Search Results (189)

Implementing energy-efficient solutions and developing energy complexes to decentralise power supply are key objectives for enhancing national security in Ukraine and Eastern Europe. This study compares the design, numerical, and experimental parameters of a channel-type jet-reaction turbine. A steam turbogenerator unit and a pilot industrial experimental test bench were developed to conduct full-scale testing of the unit. The article presents experimental data on the operation of a steam turbogenerator unit with a capacity of up to 475 kW, based on a channel-type steam jet-reaction turbine (JRT), and includes the validation of a computational fluid dynamics (CFD) model against the obtained results. For testing, a pilot-scale experimental facility and a turbogenerator were developed. The turbogenerator consists of two parallel-mounted JRTs operating on a single electric generator. During experimental testing, the system achieved an electrical output power of 404 kW at a turbine rotor speed of 25,000 rpm. Numerical modelling of the steam flow in the flow path of the jet-reaction turbine was performed using ANSYS CFX 25 R1 software. The geometry and mesh setup were described, boundary conditions were defined, and computational calculations were performed. The experimental results were compared with those obtained from numerical simulations. In particular, the discrepancy in the determination of the power and torque on the shaft of the jet-reaction turbine between the numerical and full-scale experimental results was 1.6%, and the discrepancy in determining the mass flow rate of steam at the turbine inlet was 1.34%. JRTs show strong potential for the development of energy-efficient, low-power turbogenerators. The research results confirm the feasibility of using such units for decentralised energy supply and recovering secondary energy resources. This contributes to improved energy security, reduces environmental impact, and supports sustainable development goals. Full article

Efficient water heating is essential for wool-washing processes, which demand temperatures above 70 °C. To meet this requirement sustainably, a parabolic trough solar concentrator system is proposed in this paper as an alternative to conventional natural gas systems. The design centers on a water pool constructed from bricks reinforced with an internal steel layer, enhancing heat exchange efficiency. Also, various synthetic oils were analyzed as heat transfer fluids (HTFs) within an immersed heat exchanger, such as Thermia B oil, Heat Transfer Oil 32, biphasic oil, and Therminol vp1 oil. Numerical simulations were performed using ANSYS CFX v19.2 software with the k-ε turbulence model to evaluate the thermal performance and temperature distribution. The results demonstrate the superior efficiency of the solar-powered system, with the steel-reinforced pool achieving optimal water temperatures between 78 °C and 85 °C, exceeding the required threshold for industrial wool washing. Among the various synthetic oils analyzed, Thermia B emerged as the most effective heat transfer fluid, maintaining water temperatures in the range of 75 °C to 85 °C. This superior thermal performance is attributed to its high thermal conductivity and reduced heat loss, ensuring consistent and optimal heat distribution for the wool-washing process. Full article

The ongoing efforts to convert High-Performance Research Reactors (HPRRs) using Highly Enriched Uranium (HEU) to Low-Enriched Uranium (LEU) fuel require reliable thermal–hydraulic assessments of modified core designs. The involute-shaped fuel plates used in several major HPRRs present unique modeling challenges due to their compact core geometries and high heat flux conditions. This study evaluates the capability of three commercial CFD tools, STAR-CCM+, COMSOL, and ANSYS CFX, to predict cladding-to-coolant heat transfer using Reynolds-Averaged Navier–Stokes (RANS) methods within the thermal–hydraulic regimes of involute-shaped plate reactors. Broad sensitivity analysis was conducted across a range of reactor-relevant parameters using two turbulence models ($k-ϵ$ and $k-\omega$ SST) and different near-wall treatment strategies. The results were benchmarked against the Sieder–Tate correlation and experimental data from historic studies. The codes produced consistent results, showing good agreement with the empirical correlation of Sieder–Tate and the experimental measurements. The findings support the use of these commercial CFD codes as effective tools for assessing the thermal–hydraulic performance of involute-shaped plate HPRRs and guide future LEU core development. Full article

Model validation is an essential part of CFD-based projects. Despite being successfully employed for decades, the level and extent of CFD model validation details vary significantly in the published literature, which, in turn, adversely affects the repeatability and usefulness of published models and data. This study explores the various challenges associated with validating CFD models of thermodynamic components, namely, the compressors and their performance evaluation. The methodology involves blade generation through TurboGrid and BladeGen, mesh generation to ensure computational efficiency, and pre-processing with CFX to define boundary conditions and turbulence models, all within ANSYS 2024 R1. Three case studies are discussed, each assessing different compressor configurations and common challenges encountered during the model validation stage. Based on the case studies, a number of recommendations are presented relating to best practices in terms of both the use of published materials to validate new models and the level of detail required for experimental or simulation publication to ensure they can be replicated or used to validate a new model. Full article

