This paper proposes an improved Maximum Torque Per Ampere (MTPA) control method based on The Direct Torque Control-Space Vector Modulation (DTC-SVM) control algorithm using d-axis flux optimization. The proposed algorithm simplifies the existing DTC-SVM control method by geometrically interpreting its complex equations thereby providing a more straightforward and efficient approach. The proposed algorithm geometrically computes the d-axis flux reference and compensation values for the MTPA control by continuously monitoring the q-axis flux in real time. Additionally, the compensation value of the d-axis flux reference is employed to compute the magnitude and phase reference values of the DTC-SVM voltage vector, which in turn generates the stator current values that align with the MTPA curve. The effectiveness of the proposed algorithm was validated through simulation results in MATLAB Simulink. When the proposed algorithm was applied, the torque response to the torque command improved compared to the DTC-SVM control. Additionally, for the same torque production, the stator current consumption of the IPMSM was reduced by approximately 12.55%, demonstrating improved efficiency. To further validate the effectiveness of the proposed algorithm, a dynamometer test system was established, and the IPMSM was tested across various speed ranges below the base speed while generating different torque outputs. The torque response dynamics and stator current consumption of the proposed algorithm were then compared with those of the DTC-SVM algorithm, confirming its enhanced performance. Full article

Electric vehicles demand efficient and robust motor control to maximize range and performance. This paper presents an innovative adaptive fractional-order sliding mode (FO-SM) control approach tailored for Direct Torque Control with Space Vector Modulation (DTC-SVM) applied to induction motor drives. This approach tackles the challenges of parameter variations inherent in real-world applications, such as temperature changes and load fluctuations. By leveraging the inherent robustness of FO-SM and the fast dynamic response of DTC-SVM, our proposed control strategy achieves superior performance, significantly reduced torque ripple, and improved efficiency. The adaptive nature of the control system allows for real-time adjustments based on system conditions, ensuring reliable operation even in the presence of uncertainties. This research presents a significant advancement in electric vehicle propulsion systems, offering a powerful and adaptable control solution for induction motor drives. Our findings demonstrate the potential of this innovative approach to enhance the robustness and performance of electric vehicles, paving the way for a more sustainable and efficient future of transportation. In fact, the paper proposes using an adaptive approach to control the electric vehicle’s speed based on the fractional calculus of sliding mode control. The adaptive algorithm converges to the actual values of all system parameters. Moreover, the obtained performance results are reached without precise system modeling. Full article

The present paper proposes the use of fractional derivatives in the definition of sliding function, giving a new mode control applied to induction motor drives in electric vehicle (EV) applications. The proposed Fractional-Order Sliding Mode Direct Torque Control-Space Vector Modulation (FOSM-DTC-SVM) strategy aims to address the limitations of conventional control techniques and mitigate torque and flux ripples in induction motor systems. The paper first introduces the motivation for using fractional-order control methods to handle the nonlinear and fractional characteristics inherent in induction motor systems. The core describes the proposed FOSM-DTC-SVM control strategy, which leverages a fractional sliding function and the associated Lyapunov stability analysis. The efficiency of the proposed strategy is validated via three scenarios. (i) The first scenario, where the acceleration of the desired speed is defined by pulses, leading to Dirac impulses in its second derivative, demonstrates the advantage of the proposed control approach in tracking the desired speed while minimizing flux ripples and generating pulses in the rotor pulsation. (ii) The second scenario demonstrates the effectiveness of filtering the desired speed to eliminate Dirac impulses, resulting in smoother rotor pulsation variations and a slightly slower speed response while maintaining similar flux ripples and stator current characteristics. (iii) The third scenario consists of eliminating the fractional derivatives of the pulses existing in the expression of the control, leading to the elimination of Dirac impulses. These results demonstrate the potential of the FOSM-DTC-SVM to revolutionize the performance and efficiency of EVs. By incorporating fractional control in the control scheme for PV-powered EVs, the paper showcases a promising avenue for sustainable transportation. Full article

