Search Results (16)

This study investigates the interfaces of ultra-high-performance fibre-reinforced concrete (UHPFRC). The interfaces of UHPFRC-to-UHPFRC were studied using two techniques: (i) slant shear test and (ii) shear key test. Moreover, the glass fibre-reinforced polymer (GFRP) rebars were also used in the shear plane to optimise durability. Six UHPFRC push-off specimens with different GFRP reinforcement ratios and changing shear plane angles were investigated and compared to existing models and codes. The results showed that the slant shear and shear test performed better without adding the epoxy agents due to the presence of steel fibres, which provided the excellent benefit of bridging the cracks and increasing the friction resistance. Furthermore, the shear strength increased substantially with inclined shear planes, rising from 607 kN in the vertical case to 1837 kN at a 60° inclination. However, the existing equations for predicting the shear strength overpredict the shear strength with a vertical shear plane and underpredict the shear strength of the angled shear plane. The test results also confirm that steel fibres enhance shear transfer through crack bridging, while epoxy weakens the interface by limiting mechanical interlock. The linear elastic behaviour of GFRP rebars also influences the shear transfer mechanism by contributing dowel action without yielding. Full article

The main goal of this work is to analyse the thermo-mechanical effect in single shear dowelled timber connections under fire conditions. This research includes the development of numerical models using the finite element method. The numerical methodology was validated using previously published experimental and numerical data. New models were developed to evaluate the temperature evolution, charring rate, and load-bearing capacity of the connections throughout exposure to fire. The calculations based on Eurocode 5 are conservative in the dimensioning of connections at room temperature but have less impact on the design of fire resistance, as they do not consider factors such as geometric parameters or passive protection influence on structural performance. Finally, based on the results obtained, two useful design equations are proposed, allowing the calculation of the load-bearing capacity of single shear timber connections, with or without protection, as a function of fire exposure. Full article

A high-frequency model of the toroidal powder core inductor with litz wire winding is presented. In the analyzed model, the power losses that occurred in both the winding and the magnetic core were taken into account. A new method of determining the power losses in the winding of a magnetic element made of a litz wire with a circular cross-section, wound on a toroidal magnetic core, for both sinusoidal and deformed currents, by transforming the parameters of the wire to the Dowell equation has been proposed. The methodology of estimating the resistance for the alternating component of the current flowing through a litz wire with a circular cross-section wound on a toroidal core is shown. The influence of the type of winding wire, the shape of the core, the number of winding layers, the winding angle, and the frequency range for which the litz wire obtains lower power losses than a solid-round wire are discussed. Full article

To investigate the shear performance of assembled bamboo scrimber (BS)-lightweight concrete (LC) connection systems, three groups of nine BS-LC shear connections were fabricated in this work using BS, LC, dowels, and grout. The experimental parameters included the dowel diameter and fabrication process (cast-in-place vs. assembly). Push-out tests were conducted on the specimens, and traditional linear variable displacement transducer (LVDT) measurements and the advanced digital image correlation (DIC) technique were employed to determine performance indicators such as the cross-section slip of composite members. Subsequently, the method for calculating the shear capacity of assembled BS-LC connection systems was theoretically analyzed. The research results showed that the load-slip curves measured by DIC were highly correlated with those measured by LVDT, thus, validating the reliability of the DIC data. According to the DIC data, the variations in slip of the shear connection over the interface height were further analyzed. An equation for calculating the shear capacity of dowel shear connectors was proposed based on theoretical analysis with comprehensive consideration of the experimental indicators such as the failure mode, load-slip curve, shear stiffness, and shear capacity of the specimens. The theoretical calculation values were in good agreement with the experimental results. Full article

