Intermetallic compounds (IMCs) growth can simultaneously bring about low-resistance electrical pathways and drastically reduce joint lifetime. Recently, incorporated trace nanoparticles into the free-Pb solder were found to promote the performance of the solder joints. Sn3Ag0.9Zn (SAZ) nano-composite solders were developed by doping 0.5 wt.% Al₂O₃ nanoparticles into the SAZ solder. The IMCs formation and growth behavior at the interfacial reactions between the SAZ-0.5Al₂O₃ nano-composite solder and the Cu substrate during soldering at temperatures ranging from 250 to 325 °C for 30 min were investigated. The results showed that after the addition of Al₂O₃ nanoparticles into the SAZ solder, the elongated-type IMCs layer changed into a prism-type IMCs layer, and Ag₃Sn nanoparticles were absorbed on the grain surface of the interfacial Cu₆Sn₅ phase, effectively suppressing the growth of the IMCs layers. The activation energies (Q) for the IMCs layers (Cu₆Sn₅ + Cu₃Sn) were determined to be 36.4 and 39.1 kJ/mol for the SAZ/Cu and SAZ-Al₂O₃/Cu solders, respectively. Full article

This study investigates the mechanism and effects of incorporating different ZrO₂ nano-particles into SAC0307 solder alloys. ZrO₂ nano-powder and nano-fibers in 0.25–0.5 wt% were added to the SAC0307 alloy to prepare composite solder joints by surface mount technology. The solder joints were shear tested before and after a 4000 h long 85 °C/85% RH corrosive reliability test. The incorporation of ZrO₂ nano-particles enhanced the initial shear force of the solder joint, but they decreased the corrosion resistance in the case of 0.5 wt%. SEM, EDS, and FIB analysis revealed intensive growth of SnO₂ on the solder joint surfaces, leading to the formation of Sn whiskers. Density functional theory (DFT) simulations showed that, despite Sn being able to bond to the surface of ZrO₂, the binding energy was weak, and the whole system was therefore unstable. It was also found that ZrO₂ nano-particles refined the microstructure of the solder joints. Decreased β-Sn grain size and more dispersed intermetallic compounds were observed. The microstructural refinement caused mechanical improvement of the ZrO₂ composite solder joints by dispersion strengthening but could also decrease their corrosion resistance. While ZrO₂ nano-particles improved the solder joint mechanical properties, their use is recommended only in non-corrosive environments, such as microelectronics for space applications. Full article

This study investigated the influence of reinforcing 0.50 wt.% of titanium oxide (TiO₂) and aluminium oxide (Al₂O₃) nanoparticles on the wettability performance of a Sn-3.0Ag-0.5Cu (SAC305) solder alloy. The thermal properties of the SAC305 nanocomposite solder are comparable with thos of an SAC305 solder with a peak temperature window within a range of 240 to 250 °C. The wetting behaviour of the non-reinforced and reinforced SAC305 nanocomposite solder was determined and measured using the contact angle and spreading area and the relationships between them were studied. There is an increment in the spreading area (5.6 to 7.32 mm) by 30.71% and a reduction in the contact angle (26.3 to 18.6°) by 14.29% with an increasing reflow time up to 60 s when reinforcing SAC305 solder with 0.50 wt.% of TiO₂ and Al₂O₃ nanoparticles. The SAC305 nanocomposite solder has a better wetting performance compared with the SAC305 solder. As the reflow time increased, the spreading area increased and the contact angle decreased, which restricted intermetallic compound growth and thus improved wettability performance Full article

