Search Results (138)

Search Parameters:
Keywords = ANSYS MAXWELL

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
26 pages, 4630 KB
Article
Range Extension for Underwater Communication via Magnetic Induction Using Parametric Analysis of MI Coils in IoUT Networks
by Osama Mahfooz, Miguel-Angel Luque-Nieto, Muhammad Imran Majid and Pablo Otero
Electronics 2025, 14(22), 4543; https://doi.org/10.3390/electronics14224543 - 20 Nov 2025
Viewed by 410
Abstract
This paper discusses the method for extending the range of Magnetic Induction (MI) and its application in underwater networks for the Internet of Underwater Things (IoUT). In underwater communication, this technology would provide a wider frequency band than acoustic systems, shorter propagation delay, [...] Read more.
This paper discusses the method for extending the range of Magnetic Induction (MI) and its application in underwater networks for the Internet of Underwater Things (IoUT). In underwater communication, this technology would provide a wider frequency band than acoustic systems, shorter propagation delay, and increased conductivity, with the added benefit of underwater wireless power transfer. As a use case, we consider a system that allows energy to be transferred from one circuit to another without cables, as in an aerial environment. In this work, transmit and receive coils for underwater environments are designed and analyzed using ANSYS Maxwell v16.0 software. The results show an improvement in terms of underwater magnetic field propagation. We have conducted underwater experiments by applying a frequency range up to 100 kHz and 12 Volts with varied current, achieving a distance up to 80% greater than in air, as determined by parametric analysis. With an improved bit error rate, a delay of less than 2 microseconds, a packet delivery ratio near 100%, and a packet loss ratio less than 10%, the results show an improvement in magnetic field propagation underwater. This demonstrates that it is possible to conduct future research into other underwater applications by implementing MI for underwater communication. Full article
Show Figures

Figure 1

18 pages, 6058 KB
Article
An Efficient Magnetic Coupler with Tight Coupling, Precise Alignment, and Low Leakage Shielding for UAV Wireless Charging
by Yanming Cheng, Shaojie Yu, Xiaodan Zhang, Ruiyang Zhang, Pengfei Liu and Shuairan Yu
Electronics 2025, 14(22), 4358; https://doi.org/10.3390/electronics14224358 - 7 Nov 2025
Viewed by 346
Abstract
In this paper, an efficient magnetic coupler featuring tight coupling and precise alignment is proposed for unmanned aerial vehicle (UAV) wireless charging systems. The design integrates ArUco markers for accurate landing guidance, a position-limiting guide groove to facilitate mechanical alignment, and a dual-coil [...] Read more.
In this paper, an efficient magnetic coupler featuring tight coupling and precise alignment is proposed for unmanned aerial vehicle (UAV) wireless charging systems. The design integrates ArUco markers for accurate landing guidance, a position-limiting guide groove to facilitate mechanical alignment, and a dual-coil tightly coupled configuration to significantly enhance charging efficiency. Specifically, the dual-coil structure is carefully optimized to maximize magnetic coupling and energy transfer performance. Additionally, an improved electromagnetic shielding structure is implemented to reduce electromagnetic leakage and further improve system efficiency. A suitable wireless charging circuit topology is then designed and thoroughly analyzed to match the proposed magnetic coupler, enabling constant-voltage charging operation. The performance of the system is validated through both finite element simulations using ANSYS Maxwell and experimental testing on a prototype setup. Results demonstrate that the integration of ArUco-based visual guidance with the mechanical alignment mechanism achieves a landing deviation of ±12.5 mm without requiring auxiliary positioning components, thereby simplifying system architecture. Under the tightly coupled configuration, the proposed system delivers 78.8 W of charging power to a UAV with a peak efficiency of 95.93%, confirming its effectiveness and high performance. Full article
(This article belongs to the Special Issue Wireless Power Transfer Systems: Design and Implementation)
Show Figures