In this study, the analysis and control of a multi-phase linear induction motor loaded with a variable mechanical system are carried out. Mathematical models are established, and simulation results are analyzed for an improved proportional–integral–derivative controller with closed-loop vector control for PLIM. To make the PID controller more responsive to load thrust disturbances, a fuzzy PID load thrust observer was developed. The FPID is similarly based on space-vector modulation DTC technology to regulate the PLIM’s speed, flux, and thrust. The FPID output is used to calculate the reference thrust force, which is compared to the actual thrust value to calculate the second error. To maintain the linear speed of the PLIM at the specified reference values and at different load values, the FPID controller settings are adjusted. Four indicators were used to compare the capabilities of the FPID controller with those of the conventional PID controller in order to evaluate the performance of PLIM in both cases. These indices represent the individual SSE for each operational phase and the total SSE for the entire loading period. According to the simulation results, the FPID works better than a regular PID when used to adjust the operation of DTC-SVM to drive a PLIM to improve the overall system performance. The simulation results using MATLAB Simulink for a PLIM-drive system show that the proposed FPID control provides improved control behavior and operating performance with fast and accurate speed tracking. Full article

One innovative composite fault-tolerant control tactic is presented for the reliable operation of a power transmission system, which consists of both an asymmetric six-phase permanent magnet synchronous motor (PMSM) and a T-type mid-point clamp type (T-NPC) three-level inverter. First, in order to inherit the better harmonic property of simplified space vector modulation (SVM) and the rapid dynamic capability of direct torque control (DTC), the SVM-DTC control scheme was determined, and the harmonic electric current suppression unit was added to the basic control scheme to obtain good harmonic electric current suppression. In addition, a strategy for open-circuit fault-tolerant control under the SVM-DTC scheme was designed by analyzing the mutual influence between the stator flux linkage and the stator voltage of each phase under an open-circuit fault. Finally, the PMSM drive system principle prototype was tested. By comparing the waveforms of output torque and current of each phase before and after fault tolerance, it shows that the large torque fluctuation (±5%) before fault tolerance was suppressed to ±2% and smoothed out, verifying the effectiveness of fault tolerance control. Full article

The doubly fed induction machine (DFIM)-based DC voltage generator is equipped with a stator-connected diode rectifier. The six-pulse diode rectifier as a nonlinear circuit introduces harmonics in the stator and rotor current and distorts the machine stator voltage, as well as the stator flux. This causes electromagnetic torque oscillations and instantaneous power components oscillations. The torque oscillations adversely impact the mechanical parts of the drive-train and oscillations of the p component of instantaneous power influence DC-bus voltage oscillations. The oscillations can be somewhat cancelled by control methods. However, cancellation of electromagnetic torque is not strictly coupled with cancellation of oscillations of the p component of instantaneous power. The paper presents an analysis of influence of the control methods aimed at a reduction of torque oscillations on the output voltage oscillations level in the stand-alone DFIM-based DC voltage generator. Field-oriented control FOC with current controllers and space vector modulation-based direct torque control DTC-SVM with flux module regulation have been compared with control in which electromagnetic torque is one of the commanded variables, whereas the second variable is the dot product of stator flux and rotor current space vectors. The contributions of this paper are the introduction of a new variable in the second control path in the DTC-SVM method instead of flux vector length and the proof that it can reduce torque and DC-bus voltage oscillations in the DFIG-DC system. Additionally, this paper reveals that for proper stator-to-rotor-turns ratio of a doubly fed machine necessary for reduction of the rotor converter power, lower DC-bus voltage can be obtained than is required for full realization rotor side voltage requested by rotor current controllers. This is the reason why, regardless of the control method, torque oscillations cannot be always fully cancelled, and a comparative study of the methods at these conditions has been conducted in simulation and in laboratory tests. Full article

In this paper, a full analysis of voltage vectors (VVs) in the DTC algorithm is presented. The analytical analysis shows that the application of specific VVs results in false switching states called uncontrollable angles (UCAs). A robust scheme that ensures the elimination of UCAs is proposed for medium and high speeds with (18) subsectors (SSs). Simulation results are obtained and validated using MATLAB/Simulink. Full article

This paper presents a method to extend the DC bus utilization on an induction motor (IM) by using a combination of Space-Vector Modulated Direct Torque Control (DTC–SVM) and conventional DTC. The scheme proposed in this paper exploits the advantages of both control methods. During the linear region, it allows for a low torque ripple and low current harmonic distortion (THD). During the overmodulation region, it allows for the fastest torque response up to the six-step operation region. In both regions, there is complete independence of the motor parameters. The paper describes a way to provide a smooth transition between the two control schemes. Non-linearities affect the stator flux angle estimation, which leads to the inability to decouple torque and flux. To overcome this problem, a novel PI-based control scheme as well as a simplification on the decoupling terms’ calculation are proposed. Simulation and experimental results are presented to verify the feasibility of the proposed method. Full article