To investigate the impact of sand-laden flow on energy loss in Francis turbines, this study integrates entropy generation theory with numerical simulations conducted using ANSYS CFX. The mixture multiphase flow model and the SST k-ω turbulence model are employed to simulate the solid–liquid two-phase flow throughout the entire flow passage of the turbine at the Gengda Hydropower Station (Minjiang River Basin section, 103°17′ E and 31°06′ N). The energy loss characteristics under different off-design conditions are analyzed on the basis of the average sediment concentration during the flood season (2.9 kg/m³) and a median particle diameter of 0.058 mm. The results indicate that indirect entropy generation and wall entropy generation are the primary contributors to total energy loss, while direct entropy generation accounts for less than 1%. As the guide vane opening increases, the proportion of wall entropy generation initially rises and then decreases, while the total indirect entropy generation exhibits a non-monotonic trend dominated by the flow pattern in the draft tube. Entropy generation on the runner walls increases steadily with larger openings, whereas entropy generation on the draft tube walls first decreases and then increases. The variation in entropy generation on the guide vanes remains relatively small. These findings provide technical support for the optimal design and operation of turbines in sediment-rich rivers. Full article

This study investigates the influence of modifications in the geometry of the blades—specifically, the introduction of a gap blade into the impeller blades—on the hydraulic performance of a low specific speed centrifugal pump. The research addresses the problem of efficiency losses in such pumps and explores whether implementing a blade gap can improve energy characteristics without altering the primary flow path. A set of impellers with different gap configurations was designed and manufactured using 3D printing. Experimental tests were carried out on a laboratory test rig equipped with standard pressure, flow, and power measurement instruments. Next, numerical simulations were performed using CFD methods in Ansys CFX, using the k-ω SST turbulence model. The results show that impellers with gap blades achieved higher efficiency—up to 4 percentage points compared to the reference design—and an increase in the maximum pump capacity. CFD analysis confirmed more uniform velocity distributions and reduced separation zones in the interscapular channels, along with a smoother pressure gradient across the blade surfaces. The results demonstrate that modifying impeller geometry using gap blades can improve hydraulic efficiency and expand the range of stable operation. These conclusions support further research on performance optimisation in low-specific-speed centrifugal pumps. Full article

The combustion chamber is a critical component of turbojet engines, and airflow distribution plays an essential role in ensuring flame stability and optimizing combustion efficiency. This study investigates a miniature annular combustion chamber by employing SolidWorks 2022 software to model an evaporative tube combustion chamber. A dedicated combustion test platform was constructed for the proposed miniature combustion chamber. By adjusting the air and fuel flow ratios entering the evaporative tube, the temperature at the flame tube outlet was measured, and the combustion efficiency was subsequently calculated. In addition, numerical analysis was conducted using ANSYS/CFX software to simulate the flow field in the combustion chamber. The following conclusions were drawn from an analysis of the variations in the flow field and temperature field during the simulation process: When the flow rates in the ignition and dilution zones of the miniature annular combustion chamber remained constant, modifying the air-fuel flow ratio within the evaporative tube significantly enhanced the combustion characteristics within the chamber. Specifically, the combustion efficiency is closely related to the ratio of the air mass flow rate to the fuel mass flow rate within the evaporation tube. The highest combustion efficiency was achieved when the ratio fell within the range of 4.20 to 4.96. Furthermore, the area-averaged velocity at the combustion chamber outlet was independent of the air-fuel flow ratio but exhibited a positive correlation with the fuel flow entering the combustion chamber. Full article

The steady-state aerodynamics and the aeroelastic response have been analyzed in an oscillating linear transonic cascade at the KTH Royal Institute of Technology. The investigated operating points ($\mathrm{\Pi }=1.29$ and $1.25$) represent an open-source virtual compressor (VINK) operating at a part speed line. At these conditions, a shock-induced separation mechanism is present on the suction side. In the cascade, the central blade vibrates in its first natural modeshape with a 0.69 reduced frequency, and the reference measurement span is 85%. The numerical results are computed from the commercial software Ansys CFX with an SST turbulence model, including a reattachment modification (RM). Steady-state results consist of a Laser-2-Focus anemometer (L2F), pressure taps, and flow visualization. Steady-state numerical results indicate good agreement with experimental data, including the reattachment line length, at both operating points, while discrepancies are observed at low-momentum regions within the passage. Experimental unsteady pressure coefficients at the oscillating blade display a fast amplitude decrease downstream, while numerical results overpredict the amplitude response. Numerical results indicate that, at the measurement plane, for both operating points, the harmonic amplitude is dominated by the shock location. At midspan, there is an interaction between the shock and the separation onset, where large pressure gradients are located. Experimental and numerical responses at blades adjacent to the oscillating blade are in good agreement at both operating points. Full article

