Search Results (2,863)

This study investigates the transient wheel–rail contact mechanics of welded joints in heavy-haul rails via a validated 3D finite element model, and analyzes the stick-slip behavior, dynamic response and elastoplastic characteristics in the base material zone, heat-affected zone and weld bead zone. Results show a distinct contact state transition from stick-slip in the base material to predominant slip within the welded zones, indicating higher wear susceptibility. Dynamic response analysis reveals the highest and lowest contact-point acceleration amplitudes in the base material and heat-affected zone, respectively, due to material heterogeneity. Plastic deformation consistently initiates at the rail surface, where stress and strain concentrate, establishing it as the primary site for damage nucleation. A systematic parametric study shows that plastic deformation can be effectively mitigated by increasing the yield strength and elastic modulus of the welded joint material, or reducing the wheelset velocity, unsprung mass and wheel–rail friction coefficient. In contrast, adjusting the primary suspension and fastener parameters exerts a negligible influence on plastic deformation control. These findings provide a mechanistic basis for optimizing the performance and maintenance of welded joints in heavy-haul rail operations. This study reveals the coupling law of multiple mechanisms among contact behavior, dynamic response and material failure during the damage initiation process of rail welded joints from the mechanistic perspective, which provides a theoretical basis for the structural optimization, condition assessment and maintenance of rail welded joints in heavy-haul railways. Full article

More and more urban underpass tunnels are being constructed to alleviate traffic congestion; however, for this type of underground structure, the soil–structure interaction mechanisms under earthquake loading remain unclear, and dedicated advice and guidance for their seismic design are still lacking. This paper endeavors to investigate the dynamic interaction mechanisms of an underpass tunnel and surrounding soft ground using the finite element (FE) method. Firstly, the accuracy of the FE model in reproducing seismic responses of the layered half-space is validated by comparison with results of equivalent linear one-dimensional site response. Then, the dynamic response characteristics of 3D boat-shaped excavation are analyzed to determine the influence of potential local site amplification on the underpass tunnel. Finally, seismic behaviors of open and buried sections of the underpass tunnel are investigated in detail. The results show that under high-intensity rare earthquakes, severe damage occurs at the ceiling slab near the longitudinal beam and at the base of the side wall of the tunnel’s buried section; seismic underpass–site interactions might be influenced the most by the local topography effect of the 3D boat-shaped excavation, as well as a sudden stiffness change between the open and buried sections. Full article

High-performance piezoelectric micromachined ultrasonic transducers (PMUTs) are crucial for portable medical imaging and sensing. The efficiency of advanced PMUTs relies on high-quality piezoelectric thin films and optimized device designs. However, variability in common piezoelectric thin films like Sc_xAl_1−xN (ScAlN) and PbZr_1−xTi_xO₃ (PZT) often leads to inaccurate material parameters—especially those derived from thick ceramics. To enhance simulation accuracy in standard designs affected by these inconsistencies, this work introduces an optimization framework combining first-principles calculations with multiphysics simulations. First, the intrinsic properties of PZT and ScAlN are analyzed through atomistic calculations, confirming that PZT, with its higher electromechanical coupling coefficient, is better suited for actuation. The parameters obtained from these calculations calibrate the finite-element model, addressing issues of missing or inaccurate data in commercial software libraries. Next, an efficient analytical acoustic-field model is developed. Compared to full-wave simulations in COMSOL, this model significantly reduces computational cost while maintaining accuracy, allowing for quicker scanning and optimization of large-array topologies. Additionally, results demonstrate that each individual hexagonal PMUT element outperforms a comparable circular element, achieving a peak SPL of 90.4 dB at 4.9 MHz versus 89.7 dB at 2.8 MHz. This higher acoustic output and operating frequency enable improved spatial resolution and sensitivity. This modeling approach, based on intrinsic material properties, provides a solid theoretical foundation for designing high-precision, low-power ultrasonic devices. Full article

