When tracking the peak power point in PV systems, incremental conductance is the most common technique used. This approach preserves the first trap in the local peak power point, but it is unable to quickly keep up with the ever-changing peak power point under varying irradiance and temperature conditions. In this paper, the authors propose a hybrid algorithm, combining an artificial ecosystem optimizer and an incremental-conductance-based MPPT to solve these issues of traditional MPPT under varying irradiance and temperature conditions. The proposed hybrid algorithm has been applied to three scenarios, namely the constant irradiance condition, the varying irradiance condition, and the varying temperature condition. Under the constant irradiance condition, the PV array is maintained at a temperature of 25 °C and an irradiance of 1000 $\mathrm{W}/{\mathrm{m}}^2$. The voltage of the DC link of the neutral-pointed-clamped inverter is maintained at 1000 V. Under the varying irradiance condition, the irradiance of the PV array is increased from 400$\mathrm{W}/{\mathrm{m}}^2$to 1000 $\mathrm{W}/{\mathrm{m}}^2$with a step size of 0.2 s. The same step size is maintained while decreasing the irradiance level from 1000 $\mathrm{W}/{\mathrm{m}}^2$ to 400 $\mathrm{W}/{\mathrm{m}}^2,$with a step change of 0.2 s. However, the temperature is maintained at 25 °C. Under the varying temperature condition, the temperature of the PV array varies from 35 °C, 25 °C, 15 °C, 10 °C, 15 °C, 25 °C, and 35 °C with a step size of 0.2 s, and the irradiance is maintained at 1000$\mathrm{W}/{\mathrm{m}}^2$. The DC link voltage in all three conditions is maintained at 1000 V, which confirms that the hybrid algorithm has been able to vary the duty cycle of the pulse wave modulation generator in such a manner that the variable DC voltage produced by the PV array has been changed by the flyback converter into a stable DC voltage. The simulation results show that the total harmonic distortion (THD) under all the simulated scenarios is within 5%, which agrees with IEEE standards. In the future, this algorithm may be compared with other types of available MPPTs under partial shading. Full article

This work intends to perform technical and 2E (economic & environmental) analysis for the proposed hybrid energy generating system for a part load at SRM IST at the Delhi-NCR campus, India. The investigation has been done for electricity generation and hydrogen production through renewable energy sources, mainly solar energy. It is in line with the Indian Government’s initiatives. The proposed hybrid system has to meet the electric load demand of 400 kWh/day with a peak load of 74.27 kW and hydrogen load demand of 10 kg/day with a peak demand of 1.86 kg/h. The analysis has been performed for both on-grid and off-grid conditions. As a result, optimum results have been obtained off-grid condition, with $0.408 per kWh cost of energy, $16.6 per kg cost of hydrogen, low O&M cost ($21,955 per year), a high renewable fraction (99.8%), and low greenhouse emissions (247 kg/year). In addition, sensitivity analysis has been performed between—(1) the solar PV array size & the number of battery strings, with NPC, renewable fraction & CO₂ emissions as sensitivity variables, and (2) reformer capacity & hydrogen tank capacity, with NPC as sensitivity variable. Full article

This paper mainly dealt with the technical and economic feasibility of an off-grid hybrid power generation system for a remote rural Turtuk village of Ladakh, located in the northern part of India. The study showed that the proposed configured renewable integrated hybrid system, using Hybrid Optimization of Multiple Energy Resources (HOMER) software, efficiently met the energy demand, exhibiting optimum performance with low investment. The proposed PV(115 kW)/Wind(1 kW)/Battery(164 strings of 6 V each)/DG(50 kW) hybrid system was a highly commendable, feasible solution preferred from a total of 133,156 available solutions resulting from HOMER simulations. The net present cost and energy cost of the proposed configuration were $278,176 and $0.29/kWh, respectively. The proposed hybrid configuration fulfilled local load, with 95.97% reduced dominant harmful carbon dioxide emission, as compared to the sole us of a diesel generator power supply system. The technical performance of the hybrid system was ensured, with advantages including the highest renewable penetration and least unmet load. Furthermore, the analysis exclusively evaluated the impact of the system’s economic parameters (namely, its expected inflation rate, nominal discount rate, and project lifetime) on the net present cost and cost of energy of the system using a noble single fix duo vary approach. Full article

