Optics, Volume 3, Issue 3 (September 2022) – 11 articles

Both orbital and spin energy fluxes constitute the internal flows decomposed from a Poynting vector. For generic electromagnetic waves propagating through source-free media, these energy fluxes are quadratic in field variables so that their properties are not easily predictable. Notwithstanding, their near-field behaviors play important roles in nanoscale photonics. For time-oscillatory fields, we found two hitherto-overlooked distinctions between the two internal flows. The first is an unequal level between them because the vorticity of an orbital energy flux plays a role comparable to a spin energy flux itself. The second is regarding the electric-magnetic dual symmetry in handling the two internal flows, whence the reactive helicity plays a role as important as the electromagnetic helicity. By helicity conservation, an inter-electric-magnetic transport is possible for the spin angular momentum density, while the electric and magnetic constituents of orbital energy fluxes admit only respective intra-electric and intra-magnetic transports. We have tested the validities of all these claims by exemplarily taking the electromagnetic fields induced by an electric point dipole, either a linear or a circular one. We have thus made new contributions not only in deriving explicit forms of the internal energy flows but also in revealing the magnetic activities hidden under the electromagnetic waves induced by electric point dipoles. Full article

Spectrometers have a wide range of applications ranging from optical to non-optical spectroscopy. The need for compact, portable, and user-friendly spectrometers has been a focus of attention from small laboratories to the industrial scale. Here, the Czerny Turner configuration-based optical spectrometer simulation design was carried out using ZEMAX OpticStudio. A compact and low-cost optical spectrometer in the visible range was developed by using diffraction grating as a dispersive element and a USB-type webcam CCD (charge-coupled device) as a detector instead of an expensive commercial diffraction grating and detector. Using National Instruments LabVIEW, data acquisition, processing, and display techniques were made possible. We employed different virtual images in LabVIEW programs to collect the pixel-to-pixel information and wavelength-intensity information from the image captured using the webcam CCD. Finally, we demonstrated that the OpticStudio-based spectrometer and experimental measurements with the developed spectrometer were in good agreement. Full article

This research work conducted a design and simulation of an ultra-low power all-optically tuned nonlinear ring resonator-based add-drop filter. The purpose of this study is to investigate a CMOS-compatible nonlinear material system for an optical filter with temperature resilience, polarization insensitivity, and fast and energy-efficient tunability. The all-optical tunability was achieved using an optical pump that photo-excites the high nonlinear Kerr effect in the device material system. A three-dimensional multiphysics approach was used, combining the electromagnetics and thermo-structural effects in the filter. Hybrid graphene on an ultra-rich silicon nitride ring resonator-based filter enabled the realization of an ultra-high tuning efficiency (0.275 nm/mW for TE mode and 0.253 nm/mW for TM mode) on a range of 1.55 nm and thermal stability of 0.11 pm/K. This work contributed to the existing literature by proposing (1) the integration of a high Kerr effect layer on a low loss, high index contrast, and two-photon absorption-free core material with an athermal cladding material system and (2) the use of a cross-section shape insensitive to polarization. Moreover, the tuning mechanism contributed to the realization of an all-optical on-chip integrable filter for Dense Wavelength Division Multiplexing systems in the less occupied L band. Full article

Quantum state tomography (QST) refers to any method that allows one to reconstruct the accurate representation of a quantum system based on data obtainable from an experiment. In this paper, we concentrate on theoretical methods of quantum tomography, but some significant experimental results are also presented. Due to a considerable body of literature and intensive ongoing research activity in the field of QST, this overview is restricted to presenting selected ideas, methods, and results. First, we discuss tomography of pure states by distinguishing two aspects—complex vector reconstruction and wavefunction measurement. Then, we move on to the Wigner function reconstruction. Finally, the core section of the article is devoted to the stroboscopic tomography, which provides the optimal criteria for state recovery by including the dynamics in the scheme. Throughout the paper, we pay particular attention to photonic tomography, since multiple protocols in quantum optics require well-defined states of light. Full article

We report the 3D-tracking of irregular sand particles in a wave flume using a cylindrical interferometric particle imaging set-up. The longitudinal position of each particle is deduced from the ellipticity of its speckle-like interferometric image. The size of a particle is determined from the analysis of the 2D Fourier transform of its defocused image. It is further possible to identify some rotation of the particles. Simulations accurately confirm the experimental determination of the different parameters (3D position and size of each particle). Full article

In nanoscale photonic devices, the demand for multifunctionality from 2D metasurface optics has increased rapidly. To explore the required fine-tuning in the design metrics, we reinvestigated the trapezoid-shape copper metasurface using finite-difference time-domain simulation to efficiently utilize linearly polarized light for two different functionalities. From the plasmonic band structure, we could see how the degree of asymmetry in the geometry affected the efficient resonance coupling of the traveling plasmonic modes, along with the different types of mode hybridization profiles that were related to the nanoantenna’s geometric shape. By tuning the nanoantenna’s length, we could excite the effective plasmon mode that was supported by this configuration and guide surface waves unidirectionally from the normal incidence free-space light within the visible to infrared range. The directed surface plasmon polaritons had both antisymmetric and symmetric modes that oscillated between the top and bottom surfaces of the continuous metal layer, depending on the nanoantenna’s length and wavelength. This proposed copper metasurface was optimized for a far-field application of broadband (600–900 nm) anomalous beam steering for an average of 60% efficiency with a maximum angle of 64°. This work offers more understanding of a metasurface being implemented in small plasmonic devices, waveguide mode controlling and beam steering with wavelength-dependent functionalities. Full article