Pt-nanoparticle (NP)-alloyed Sn-58Bi solders were reacted with electroless nickel-immersion gold (ENIG) and electroless nickel-electroless palladium-immersion gold (ENEPIG) surface finishes. We investigated formation of intermetallic compounds (IMCs) and their diffusion barrier properties at reaction interfaces as functions of Pt NP content in the composite solders and duration of solid-state aging at 100 °C. At Sn-58Bi-xPt/ENIG interfaces, typical Ni₃Sn₄/Ni₃P(P-rich layer) microstructure was formed. With the large consumption of the Ni-P layer, the Ni-P and Cu layers were intermixed and Cu atoms spread over the composite solder after 500 h of aging. By contrast, a (Pd,Ni)Sn₄/thin Ni₃Sn₄ microstructure was observed at the Sn-58Bi-xPt/ENEPIG interfaces. The (Pd,Ni)Sn₄ IMC effectively suppressed the consumption of the Ni-P layer and Ni₃Sn₄ growth, functioning as a good diffusion barrier. Therefore, the Sn-58Bi-xPt/ENEPIG joint survived 500 h of aging without microstructural degradation. Based on the experimental results and analysis of this study, Sn-58Bi-0.05Pt/ENEPIG is suggested as the optimum combination for future low-temperature soldering systems. Full article

A 3–5 μm Cu@Sn core-shell powder was prepared by chemical plating. Based on the mixture of this Cu@Sn and Ag NPs (nanoparticles), a soldering material for third-generation semiconductors was prepared. The joints prepared with this soldering material had a shear strength of over 40 MPa at 25 °C. This joint did not fail after more than 600 thermal cycles from −40 °C to 140 °C. The special feature of this joint is that the energy potential difference between nanoparticles and micron particles generated in the surface force field during reflow promoted the surface pre-melting of the particles by releasing the excess energy. By this mechanism, it was possible to reduce the porosity of the sintered layer. At the same time, due to the high surface activity energy of nano-silver, the diffusion of the Sn atoms was promoted, further enhancing the bond strength. Full article

Nanowire interconnection is the basis for the construction and integration of micro-nano functional devices. But so far, it is still difficult to achieve a reliable interconnection of metal oxide nanowires. This letter proposes an approach for soldering ZnO nanowires through femtosecond laser irradiation of Ag nanoparticles solder. In this paper, the effect of femtosecond laser fluence and irradiation time on the morphology of Ag solders and the interconnection state of ZnO nanowires are studied, respectively. The I-V electrical characterization of nanowire interconnection before and after soldering is completed. The results demonstrate that ZnO nanowires achieve better interconnection. The UV light response of the ZnO-Ag-ZnO interconnection structure after soldering is investigated. The approach confirms the effectiveness of a femtosecond irradiated metal nanoparticles solder to achieve metal oxide interconnection, offering the prospect of more metal oxide nanowires interconnection and device development. Full article

The properties of Sn99Ag0.3Cu0.7 (SACX0307) solder alloy reinforced with ZnO nanoparticles were investigated. The primary ZnO particle sizes were 50, 100, and 200 nm. They were added to a solder paste at a ratio of 1.0 wt %. The wettability, the void formation, the mechanical strength, and the thermoelectric parameters of the composite solder alloys/joints were investigated. Furthermore, microstructural evaluations were performed using scanning electron and ion microscopy. ZnO nanoparticles decreased the composite solder alloys’ wettability, which yielded increased void formation. Nonetheless, the shear strength and the thermoelectric parameters of the composite solder alloy were the same as those of the SACX0307 reference. This could be explained by the refinement effects of ZnO ceramics both on the Sn grains and on the Ag₃Sn and Cu₆Sn₅ intermetallic grains. This could compensate for the adverse impact of lower wettability. After improving the wettability, using more active fluxes, ZnO composite solder alloys are promising for high-power applications. Full article

Metal nanoparticles (NPs) have attracted growing attention in recent years for electronic packaging applications. Ag NPs have emerged as a promising low-temperature bonding material owing to their unique characteristics. In this study, we mainly review our research progress on the interconnection of using polyol-based Ag NPs for electronic packaging. The synthesis, sintering-bonding process, bonding mechanism, and high-temperature joint properties of Ag NP pastes are investigated. The paste containing a high concentration of Ag NPs was prepared based on the polyol method and concentration. A nanoscale layer of organic components coated on the NPs prevents the coalescence of Ag NPs. The effects of organic components on the bondability of the Ag NP paste were studied. Compared to the aqueous-based Ag NP paste, the polyol-based Ag NP with the reduction of organic component can improve the bondability, and the coffee ring effect was successfully depressed due to the increased Marangoni flow. The sintering behaviors of Ag NPs during the bonding process were investigated using the classical sphere-to-sphere approach. The mechanical property of joints using this Ag paste was better than that using Pb₉₅Sn₅ solders after storage at high temperatures. The sintering–bonding technology using polyol-based Ag NPs was helpful to the low-temperature interconnection for electronic packaging applications. Full article