This paper focuses on the application of the direct torque control based on space vector modulation (DTC-SVM), combined with the input–output feedback linearization (IOFL) technique on a three-phase dual open-end windings induction motor (DOEWIM) fed by two dual indirect matrix converters. The main aim of integrating the non-linear technique is to overcome the main drawbacks met within the application of the conventional DTC-SVM on dual-stator induction motor (DSIM), such as the torque and flux ripples reduction, the stator harmonics current minimization, and the elimination of the common-mode voltage (CMV). Furthermore, it is proved in this paper that the proposed control on DOEWIN can ensure more flexibility versus speed reverse and variation, load torque changes, and motor parameters variation. The obtained results prove the validity of the proposed control on the studied induction motor topology in ensuring the main aforementioned advantages compared to the conventional DTC-SVM control on DSIM, which presents a promising solution, especially in industrial applications in which high-power motors are required. Full article

This paper proposes a simple method to generate stable voltage commands for permanent magnet synchronous motors to achieve low torque ripple based on space vector modulation direct torque control (SVM-DTC). The relationship between applied voltage and electromagnetic torque is first analyzed and the effect of the voltage and flux linkage on torque ripple is discussed. Then, the new method is developed to reduce torque ripple by giving low-fluctuation voltage commands to the voltage source inverter. The magnitude of the voltage command is calculated by avoiding the effect of flux linkage angle that can be estimated inaccurately during motor operation. Therefore, the fluctuation of the voltage command can be significantly reduced. In order to validate the proposed method, Simulink is first used for simulation and the performance of the proposed method is evaluated. It is found that the torque ripple can be substantially reduced while keeping a low switching frequency and improving system response. Then, a hardware-in-the-loop (HIL) technique is applied to test the developed algorithm that is written into a Texas Instruments microcontroller. This validates the simulation results and the proposed method. Full article

An improved direct torque control with space-vector modulation (DTC-SVM) scheme is presented in this paper. In the conventional DTC-SVM scheme, torque control performance is affected by the load conditions, due to the inappropriate linearization of the relationship between the flux angle and electromagnetic torque. Different from the conventional method, a torque controller with load angle estimation (TC-LAE) is proposed and the change rate of torque is regulated according to the variation of the load conditions, which could ensure the rapidity and consistency of torque performance at different load conditions. Meanwhile, an online permanent magnet synchronous motor and maximum torque per ampere (PMSM-MTPA) operation strategy based on the fitting solving method is proposed instead of the traditional two-dimensional look-up table, and the reference value of flux amplitude is calculated online to meet the MTPA requirement with the proposed method. The improved strategy is applied on a 6 kW PMSM, and the simulation and experimental results verified the effectiveness and the feasibility of the proposed strategy. Full article

A novel direct torque control (DTC) method based on sliding-mode-control (SMC) strategy is proposed for permanent magnet synchronous motor (PMSM) which is used in electric vehicles (EVs). In order to improve the dynamic response time and enhance the robustness performance against the external loading disturbances and motor parameter’s variation, a kind of SMC-based torque controller and speed controller are designed to regulate the torque angle increment and the speed respectively. The torque controller is designed based on a sliding mode controller with an asymmetric boundary layer to reduce the overshoot. Compared with other DTC methods based on space vector modulation (SVM) in the literature, the proposed DTC scheme adopts the asymmetric boundary layer SMC instead of the proportional-integral (PI) regulator. The simulation results have validated the effectiveness of the proposed SMC-based DTC method. Full article

The interior permanent magnet synchronous motor (PMSM) can offer many advantages, including high power-to-weight ratio, high efficiency, rugged construction, low cogging torque and the capability of reluctance torque, so it is widely used in electric vehicle (EV). Two control schemes, namely field oriented control (FOC) and direct torque control (DTC) are used in PMSM drive. In order to decrease current and torque ripple and fix switching frequency, an improved DTC scheme based on the control of stator flux, torque angle and torque was proposed, which used voltage vector selection strategy and the technology of space vector modulation (SVM) to generate the applied voltage vector instead of switching table. And this paper compared these three control schemes based on a 15-kW interior PMSM used in Honda Civic 06My hybrid electrical vehicle. Experimental results show for the FOC using the hysteresis current control, due to the lower sampling period, stator current is more sinusoidal. But it needs the continuous rotor position information and the switching frequency of the VSI is not constant. For the DTC using switching table, current ripple is higher and the switching frequency of the VSI is also not constant. But it does not need the rotor position information except for the initial rotor position. Compared with switching table, the proposed DTC can decrease current and torque ripple and fix switching frequency. Full article
