Metastatic breast cancer remains the leading cause of death in women worldwide. This condition necessitates extensive research to find an effective treatment, one of which is the natural medicine approach. Kaempferia parviflora (KP) is a plant believed to possess anticancer properties. Therefore, this study aims to determine KP’s bioactive compound, cytotoxic, and anti-migration activity in the highly metastatic breast cancer cell line model 4T1, also in the breast cancer cell model MCF-7 and noncancerous cell line NIH-3T3. Maceration with ethanol (EEKP) and infusion with distilled water (EWKP) was used for extraction. The MTT assay was used to test for cytotoxicity, and the scratch wound healing assay was used to test for the inhibition of migration. Phytochemical profiling of EEKP was performed using UHPLC-MS, and the results were studied for in silico molecular docking. Result showed that EEKP had a better cytotoxic activity than EWKP with an IC₅₀ value of 128.33 µg/mL (24 h) and 115.09 µg/mL (48 h) on 4T1 cell line, and 138.43 µg/mL (24 h) and 124.81 µg/mL (48 h) on MCF-7 cell line. Meanwhile, no cytotoxic activity was observed at concentrations ranging from 3–250 µg/mL in NIH-3T3. EEKP also showed anti-migration activity in a concentration of 65 µg/mL. Mass Spectrophotometer (MS) structures from EEKP are 5-Hydroxy-7,4′-dimethoxyflavanone (HDMF), 5-Hydro-7,8,2′-trimethoxyflavanone (HTMF), Retusine, and Denbinobin. The in silico docking was investigated for receptors Bcl-2, Bcl-XL, ERK2, and FAK, as well as their activities. In silico result indicates that HTMF and denbinobin are bioactive compounds responsible for EEKP’s cytotoxic and anti-migration activity. These two compounds and standardized plant extract can be further studied as potential breast cancer treatment candidates. Full article

High electron mobility transistor (HEMT) biosensors hold great potential for realizing label-free, real-time, and direct detection. Owing to their unique properties of two-dimensional electron gas (2DEG), HEMT biosensors have the ability to amplify current changes pertinent to potential changes with the introduction of any biomolecules, making them highly surface charge sensitive. This review discusses the recent advances in the use of AlGaN/GaN and AlGaAs/GaAs HEMT as biosensors in the context of different gate architectures. We describe the fundamental mechanisms underlying their operational functions, giving insight into crucial experiments as well as the necessary analysis and validation of data. Surface functionalization and biorecognition integrated into the HEMT gate structures, including self-assembly strategies, are also presented in this review, with relevant and promising applications discussed for ultra-sensitive biosensors. Obstacles and opportunities for possible optimization are also surveyed. Conclusively, future prospects for further development and applications are discussed. This review is instructive for researchers who are new to this field as well as being informative for those who work in related fields. Full article

This paper presents reduced dislocation of the AlGaN/GaN heterostructure for high-voltage lateral high-electron-mobility transistor (HEMT) devices. AlGaN/GaN heterostructure was grown on sapphire substrate. Prior to the growth of the AlGaN layer, the GaN layer was grown via two-step growth. In the first step, the V/III ratio was applied at 1902 and then at 3046 in the second step. The FWHMs of the XRD (002) and (102) peaks of the GaN layer were around 205 arcsec ((002) peak) and 277 arcsec ((102) peak). Moreover, the surface of the GaN layer showed clear evidence of step flows, which resulted in the smooth surface of the layer as well as the overgrown of the AlGaN layer. Subsequently, the AlGaN/GaN heterostructure was fabricated into a lateral HEMT with wide gate-to-drain length (L_GD). The device exhibited a clear working HEMT characteristic with high breakdown voltages up to 497 V. In comparison to many reported AlGaN/GaN HEMTs, no AlGaN interlayer was inserted in our AlGaN/GaN heterostructure. By improving the growth conditions for the two-step growth, the performance of AlGaN/GaN HEMTs could be improved further. Full article

The emergence of gallium nitride high-electron-mobility transistor (GaN HEMT) devices has the potential to deliver high power and high frequency with performances surpassing mainstream silicon and other advanced semiconductor field-effect transistor (FET) technologies. Nevertheless, HEMT devices suffer from certain parasitic and reliability concerns that limit their performance. This paper aims to review the latest experimental evidence regarding HEMT technologies on the parasitic issues that affect aluminum gallium nitride (AlGaN)/GaN HEMTs. The first part of this review provides a brief introduction to AlGaN/GaN HEMT technologies, and the second part outlines the challenges often faced during HEMT fabrication, such as normally-on operation, self-heating effects, current collapse, peak electric field distribution, gate leakages, and high ohmic contact resistance. Finally, a number of effective approaches to enhancing the device’s performance are addressed. Full article