Figure 1

17 pages, 3323 KB
Article
Enhancing Torque Output for a Magnetic Actuation System for Robotic Spinal Distraction
by Yumei Li, Zikang Li, Ding Lu, Tairan Peng, Yunzhi Chen, Gang Fu, Zhenguo Nie and Fangyuan Wei
Sensors 2025, 25(20), 6497; https://doi.org/10.3390/s25206497 - 21 Oct 2025
Viewed by 671
Abstract
Magnetically controlled spinal growing rods, used for treating early-onset scoliosis (EOS), face a critical clinical limitation: insufficient distraction force. Compounding this issue is the inherent inability to directly monitor the mechanical output of such implants in vivo, which challenges their safety and efficacy. [...] Read more.
Magnetically controlled spinal growing rods, used for treating early-onset scoliosis (EOS), face a critical clinical limitation: insufficient distraction force. Compounding this issue is the inherent inability to directly monitor the mechanical output of such implants in vivo, which challenges their safety and efficacy. To overcome these limitations, optimizing the rotor’s maximum torque is essential. Furthermore, defining the “continuous rotation domain” establishes a vital safety boundary for stable operation, preventing loss of synchronization and loss of control, thus safeguarding the efficacy of future clinical control strategies. In this study, a transient finite element magnetic field simulation model of a circumferentially distributed permanent magnet–rotor system was established using ANSYS Maxwell (2024). The effects of the clamp angle between the driving magnets and the rotor, the number of pole pairs, the rotor’s outer diameter, and the rotational speed of the driving magnets on the rotor’s maximum torque were systematically analyzed, and the optimized continuous rotation domain of the rotor was determined. The results indicated that when the clamp angle was set at 120°, the number of pole pairs was one, the rotor outer diameter was 8 mm, the rotor achieved its maximum torque and exhibited the largest continuous rotation domain, while the rotational speed of the driving magnets had no effect on maximum torque. Following optimization, the maximum torque of the simulation increased by 201% compared with the pre-optimization condition, and the continuous rotation domain was significantly enlarged. To validate the simulation, a rotor torque measurement setup incorporating a torque sensor was constructed. Experimental results showed that the maximum torque improved from 30 N·mm before optimization to 90 N·mm after optimization, while the driving magnets maintained stable rotation throughout the process. Furthermore, a spinal growing rod test platform equipped with a pressure sensor was developed to evaluate actuator performance and measure the maximum distraction force. The optimized growing rod achieved a peak distraction force of 413 N, nearly double that of the commercial MAGEC system, which reached only 208 N. The simulation and experimental methodologies established in this study not only optimizes the device’s performance but also provides a viable pathway for in vivo performance prediction and monitoring, addressing a critical need in smart implantable technology. Full article
(This article belongs to the Special Issue Recent Advances in Medical Robots: Design and Applications)
Show Figures

Figure 1

14 pages, 4328 KB
Article
Analysis and Design of a Brushless WRSM with Harmonic Excitation Based on Electromagnetic Induction Power Transfer Optimization
by Arsalan Arif, Farhan Arif, Zuhair Abbas, Ghulam Jawad Sirewal, Muhammad Saleem, Qasim Ali and Mukhtar Ullah
Magnetism 2025, 5(4), 26; https://doi.org/10.3390/magnetism5040026 - 18 Oct 2025
Viewed by 594
Abstract
This paper proposes a method to analyze the effect of the rotor’s harmonic winding design and the output of a brushless wound rotor synchronous machine (WRSM) for optimal excitation power transfer. In particular, the machine analyzed by the finite-element method was a 48-slot [...] Read more.
This paper proposes a method to analyze the effect of the rotor’s harmonic winding design and the output of a brushless wound rotor synchronous machine (WRSM) for optimal excitation power transfer. In particular, the machine analyzed by the finite-element method was a 48-slot eight-pole 2D model. The subharmonic magnetomotive force was additionally created in the air gap flux, which induces voltage in the harmonic winding of the rotor. This voltage is rectified and fed to the field winding through a full bridge rectifier. Eventually, a direct current (DC) flows to the field winding, removing the need for external excitation through brushes and sliprings. The effect of the number of harmonic winding turns is analyzed and the field winding turns were varied with respect to the available rotor slot space. Optimization of the harmonic excitation part of the machine will maximize the rotor excitation for regulation purposes and optimize the torque production at the same time. Two-dimensional finite-element analysis has been performed in ANSYS Maxwell 19 to obtain the basic results for the design of the machine. Full article
Show Figures

