Search Results (28)

Grouting technology is widely used in construction and civil engineering, where evaluating grouting effectiveness is crucial due to the uncertainty of subsurface conditions. Existing methods face drawbacks such as destructiveness, high cost, poor durability, and limited data collection. To address these issues, this paper proposes a novel wireless real-time monitoring system based on a ZigBee sensor network framework. The sensor system integrates a direct current method in geophysics with apparent resistivity measurement to assess grouting effectiveness in real time. It consists of multichannel data acquisition units with electrodes for sensing underground currents and a user control unit for centralized management and data processing. A system acquisition performance test confirmed that the differential input channel’s equivalent input noise of the ADC was only 175 μV and 188 μV, and the average error of the captured sine wave data was 4.51 mV and 4.19 mV, ensuring the voltage measurement accuracy of the data acquisition units. Stability testing of the equipment in road and construction environments showed an average RSD of 2.86% and 2.92%, respectively, indicating good stability of the measurements. ZigBee network performance tests in three simulated environments and a field test showed that the packet loss rate (PLR) was less than 2% from 0 to 50 m, ensuring network communication in grouting project scenarios. On-site experiments demonstrate that the system can simultaneously monitor multiple profiles and perform inversions in the grouting area, which can be assembled into 3D inversion images for evaluating grout diffusion, offering valuable insights for optimizing construction operations, and enhancing grouting efficiency. Full article

Field implementations of fully underground sensor networks face many practical challenges that have limited their overall adoption. Power management is a commonly cited issue, as operators are required to either repeatedly excavate batteries for recharging or develop complex underground power infrastructures. Prior works have proposed wireless inductive power transfer (IPT) as a potential solution to these power management issues, but misalignment is a persistent issue in IPT systems, particularly in applications involving moving vehicles or obscured (e.g., underground) coils. This paper presents an automated methodology to sense misalignments and align IPT coils using robotic actuators and sequential Monte Carlo methods. The misalignment of a Class EF inverter-driven IPT system was modeled by tracking changes as its coils move apart laterally and distally. These models were integrated with particle filters to estimate the location of a hidden coil in 3D, given a sequence of sensor measurements. During laboratory tests on a Cartesian robot, these algorithms aligned the IPT system within 1 cm (0.025 coil diameters) of peak lateral alignment. On average, the alignment algorithms required less than four sensor measurements for localization. After laboratory testing, this approach was implemented with an agricultural sensor platform at the Utah Agricultural Experiment Station in Kaysville, Utah. In this implementation, a buried sensor platform was successfully charged using an aboveground, vehicle-mounted transmitter. Overall, this work contributes to the field of underground sensor networks by successfully integrating a self-aligning wireless power delivery system with existing agricultural infrastructure. Furthermore, the alignment strategy presented in this work accomplishes coil misalignment correction without the need for complex sensor or coil architectures. Full article

In the context of urban space constraints, subway and underground projects have become crucial strategies to alleviate urban congestion and enhance residents’ quality of life. However, pit engineering, a frequent accident area in geotechnical engineering, urgently requires innovative safety monitoring technologies. Traditional monitoring methods face challenges such as high labor costs, lengthy monitoring cycles, high-risk working environments, and over-reliance on human judgment. To address these issues, this paper introduces an innovative monitoring system integrating Fiber Bragg Grating (FBG) sensing technology based on a subway pit project in Guangzhou. This system not only achieves fully automated data acquisition but also includes an intelligent monitoring cloud platform, providing unprecedented automated and intelligent monitoring solutions for support structures and the surrounding environment during mechanical shaft construction. The key findings of this paper include the following: (1) The breakthrough application of distributed optical fiber monitoring technology, including successfully deploying this advanced technology in complex pit engineering environments, enabling the precise and continuous monitoring of support structures and surrounding changes, and demonstrating its high effectiveness and intelligence in practical engineering. (2) The innovative design of an intelligent safety monitoring system. By integrating sensors and wireless communication technology, an efficient data networking architecture is constructed, supporting remote configuration and flexible adjustment of monitoring equipment, significantly enhancing data collection‘s real-time performance and continuity while greatly reducing safety risks for field staff, achieving an intelligent upgrade of monitoring work. (3) Comprehensive and accurate empirical analysis. During shaft excavation, the monitoring data collected by the system were stable and reliable, with all indicators maintained within reasonable ranges and closely matching expected changes caused by construction activities, validating the system’s practical application effectiveness in complex construction environments and providing a scientific basis for pit engineering safety management. Full article