Recently, there has been increasing interest in electrochemical printed sensors for a wide range of applications such as biomedical, pharmaceutical, food safety, and environmental fields. A major challenge is to obtain selective, sensitive, and reliable sensing platforms that can meet the stringent performance requirements of these application areas. Two-dimensional (2D) nanomaterials advances have accelerated the performance of electrochemical sensors towards more practical approaches. This review discusses the recent development of electrochemical printed sensors, with emphasis on the integration of non-carbon 2D materials as sensing platforms. A brief introduction to printed electrochemical sensors and electrochemical technique analysis are presented in the first section of this review. Subsequently, sensor surface functionalization and modification techniques including drop-casting, electrodeposition, and printing of functional ink are discussed. In the next section, we review recent insights into novel fabrication methodologies, electrochemical techniques, and sensors’ performances of the most used transition metal dichalcogenides materials (such as MoS₂, MoSe₂, and WS₂), MXenes, and hexagonal boron-nitride (hBN). Finally, the challenges that are faced by electrochemical printed sensors are highlighted in the conclusion. This review is not only useful to provide insights for researchers that are currently working in the related area, but also instructive to the ones new to this field. Full article

A new generation of high-efficiency power devices is being developed using wide bandgap (WBG) semiconductors, like GaN and SiC, which are emerging as attractive alternatives to silicon. The recent interest in GaN has been piqued by its excellent material characteristics, including its high critical electric field, high saturation velocity, high electron mobility, and outstanding thermal stability. Therefore, the superior performance is represented by GaN-based high electron mobility transistor (HEMT) devices. They can perform at higher currents, voltages, temperatures, and frequencies, making them suitable devices for the next generation of high-efficiency power converter applications, including electric vehicles, phone chargers, renewable energy, and data centers. Thus, this review article will provide a basic overview of the various technological and scientific elements of the current GaN HEMTs technology. First, the present advancements in the GaN market and its primary application areas are briefly summarized. After that, the GaN is compared with other devices, and the GaN HEMT device’s operational material properties with different heterostructures are discussed. Then, the normally-off GaN HEMT technology with their different types are considered, especially on the recessed gate metal insulator semiconductor high electron mobility transistor (MISHEMT) and p-GaN. Hereafter, this review also discusses the reliability concerns of the GaN HEMT which are caused by trap effects like a drain, gate lag, and current collapse with numerous types of degradation. Eventually, the breakdown voltage of the GaN HEMT with some challenges has been studied. Full article

Face recognition is one of the most sophisticated disciplines of biometric systems. The use of VCSEL in automotive applications is one of the most recent advances. The existing VCSEL package with a diffuser on top of a lens intended for automotive applications could not satisfy the criteria of the automotive TS16949: 2009 specification because the package was harmed and developed a lens fracture during 100 thermal cycle tests. In order to complete a cycle, the temperature rises from −40 °C to 150 °C and then rises again from 150 °C to 260 °C. The package then needs to be tested 500 times to ensure it fits the requirements without failing in terms of appearance or functionality. To this extent, the goal of this research is to develop packaging for 1 mm² VCSEL chips with a diffuser on top that prevents fractures or damage to the package during heat cycle testing with multiple materials. The package was created using the applications SolidWorks 2017 and AutoCAD Mechanical 2017. The ANSYS Mechanical Structural FEA Analysis program simulated all packages for mechanical stress to guarantee that all packages generated were resilient to high temperature conditions. All packages exhibit no abnormalities and are robust for various temperatures ranging from low to high. Therefore, these packaged 1 mm² VCSEL chips with a diffuser on top provide an effective approach for the application of VCSEL suitable in high temperature conditions. Full article