Sn-based lead-free solders such as Sn-Ag-Cu, Sn-Cu, and Sn-Bi have been used extensively for a long time in the electronic packaging field. Recently, low-temperature Sn-Bi solder alloys attract much attention from industries for flexible printed circuit board (FPCB) applications. Low melting temperatures of Sn-Bi solders avoid warpage wherein printed circuit board and electronic parts deform or deviate from the initial state due to their thermal mismatch during soldering. However, the addition of alloying elements and nanoparticles Sn-Bi solders improves the melting temperature, wettability, microstructure, and mechanical properties. Improving the brittleness of the eutectic Sn-58wt%Bi solder alloy by grain refinement of the Bi-phase becomes a hot topic. In this paper, literature studies about melting temperature, microstructure, inter-metallic thickness, and mechanical properties of Sn-Bi solder alloys upon alloying and nanoparticle addition are reviewed. Full article

The effects of Ag nanoparticle (Ag NP) addition on interfacial reaction and mechanical properties of Sn–58Bi solder joints using ultra-fast laser soldering were investigated. Laser-assisted low-temperature bonding was used to solder Sn–58Bi based pastes, with different Ag NP contents, onto organic surface preservative-finished Cu pads of printed circuit boards. The solder joints after laser bonding were examined to determine the effects of Ag NPs on interfacial reactions and intermetallic compounds (IMCs) and high-temperature storage tests performed to investigate its effects on the long-term reliabilities of solder joints. Their mechanical properties were also assessed using shear tests. Although the bonding time of the laser process was shorter than that of a conventional reflow process, Cu–Sn IMCs, such as Cu₆Sn₅ and Cu₃Sn, were well formed at the interface of the solder joint. The addition of Ag NPs also improved the mechanical properties of the solder joints by reducing brittle fracture and suppressing IMC growth. However, excessive addition of Ag NPs degraded the mechanical properties due to coarsened Ag₃Sn IMCs. Thus, this research predicts that the laser bonding process can be applied to low-temperature bonding to reduce thermal damage and improve the mechanical properties of Sn–58Bi solders, whose microstructure and related mechanical properties can be improved by adding optimal amounts of Ag NPs. Full article

This study investigates the shear strength and aging characteristics of Sn-3.0Ag-0.5Cu (SAC 305)/Cu joints by the addition of ZrO₂ nanoparticles (NPs) having two different particle size: 5–15 nm (ZrO₂A) and 70–90 nm (ZrO₂B). Nanocomposite pastes were fabricated by mechanically mixing ZrO₂ NPs and the solder paste. ZrO₂ NPs decreased the β-Sn grain size and Ag₃Sn intermetallic compound (IMC) in the matrix and reduced the Cu₆Sn₅ IMC thickness at the interface of lap shear SAC 305/Cu joints. The effect is pronounced for ZrO₂A NPs added solder joint. The solder joints were isothermally aged at 175 °C for 24, 48, 144 and 256 h. NPs decreased the diffusion coefficient from 1.74 × 10^–16 m/s to 3.83 × 10^–17 m/s and 4.99 × 10^–17 m/s for ZrO₂A and ZrO₂B NPs added SAC 305/Cu joints respectively. The shear strength of the solder joints decreased with the aging time due to an increase in the thickness of interfacial IMC and coarsening of Ag₃Sn in the solder. However, higher shear strength exhibited by SAC 305-ZrO₂A/Cu joints was attributed to the fine Ag₃Sn IMC’s dispersed in the solder matrix. Fracture analysis of SAC 305-ZrO₂A/Cu joints displayed mixed solder/IMC mode upon 256 h of aging. Full article