Underground mines are considered one of the riskiest facilities for human activities due to numerous accidents and geotechnical failures recorded worldwide over the last century, which have resulted in unsafe labor conditions, poor health outcomes, injuries, and fatalities. One significant cause of these accidents is the inadequate or nonexistent capacity for the real-time monitoring of safety conditions in underground mines. In this context, new emerging technologies linked to the Industry 4.0 paradigm, such as sensors, the Internet of Things (IoT), and LoRaWAN (Long Range Wide Area Network) wireless connectivity, are being implemented for planning the efficient, safe, and sustainable performance of underground mine labor environments. This paper studies the implementation of an ecosystem composed of IoT sensors and LoRa wireless connectivity in a data-acquisition system, which eliminates the need for expensive cabling and manual monitoring in mining operations. Laying cables in an underground mine necessitates cable support and protection against issues, such as machinery operations, vehicle movements, mine operator activities, and groundwater intrusion. As the underground mine expands, additional sensors typically require costly cable installations unless wireless connectivity is employed. The results of this review indicate that an IoT LoRaWAN-based wireless sensor network (WSN) provides real-time data under complex conditions, effectively transmitting data through physical barriers. This network presents an attractive low-cost solution with reliable, simple, scalable, secure, and competitive characteristics compared to cable installations and manually collected readings, which are more sporadic and prone to human error. Reliable data on the behavior of the underground mine enhances productivity by improving key performance indicators (KPIs), minimizing accident risks, and promoting sustainable environmental conditions for mine operators. Finally, the adoption of IoT sensors and LoRaWAN wireless connectivity technologies provides information of the underground mine in real-time, which supports better decisions by the mining industry managers, by ensuring compliance with safety regulations, improving the productive performance, and fostering a roadmap towards more environmentally friendly labor conditions. Full article

This paper presents a novel methodology for deploying wireless sensor nodes in the Industrial Internet of Things (IIoT) to address the safety and efficiency challenges in underground coal mining. The methodology is intended to support long-term planning on mitigating the risks in occupational health and safety policies. To ensure realistic and accurate deployment, we propose a software tool that generates mine models based on geolocation data or blueprints in image format, allowing precise adaptation to the specific conditions of each mine. Furthermore, the process is based on sensing and communication range values obtained through simulations and on-site experiments. The deployment strategy is articulated in two complementary steps: a deterministic deployment, where nodes are strategically placed according to the structure of the tunnels, followed by a random stage to include additional nodes that ensure optimal coverage and connectivity inside the mine by comparing different methodologies for deploying sensor networks using coverage density as a performance metric. We analyze coverage and connectivity based on the three probability density functions (PDFs) for the random deployment of nodes: uniform, normal, and exponential, evaluating both the degree of coverage (k-coverage) and the degree of connectivity (k-connectivity). The results show that our proposed methodology stands out for its lower density of sensors per square meter, which translates into a reduction of between 20.81% and 23.46% for uniform and exponential PDFs, respectively, concerning the number of sensors compared to the analyzed methodologies. In this way, it is possible to determine which distribution is suitable to cover the elongated area with the smallest number of nodes, considering the coverage and connectivity requirements, to reduce the deployment cost. The uniform PDF minimizes the number of sensors needed by 44.70% in small mines and 46.27% in medium ones compared to the exponential PDF. These findings provide valuable information to optimize node deployment regarding cost and efficiency; a uniform function is a good option depending on prices. The exponential distribution reached the highest values of k-coverage and k-connectivity for small and medium-sized mines; in addition, it has greater robustness and tolerance to faults like signal network intermittence. This methodology not only improves the collection of critical information for the mining operation but also plays a vital role in reducing the risks to the health and safety of workers by providing a more robust and adaptive monitoring system. The approach can be used to plan IIoT systems based on Wireless Sensor Networks (WSN) for underground mining exploitation, offering a more reliable and adaptable strategy for monitoring and managing complex work environments. Full article