This study addresses the critical issue of dowel-bearing strength in Bambusa blumeana, a key sustainable construction material crucial for climate change mitigation. Given the lack of bamboo connection standards, this research focuses on determining the dowel-bearing strength of Bambusa blumeana, emphasizing factors such as dowel diameter, node placements, and the physical properties of bamboo. A predictive equation is derived, enhancing the practicality of bamboo in structural design. The results underscore a notable correlation between dowel diameter and characteristic strength, with implications for engineering practices. Node placements significantly affect dowel-bearing capacity, while bamboo’s physical attributes, including thickness, culm diameter, and moisture content, exhibit modest correlations with strength. The derived equation aims to assist in structural design, mitigating splitting and bearing failures in bamboo structures. This research establishes a foundation for optimizing the use of Bambusa blumeana in sustainable construction, advancing the understanding of its dowel-bearing strength for improved sustainability and resilience in the construction industry. Future research suggestions include exploring bamboo–mortar composites, additional node placements, and employing more comprehensive empirical equations and curve-fitting techniques. The study advocates for further investigations with more diverse and larger bamboo samples to bolster robustness. Additionally, delving into bamboo ductility may offer valuable insights. Full article

The purpose of this research is to compare the bending behaviour of non-glue-laminated timber beams and glulams by full-scale four-point bending tests. The focus is on the non-glue beams laminated by different materials or techniques and then to determine their bending stiffness and failure modes. The laminating efficiency of various materials or techniques is underlined. The manufacturing process concerning non-glue-laminated timber beams has to be determined. As structural elements with large dimensions, such components require adaptable laminating and producing techniques. While the beams composed of wooden dowels refer to the dowel-laminated timber (DLT), those made of self-tapping screws (STSs) can be simply related to nail-laminated timber (NLT) products. Then, a full-scale four-point bending test was carried out to appraise 26 laminated beams, including non-glue- and glue-laminated timber. The results of the test demonstrated that the material, the spacing and the angle of the transversal fasteners significantly influence bending behaviour. The bending stiffness of the beams laminated by STSs was about 7.86% higher than the value of the beams with wooden dowels, although the tendency of each pair of beams did not remain convergent. Reducing the interval of the fasteners can considerably increase the bending stiffness of the beams. Fasteners inserted at 45 degrees, or in a so-called V-type pattern, contribute to improving bending stiffness, and both wooden dowels and STSs reveal the same tendency. At this angle, STSs demonstrate better laminating efficiency than wooden dowels. The STS beams’ bending stiffness was about 48.6% of that determined for glulams. On the contrary, in beams with 135-degree fasteners, or, namely, an A-type pattern, inserted fasteners possessed lower bending stiffness than in those with 90-degree fasteners. In addition to the considerable bending stiffness, the STS beams revealed a stable response as far as their load-deflection curves were concerned. A comparison of experimental and theoretical results contributes to verifying the feasibility as well as the weakness of two analytic methods. The predicting capacity of the associated equations needs to be improved, particularly for the withdrawal resistance and connecting effect of inclined STSs. Full article

In many cases, power inductors are responsible for most of the power loss, volume, and cost if applied to high-frequency power electronics applications. It is desirable to optimize their design by the proper calculation of winding and core loss. It allows faster and cheaper commercial product release, which is the key to being successful in a highly competitive market. This is only possible if existing calculation techniques and technical data given by, e.g., core manufacturers, are verified and correct; otherwise, the inductor optimization process is less precise and requires several iterations to achieve good convergence. This paper addresses existing and proposes improved measurement and calculation techniques with regard to complex permeability, one of the key quantities that define inductor behavior in the frequency domain. This is done through impedance measurement and improved definition of the equivalent inductor model. Moreover, the proposed calculation techniques fulfill the need for the simple, accurate analytical methods required in commercial designs. Full article

This work aims to present a study approach for double-shear connections of wood under fire with dowel pins and plates in steel material, using different types of glulam. The simplified Eurocode equations for ambient temperature were used to determine the dimensions and the number of dowel pins that each studied connection needs in order to resist an applied tensile load. Following this methodology, the finite element method was used to assess the thermal analysis of the studied connections under fire. The study aims to increase the information on these connections, where the wood material represents a complicated behavior in fire circumstances, with the addition of the steel material. The heat conducted by the dowel pin inside the connection, and the steel plate and its effect on the wood were analyzed. According to the results, it can be assumed that the temperature evolution is due to the geometry of the connection, the dowel pin or plate position, and the glulam density. Inside the wood element, the temperature remains lower, and externally a charred depth is developed when the target temperature of 300 °C is reached, and, in the vicinity of the dowel pin or the steel plate, a burned wood depth is indirectly formed. The rate of the charred layer is not constant throughout the entire fire exposure. Steel-to-timber connections with an internal steel plate with high glulam density have greater fire resistance due to the lower temperatures obtained. Full article