Figure 1

31 pages, 16219 KB
Article
Design, Simulation, Construction and Experimental Validation of a Dual-Frequency Wireless Power Transfer System Based on Resonant Magnetic Coupling
by Marian-Razvan Gliga, Calin Munteanu, Adina Giurgiuman, Claudia Constantinescu, Sergiu Andreica and Claudia Pacurar
Technologies 2025, 13(10), 442; https://doi.org/10.3390/technologies13100442 - 1 Oct 2025
Viewed by 632
Abstract
Wireless power transfer (WPT) has emerged as a compelling solution for delivering electrical energy without physical connectors, particularly in applications requiring reliability, mobility, or encapsulation. This work presents the modeling, simulation, construction, and experimental validation of an optimized dual-frequency WPT system using magnetically [...] Read more.
Wireless power transfer (WPT) has emerged as a compelling solution for delivering electrical energy without physical connectors, particularly in applications requiring reliability, mobility, or encapsulation. This work presents the modeling, simulation, construction, and experimental validation of an optimized dual-frequency WPT system using magnetically coupled resonant coils. Unlike conventional single-frequency systems, the proposed architecture introduces two independently controlled excitation frequencies applied to distinct transistors, enabling improved resonance behavior and enhanced power delivery across a range of coupling conditions. The design process integrates numerical circuit simulations in PSpice and three-dimensional electromagnetic analysis in ANSYS Maxwell 3D, allowing accurate evaluation of coupling coefficient variation, mutual inductance, and magnetic flux distribution as functions of coil geometry and alignment. A sixth-degree polynomial model was derived to characterize the coupling coefficient as a function of coil separation, supporting predictive tuning. Experimental measurements were carried out using a physical prototype driven by both sinusoidal and rectangular control signals under varying load conditions. Results confirm the simulation findings, showing that specific signal periods (e.g., 8 µs, 18 µs, 20 µs, 22 µs) yield optimal induced voltage values, with strong sensitivity to the coupling coefficient. Moreover, the presence of a real load influenced system performance, underscoring the need for adaptive control strategies. The proposed approach demonstrates that dual-frequency excitation can significantly enhance system robustness and efficiency, paving the way for future implementations of self-adaptive WPT systems in embedded, mobile, or biomedical environments. Full article
Show Figures

Figure 1

20 pages, 5577 KB
Article
Electromagnetic Vibration Analysis and Mitigation of FSCW PM Machines with Auxiliary Teeth
by Huang Zhang, Wei Wang, Xinmin Li and Zhiqiang Wang
Machines 2025, 13(9), 867; https://doi.org/10.3390/machines13090867 - 18 Sep 2025
Viewed by 484
Abstract
Auxiliary teeth are usually used in fractional-slot concentrated winding (FSCW) machines for fault tolerance. However, the influence of auxiliary teeth on torque and electromagnetic vibration performance differs with different slot–pole configurations. Thus, this paper investigates electromagnetic vibration and mitigation methods in FSCW permanent [...] Read more.
Auxiliary teeth are usually used in fractional-slot concentrated winding (FSCW) machines for fault tolerance. However, the influence of auxiliary teeth on torque and electromagnetic vibration performance differs with different slot–pole configurations. Thus, this paper investigates electromagnetic vibration and mitigation methods in FSCW permanent magnet (PM) machines with auxiliary teeth. The relationship between yoke forces and tooth parameters of two dual three-phase (DTP) FSCW-PM machines with 12-slot/14-pole configuration and 12-slot/10-pole configuration is studied and compared. Results reveal that (1) the 2p-order airgap electromagnetic force reduces second-order yoke force in the 12-slot/14-pole machine but increases it in the 12-slot/10-pole machine. (2) Through optimized tooth width, slot harmonics can be mitigated, but the fundamental winding magnetic field in the 12-slot/10-pole machine is also weakened, whereas the 12-slot/14-pole machine achieves fundamental field preservation or enhancement. Based on these findings, auxiliary tooth optimization and rotor pole profile shaping are proposed for vibration reduction in 12-slot/14-pole machine. Electromagnetic–mechanical coupled simulations conducted in ANSYS Maxwell/Workbench 2023 demonstrate that the optimized design reduces the cogging torque peak from 11.4 mN·m to 2.9 mN·m (74.6% reduction), suppresses housing surface vibration acceleration by 21%, and maintains the average output torque without reduction. Full article
(This article belongs to the Special Issue Advances in Analysis, Control and Design of Permanent Magnet Machines)
Show Figures