Turbocharged internal combustion engines offer efficient power-to-weight ratios, aiding in fuel-saving efforts within the automotive industry. However, when the flow is low, compressors show various instabilities, i.e., stall and inlet recirculation, which have a negative influence on their performance. This paper uses transient numerical simulations to explore the inlet recirculation phenomenon in a turbocharger compressor. The Reynolds-Averaged Navier–Stokes equations and k-ω SST turbulence model were solved using ANSYS CFX. The numerical model was verified using the experimental data for the design speed line. Analysis of mesh independence was performed to assess the discretization uncertainty near the design and surge line points. The results indicate that the inlet recirculation appears for moderate flows lower than design conditions. It shows significant radial and streamwise growth as the flow decreases. The reversed flow area increases more intensely in the radial direction at medium mass flow rates, whereas the streamwise growth is more substantial at low mass flow rates. The reversed flow reached 27% of the total inlet area at the point on the surge line. It was accompanied by a 15.7% drop in efficiency between the points with weak and strong inlet recirculation. The presented research indicates significant changes in the size of the inlet recirculation zone in the circumferential direction. It reaches its highest intensity close to the angular position of the volute tongue. Full article

The core inlet flow distribution in the APR1000 reactor is critical for ensuring the reactors safety and efficient operation by maintaining uniform coolant flow across fuel assemblies. Previous studies, though insightful, faced challenges in fully replicating reactor-scale flow conditions due to technical and economic constraints associated with scaled-down experimental models and the limited numerical validation methodologies. This study addresses these limitations by developing and validating a robust computational fluid dynamics (CFD) methodology to accurately analyze the core inlet flow distribution. A 1/5 scaled-down experimental model adhering to similarity laws was employed for validation. CFD analyses using ANSYS Fluent and CFX, combined with turbulence model evaluations and grid sensitivity studies, demonstrated that the SST and RNG k-ε turbulence models provided the most accurate predictions, with a high correlation to previous experimental data. Full-scale simulations revealed uniform coolant distribution at the core inlet, with peripheral assemblies exhibiting higher flow rates, consistent with previous experimental observations. Quantitative metrics such as the coefficient of variation (COV), relative error (RD), and root mean square error (RMSE) confirmed the superior performance of the SST model in CFX, achieving a COV of 7.993% (experimental COV: 5.694%) and an RD of 0.047. This methodology not only validates the CFD approach but also highlights its applicability to reactor design optimization and safety assessment. The findings of this study provide critical guidelines for analyzing complex thermal-fluid systems in nuclear reactor designs. Full article

Hydrogen is a promising environmentally friendly fuel with the potential for zero-carbon emissions, particularly in maritime applications. However, owing to its wide flammability range (4–75%), significant safety concerns persist. In confined spaces, hydrogen leaks can lead to explosions, posing a risk to both lives and assets. This study conducts a numerical analysis to investigate hydrogen flow within hydrogen storage rooms aboard ships, with the goal of developing efficient ventilation strategies. Through simulations performed using ANSYS-CFX, this research evaluates hydrogen diffusion, stratification, and ventilation performance. A vertex angle of 120° at the ceiling demonstrated superior ventilation efficiency compared to that at 177°, while air inlets positioned on side-wall floors or mid-sections proved more effective than those located near the ceiling. The most efficient ventilation occurred at a velocity of 1.82 m/s, achieving 20 air exchanges per hour. These findings provide valuable insights for the design of safer hydrogen vessel operations. Full article

This study delves into rotor–stator interaction within a bidirectional bulb tubular pump under cavitation conditions. Using pressure pulsation tests on a model pump and numerical simulations performed with ANSYS CFX software, we analyzed pressure pulsation and flow field data across three distinct flow rates and multiple cavitation numbers. Both time-domain and frequency-domain analyses were conducted to examine the patterns of pressure pulsation influenced by flow rates and cavitation numbers at various monitoring locations. A numerical flow field analysis further validated the findings. The results reveal that rotor–stator interaction manifests in the vaneless spaces of the pump during cavitation. The onset of cavitation alters the amplitudes of dominant frequencies at different flow rates. Near the guide vane and impeller, the dominant frequencies shift toward the impeller frequency and guide vane frequency, respectively. Under low-flow conditions, the rotor–stator interaction effect is more conspicuous due to the deteriorated flow pattern. Pressure pulsations are more strongly influenced in the front vaneless space (FVP) than in the rear vaneless space (RVP). This difference arises because the front guide vane destabilizes rather than stabilizes the flow pattern, worsening the rotor–stator interaction. Additionally, the FVP is less affected by the impeller than the RVP, further amplifying the influence of rotor–stator interaction on pressure pulsation. These findings provide a theoretical foundation for mitigating the effects of rotor–stator interaction on the operational stability and efficiency of bidirectional bulb tubular pumps. Full article