This study investigates the sound insulation performance of an anechoic chamber, exploring the influence patterns of different multilayer material combinations on wall sound insulation characteristics. Based on sound transmission theory, a predictive model for multilayer material wall sound insulation was established. The finite element method was employed to simulate the sound propagation characteristics of walls and glass doors with various material combinations. After validating the simulation results through a double-room method experiment, the material combination scheme for the anechoic chamber walls and glass doors was optimized. Based on this, a 1000 mm × 1000 mm × 2300 mm soundproof room prototype was designed and constructed. Its sound insulation performance under reverberant conditions was tested using the insertion loss method and compared with simulation data. Simultaneously, a hybrid calculation method combining low-frequency finite element analysis with high-frequency statistical energy analysis enabled precise and efficient prediction of the overall sound insulation performance of the soundproof room. Research revealed that single-pane glass with thicknesses between 5 and 20 mm conformed to the mass law, with sound insulation increasing by an average of 0.8 dB per additional millimeter. The 10 mm single-pane glass emerged as the optimal choice for the soundproof room’s glass door due to its ideal thickness and excellent low-to-mid-frequency sound insulation. The optimized wall structure featured compact thickness, outstanding low-frequency sound insulation, and balanced mid-to-high-frequency performance. Simulation and experimental results for the core frequency range of 63–1000 Hz showed high consistency, which validates the reliability of the theoretical model and simulation methodology within this frequency band. The deviation of simulation results from experimental data in the frequency range above 1000 Hz is mainly caused by acoustic leakage due to experimental sealing defects, and the high-frequency simulation results are only used for trend analysis rather than conclusion support. This study identifies the optimal multi-layer material combination for soundproof rooms, providing practical material strategies for acoustic design. It also reveals the sound insulation mechanisms of multi-layer composite structures. The findings offer significant reference for optimizing soundproofing materials and structures in architectural acoustics and transportation noise control. Full article

This paper proposes a multi-objective optimization method based on response surface methodology and genetic algorithm to address the electromagnetic noise issue in external rotor permanent magnet synchronous motors. Theoretical analysis and 2D finite element simulation of electromagnetic force were conducted to identify the main orders of electromagnetic force; subsequently, through motor load and no-load tests, it was determined that the 6th-order radial electromagnetic force is the primary source of electromagnetic noise. Taking the 6th-order radial electromagnetic force, average torque, and torque ripple as optimization objectives, three key structural parameters were selected from eight optimization variables to construct a response surface model. The structural parameter optimization scheme for the motor was then obtained using a genetic algorithm. Finally, the optimization scheme obtained by the response surface method was validated under motor load conditions using two-dimensional finite element simulation; simulation results indicate that, compared to the original design, the optimized motor, exhibits a reduction in torque ripple by 65%, with the harmonic content of the radial air-gap flux density at the 1st, 3rd, 5th, and 7th orders decreasing by 8.7%, 6.4%, 12.5%, and 10.7%, respectively, and the 6th-order radial electromagnetic force reduced by 16.4%. Based on experimental identification of the dominant noise source, this reduction is expected to effectively suppress electromagnetic noise, which will be validated on a prototype in future work. Full article

Achieving high density in complex powder metallurgy components like spur gears is often hindered by friction-induced density gradients and ejection defects. This study investigates a novel elastic die system designed to mitigate these issues through controlled radial deformation. Spur gears were compacted using Ancorsteel 2000 powder under pressures of 400–700 MPa, utilizing a tapered elastic sleeve to apply radial compression. Green and sintered densities were measured, while porosity distribution was quantified via image analysis. Additionally, a 3D finite element simulation using FORGE software was conducted to model the thermo-mechanical behavior and stress distribution during the process. Experimental trials demonstrated that the elastic relaxation of the sleeve enabled free ejection of the compacts without requiring an extraction force. Image analysis confirmed a homogenous porosity distribution across the gear teeth, and higher die pre-stressing strokes were found to correlate with increased sintered density. Finite element modeling accurately predicted critical stress concentrations of 700 MPa at the die–sleeve interface and validated the strain distribution. The results confirm that elastic die technology effectively eliminates ejection friction and improves density uniformity in complex gears, offering a viable solution for reducing tool wear and manufacturing defects in high-precision powder metallurgy. Full article

This paper investigates the electromagnetic performance of an outer-rotor spoke-type permanent magnet synchronous generator intended for small wind turbine applications below 5 kW. The study focuses on the influence of structural ferromagnetic components on magnetic flux distribution and overall machine performance. The generator was initially designed and optimized using 2D finite element analysis, followed by a comprehensive 3D model to account for axial flux leakage and structural details; particular attention was given to the fastening screws used. Experimental validation on a dedicated laboratory test bench confirms the accuracy of the 3D model, mainly at lower wind speeds. The results highlight the necessity of including structural components in three-dimensional electromagnetic modeling for accurate performance prediction of flux-concentrating wind turbine generators. Full article

