Real-time, non-contact velocity measurement of hot-rolled bars is critical for metallurgical process control, but conventional laser Doppler velocimetry (LDV) systems often fail in these environments. The intense broadband thermal radiation from targets up to 1000 °C, coupled with severe surface depolarization, overwhelms weak scattered signals in high-speed (up to 40 m/s) rolling zones. To address this issue, we developed a fully integrated, thermal-radiation-resistant LDV sensing system. Hardware optimization was achieved by eliminating polarized-light transmission and adopting a parallel-beam design, which significantly enlarges the laser overlap area and increases detection depth. Furthermore, a 1550 nm laser (100 mW) was coaxially combined with a 10 nm narrow-band filter to isolate the thermal background and boost signal strength. A customized workflow utilizing continuous Fourier transform (CFT) spectral refinement and energy centroid estimation was implemented to precisely extract the true Doppler shift. Performance evaluations show the system achieves an excellent signal-to-noise ratio (SNR) of 29,532. Allan variance analysis confirms a stable detection sensitivity of 0.003 m/s (0.1 s integration time), a local short-to-medium-term optimal limit of 1.6 × 10⁻⁴ m/s, and a statistical accuracy of 0.005 m/s. Finally, the system was successfully deployed on an industrial rolling mill production line. It provided reliable velocity feedback for mill speed adjustment, achieving a near-zero-tension rolling process and fundamentally resolving workpiece dragging, squeezing, and steel pile-up. Full article

Ocean surface radial current velocities can be derived from synthetic aperture radar (SAR) Doppler shift observations using the Doppler centroid technique and a recently developed Doppler velocity model. However, comprehensive evaluations of the accuracy and reliability of these retrievals remain limited. To address this gap, we analyzed 6341 Sentinel-1 SAR scenes acquired over the South China Sea (SCS) between December 2017 and October 2023, in conjunction with drifting buoy observations, to systematically validate the retrieved radial current velocities. A linear fitting method and the dual co-polarization Doppler velocity (DPDop) model were applied to correct for the influence of non-geophysical factors and sea state effects. The validation against the drifter data yielded a bias of 0.01 m/s, a root mean square error (RMSE) of 0.18 m/s, and a mean absolute error (MAE) of 0.16 m/s. Further comparisons with the Surface and Merged Ocean Currents (SMOC) dataset revealed bias, RMSE, and MAE values of 0.07 m/s, 0.14 m/s, and 0.12 m/s in the Beibu Gulf, and −0.06 m/s, 0.23 m/s, and 0.19 m/s in the Kuroshio intrusion area. These results demonstrate that SAR Doppler measurements have a strong potential to complement existing ocean observations in the SCS by providing high-resolution (1 km) ocean surface current maps. Full article

Sea surface wind, waves, and currents are the three basic parameters that describe the dynamic process of sea surface, and they are coupled with each other. To more accurately describe large-scale ocean motion and extract the ocean dynamic parameters, we adopt the spaceborne Doppler measurement to estimate the radial Doppler velocity generated by the sea surface motion. Due to the presence of wind and waves, the Doppler spectrum will be formed, shifted and broadened. Pulse-pair phase interference is used to obtain the Doppler spectrum from the sea surface echo. We simulate the Doppler spectrum with different look geometry and ocean states in a spaceborne condition. In this paper, the Doppler centroid variations are estimated after reducing the platform Doppler velocity under different observation conditions. With the increase in wind speed, the measured Doppler shift increases, and the simulated Doppler centroid accuracy is estimated. In addition, the measurement error along the trace direction is at the maximum, and the error in the cross-track is the smallest. At moderate wind-wave conditions, the Doppler velocity offset can be less than 0.1 m/s. Full article