The limited availability of fossil fuels such as coal and increasing air pollution levels due to the burning of coal have pushed the trend of generating electricity from fossil fuels to generating it from locally available renewable resources. It is expected that the cost of electricity will decrease when locally available renewable resources are used. In this paper, it was proposed to commission a solar PV system in a part of an academic building of SRM IST University. The present study is an effort in-line with many initiatives taken up by the Indian Government. The performance index of solar PV system was analyzed. Supporting data were obtained from the NASA PDAV tool and then techno-economical analysis was carried out on HOMER. The average performance ratio and capacity factor of the solar PV system were obtained as 64.49% and 14.90%, respectively. For the optimal configuration, the net present cost and the levelized cost of electricity are $639,981 and $0.34 per kWh, respectively. As per the estimation, there will be no air pollution due to the proposed configuration, whereas if only a diesel generator is commissioned, then 200,417 kg of carbon dioxide will be emitted annually. Full article

With the increase in the complexity of the topology of transmission and distribution systems, associated with the predictability in the management of the dispatch of prosumers, new techniques for state estimation, and application of metaheuristics are necessary. In the current work a pilot project in Greece that addresses the difficulties of congestion and balancing management that system operators face in the renewable energy sources era, in accordance with the OneNet’s architecture is described. Available resources of grid’s flexibility are identified, and the implementation of an integrated monitoring system based on weather conditions with an energy control and dispatch system in the Greek electricity grid is addressed. The document suggests that flexibility resources will derive through predictions that have been improved and efficient forecasts from increased spatial resolution Numerical Weather Predictions and integration of Artificial Intelligence preventing the power system of entering dangerous topological or operational states. Full article

This study investigates the effect of distributed Energy Storage Systems (ESSs) on the power quality of distribution and transmission networks. More specifically, this project aims to assess the impact of distributed ESS integration on power quality improvement in certain network topologies compared to typical centralized ESS architecture. Furthermore, an assessment is made to see if the network topology in which an ESS position supports its ability to restore node voltage magnitude within acceptable ranges. The power quality of a benchmark interconnected distribution and transmission network was determined using NEPLAN software. Following that, twelve variants of the benchmark were modeled, each with a different ESS integration architecture and (or) topology. Their power quality performance was compared to that of a benchmark network in addition to several cross analyses to determine the relative impact on power quality within the context of their respective ESS integration methodologies. The findings of this study buttress the understanding that the distributed ESS integration architecture within the distribution network topology, where the majority of consumer loads are connected, provides the strongest case for voltage magnitude power quality compensation, as required by the UK Electrical System Grid Code’s 5% rated node voltage compliance processes regulation. Full article

The magnetic and electric fields of electrostatic discharges are assessed using the Naïve Bayes algorithm, a machine learning technique. Laboratory data from electrostatic discharge generators were used for the implementation of this algorithm. The applied machine learning algorithm can be used to predict the radiated field knowing the discharge current. The results of the Naïve Bayes algorithm are compared to a previous software tool derived by Artificial Neural Networks, proving its better outcome. The Naïve Bayes algorithm has excellent performance on most classification tasks, despite its simplicity, and usually is more accurate than many sophisticated methods. The proposed algorithm can be used by laboratories that conduct electrostatic discharge tests on electronic equipment. It will be a useful software tool, since they will be able to predict the radiating electromagnetic field by simply measuring the discharge current from the electrostatic discharge generators. Full article

During the last decades, renewable energy production has significantly increased in an effort to produce clean energy that will not affect the environment. Governments around the world are focusing on reducing greenhouse gas emissions by increasing the utilization of renewable energy sources in the power chain. Wind farms and wind generators are the main renewable technology that are used worldwide. The main scope of wind farm designers is the achievement of the maximum possible power, restraining the installation cost that is related to the use of a specific number of wind turbines for specific power production, and considering the area of land to be occupied. A harmony search method is presented in this paper for the determination of the optimum number of wind turbines in a wind farm and the total electric power produced. The method is applied for comparison purposes on data from previously published methodologies proving its accuracy and effectiveness. The harmony research method can be used in the studies of wind farm designers aiming to reduce installation costs. Full article