Figure 1

22 pages, 8473 KB
Article
Designing a Power Supply System for an Amphibious Robot Based on Wave Energy Generation
by Lishan Ma, Fang Huang, Lingxiao Li, Qiang Fu, Chunjie Wang and Xinpeng Wang
J. Mar. Sci. Eng. 2025, 13(8), 1466; https://doi.org/10.3390/jmse13081466 - 30 Jul 2025
Viewed by 670
Abstract
As the range of applications for amphibious robots expands, higher demands are being placed on their working time and working range. This paper proposed a power supply system for an amphibious robot based on wave energy generation, which can convert wave energy into [...] Read more.
As the range of applications for amphibious robots expands, higher demands are being placed on their working time and working range. This paper proposed a power supply system for an amphibious robot based on wave energy generation, which can convert wave energy into electric energy to enhance endurance. First, the no-load induced electromotive force, magnetic line distribution vector diagrams, and magnetic density cloud diagrams of the cylindrical and flat generators were compared by finite element simulation, which determined that the cylindrical structure has better power generation performance. Then, the electromagnetic parameters of the cylindrical generator were analyzed using Ansys Maxwell, and the final dimensions were determined. Finally, the wave motion was simulated using a swing motor, and the effects of different cutting speeds for the actuator before and after rectification, as well as series-parallel capacitance on the power generation performance of the designed generator, were experimentally analyzed. This provides a potential solution to enhance the working time and working range of amphibious robots. Full article
(This article belongs to the Section Ocean Engineering)
Show Figures

Figure 1

25 pages, 7503 KB
Article
Shaft Generator Design Analysis for Military Ships in Maritime Applications
by Kamer Gökbulut Belli and Tuğçe Demirdelen
Energies 2025, 18(14), 3792; https://doi.org/10.3390/en18143792 - 17 Jul 2025
Cited by 1 | Viewed by 1206
Abstract
Naval ships are of paramount importance to national security, culture, and naval operations. A primary challenge for naval authorities is to balance the imperatives of maritime dominance with the operational demands of achieving sufficient, sustainable reliability. Shaft generators (SGs) are crucial to the [...] Read more.
Naval ships are of paramount importance to national security, culture, and naval operations. A primary challenge for naval authorities is to balance the imperatives of maritime dominance with the operational demands of achieving sufficient, sustainable reliability. Shaft generators (SGs) are crucial to the energy conversion systems on naval ships, functioning as part of the main power systems on board and providing both propulsion and power for various operational loads. In this sense, the design of shaft generators is an engineering element that has a major impact on the overall ship performance. The design process will be conducted within the MATLAB/Simulink environment, a platform that facilitates the study of the dynamic behaviors of the system through simulation. The increasing demand for efficiency, reliability, and sustainability in the military, along with the impact of emerging technologies, will further underscore the significance of shaft generators. Analyses carried out in MATLAB/Simulink demonstrate that the selection of the most suitable power system for naval ships is dictated by the system requirements and operational demands. The main construction is such that this work is the first of its kind in the field of shaft generator research for naval ships. Full article
(This article belongs to the Topic Marine Energy)
Show Figures