Nowadays, sea surface analysis and monitoring increasingly use remote sensing, with particular interest in Synthetic Aperture Radar (SAR). Several SAR techniques exist in literature to understand the marine phenomena affecting the sea surface. In this work, we focus on the Doppler Centroid Anomaly (DCA), which accounts for the Doppler shift induced by sea surface movements. Starting from SAR raw data, we develop a processing chain to elaborate them and output the surface velocity map using DCA. The DCA technique has often been presented in the marine literature for estimating sea surface velocity, but more recently it has also been used to detect near-surface wind fields. This paper deals with estimating the sea surface wind field using Doppler information and SAR backscatter, combined with wind information provided by ECMWF and geophysical wind and Doppler model functions. We investigate the application of the approach in the coastal area of the northern Adriatic Sea (Northeast Italy). The test site is interesting, both for its particular orography, as it is a semi-enclosed basin largely surrounded by mountains, and for its complex meteorological phenomena, such as the Bora wind. Results obtained combining SAR backscatter and DCA information show an improvement in wind field estimation. Full article

The azimuth multichannel synthetic aperture radar (MC-SAR) is an effective means of earth observation due to its high-resolution and wide-swath (HRWS) imaging capability. Compared with the traditional MC-SAR, the two-dimensional (2D) spectrum of the squint multichannel synthetic aperture radar (SMC-SAR) is skewed, leading to the severe coupling between azimuth signals and range signals. Therefore, the traditional imaging algorithms are inapplicable to SMC-SAR. Currently, the existing imaging algorithms for SMC-SAR need interpolation or sub-aperture processing, which results in low efficiency. This paper proposes a novel imaging scheme for spaceborne SMC-SAR to handle this issue. With the squint angle known, the Doppler centroid can be compensated for by the spectrum shift function. Additionally, the frequency correlation method (FCM) is utilized to estimate the channel phase imbalance. After that, the azimuth multichannel data are reconstructed by the filter banks to eliminate the Doppler spectrum aliasing. Finally, the data are imaged based on the modified equivalent slant range model (MESRM). Both the simulation and Gaofen-3 (GF-3) data experiments demonstrate the effectiveness and efficiency of the proposed method. Full article

In range-Doppler ultrasound applications, the velocity of a target can be measured by transmitting a mechanical wave, and by evaluating the Doppler shift present on the received echo. Unfortunately, detecting the Doppler shift from the received Doppler spectrum is not a trivial task, and several complex estimators, with different features and performance, have been proposed in the literature for achieving this goal. In several real-time applications, hundreds of thousands of velocity estimates must be produced per second, and not all of the proposed estimators are capable of performing at these high rates. In these challenging conditions, the most widely used approaches are the full centroid frequency estimate or the simple localization of the position of the spectrum peak. The first is more accurate, but the latter features a very quick and straightforward implementation. In this work, we propose an alternative Doppler frequency estimator that merges the advantages of the aforementioned approaches. It exploits the spectrum peak to get an approximate position of the Doppler frequency. Then, centered in this position, a centroid search is applied on a reduced frequency interval to refine the estimate. Doppler simulations are used to compare the accuracy and precision performance of the proposed algorithm with respect to current state of the art approaches. Finally, a Field Programmable Gate Array (FPGA) implementation is proposed that is capable of producing more than 200 k low noise estimates per second, which is suitable for the most demanding real-time applications. Full article

Multi-channel beam-steering synthetic aperture radar (multi-channel BS-SAR) can achieve high resolution and wide-swath observations by combining beam-steering technology and azimuth multi-channel technology. Various imaging algorithms have been proposed for multi-channel BS-SAR but the associated parameter estimation and error calibration have received little attention. This paper focuses on errors in the main parameters in multi-channel BS-SAR (the derotation rate and constant Doppler centroid) and phase inconsistency errors. These errors can significantly reduce image quality by causing coarser resolution, radiometric degradation, and appearance of ghost targets. Accurate derotation rate estimation is important to remove the spectrum aliasing caused by beam steering, and spectrum reconstruction for multi-channel sampling requires an accurate estimate of the constant Doppler centroid and phase inconsistency errors. The time shift and scaling effect of the derotation error on the azimuth spectrum are analyzed in this paper. A method to estimate the derotation rate is presented, based on time shifting, and integrated with estimation of the constant Doppler centroid. Since the Doppler histories of azimuth targets are space-variant in multi-channel BS-SAR, the conventional estimation methods of phase inconsistency errors do not work, and we present a novel method based on minimum entropy to estimate and correct these errors. Simulations validate the proposed error estimation methods. Full article