This paper reviews protection schemes for meshed distribution networks. It gives emphasis to the increasing penetration of electric vehicles, their charging patterns, and to the increasing value of distributed generators, especially from renewables. It includes a preliminary analysis on system planning with electric vehicles that is studied probabilistically and a more detailed analysis of the expected changes introduced by these new loads. Finally, a real time hardware-in-the-loop review analysis for protection systems and the open source networks available for protection studies from several sources are also provided. This work could be useful as a collective review of the recent bibliography on protection for meshed networks, giving emphasis to electric vehicles and their real time simulation. Full article

The voltage distribution along the non-linear resistance of metal oxide surges is of great importance for their proper operation, since the non-uniform potential distribution results in higher thermal stresses of the varistor discs near the high voltage electrode, leading to a faster ageing of the discs at the top and, consequently, a downgrade in arrester effectiveness and reliability or even failures. The current work deals with the examination of the voltage distribution along the non-linear resistance of medium voltage metal oxide gapless surge arresters, using an appropriate computer tool, discussing configuration that improve the voltage distribution. Moreover, the impact of various factors on the voltage distribution is examined. The extracted results can contribute to the more efficient design of modern metal oxide gapless surge arresters, in an effort to ensure their reliable operation to protect the electrical equipment against lightning surges. Full article

The connection of electric vehicles to distribution networks has been an emerging issue of paramount importance for power systems. On one hand, it provides new opportunities for climate change mitigation, if electric energy used for charging is produced from zero emission sources. On the other hand, it stresses networks that are now required to accommodate, in addition to the loads and production from distributed generation they are initially designed for, loads from electric vehicles charging. In order to achieve maximum use of the grid without substantially affecting its performance, these issues have to be addressed in a coordinated manner, which requires adequate knowledge of the system under consideration. It is advantageous that electric vehicle charging can be controlled to a certain degree. This research provides better understanding of real distribution networks’ operation, proposing specific operational points through minimizing electric vehicle charging effects. The probabilistic Monte Carlo method on high performance computers is used for the calculations. Full article

The adequate protection against lightning surges and the limitation of the expected annual failure rate of high-voltage substations are critical issues, in an effort to secure the safety of the equipment and the personnel. Various factors affect the lightning performance of the substations, determining the developed lightning surges and the expected outage rate, i.e., the grounding resistance, the length of the underground cable between the connected overhead transmission line and the power transformer, and the installation position of the arresters. In the current work, a heuristic method is developed to adjust different parameters of high-voltage substations that upgrade their lightning performance. The proposed methodology can be useful to the studies of substations’ designers and engineers, contributing effectively in the reduction or/and elimination of lightning failures. Full article

The appropriate circuit modeling of metal oxide gapless surge arresters is critical for insulation coordination studies. Metal oxide arresters present a dynamic behavior for fast front surges; namely, their residual voltage is dependent on the peak value, as well as the duration of the injected impulse current, and should therefore not only be represented by non-linear elements. The aim of the current work is to adjust the parameters of the most frequently used surge arresters’ circuit models by considering the magnitude of the residual voltage, as well as the dissipated energy for given pulses. In this aim, the harmony search method is implemented to adjust parameter values of the arrester equivalent circuit models. This functions by minimizing a defined objective function that compares the simulation outcomes with the manufacturer’s data and the results obtained from previous methodologies. Full article

In this paper a realistic medium voltage (MV) network with four different distributed generation technologies (diesel, gas, hydro and wind) along with their excitation and governor control systems is modelled and simulated. Moreover, an exponential model was used to represent the loads in the network. The dynamic and steady state behavior of the four distributed generation technologies was investigated during grid-connected operation and two transition modes to the islanding situation, planned and unplanned. This study aims to address the feasibility of planned islanding operation and to investigate the effect of unplanned islanding. The load sharing islanding method has been used for controlling the distributed generation units during grid-connected and islanding operation. The simulation results were validated through various case studies and have shown that properly planned islanding transition could provide support to critical loads at the event of utility outages. However, a reliable protection scheme would be required to mitigate the adverse effect of unplanned islanding as all unplanned sub-cases returned severe negative results. Full article