In this work, we performed laser annealing of thin Sb₂Te₃ films to optimize crystallization time and their nonlinear optical properties. The annealed layers were studied by electron microscopy and UV–Vis spectrophotometry. Their nonlinear optical response was investigated by nonlinear transmission and Z-scan measurements. These studies were performed by a femtosecond laser system providing 400 fs laser pulses at 1030 nm. The results were compared with previous findings based on studies of oven-annealed thin films. Full article

In this paper, we present a real and simulated study of a frequency up mixing employing an electro-optical sampling semiconductor optical amplifier Mach–Zehnder interferometer (SOA–MZI) along with the differential modulation schema. The sampling signal is generated by an optical pulse clock (OPC) at a frequency of $f_s=$ 19.5 GHz. The quadratic phase shift keying (QPSK) signal at an intermediate frequency (IF) $f_{IF}$ is shifted to high frequencies $n{f}_s \pm f_{IF}$ at the SOA–MZI output. Using a simulator entitled Virtual Photonics Inc. (VPI), we generate sampled QPSK signals and analyze their merits during conversion gains and error vector magnitudes (EVMs). We conducted simulations of mixing in the SOA–MZI operating in a high-frequency band up to 195.5 GHz. The positive conversion gain is accomplished over the mixing frequencies. The EVM is used to evaluate the performance of the electro-optical sampling up-convertor. The EVM reaches 14% at a data rate of 5 Gbit/s at 195.5 GHz. During the experimental work, the results obtained in simulations are set side by side with the factual ones in the frequency range up to 59 GHz. Thus, the comparison between them confirms that they have approximately the same performance. Full article

Tungsten (W) is the material selected for the divertor exhaust of the international nuclear fusion experiment ITER. In this harsh environment, the interactions of heat loads and ion fluxes with W can induce temporary or permanent evolution in the optical properties. Poor knowledge of such evolution during a plasma operation can lead to errors in temperature measurements performed by optical diagnostics. Therefore, it is of fundamental importance to characterize possible changes in W optical properties. In this work, we studied the role of morphology and temperature on the optical response of W. The reflectivities of five W samples with different roughness values (20–100 nm) were measured during laser annealing (25–800 °C) in the visible and near-infrared domains (500–1100 nm). We observed an increase in reflectivity after annealing and we demonstrated that it was due to a change in the chemical composition of the surface, in particular a reduction in the amount of native oxide. Moreover, we show that roughness does not sensibly vary in the investigated temperature range. By highlighting the role played by roughness and surface impurities (e.g., oxide), we provide insight in how W optical properties can evolve in tokamaks where high ion fluxes, heat loads, and impurities can induce the evolution of both the morphology and surface composition of W. Full article

The purpose of this case report is to verify if the adaptation of a rigid gas-permeable contact lens can improve VA and comfort in a patient with complications derived from radial keratotomy (RK) surgery. A semi-scleral contact lens was fitted in a 46-year-old female patient who had undergone bilateral RK before 30 years. The uncorrected distance visual acuity in the right eye (RE) and left eye (LE) was 0.5 and 0.6 logMAR (minimum angle resolution), respectively. The RE and LE manifest refractions were +2.00 − 4.25 × 155 diopters (D) and +2.00 − 3.00 × 15 D, respectively. A semi-scleral rigid gas-permeable Rose K2 XL™ lens was fitted in both eyes. The central clearance was 400–450 µm in the RE and 300–350 µm in the LE. The semi-scleral corrected distance visual acuity in the RE and LE was 0.1 and 0.16 logMAR, respectively. Semi-scleral contact lenses are comfortable and a beneficial choice for patients after RK when associated with visual problems and intolerance to other therapeutic options. Semi-scleral lenses permit prolonged duration of use without discomfort, adverse alterations, and improve the feeling of glare in scotopic vision. In the present case, there were multiple factors that influenced the resolution, such as the amount of apical space, lens diameter, limbal clearance, peripheral O-rings, and tear exchange. Full article

Multipartite quantum key distribution (QKD) is a promising area of quantum networks that provides unconditional secret keys among multiple parties, enabling only legitimate users to decrypt the encrypted message. However, security proofs of existing multipartite QKD typically assume perfect state preparation devices of legitimate users and neglect the relative rotation of reference frames. These presumptions are, nevertheless, very difficult to meet in practice, and thus the security of current multipartite QKD implementations is not guaranteed. By combining the idea of a loss tolerant technique, introduced by Tamaki et al. (K. Tamaki et al., Phys. Rev. A, 90, 052314, 2014), and the concept of a reference frame-independent protocol, we propose a three-party QKD protocol that considers state preparation flaws and the slow drift of reference frames. Through a numerical simulation, the influence of misaliged reference frames on the protocol’s stability was examined by drifting reference frames through angles $\beta =\pi /5$, $\beta =\pi /6$ and $\beta =\pi /7$. In addition, the performance of the proposed protocol was examined for the encoding flaws set at $\delta =0.35$, $\delta =0.20$, and $\delta =0.10$. The results show that the protocol is robust against state preparation flaws, and is insignificantly impacted by misalignment of the reference frames because the achieved transmission distances and secret key rates are comparable to the perfect scenarios. This work dramatically contributes toward the realization of practical and secure multipartite QKD. The proposed protocol has direct applications in quantum communication network environments that involve unknown and slowly varying reference frames, web conferences, and online communications. Full article