Cross-flow turbines are widely used in microhydropower systems because of their cost-effectiveness, environmental sustainability, adaptability, and robust design. However, their relatively lower efficiency than other turbine types limit their application in large-scale projects. Previous studies have identified poor flow profiles as a significant factor contributing to inefficiency, with the number of blades playing a critical role in the flow behavior, efficiency, and structural stability. This study employed numerical simulations to analyze how varying the number of blades affects the internal flow characteristics and performance of the turbine at, and off, its best operating points. Configurations with 16, 20, 24, 28, 32, 36, 40, and 44 blades were investigated under constant low-head conditions, fully open valve settings, and varying runner speeds. Simulations were performed using ANSYS CFX, incorporating steady-state conditions, a two-phase flow model with a movable free surface, and a shear stress turbulence model. The results indicate that the 28-blade configuration achieved a maximum hydraulic efficiency of 83%, outperforming the preset 24-blade setup by 6%. Flow profiles were examined using pressure and velocity gradients to identify regions of adverse pressure. Due to the impulse nature of the turbine, the flow profile is more sensitive to changes in the flow speed than to pressure. The flow trajectory showed stability in the first stage but exhibited discrepancies in the second stage, which were attributed to turbulence, recirculation, and shaft flow impingement. The observed performance improvements were linked to reduced hydraulic losses due to flow separation and friction, emphasizing the significance of the number of blades and the regions of optimal efficiency under low-head conditions. Full article

Gas turbine engines are used in many applications such as power plants and aircrafts. The energy generated through fuel combustion has a significant impact on fluid flow characteristics and thrust force produced by gas turbine engines. This energy generation is based on the precise mixing of fuel and air with known proportions. The present research work attempts to examine the characteristics of fluid flow for aero-engine combustion in a chamber with either a single fuel inlet or multiple fuel inlets using the computational fluid dynamics (CFD) technique. Developed in Creo-6.0 parametric design software, the combustion chamber was modeled and simulated using the ANSYS CFX simulation platform to determine the pressure and other fluid flow-induced characteristics. The analysis was performed for both single fuel inlet and multiple fuel inlet combustion chamber designs. The outlet pressure of the combustion chamber is a key parameter in determining the combustion characteristics and subsequent gas expansion in gas turbine performance. Our results indicated that the outlet pressure from the double fuel inlet design was 49.04% higher than the single fuel inlet design. The thrust force (propulsion) in gas turbine engines is a result of the mass flow rate of exhaust gasses, as quantified by the gas exit velocity. Induced thrust on a combustor with double fuel inlet was 48.3% higher than the induced thrust in the single fuel inlet design, making the double fuel inlet design a more viable option. The higher outlet pressure obtained in the double fuel inlet design showed higher enthalpy generation and greater energy conversion into thrust. The cause of this higher enthalpy is attributed to better fuel combustion in the primary zone. It appears that the double fuel inlet design could improve total turbine efficiency, reduce fuel consumption, and lower emissions. Full article

In this article, thermophysical modeling of boiling flows in the motive nozzle is carried out for a liquid–vapor jet apparatus (LVJA). Existing thermophysical models make it possible to calculate nozzles, which, in their shape, are close to Laval nozzles. They also allow for determining the position of the outlet cross-sectional area of the nozzle, where the flow separation from the channel walls occurs. However, these models do not allow for profiling the nozzle’s supersonic part, which does not make it possible to ensure the maximum efficiency of the vaporization process. Therefore, in the presented article, the available thermophysical model was improved significantly, which made it possible to obtain the profile of the supersonic part of the nozzle. As a result, a geometric shape that ensures the highest efficiency of the outflow process can be chosen for the primary flow at specified initial and final thermodynamic parameters. According to the calculation results and the proposed methodology, parameters were distributed along the nozzle for the primary flow. Also, efficiency indicators of the outflow of the boiling liquid underheated to saturation were achieved for the different geometric shapes. Mathematical modeling of the operating process in the motive nozzle using ANSYS CFX 2004 R1 (ANSYS, Inc., Canonsburg, PA, USA) was performed to prove the reliability of the results. Also, a comparative analysis of the obtained calculation and simulation results for nozzles with a profiled supersonic part and straight walls was carried out. To assess the expediency of profiling the supersonic part of the nozzle for the primary flow at the LVJA, a comparison of analytical modeling and numerical simulation results with the experimental studies was carried out for nozzles with straight walls. Finally, the velocity ratios of nozzles with profiled supersonic parts and straight walls were obtained. This allowed for rational choosing of the nozzle shape to ensure the highest vaporization efficiency. Full article