Low-density cancellous bone results in reduced trabecular support and may increase crestal cortical strain around implants. Osseodensification (OD) compacts trabecular bone and may create a peri-osteotomy densified zone, but its strain-level effects in osteoporotic-like bone are unclear. This study evaluated whether an OD-inspired peri-implant densified trabecular zone reduces crestal cortical strain compared with conventional drilling (CD) in an osteoporotic-like model. A three-dimensional finite element model of a mandibular posterior segment with a 2.0-mm cortical shell and D4 cancellous core was constructed with a 4.3 × 11.4-mm titanium implant and a cemented monolithic zirconia crown. CD used a 4.0-mm osteotomy in D4 bone. The OD model used the same osteotomy plus a concentric peri-implant densified shell with radial density gradation from D1 to D3. The implant–bone interface was defined as bonded. Static 100 N axial and 45° oblique loads were applied. Outcomes were ε_eq, ε_max, and ε_min, summarized as mean top-10 nodal values. OD reduced crestal cortical strains under both loads. Under axial loading, ε_eq, ε_max, and |ε_min| decreased by 17.7%, 19.0%, and 24.1%, respectively. Under oblique loading, the corresponding reductions were 9.8%, 8.0%, and 8.9%. Oblique loading produced higher cortical strains than axial loading in both models. OD-inspired peri-implant densification reduced crestal cortical strain in this osteoporotic-like model, whereas oblique loading remained the main driver of elevated strain. These findings support occlusal/prosthetic strategies that minimize oblique forces and warrant experimental and clinical validation. Full article

To address the inherent inaccuracies of the classical beam theory (which overestimates the flexural stiffness) and the “quasi-plane section method” (which neglects the shear deformation) in the deflection analysis of steel truss web–concrete composite beams, this study homogenizes discrete steel truss web members into a continuous steel web with equivalent thickness based on the strain energy equivalence principle. This homogenization is conducted under the assumption of fixed-end constraints for web members, thus establishing a sandwich laminated beam model. Incorporating the assumptions of zigzag axial displacement and layer-wise quadratic parabolic transverse shear stress, this study adopts the governing equations for static bending of composite beams derived via Hamilton’s mixed energy variational principle—this theory eliminates the need for an artificial shear correction factor, as the transverse shear stress naturally satisfies the zero boundary conditions at the upper and lower surfaces and the continuity condition at the interlayers. Analytical solutions for bending deflection under uniformly distributed loads are derived and validated against three-dimensional (3D) finite element (FE) models. The analysis results of a 45-meter-span beam demonstrate that the relative error in the maximum deflection of both simply supported beams and cantilever beams calculated by the proposed method is approximately 5%, which is significantly superior to the classical beam theory; the deflection induced by the zigzag effect at the mid-span of simply supported beams accounts for 15% of the total deflection, making it an indispensable key component in structural design. This method enables accurate deflection prediction and provides reliable technical guidance for the preliminary design of steel truss web–concrete composite beam bridges. Full article

The built environment in the EU accounts for 40% of the total energy consumption and 36% of the total greenhouse gas emissions. To address the inefficiency of existing buildings, renovation could reduce their total energy consumption by 5–6% and lower carbon dioxide emissions by approximately 5%. A retrofit solution for existing buildings involves the use of lightweight prefabricated systems, some of which include integrated HVAC components that are able to enhance their functionality. Indeed, such prefabricated facade elements with integrated HVAC systems can represent a minimally invasive method for reducing the energy consumption of an existing building. To assess the potential of this approach, a full-scale mock-up of a prefabricated timber facade with integrated HVAC system was tested at the Facade System Interactions Lab (FSIL) of Eurac Research, Bolzano. The experimental data were used to develop a calibrated and validated 3D finite element model in COMSOL Multiphysics. The validated model was used to evaluate the facade’s thermal performance under standard heating conditions through a proposed equivalent thermal transmittance indicator (U_eq). Results show that the active facade achieves 0.07 W m⁻² K⁻¹, compared to 0.21 W m⁻² K⁻¹ for the passive facade with identical materials but without active components. Full article

Addressing the insufficient sensitivity of typical Archimedean spiral antennas for detecting partial discharge (PD) in electrical equipment, this paper proposes a high-sensitivity regulation technique for PD Archimedean antennas based on rotating unit-cell reflective metasurfaces. First, a finite element model of the ultra-high-frequency Archimedean antenna was constructed. Then, employing metasurface electromagnetic wave reflection technology and phase compensation principles, a rotating-unit reflective metasurface was designed to optimize its full-bandwidth gain. A multi-parameter joint optimization method was used to obtain the optimal data for the antenna and metasurface parameters. Finally, simulations and experimental analyses of the super-surface-controlled Archimedean antenna revealed the following: The gain of the Archimedean antenna controlled by the rotating-unit super-surface increases by up to 15.61 dB in the 0.3–1.5 GHz band, with an average full-band gain enhancement of 3.42 dB. During electrostatic discharge (ESD), the amplitude of UHF signals detected by the Archimedean antenna increases by approximately 88.9%, and the amplitude detection of UHF signals during GIS discharges increases by approximately 138.6–150%. These results demonstrate that the metasurface significantly enhances the antenna’s gain performance, providing a reference for highly sensitive control technologies in detecting discharges in electrical equipment. Full article