Figure 1

13 pages, 31731 KB
Article
Optimized Coupling Coil Geometry for High Wireless Power Transfer Efficiency in Mobile Devices
by Fahad M. Alotaibi
J. Low Power Electron. Appl. 2025, 15(2), 36; https://doi.org/10.3390/jlpea15020036 - 17 Jun 2025
Cited by 1 | Viewed by 1334
Abstract
Wireless Power Transfer (WPT) enables efficient, contactless charging for mobile devices by eliminating mechanical connectors and wiring, thereby enhancing user experience and device longevity. However, conventional WPT systems remain prone to performance issues such as coil misalignment, resonance instability, and thermal losses. Addressing [...] Read more.
Wireless Power Transfer (WPT) enables efficient, contactless charging for mobile devices by eliminating mechanical connectors and wiring, thereby enhancing user experience and device longevity. However, conventional WPT systems remain prone to performance issues such as coil misalignment, resonance instability, and thermal losses. Addressing these challenges involves designing coil geometries that operate at lower resonant frequencies to strengthen magnetic coupling and decrease resistance. This work introduces a WPT system with a performance-driven coil design aimed at maximizing magnetic coupling and mutual inductance between the transmitting (Tx) and receiving (Rx) coils in mobile devices. Due to the nonlinear behavior of magnetic flux and the high computational cost of simulations, exploring the full design space for coils using ANSYS Maxwell becomes impractical. To address this complexity, a machine learning (ML)-based optimization framework is developed to efficiently navigate the design space. The framework integrates a hybrid sequential neural network and multivariate regression model to optimize coil winding and ferrite core geometry. The optimized structure achieves a mutual inductance of 12.52 μH with a conventional core, outperforming many existing ML models. Finite element simulations and experimental results validate the robustness of the method, which offers a scalable solution for efficient wireless charging in compact, misalignment-prone environments. Full article
Show Figures

Figure 1

19 pages, 15213 KB
Article
Derivation and Experimental Validation of Multi-Parameter Performance Optimization of Magnetic Adhesion Unit of Wall-Climbing Robot
by Helei Zhu, Haifeng Ji, Peixing Li and Leijie Lai
Actuators 2025, 14(6), 270; https://doi.org/10.3390/act14060270 - 29 May 2025
Cited by 3 | Viewed by 1648
Abstract
Wall-climbing robots have broad application potential in industrial equipment inspection, chemical storage tank maintenance, and high-altitude operations. However, their practical implementation is challenged by the robots’ adhesion requirements in complex wall environments. This study uses a systematic methodology integrating computational simulation and experimental [...] Read more.
Wall-climbing robots have broad application potential in industrial equipment inspection, chemical storage tank maintenance, and high-altitude operations. However, their practical implementation is challenged by the robots’ adhesion requirements in complex wall environments. This study uses a systematic methodology integrating computational simulation and experimental validation to design and optimize a magnetic adsorption system for wall-climbing robots. Firstly, an adjustable suspended magnetic adhesion unit is designed to achieve intelligent control of a wall-climbing robot’s adhesion force on a wall surface. The Maxwell software (AnsysEM21.1) is used to simulate and analyze the critical parameters of the magnetic adsorption unit, including the thickness of the magnet and yoke, as well as the distance and angle between the magnet and the wall surface. Then, a magnetic wheel is designed for the wall-climbing robot based on the optimization of the structure and parameters of the magnetic adhesion unit. The absorption and demagnetization of the magnetic wheels are achieved by rotating the magnetic absorption unit. Subsequently, the simulation results are verified on the experimental platform, and adhesion performance tests are conducted on both standard flat surfaces and inclined walls. The results show that the optimized single magnetic adhesion unit gives the wall-climbing robot an adhesion force of 2767 N under normal working conditions, with a simulation experiment error margin as low as 8.3%. These results both provide theoretical guidance and highlight practical methodologies for developing high-performance magnetic adsorption systems in complex operational environments. Full article
(This article belongs to the Section Actuators for Robotics)
Show Figures

Figure 1

16 pages, 5275 KB
Article
Nanoscale Polishing of TC4 Titanium Alloy Surface Based on Dual-Pole Magnetic Abrasive Finishing Method
by Zhenfeng Zhou, Xu Sun, Shibing Liang, Ying Fang, Yanzhen Yang, Yongjian Fu and Shiqing Zou
Micromachines 2025, 16(6), 620; https://doi.org/10.3390/mi16060620 - 25 May 2025
Viewed by 645
Abstract
The dual-pole magnetic abrasive finishing (DMAF) method was proposed to achieve a smooth surface on TC4 titanium alloy. Firstly, both the distribution of the magnetic field and the intensity of magnetic induction produced by nine combinations of magnetic poles of different shapes were [...] Read more.
The dual-pole magnetic abrasive finishing (DMAF) method was proposed to achieve a smooth surface on TC4 titanium alloy. Firstly, both the distribution of the magnetic field and the intensity of magnetic induction produced by nine combinations of magnetic poles of different shapes were simulated using Ansys Maxwell software (2024R2). According to the results of the simulation, the optimal combination of magnetic poles was determined. Then, the machining parameters of multi-stage DMAF were optimized through comparative experiments on major single factors. Finally, combinations of the mixed magnetic abrasive in three polishing stages were obtained as follows: #100 electrolytic iron powder (Fe3O4) + #2000 white abrasive (WA), #200 Fe3O4 + #8000 WA, and #450Fe3O4 + #w1 diamond (DMD). The gap between the upper and lower magnetic poles was set to 5 mm, the rotational speed of the magnetic pole was set to 300 rpm, and the quality ratio of the abrasive was 2:1. The experiments indicated that the average surface roughness Ra was reduced from an initial value of 0.433 μm to 8 nm after 30 min of multi-stage DMAF, and a nano-level mirror polishing effect was essentially achieved in the polishing zone. Full article
(This article belongs to the Section E:Engineering and Technology)
Show Figures

