted on double-channel, sigma, G, and omega sections, both with and without inverted lips, as well as the effects of L, channel, and trapezoidal stiffeners and length-to-depth ratios. The double-omega section with ordinary concrete achieved the highest first peak load of 365.2 kN and a toughness increase of 181.1%. Inverted lips enhanced toughness in the double-G and sigma sections, with increases of 156.9% and 158.3%, respectively. Among ECC configurations, the double-omega section with ECC3 slab reached 387.4 kN and a toughness increase of 199.5%. Thinner ordinary concrete sections (70 mm and 90 mm) negatively impacted toughness, emphasizing the need for adequate thickness. Trapezoidal stiffeners also improved toughness. These findings highlight the importance of geometrical design and material selection in optimizing CFSB performance, offering valuable insights for future design practices. Full article

Reinforcing concrete beams with adhesive steel plates is a widely adopted method for enhancing structural performance. However, its ability to significantly improve the load-carrying capacity of reinforced concrete (RC) beams is constrained and often leads to “over-reinforced” failure. To overcome these limitations, this study introduces a novel composite reinforcement strategy that integrates steel plates in the tensile zone with Engineered Cementitious Composite (ECC) layers in the compression zone of RC beams. Static and fatigue tests were conducted on the reinforced beams, and a finite element model was developed to perform nonlinear analyses of their structural behavior under cyclic loading. The model incorporates the nonlinear material properties of concrete and rebar, enabling accurate simulation of material degradation under cyclic conditions. The model’s accuracy was validated through comparison with experimental data, demonstrating its effectiveness in analyzing the structural performance of RC beams under cyclic loading. Furthermore, a parametric study demonstrated that increasing the thickness of steel plates and ECC layers substantially improves the beams’ ductility and load-carrying capacity. These findings provide effective reinforcement strategies and offer valuable technical insights for engineering design. Full article

Reinforced concrete (RC) structures are vulnerable to damage under dynamic loads such as earthquakes, necessitating innovative solutions that enhance both performance and sustainability. This study investigates the integration of Engineered Cementitious Composites (ECC) in RC frames to improve ductility, durability, and energy dissipation while considering cost-effectiveness. To achieve this, the partial replacement of concrete with ECC at key structural locations, such as beam–column joints, was explored through experimental testing and numerical simulations. Small-scale beams with varying ECC replacements were tested for failure modes, load–deflection responses, and crack propagation patterns. Additionally, nonlinear quasi-static cyclic and modal analyses were performed on full RC frames, ECC-reinforced frames, and hybrid frames with ECC at the joints. The results demonstrate that ECC reduces the need for shear reinforcement due to its crack-bridging ability, enhances ductility by up to 25% in cyclic loading scenarios, and lowers the formation of plastic hinges, thereby contributing to improved structural resilience. These findings suggest that ECC is a viable, sustainable solution for achieving resilient infrastructure in seismic regions, with an optimal balance between performance and cost. Full article

Ultra-high performance engineered cementitious composite (UHP-ECC), which is a new and ductile version of concrete, has attracted researchers recently due to its exceptional mechanical properties: its very high compressive strength (from 100 to 200 MPa) and very high tensile strain capacity (not less than 3% and up to 8%). However, the available experimental literature is small due to its very high cost. To overcome the high cost of the experiments of UHP-ECC, the finite element modeling package ANSYS was used to create a new modeling technique using the Menetrey–Willam constitutive model, recently added to ANSYS. This technique was validated using previous experimental results for UHP-ECC beams and found to be accurate and effective. The previous FE model was used to conduct a parametric study and the variables—the compressive strength of the concrete, the percentage of the volume content of polyethylene fibers, the tensile reinforcement ratio, and the span-to-depth ratio—were found to be effective upon the flexure behavior of the reinforced UHP-ECC beams. As the analysis and design of UHP-ECC beams fabricated with polyethylene fiber are not available yet through design codes, an analytical model including some equations was deduced to calculate the flexure capacity of such beams. The results of the parametric study were used to investigate the validity and accuracy of the analytical model. The proposed equations demonstrated a good estimation compared with the numerical analysis results. Full article