Real-time monitoring and timely risk warnings for the safety, health, and fatigue of underground miners are essential for establishing intelligent mines, enhancing the safety of production, and safeguarding the well-being of miners. This concerns the collection, transmission, and processing of relevant data. To minimize physical strain on miners, data collection functions are consolidated into two wearable terminals: an electronic bracelet equipped with reliable, low-power components for gathering vital sign data and transmitting them via Bluetooth and a miner lamp that integrates multi-gas detection, personnel positioning, and wireless communication capabilities. The gas sensors within the miner lamp undergo regular calibration to maintain accuracy, while the positioning tag supports round-trip polling to ensure a deviation of less than 0.3 m. Data transmission is facilitated through the co-deployment of 5G communication and UWB positioning base stations, with distributed MIMO networking to minimize frequent cell handovers and ensure a low latency of no more than 20 ms. In terms of data processing, a backpropagation mapping model was developed to estimate miners’ fatigue, leveraging the strong correlation between saliva pH and fatigue, with vital signs as the input layer and saliva pH as the output layer. Furthermore, a unified visualization platform was established to facilitate the management of all miners’ states and enable prompt emergency response. Through these optimizations, a monitoring system for underground miners’ status based on mine IoT technology can be constructed, meeting the requirements of practical operations. Full article

In recent years, the use of massive multiple-input multiple-output (MIMO) systems and higher frequency bands for next-generation urban rail transportation systems has emerged as an intriguing research topic due to its potential to significantly increase network capacity by utilizing available narrowband and broadband spectrums. In metro and mining applications, the high-reliability wireless sensor network (WSN) plays a vital role in providing personal safety, channel optimization, and improving operational performance. Through the duration of 1921–2023, this paper provides the survey on the progress of fifth-generation (5G) and beyond-fifth-generation (B5G) wireless communication systems in underground environments such as tunnels and mines, the evolution of the earliest technologies, development in channel modeling for vehicle-to-vehicle (V2V) communications, and realization of different wireless propagation channels in high-speed train (HST) environments. In addition, the most recent advanced channel modeling methods are examined, including the development of new algorithms and their use in intelligent transportation systems (ITS); mathematical, analytical, and experimental techniques for propagation design; and the significance of the radiation characteristics, antenna placing, and physical environment effect on wireless communications. Leaky coaxial cable (LCX) and distributed antenna system (DAS) designs are introduced in the demonstrated systems for improving the channel capacity of narrowband and wideband channels as well as the spatial characteristics of various MIMO systems. The review article concludes by figuring out open research directions for future technologies. Full article

Internet of underground things (IoUTs) and wireless underground sensor networks (WUSNs) are new technologies particularly relevant in agriculture to measure and transmit environmental data, enabling us to optimize both crop growth and water resource management. The sensor nodes can be buried anywhere, including in the passage of vehicles, without interfering with aboveground farming activities. However, to obtain fully operational systems, several scientific and technological challenges remain to be addressed. The objective of this paper is to identify these challenges and provide an overview of the latest advances in IoUTs and WUSNs. The challenges related to the development of buried sensor nodes are first presented. The recent approaches proposed in the literature to autonomously and optimally collect the data of several buried sensor nodes, ranging from the use of ground relays, mobile robots and unmanned aerial vehicles, are next described. Finally, potential agricultural applications and future research directions are identified and discussed. Full article

Earth dams or embankments are susceptible to instability due to internal seepage, piping, and erosion, which can lead to catastrophic failure. Therefore, monitoring the seepage water level before the dam collapses is an important task for early warning of dam failure. Currently, there are hardly any monitoring methods that use wireless underground transmission to monitor the water content inside earth dams. Real-time monitoring of changes in the soil moisture content can more directly determine the water level of seepage. Wireless transmission of sensors buried underground requires signal transmission through the soil medium, which is more complex than traditional air transmission. Henceforth, this study establishes a wireless underground transmission sensor that overcomes the distance limitation of underground transmission through a hop network. A series of feasibility tests were conducted on the wireless underground transmission sensor, including peer-to-peer transmission tests, multi-hop underground transmission tests, power management tests, and soil moisture measurement tests. Finally, field seepage tests were conducted to apply wireless underground transmission sensors to monitor the internal seepage water level before an earth dam failure. The findings show that wireless underground transmission sensors can achieve the monitoring of seepage water levels inside earth dams. In addition, the results supersede those of a conventional water level gauge. This could be crucial in early warning systems during the era of climate change, which has caused unprecedented flooding events. Full article