Figure 1

20 pages, 16930 KB
Article
Design of Magnetic Concrete for Inductive Power Transfer System in Rail Applications
by Karl Lin, Shen-En Chen, Tiefu Zhao, Nicole L. Braxtan, Xiuhu Sun and Lynn Harris
Appl. Sci. 2025, 15(9), 4987; https://doi.org/10.3390/app15094987 - 30 Apr 2025
Cited by 2 | Viewed by 1377
Abstract
Inductive power transfer (IPT) systems are transforming railway infrastructure by enabling efficient, wireless energy transmission for electric locomotives equipped with Li-ion batteries. This technology eliminates the need for overhead power lines and third rails, offering financial and operational advantages over conventional electric propulsion [...] Read more.
Inductive power transfer (IPT) systems are transforming railway infrastructure by enabling efficient, wireless energy transmission for electric locomotives equipped with Li-ion batteries. This technology eliminates the need for overhead power lines and third rails, offering financial and operational advantages over conventional electric propulsion systems. Despite its potential, IPT deployment in rail applications faces significant challenges, including the fragility of materials (i.e., ferrite and Litz wires), thermal management during high-power transfers, and electromagnetic interference (EMI) on the transmitter side. This study discusses several factors affecting IPT efficiency and introduces magnetic concrete as a durable and cost-effective material solution for IPT systems. Magnetic concrete combines soft ferrite powder with water and coarse aggregates to enhance magnetic functionality while maintaining structural strength comparable to conventional concrete. Its durability and optimized magnetic properties promote consistent power transfer efficiency, making it a viable alternative to traditional ferrite cores. A comparative study has been performed on non-magnetic and magnetic concrete (with 33% ferrite powder) using both permeability tests and finite element analysis (FEA). The FEA includes both thermal and electromagnetic simulations using Ansys Maxwell (v.16), revealing that magnetic concrete can improve temperature management and EMI mitigation, and the findings underscore its potential to revolutionize IPT technology by overcoming the limitations of traditional materials and enhancing durability, cost-efficiency, and power transfer efficiency. By addressing the challenges of fragility, thermal management, and shielding of the unique coil topology design presented, this study lays the groundwork for improving IPT infrastructure in sustainable and efficient rail transport systems. Full article
(This article belongs to the Section Electrical, Electronics and Communications Engineering)
Show Figures