Different conductive bonding strategies for the hybrid integration of flexible, inkjet-printed electronics are investigated. The focus of the present work lies on providing a practical guide comprising standard techniques that are inexpensive, easily implementable and frequently used. A sample set consisting of identical conductive test structures on different paper and plastic substrates was prepared using silver (Ag) nanoparticle ink. The sintered specimens were electrically contacted using soldering, adhesive bonding and crimping. Electrical and mechanical characterization before and after exposing the samples to harsh environmental conditions was performed to evaluate the reliability of the bonding methods. Resistance measurements were done before and after connecting the specimens. Afterwards, 85 °C/85% damp-heat tests and tensile tests were applied. Adhesive bonding appears to be the most suitable and versatile method, as it shows adequate stability on all specimen substrates, especially after exposure to a 85 °C/85% damp-heat test. During exposure to mechanical tensile testing, adhesive bonding proved to be the most stable, and forces up to 12 N could be exerted until breakage of the connection. As a drawback, adhesive bonding showed the highest increase in electrical resistance among the different bonding strategies. Full article

The effect of the microstructure of solder joints on the thermal properties of power LEDs is investigated. Solder joints were prepared with different solder pastes, namely 99Sn0.3Ag0.7Cu (as reference solder) and reinforced 99Sn0.3Ag0.7Cu–TiO₂ (composite solder). TiO₂ ceramic was used at 1 wt.% and with two different primary particle sizes, which were 20 nm (nano) and 200 nm (submicron). The thermal resistance, the electric thermal resistance, and the luminous efficiency of the power LED assemblies were measured. Furthermore, the microstructure of the different solder joints was analyzed on the basis of cross-sections using scanning electron and optical microscopy. It was found that the addition of submicron TiO₂ decreased the thermal and electric thermal resistances of the light sources by 20% and 16%, respectively, and it slightly increased the luminous efficiency. Microstructural evaluations showed that the TiO₂ particles were incorporated at the Sn grain boundaries and at the interface of the intermetallic layer and the solder bulk. This caused considerable refinement of the Sn grain structure. The precipitated TiO₂ particles at the bottom of the solder joint changed the thermodynamics of Cu₆Sn₅ formation and enhanced the spalling of intermetallic grain to solder bulk, which resulted in a general decrease in the thickness of the intermetallic layer. These phenomena improved the heat paths in the composite solder joints, and resulted in better thermal and electrical properties of power LED assemblies. However, the TiO₂ nanoparticles could also cause considerable local IMC (Intermetallic Compounds) growth, which could inhibit thermal and electrical improvements. Full article

Electrically conductive adhesives (ECAs) are one of the low temperature bonding materials. It can be used to replace toxic Sn-Pb solder. The key issue for the application of ECAs is how to improve their electrical properties. In the present study, we develop an effective method to promote the electrical properties of ECAs by addition of polyaniline (PANI) nanoparticles. PANIs were synthesized via a facile one-step chemical oxidative polymerization method. After adding 0.5 wt% PANI nanoparticles, the conductivity of ECAs increased dramatically by an order of magnitude. The bulk resistivity of 8.8 × 10⁻⁵ Ω·cm is achieved for 65 wt% silver fillers with 0.5 wt% PANIs loaded ECAs. Besides, this improvement has no negative effect on the shear strength and the aging life of ECAs. Moreover, the use of PANIs not only lowers the percolation threshold of ECAs, but also reduces the cost and improves the bonding reliability. Finally, PANIs enhanced ECAs patterns were successfully printed by a stencil printing method, which proved their potential applications in replacing conventional solder pastes and printing functional circuits. Full article

With the development of microelectronic packaging and increasingly specific service environment of solder joints, much stricter requirements have been placed on the properties of lead-free solders. On account of small size effect and high surface energy, nanoparticles have been widely used to improve the microstructure and properties of lead-free solders. Therefore, the composite solders bearing nanoparticles have recently attracted wide attention. This article reviewed the recent research on SnAgCu, SnBi, and SnZn composite solder alloys and introduced the effect of nanoparticles on their microstructure, mechanical properties, wettability, and reliability. The mechanism of nanoparticles strengthening was analyzed and summarized. In addition, the shortcomings and future development trends of nanoparticle-reinforced lead-free solders were discussed, which is expected to provide some theoretical reference for the application of these composite solder in 3D IC package. Full article