Multi-year field measurements of sea surface Ka-band dual-co-polarized (vertical transmit–receive polarization (VV) and horizontal transmit–receive polarization (HH)) radar Doppler characteristics from an oceanographic platform in the Black Sea are presented. The Doppler centroid (DC) estimated using the first moment of 5 min averaged spectrum, corrected for measured sea surface current, ranges between 0 and ≈1 m/s for incidence angles increasing from 0 to ${70}^{\circ }$ . Besides the known wind-to-radar azimuth dependence, the DC can also depend on wind-to-dominant wave direction. For co-aligned wind and waves, a negative crosswind DC residual is found, ≈−0.1 m/s, at ≈20 ${}^{\circ }$ incidence angle, becoming negligible at ≈ 60 ${}^{\circ }$ , and raising to, ≈+0.5 m/s, at ${70}^{\circ }$ . For our observations, with a rather constant dominant wave length, the DC is almost wind independent. Yet, results confirm that, besides surface currents, the DC encodes an expected wave-induced contribution. To help the interpretation, a two-scale model (KaDOP) is proposed to fit the observed DC, based on the radar modulation transfer function (MTF) previously developed for the same data set. Assuming universal spectral shape of energy containing sea surface waves, the wave-induced DC contribution is then expressed as a function of MTF, significant wave height, and wave peak frequency. The resulting KaDOP agrees well with independent DC data, except for swell-dominated cases. The swell impact is estimated using the KaDOP with a modified empirical MTF. Full article

This paper presents a fast SAR imagery algorithm for Ground Moving Target Imaging (GMTIm) based on the slope detection strategy combined with Time-Frequency Representation (TFR), which is known as Lv’s Distribution (LVD). This fast imagery algorithm focuses on the solution of the ambiguity problems and relevant heavy computing load in SAR imagery. Firstly, according to the relationship between the slope of the range walk trajectory and the cross-track velocity of moving target, a new high-efficiency slope detection strategy based on gradient and level-line angle is presented in the image domain. Then, the Doppler centroid shift induced by cross-track velocity can also be obtained. Secondly, owing to the cross-track velocity estimated before, the Range Walk Migration Correction (RWMC) can be performed to concentrate the echo response of the moving target into a single range cell. Finally, due to the superior performance in representing multi-component Linear Frequency Modulation (LFM) signal, LVD is adopted here to represent the Doppler chirp rate of multiple moving targets in a Doppler Centroid Frequency and Chirp Rate domain (CFCR). The performance of the proposed algorithm is evaluated in terms of superiority and effectiveness using simulations, and the comparison between the proposed algorithm and the other conventional algorithms is also presented. Full article

Circular scanning synthetic aperture radar (SAR) is a novel imaging mode wherein the radar antenna rotates from 0 degrees to 360 degrees along the platform flight direction, providing us with a potentially effective technique to estimate the sea surface current velocity. In this paper, we propose a novel method to estimate the sea surface current velocity utilizing the Doppler centroid shifts of different scan angles over 360 degrees after the airborne platform motion compensation. In this method, the Doppler centroid shifts of the sea clutter at different scan angles are first extracted, and the corresponding compensation errors caused by the azimuth pointing and the incidence angle of the radar beam are considered. Finally, the least squares (LS) technique is applied to estimate the along-track velocity component and the cross-track velocity component of the sea surface current. The effectiveness of the proposed method is verified by the real data recorded by an airborne circular scanning SAR system. Full article