Wireless Underground Sensor Networks (WUGSNs) transmit data collected from underground objects such as water substances, oil substances, soil contents, and others. In addition, the underground sensor nodes transmit the data to the surface nodes regarding underground irregularities, earthquake, landslides, military border surveillance, and other issues. The channel difficulties of WUGSNs create uncertain communication barriers. Recent research works have proposed different types of channel assessment techniques and security approaches. Moreover, the existing techniques are inadequate to learn the real-time channel attributes in order to build reactive data transmission models. The proposed system implements Deep Learning-based Multi-Channel Learning and Protection Model (DMCAP) using the optimal set of channel attribute classification techniques. The proposed model uses Multi-Channel Ensemble Model, Ensemble Multi-Layer Perceptron (EMLP) Classifiers, Nonlinear Channel Regression models and Nonlinear Entropy Analysis Model, and Ensemble Nonlinear Support Vector Machine (ENLSVM) for evaluating the channel conditions. Additionally, Variable Generative Adversarial Network (VGAN) engine makes the intrusion detection routines under distributed environment. According to the proposed principles, WUGSN channels are classified based on the characteristics such as underground acoustic channels, underground to surface channels and surface to ground station channels. On the classified channel behaviors, EMLP and ENLSVM are operated to extract the Signal to Noise Interference Ratio (SNIR) and channel entropy distortions of multiple channels. Furthermore, the nonlinear regression model was trained for understanding and predicting the link (channel behaviors). The proposed DMCAP has extreme difficulty finding the differences of impacts due to channel issues and malicious attacks. In this regard, the VGAN-Intrusion Detection System (VGAN-IDS) model was configured in the sensor nodes to monitor the channel instabilities against malicious nodes. Thus, the proposed system deeply analyzes multi-channel attribute qualities to improve throughput in uncertain WUGSN. The testbed was created for classified channel parameters (acoustic and air) with uncertain network parameters; the uncertainties of testbed are considered as link failures, noise distortions, interference, node failures, and number of retransmissions. Consequently, the experimental results show that DMCAP attains 10% to 15% of better performance than existing systems through better throughput, minimum retransmission rate, minimum delay, and minimum energy consumption rate. The existing techniques such as Support Vector Machine (SVM) and Random Forest (RF)-based Classification (SMC), Optimal Energy-Efficient Transmission (OETN), and channel-aware multi-path routing principles using Reinforcement Learning model (CRLR) are identified as suitable for the proposed experiments. Full article

The development of Wireless Underground Sensor Networks (WUSNs) is a recent research axis based on sensor nodes buried a few dozen centimeters deep. The communication ranges are, however, highly reduced due to the high attenuation of electromagnetic waves in soil, leading to issues of data collection. This paper proposes to embed a data collector on an Unmanned Aerial Vehicle (UAV) coming close to each buried sensor node. The whole system was developed (sensor nodes, data collector, gateway) and experimentations were carried out in real conditions. In hovering mode, the measurements on the RSSI levels with respect to the position of the UAV highlight the interest in maintaining a high altitude when the UAV is far from the node. In dynamic mode, the experimental results demonstrate the feasibility of carrying out the data collection task while the UAV is moving. The speed of the UAV has, however, to be adapted to the required time to collect the data. In the case of numerous buried sensor nodes, evolutionary algorithms are implemented to plan the trajectory of the UAV optimally. To the best of our knowledge, this paper is the first one that reports experiment results combining WUSN and UAV technologies. Full article