Eco-friendly concrete that considers waste material and requires less energy for production is in demand because it produces less carbon dioxide, reduces the consumption of raw material, and can be a cheaper option to conventional concrete. The objectives of this study are to investigate the shear behavior of reinforced concrete beams made with locally produced recycled coarse aggregate from construction demolition waste, study the important parameters that affect the shear strength and ductility, and check the applicability of the available theoretical shear strength predictive equations to recycled concrete. An experimental program that involved the testing of fifteen half-scale beams in shear without stirrups was carried out with a theoretical component. Results of the study showed that recycled concrete beams employing 50% recycled coarse aggregate had on average 27% lower shear strength than corresponding beams made with natural aggregate when tested at a shear span-to-depth ratio equal to 1.15, and almost the same strength as the natural aggregate beams when subjected to a shear span-to-depth ratio equal to 2.5. On the other hand, the average shear strength of beams utilizing 100% recycled aggregate was lower by 5% than the strength of their natural aggregate counterparts, irrespective of the shear span-to-depth ratio. The longitudinal steel reinforcement ratio had less effect on the shear strength provided by recycled concrete beams than on those made with natural aggregate, possibly due to the reduced ability of such concrete to develop strong dowel action. Although the use of higher strength concrete improved the shear strength of recycled aggregate beams, there was no clear correlation between the square-root of the concrete compressive strength and the shear strength provided by the concrete. The theoretical part of the study showed that the ACI 318 code and the strut-and-tie method can be reliably used to predict the shear strength of concrete made with recycled coarse aggregate employed in shallow and deep beams, respectively. Full article

In the de Sitter gauge theory (DGT), the fundamental variables are the de Sitter (dS) connection and the gravitational Higgs/Goldstone field ${\xi }^A$, where A is a 5 dimensional index. Previously, a model for DGT was analyzed, which generalizes the MacDowell–Mansouri gravity to have a variable cosmological constant, $\mathsf{\Lambda }=3/l^2$, where l is related to ${\xi }^A$ by ${\xi }^A{\xi }_A=l^2$. It was shown that the model sourced by a perfect fluid does not support a radiation epoch and the accelerated expansion of the parity invariant universe. In this paper, I consider a similar model, namely, the Stelle–West gravity, and couple it to a modified perfect fluid, such that the total Lagrangian 4-form is polynomial in the gravitational variables. The Lagrangian of the modified fluid has a nontrivial variational derivative with respect to l, and as a result, the problems encountered in the previous study no longer appear. Moreover, to explore the elegance of the general theory, as well as to write down the basic framework, I perform the Lagrange–Noether analysis for DGT sourced by a matter field, yielding the field equations and the identities with respect to the symmetries of the system. The resulted formula are dS covariant and do not rely on the existence of the metric field. Full article

To improve interface bonding stress, early-strength self-compacting shrinkage-compensating high-performance concrete (ESS-HPC) was selected as an excellent strengthening material to investigate by direct shear test. Tests on seventeen Z-type specimens were carried out considering the ESS-HPC and ordinary concrete substrate (OCS) compressive strength grade, the ESS-HPC curing age, the OCS surface roughness, and the ratio of steel shear dowels as the variables. A bond stress–slip model of the interface was proposed via statistical fitting. The results show that the surface roughness and ratios of steel shear dowels had the most important influence on the shear bond stress. The shear bond stress of the specimens without steel shear dowels increased by almost 15% as the ESS-HPC strength grade changed from C60 to C75. With the increase in the curing age, the shear bond stress showed a changing trend of first increasing and then decreasing. The coarser surface with the drilling method can improve the shear bond stress by 89%. To achieve a secondary increase in the shear bond stress of specimens with steel shear dowels, the minimum ratio of steel shear dowels was 0.83%. Analytical equations are proposed in combination with the CEB-FIB Model 2010 and AASHTO Model. The calculated results show reasonable agreement with the experimental results within an acceptable range. Full article