Conventional pseudomorphic high electron mobility transistor (pHEMTs) with lattice-matched InGaAs/InAlAs/InP structures exhibit high mobility and saturation velocity and are hence attractive for the fabrication of three-terminal low-noise and high-frequency devices, which operate at room temperature. The major drawbacks of conventional pHEMT devices are the very low breakdown voltage (<2 V) and the very high gate leakage current (∼1 mA/mm), which degrade device and performance especially in monolithic microwave integrated circuits low-noise amplifiers (MMIC LNAs). These drawbacks are caused by the impact ionization in the low band gap, i.e., the In${}_x$Ga${}_{(1-x)}$As (x = 0.53 or 0.7) channel material plus the contribution of other parts of the epitaxial structure. The capability to achieve higher frequency operation is also hindered in conventional InGaAs/InAlAs/InP pHEMTs, due to the standard 1 $\mathsf{\mu }$m flat gate length technology used. A key challenge in solving these issues is the optimization of the InGaAs/InAlAs epilayer structure through band gap engineering. A related challenge is the fabrication of submicron gate length devices using I-line optical lithography, which is more cost-effective, compared to the use of e-Beam lithography. The main goal for this research involves a radical departure from the conventional InGaAs/InAlAs/InP pHEMT structures by designing new and advanced epilayer structures, which significantly improves the performance of conventional low-noise pHEMT devices and at the same time preserves the radio frequency (RF) characteristics. The optimization of the submicron T-gate length process is performed by introducing a new technique to further scale down the bottom gate opening. The outstanding achievements of the new design approach are 90% less gate current leakage and 70% improvement in breakdown voltage, compared with the conventional design. Furthermore, the submicron T-gate length process also shows an increase of about 58% and 33% in f${}_T$ and f${}_{max}$, respectively, compared to the conventional 1 $\mathsf{\mu }$m gate length process. Consequently, the remarkable performance of this new design structure, together with a submicron gate length facilitatesthe implementation of excellent low-noise applications. Full article

Heavy metal pollution remains a major concern for the public today, in line with the growing population and global industrialization. Heavy metal ion (HMI) is a threat to human and environmental safety, even at low concentrations, thus rapid and continuous HMI monitoring is essential. Among the sensors available for HMI detection, the field-effect transistor (FET) sensor demonstrates promising potential for fast and real-time detection. The aim of this review is to provide a condensed overview of the contribution of certain semiconductor substrates in the development of chemical and biosensor FETs for HMI detection in the past decade. A brief introduction of the FET sensor along with its construction and configuration is presented in the first part of this review. Subsequently, the FET sensor deployment issue and FET intrinsic limitation screening effect are also discussed, and the solutions to overcome these shortcomings are summarized. Later, we summarize the strategies for HMIs’ electrical detection, mechanisms, and sensing performance on nanomaterial semiconductor FET transducers, including silicon, carbon nanotubes, graphene, AlGaN/GaN, transition metal dichalcogenides (TMD), black phosphorus, organic and inorganic semiconductor. Finally, concerns and suggestions regarding detection in the real samples using FET sensors are highlighted in the conclusion. Full article

In this paper, we report on the effect of carboxyl- and amine terminations on a boron-doped diamond surface (BDD) in relation to pH sensitivity. Carboxyl termination was achieved by anodization oxidation in Carmody buffer solution (pH 7). The carboxyl-terminated diamond surface was exposed to nitrogen radicals to generate an amine-terminated surface. The pH sensitivity of the carboxyl- and amine-terminated surfaces was measured from pH 2 to pH 12. The pH sensitivities of the carboxyl-terminated surface at low and high pH are 45 and 3 mV/pH, respectively. The pH sensitivity after amine termination is significantly higher—the pH sensitivities at low and high pH are 65 and 24 mV/pH, respectively. We find that the negatively-charged surface properties of the carboxyl-terminated surface due to ionization of –COOH causes very low pH detection in the high pH region (pH 7–12). In the case of the amine-terminated surface, the surface properties are interchangeable in both acidic and basic solutions; therefore, we observed pH detection at both low and high pH regions. The results presented here may provide molecular-level understanding of surface properties with charged ions in pH solutions. The understanding of these surface terminations on BDD substrate may be useful to design diamond-based biosensors. Full article

This paper explores the concept of a Forward Scattering Radar (FSR) system with a rotational transmitter for target detection and localization. Most of the research and development in FSR used a fixed dedicated transmitter; therefore, the detection of stationary and slow moving target is very difficult. By rotating the transmitter, the received signals at the receiver contain extra information carried by the Doppler due to the relative movement of the transmitter-target-receiver. Hence, rotating the transmitter enhances the detection capability especially for a stationary and slow-moving target. In addition, it increases the flexibility of the transmitter to control the signal direction, which broadens the coverage of FSR networks. In this paper, a novel signal processing for the new mode of FSR system based on the signal’s joint time-frequency is proposed and discussed. Additionally, the concept of the FSR system with the rotational transmitter is analyzed experimentally for the detection and localization of a stationary target, at very low speed and a low profile target crossing the FSR baseline. The system acts as a virtual fencing of a remote sensor for area monitoring. The experimental results show that the proposed mode with the new signal processing scheme can detect a human intruder. The potential applications for this system could be used for security and border surveillance, debris detection on an airport runway, ground aerial monitoring, intruder detection, etc. Full article
