Regulated Charge Pumps: A Comparative Study by Means of Verilog-AMS

DIEEI (Dipartimento di Ingegneria Elettrica Elettronica e Informatica), University of Catania, 95125 Catania, Italy
*
Author to whom correspondence should be addressed.
Electronics 2020, 9(6), 998; https://doi.org/10.3390/electronics9060998
Received: 22 May 2020 / Revised: 10 June 2020 / Accepted: 11 June 2020 / Published: 15 June 2020
(This article belongs to the Special Issue Low-Voltage Integrated Circuits Design and Application)
This paper proposes a comparative study of regulation schemes for charge-pump-based voltage generators using behavioral models in Verilog- Analog Mixed Signal (AMS) code. An accurate and simple model of the charge pump is first introduced. It allows reducing the simulation time of complex electronic systems made up by both analog and digital circuits while maintaining a good agreement with transistor-level simulations. Finally, a comprehensive comparative study of the different regulation schemes for charge pumps is reported which allows the designer to choose the most suitable topology for a given application and Charge Pump (CP) operative zone. View Full-Text
Keywords: charge pump; regulated DC-DC converters; Systems on a Chip; Verilog-AMS charge pump; regulated DC-DC converters; Systems on a Chip; Verilog-AMS
Show Figures

Figure 1
