We are witnessing a global commitment to sustainable mobility that requires advanced materials and manufacturing techniques, such as fused filament fabrication (FFF), to create lightweight, durable, and recyclable machine components. Acknowledging that friction and wear significantly contribute to energy loss globally, developing high-performance polymeric materials with customizable properties is essential for greener mechanical systems. FFF inherently drives resource efficiency and offers the geometric freedom necessary to engineer complex internal structures, such as the gyroid pattern, enabling substantial mass reduction. This study evaluates the tribological performance of FFF-printed thermoplastic polyurethane (TPU 82A) specimens fabricated with three distinct gyroid infill densities (10%, 50%, and 100%). Ball-on-disc testing was conducted under dry sliding conditions against a 100Cr6 spherical ball, with a constant normal load of 5 N, resulting in an initial maximum theoretical Hertz contact pressure of 231 MPa, over a total sliding distance of 300 m. Shore A hardness and surface roughness (
Ra) were also measured to correlate mechanical and structural characteristics with frictional response. Results reveal a non-monotonic relationship between infill density and friction, with a particular absence of quantifiable mass loss across all samples. The intermediate 50% infill (75.9 ± 1.80 Shore A) exhibited the peak mean friction coefficient of
(
), which can be attributed to its balanced structural stiffness that promotes localized surface indentation and an increased real contact area during sliding. By contrast, the rigid 100% infill (86.3 ± 1.92 Shore A) yielded the lowest mean friction (
= 0.465), while the highly compliant 10% infill (44.3 ± 1.94 Shore A) demonstrated viscoelastic energy damping, stabilizing at
= 0.504. This work highlights the novelty of using FFF gyroid architectures to precisely tune TPU 82A’s tribological behavior, offering design pathways for sustainable mobility. The ability to tailor components for low-friction operations (e.g.,
μ ≈ 0.465 for bushings) or high-grip requirements (e.g.,
μ ≈ 1.002 for anti-slip systems) provides eco-efficient solutions for automotive, railway, and micromobility applications, while the exceptional wear resistance supports extended service life and material circularity.