Wireless Underground Sensor Networks (WUSNs) have been showing prospective supervising application domains in the underground region of the earth through sensing, computation, and communication. This paper presents a novel Deep Learning (DL)-based Cooperative communication channel model for Wireless Underground Sensor Networks for accurate and reliable monitoring in hostile underground locations. Furthermore, the proposed communication model aims at the effective utilization of cluster-based Cooperative models through the relay nodes. However, by keeping the cost effectiveness, reliability, and user-friendliness of wireless underground sensor networks through inter-cluster Cooperative transmission between two cluster heads, the determination of the overall energy performance is also measured. The energy co-operative channel allocation routing (ECCAR), Energy Hierarchical Optimistic Routing (EHOR), Non-Cooperative, and Dynamic Energy Routing (DER) methods were used to figure out how well the proposed WUSN works. The Quality of Service (QoS) parameters such as transmission time, throughput, packet loss, and efficiency were used in order to evaluate the performance of the proposed WUSNs. From the simulation results, it is apparently seen that the proposed system demonstrates some superiority over other methods in terms of its better energy utilization of 89.71%, Packet Delivery ratio of 78.2%, Average Packet Delay of 82.3%, Average Network overhead of 77.4%, data packet throughput of 83.5% and an average system packet loss of 91%. Full article

Wireless Underground Sensor Networks (WUSNs) that collect geospatial in situ sensor data are a backbone of internet-of-things (IoT) applications for agriculture and terrestrial ecology. In this paper, we first show how WUSNs can operate reliably under field conditions year-round and at the same time be used for determining and mapping soil conditions from the buried sensor nodes. We demonstrate the design and deployment of a 23-node WUSN installed at an agricultural field site that covers an area with a 530 m radius. The WUSN has continuously operated since September 2019, enabling real-time monitoring of soil volumetric water content (VWC), soil temperature (ST), and soil electrical conductivity. Secondly, we present data collected over a nine-month period across three seasons. We evaluate the performance of a deep learning algorithm in predicting soil VWC using various combinations of the received signal strength (RSSI) from each buried wireless node, above-ground pathloss, the distance between wireless node and receive antenna (D), ST, air temperature (AT), relative humidity (RH), and precipitation as input parameters to the model. The AT, RH, and precipitation were obtained from a nearby weather station. We find that a model with RSSI, D, AT, ST, and RH as inputs was able to predict soil VWC with an R² of 0.82 for test datasets, with a Root Mean Square Error of ±0.012 (m³/m³). Hence, a combination of deep learning and other easily available soil and climatic parameters can be a viable candidate for replacing expensive soil VWC sensors in WUSNs. Full article

The technologies of the fourth industrial revolution have the potential to make zero harm possible for the first time in the history of mining. In the journey toward zero harm, rock stress monitoring systems are important for the risk management process. Although communication systems for underground mining have improved significantly over the past two decades, it remains difficult to achieve reliable-all-the-time wireless communication in ultra-deep level underground mines. The aim of this study is to explore and test a smart phone network for communicating sensor data from the underground production environment to the surface. In this paper, the evaluation and performance over distance of a wireless communication system is performed in underground mining environments. The wireless system transmits the data collected from a sensor installed in a narrow reef stope, horizontal tunnel, and vertical shaft area of a mock underground mine. The evaluation was performed using the received signal strength of a mobile receiver over distance. The path loss coefficients of the underground mining environment were then derived for the measurement areas. The results show that a communication speed of 80 Mbps was achieved in a 60 m range, thus, indicating the potential for the support of applications requiring higher data rates. Full article

This article presents a proposal for a wireless diagnostic system for checking the air tightness of the ventilation network. The solution is designed to increase crew safety in underground mining plants and increase the energy efficiency of the ventube ventilation system. The system is based on sensors measuring the pressure inside the ventilation duct in relation to the barometric pressure in the immediate vicinity of the duct. The flow of diagnostic data is based on a cascade transfer. The data from the first sensor are transferred successively to the last one. Based on the prior calibration of alarm thresholds in each device, the leakage or factor influencing the increase of air flow resistance is located. The article presents the genesis of the creation and discusses the principle and purpose of the system. In the following chapters, the progress of work related to testing the system in laboratory, industrial, and underground conditions at the Velenje Premogovnik mine (Slovenia) is presented. The authors analyze the test results and indicate the directions of possible further work on improving the system. The proposed leak detection system is based on a network of pressure sensors that communicate with each other to clearly pinpoint the leak location. The system has been designed for operation in underground mining plants with limited space. Full article