Figure 1

20 pages, 6392 KB
Article
A Rotational Speed Sensor Based on Flux-Switching Principle
by Duy-Tinh Hoang, Joon-Ku Lee, Kwang-Il Jeong, Kyung-Hun Shin and Jang-Young Choi
Mathematics 2025, 13(8), 1341; https://doi.org/10.3390/math13081341 - 19 Apr 2025
Viewed by 878
Abstract
This study proposes a rotational speed measurement machine based on the flux-switching principle with a 6-stator-slot/19-rotor-pole (6s/19p) topology. With a rotor shape similar to a variable reluctance sensor (VRS), the proposed machine features a simple and robust structure while ensuring the same output [...] Read more.
This study proposes a rotational speed measurement machine based on the flux-switching principle with a 6-stator-slot/19-rotor-pole (6s/19p) topology. With a rotor shape similar to a variable reluctance sensor (VRS), the proposed machine features a simple and robust structure while ensuring the same output frequency as VRS. Additionally, compared to the conventional 12s/10p topology, the 6s/19p configuration reduces permanent magnet (PM) consumption by half while maintaining high induced voltage characteristics. A nonlinear analytical model (NAM), which incorporates the harmonic modeling (HM) technique and an iterative process, is presented. This model more accurately captures the rectangular shape of the PM and stator teeth while accounting for core saturation effects. Based on this model, the optimal dimensions of the proposed machine are investigated to achieve the best performance for speed measurement applications. A coupling FEA simulation between Ansys Maxwell and Twin Builder further analyzes the machine’s performance. Compared to a commercial product of the same size, the proposed machine achieves 31.5% higher output voltage while ensuring lower linearity errors. Moreover, superior load characteristics are observed, with a voltage drop of only 1.58% at 1500 rpm and 30 mA. The proposed machine and NAM provide an improved solution and analytical tool for speed measurement applications. Full article
Show Figures

Figure 1

18 pages, 6112 KB
Article
Improved Design of an Eddy-Current Speed Sensor Based on Harmonic Modeling Technique
by Duy-Tinh Hoang, Manh-Dung Nguyen, Yong-Joo Kim, Anh-Tuan Phung, Kyung-Hun Shin and Jang-Young Choi
Mathematics 2025, 13(5), 844; https://doi.org/10.3390/math13050844 - 3 Mar 2025
Cited by 3 | Viewed by 1454
Abstract
This study proposes an improved design of an eddy-current speed sensor (ECSS) by adding a ferromagnetic core to the stator, resulting in a sensitivity enhancement ranging from three to sixty times compared to a reference model according to shaft materials. An improved analytical [...] Read more.
This study proposes an improved design of an eddy-current speed sensor (ECSS) by adding a ferromagnetic core to the stator, resulting in a sensitivity enhancement ranging from three to sixty times compared to a reference model according to shaft materials. An improved analytical model (AM) based on harmonic modeling (HM) is developed to account for the effects of core permeability, validated through finite element analysis (FEA), demonstrating excellent agreement between the two methods. Based on this model, the optimal dimensions of the proposed design are obtained, and comprehensive analyses of shaft materials and excitation source parameters are performed. The results show that the magnetic shaft offers the highest sensitivity, while a nonmagnetic shaft with low conductivity ensures optimal linearity. Meanwhile, a nonmagnetic shaft with high conductivity leads to low sensitivity and higher linearity errors. Furthermore, a high-frequency excitation source enhances output linearity but necessitates careful selection based on the shaft materials. The dynamic characteristics of the proposed design under different operating conditions are analyzed using a coupled Ansys Twin Builder and Maxwell 2D model. The proposed design and AM significantly improve ECSS performance and the analyzing tool, providing a robust and practical solution for precise speed measurement in various applications. Full article
Show Figures

Figure 1

16 pages, 8423 KB
Article
Development of Spherical Actuator with L-Shaped Yoke
by Yu-Wen Huang, Hao-Wen Chung, Yu-Ming Chen, Chien-Sheng Liu and Ming-Fu Chen
Actuators 2025, 14(1), 30; https://doi.org/10.3390/act14010030 - 15 Jan 2025
Viewed by 1867
Abstract
In this paper, a two-DOF L-shaped yoke spherical actuator based on the principle of traditional voice coil actuators is developed. By utilizing the shape characteristics of the yoke and the magnetization direction of the magnet, the magnetic flux is concentrated and the magnet [...] Read more.
In this paper, a two-DOF L-shaped yoke spherical actuator based on the principle of traditional voice coil actuators is developed. By utilizing the shape characteristics of the yoke and the magnetization direction of the magnet, the magnetic flux is concentrated and the magnet is shared, thereby improving the performance of the actuator. In the design process, SOLIDWORKS 2018 software is used for design modeling and assembly simulation, ANSYS Maxwell 2018 software is employed for magnetic circuit analysis and electromagnetic simulation, while MATLAB is utilized for analyzing the dynamic characteristics through a mathematical model. A prototype was also fabricated, and torque measurement experiments were conducted to verify the performance and feasibility of the proposed design. Full article
Show Figures

Figure 1