Superposed perfobond connectors are a type of connector used in composite structures. When the construction conditions are limited to increase the diameter of the opening, the shear capacity of the connector can be improved by enhancing the confining effect of the concrete dowel. In this study, 12 superposed perfobond connectors were fabricated to investigate the influence of lateral constraints on their shear behavior. The effects of hole area and holes’ number, diameter of the perforating rebar, concrete compressive strength, and the number of transverse reinforcements were investigated via the failure modes and load–slip curves. The results indicate that double-sided shear failure occurs in connectors with perfobond rib thicknesses exceeding 9 mm, and the connectors featuring strong lateral constraints not only exhibited higher bearing capacities but also superior load-holding capacities after peak load. Finally, an equation for the shear capacity of multi-hole perfobond connectors, considering lateral constraints, was proposed according to the double-sided shear theory. Full article

The lateral resistance of dowel-type connections with CLT is related to its lay-up, species of the laminations and even the manufacture method. Treating the CLT as homogeneous material, current methods develop new equations through test results or make use of the existing equations for the embedment strength already used in design codes; thus, the lateral resistance of dowel-type connections of CLT can be calculated. This kind of approach does not take the embedment stress distribution into account, which may lead to inaccuracy in predicting the lateral resistance and yield mode of the dowel-type connections in CLT. In this study, tests of the bolted connections and the screwed connections of CLT were conducted by considering the effects of the orientation of the laminations, the thickness of the connected members, the fastener diameter and strength of the materials. The material properties including yield strength of the fasteners and embedment strength of the CLT laminations were also tested. Using analysis of the dowel-type connections of CLT by introducing the equivalent embedment stress distribution, equations for the lateral resistance of the connections based on the European Yield Model were developed. The predicted lateral resistance and yield modes were in good agreement with the test results; the correctness and the feasibility of the equations were thus validated. Full article

This work presents the results of three types of timber connections, in double-shear, with metal dowel-type fasteners, using the simplified equations from of Eurocode 5. All the design parameters were established and compared using three different properties of strength and density of the wood that represent the connecting members. A total of eighty-one connections were obtained, allowing for the determination of the number of fasteners needed for the applied tensile load. A large number and different types of connections allow the verification of the effect of the dowel parameters together with the wood characteristics. In all of the types of timber connections studied, the number of dowels increases with the applied tensile load, with lower dowel diameter, lower wood density, and strength. The design characteristic load-carrying capacity per shear plane and fastener also decreases with the previously considered parameters. Full article

Dowel-type fasteners are one of the most used type of connections in timber joints. Its design follows the equations included in the Eurocode 5. The problem with these equations is that they do not adequately contemplate the resistive capacity increase of these joints, when using configurations which provoke the so-called rope effect. This effect appears when using threaded surface dowels instead of flat surface dowels, expansion kits or nut-washer fixings at the end of the dowel. The standards consider this increase through a constant value, which is a poor approximation, because it is clearly variable, depending on the joint displacement and because is much bigger, especially when using nut-washer fixings. It is also very important because of the rope effect trigger interesting mechanisms that avoids fragile failures without warning of the joints. For these reasons, it is essential to know how these configurations work, how they help the joint to resist the external loads and how much is the increase resistance capacity in relationship with the joint displacement. The methods used to address these issues consisted of a campaign of experimental tests using actual size specimens with flat surface dowels, threaded surface dowels and dowels with washer-nut fixings at their ends. The resistance capacity results obtained in all the cases has been compared with the values that will come using the equations in the standards. After the tests the specimens were cut to analyze the timber crushings, their widths, the positions and level of plasticizations suffer in the steel dowels and in the washer-nut fixings and the angle formed in the dowel plastic hinges. With all this information the failure mode suffered by the joints has been identified and compared with the ones that the standards predict. The results for the size materials and types of joints studied shows that the crush width average values go from 20 mm with flat surface dowels, to 24 mm in threaded to 32 mm in threaded with washer-nut fixings. The rope effect force/displacement goes from 100 N/m in threaded surface dowels to 500 N/m in threaded with washer-nut fixings. Finally, the load capacities are on average 290% higher those indicated in the standard. The main conclusion is that the rope effect force should be considered in the standards in more detail as a function of multiple variables, especially the displacement of the joint. Full article