This paper investigates, experimentally and numerically, the shear strengthening of Normal Concrete (NC) beams using post-tensioning steel bars and Engineered Cementitious Composite (ECC) reinforced with chemically cured Palm Fronds (PFs). The benefits of strain-hardening ECC and the tensile strength of PFs cured with 6% wt Alkali NaOH solution beside post-tensioned bars have been employed herein. Seven full-scale Reinforced Concrete (RC) beams were fabricated and experimented with under three-point loading until failure. The test parameters include the strengthening technique, type, and configuration of the material used for strengthening. The strengthening process has been implemented through two techniques: Externally Bonded Reinforcement (EBR) and Near-Surface Mounted (NSM) Reinforcement. The strengthening materials have been configured and placed in horizontal, vertical, and inclined positions. The effectiveness of the strengthening methods has been evaluated by examining their cracking propagations, load-deflection responses, collapse modes, elastic stiffness, and absorbed energy. It was found that the proposed strengthening systems could significantly control the crack pattern and failure mode, and they could enhance the ultimate load amplitude up to 37% and 50% for NSM ECC with PFs and EBR post-tensioning steel bars, respectively. Nonlinear three-dimensional finite element models of the tested beams were developed and validated with the test data, where it was found that finite element models predict the structural performance of tested beams with a maximum error of only 2%. Full article

Precast rectangular reinforced concrete (PRRC) beams are joined on construction sites using concrete in situ to achieve the desired length. Limited research exists on the effect of intermediate connection shapes and the types of infilled concrete on the flexural performance of PRRC beams. This paper presents a comprehensive experimental and numerical investigation into the performance of PRRC beams with various intermediate connection geometries and infilled materials under flexural loading. The study examines rectangular, triangular, and semi-circular intermediate connections, along with the performance of beams infilled with normal concrete (NC), engineered cementitious composites (ECC), ultra-high-performance ECC (UHPECC), and rubberized ECC (RECC). The experimental results indicate that the rectangular intermediate connection exhibits superior performance in terms of strength and energy absorption compared to the triangular and semi-circular shapes. Beams incorporating UHPECC demonstrated the most significant improvements in strength and energy absorption, outperforming those with ECC and RECC for any shape of intermediate connection. Moreover, beams with rectangular connections and UHPECC infill exhibited the most significant increase in energy absorption and ultimate load compared to the beams with ECC and RECC. The ultimate load of the beams with UHPECC and tensile reinforcement bar diameters of 10 mm and 12 mm increased by 13% and 29%, respectively, compared to the control beam. The energy absorption of the beams with tensile reinforcement bar diameters of 10 and 12 mm was found to be 75% and 184% higher, respectively, than the control beam. In addition, an increase in tensile bar diameter was found to enhance both the energy absorption and the ultimate load capacity of the beams, regardless of the type of infill concrete. Beams incorporating UHPECC demonstrated the most significant improvements in strength and energy absorption, outperforming those with ECC and RECC. In particular, beams with rectangular connections and UHPECC infill exhibited an increase in energy absorption and ultimate load of up to 184% and 29%, respectively. UHPC was calculated to be as high as 184%, and 29%, respectively, compared to the control beams. In addition, an increase in tensile bar diameter was found to enhance both energy absorption and ultimate load capacity. Finite element modeling (FEM) was developed and validated against the experimental results to ensure accuracy. A parametric study was conducted to study the effects of various concrete types in triangular and semi-circular connections, as well as the influence of intermediate connection length on semi-circular connections under flexural loads. The findings reveal that increasing the length of intermediate connections increases the ultimate load of the beams. Full article

A Rectangular Dielectric Resonator Antenna (RDRA) design for mmWave-frequency-band MIMO metrics is proposed, with a compact, low-complexity, high-gain structure that is easy to fabricate and offers reduced inter–port isolation. The RDRA operates in the mmWave spectrum, featuring a compact size of 1.307${\lambda }_0$ × 1.307${\lambda }_0$, an impedance bandwidth of 6%, and a resonant frequency of 28 GHz, with a peak gain of 7 dBi. A four element MIMO system iteration was developed while maintaining the performance of the single element antenna. Additionally, a simple, low-complexity slot-etching technique was applied to achieve an average inter-port element isolation of 14 dB. The design also achieved a novel four-beam petal-splitting radiation pattern. The MIMO metrics, with an envelope correlation coefficient (ECC) of <0.5 and a diversity gain (DG) < 10, were successfully met. The simulated and measured results are in good agreement. Full article