Tunnel linings are critical structural components of underground infrastructure, and their seismic performance plays a decisive role in maintaining the serviceability and safety of tunnels. Under dynamic loading, excessive deformation and damage of the lining may reduce the effective cross-sectional capacity and threaten the minimum safety clearance required for tunnel operation. Therefore, it is essential to investigate the deformation behavior and failure mechanisms of tunnel linings subjected to seismic excitation and to evaluate the effectiveness of reinforcement measures. In this study, a coupled numerical framework combining the finite difference method (FLAC3D) and the discrete element method (PFC3D) is developed to analyze the dynamic response of tunnel lining systems. The surrounding rock mass is modeled in FLAC3D to simulate stress wave propagation and global deformation, while the tunnel lining is represented in PFC3D using bonded particles to capture crack initiation, propagation, and post-peak failure behavior. The proposed FLAC3D–PFC3D coupled approach provides an effective tool for evaluating the seismic performance of reinforced tunnel linings and offers a practical basis for the design and assessment of seismic strengthening measures in underground engineering. Full article

Ensuring the crashworthiness of heavy-duty truck cabs is essential for reducing occupant fatalities and improving passive safety in commercial vehicles. Regulatory frameworks such as UNECE Regulation No. 29 (R29) define structural integrity requirements through full-scale destructive impact tests, which are costly and limit iterative design. In this study, an integrated experimental–numerical methodology is presented for the impact assessment of a real Iveco Eurocargo 120E18 truck cab reconstructed using high-resolution 3D scanning. The scanned geometry was used to generate a dimensionally accurate CAD model of the load-bearing cab structure, which was analysed using explicit finite element simulations in ANSYS Academic Mechanical and CFD Teaching package under impact conditions compliant with UNECE R29 and implemented according to the Swedish regulation VVFS 2003:29. In parallel, a full-scale physical pendulum impact test was performed on the same cab using a cylindrical impactor with a diameter of 580 mm, a length of 1800 mm, and a mass of approximately 1000 kg, impacting the upper region of the A-pillar. The experimental setup was instrumented using high-speed optical measurements and an accelerometer to capture impact kinematics and structural response. The numerical predictions showed good agreement with experimental results in terms of acceleration–time histories, absorbed energy evolution, and structural deformation, with differences generally below 6%. Critical regions susceptible to local buckling and plastic collapse were consistently identified in both approaches, while preservation of the driver survival space was confirmed. The results demonstrate that scan-based finite element models, when properly calibrated and validated, can reliably reproduce certification-level impact behaviour. The proposed workflow provides a robust and cost-effective framework for regulatory pre-validation, structural optimisation, and digitalisation of crashworthiness assessment for heavy-duty truck cabs. Full article

This article mainly researches the model dimension reduction in the finite volume element (FVE) method based on proper orthogonal decomposition (POD) for the two-dimensional (2D) hyperbolic equation. For this objective, an FVE method with unconditional stability and second-order temporal accuracy, and the existence, stability, and error estimates of the FVE solutions are first reviewed. Thereafter, most importantly, a new FVF model dimension reduction (FVEMDR) formulation is established by applying POD technology to lower the dimension of the vectors composed of unknown coefficients for the FVE solutions. The greatest contribution of this article is the theoretical analysis of the existence, unconditional stability, and error estimations for the FVEMDR solutions. Moreover, in computation, two sets of numerical simulations are provided to confirm the validity of the theoretical results and show the effectiveness of the FVEMRD formulation. Full article

Swim bladders in some teleost fish can act as gas-filled cavities that oscillate under acoustic pressure and transfer the sound energy to the inner ears. Quantifying the resonance frequency and damping of these oscillations is useful for linking swim bladder mechanics to hearing-related and behavioural questions, but many established direct-measure approaches have relied on open-water deployments and careful avoidance of boundary reflections, making experiments logistically demanding and difficult to reproduce (e.g., requiring deep-water sites, careful control of surface/boundary reflections, and complex deployment geometries). This study presents a compact laboratory methodology for estimating swim bladder resonance properties using a closed, fully water-filled, stainless-steel impedance tube. Broadband pseudorandom excitation is applied via an end-plate shaker, and the acoustic response of the system is recorded using wall-mounted hydrophones. Resonance peaks are identified using power spectral estimates of recorded signals, allowing resonance frequency and quality factor to be extracted from the peak location and −3 dB bandwidth. The approach is first established using inflated latex balloons as surrogate encapsulated gas cavities, providing a controlled benchmark for repeatability and interpretation. It is then applied to recently euthanised brown trout (Salmo trutta), where clear resonance features attributable to the swim bladder are observed and show systematic variation with body size. A coupled finite element model reproduces the principal resonance behaviour under the experimental loading and supports interpretation of the measured peaks as swim bladder resonance. The results provide a validated foundation for subsequent non-invasive measurements on live, free-swimming fish, as well as for future applications where swim bladder condition may be relevant to management or conservation. Full article
