This study proposes a hybrid forecast-enabled adaptive crowbar coordination strategy to enhance low-voltage ride-through (LVRT) performance of doubly fed induction generator (DFIG) wind turbines. A unified electro-mechanical model in the αβ/dq frames with dual closed-loop control for rotor- and grid-side converters is built in MATLAB/Simulink (R2018b), and LVRT constraints on current safety and DC-link energy are explicitly formulated, yielding an engineering crowbar-resistance range of 0.4–0.8 p.u. On the forecasting side, a CEEMDAN-based decomposition–modeling–reconstruction pipeline is adopted: high- and mid-frequency components are predicted by a dual-stream Informer–LSTM, while low-frequency components are modeled by XGBoost. Using six months of wind-farm data, the hybrid forecaster achieves best or tied-best MSE, RMSE, MAE, and R² compared with five representative baselines. Forecasted power, ramp rate, and residual-based uncertainty are mapped to overcurrent and DC-link overvoltage risk indices, which adapt crowbar triggering, holding, and release in coordination with converter control. In a 9 MW three-phase deep-sag scenario, the strategy confines DC-link voltage within ±3% of nominal, shortens re-synchronization from ≈0.35 s to ≈0.15 s, reduces rotor-current peaks by ≈5.1%, and raises the reactive-support peak to 1.7 Mvar, thereby improving LVRT safety margins and grid-friendliness without hardware modification. Full article

This work proposes an effective control technique for enhancing the stability of Doubly Fed Induction Generator-Based Wind Turbines (DFIG-WTs) connected to the grid during voltage sag and swell events, ensuring the reliable and efficient operation of wind energy systems integrated with the grid. The proposed approach integrates a Dynamic Voltage Restorer (DVR) in series with a Wind Turbine Generator (WTG) output terminal to enhance the Fault Ride-Through (FRT) capability during grid disturbances. To develop a flexible control strategy for both unbalanced and balanced fault conditions, a combination of feedforward and feedback control based on a sliding mode control (SMC) for DVR converters is used. This hybrid strategy allows for precise voltage regulation, enabling the series compensator to inject the required voltage into the grid, thereby ensuring constant generator terminal voltages even during faults. The SMC enhances the system’s robustness by providing fast, reliable regulation of the injected voltage, effectively mitigating the impact of grid disturbances. To further enhance system performance, Model Predictive Control (MPC) is implemented for the Rotor-Side Converter (RSC) within the back-to-back converter (BTBC) configuration. The main advantages of the predictive control method include eliminating the need for linear controllers, coordinate transformations, or modulators for the converter. Additionally, it ensures the stable operation of the generator even under severe operating conditions, enhancing system robustness and dynamic response. To validate the proposed control strategy, a comprehensive simulation is conducted using a 2 MW DFIG-WT connected to a 120 kV grid. The simulation results demonstrate that the proposed control approach successfully limits overcurrent in the RSC, maintains electromagnetic torque and DC-link voltage within their rated values, and dynamically regulates reactive power to mitigate voltage sags and swells. This allows the WTG to continue operating at its nominal capacity, fully complying with the strict requirements of modern grid codes and ensuring reliable grid integration. Full article

In order to enhance the transient stability of offshore wind turbines (OWTs) in marine energy systems, the grid codes stipulate that OWTs should possess the low-voltage ride-through (LVRT) ability of being grid-tied and injecting reactive current during grid fault. However, the grid-side converter (GSC) of OWTs may lose stability under weak grid or severe fault conditions due to inaccurate current references. To address this issue, a novel transient current control method is proposed to improve the transient stability of permanent-magnet-synchronous-generator (PMSG)-based OWTs. The feature of DC-link overvoltage is investigated and is alleviated by utilizing the GSC’s overcurrent capacity and chopper. Additionally, the equivalent circuit of the PMSG-based OWT connected to the onshore grid is derived based on Thevenin’s theorem. The feasible current region (FCR) is then determined, taking into account the GSC capacity, pre-fault power ability, LVRT requirement, and synchronization stability. Furthermore, a grid-impedance-based transient current control method is designed to enhance the fault ride-through performance and mitigate power oscillation of the OWT under various transient grid impedance and fault conditions. Finally, a simulation model is conducted using PSCAD v4.6.3 software to validate the effectiveness of the proposed method. Full article

Recently, there has been a significant increase in the integration of distributed energy resources (DERs) such as small-scale photovoltaic systems and wind turbines in power distribution systems. When the aggregated outputs of DERs are combined, excessive reverse current may occur in distribution lines, leading to overvoltage issues and exceeding thermal limits of the distribution lines. To address these issues, it is necessary to limit the output of DERs to a certain level, which results in constraining the hosting capacity of DERs in the distribution system. In this paper, coordination control methodologies of DERs are developed and executed to mitigate the overvoltage and overcurrent induced by DERs, thereby increasing the hosting capacity for DERs of the distribution system. This paper proposes three coordinated approaches of active and reactive power control of DERs, namely Var Precedence, Watt Precedence, and Integrated Watt and Var Control. The Var and Watt Precedence prioritizes reactive power for voltage (Q–V) and active power for current (P–I) to address network congestion, thereby enhancing hosting capacity. Conversely, the Integrated Var and Watt Precedence propose a novel algorithm that combines four control indices (Q–V, P–V, Q–I, and P–I) to solve network problems while maximizing hosting capacity. The three proposed methods are based on the sensitivity analysis of voltage and current to the active and reactive power outputs at the DER installation locations on the distribution lines, aiming to minimize DER active power curtailment. Each sensitivity is derived from linearized power equations at the operating points of the distribution system. To minimize the computation burden of iterative computation, each proposed method decouples active and reactive power and proceeds with sequential control in its own unique way, iteratively determining the precise output control of distributed power sources to reduce linearization errors. The three proposed algorithms are verified via case studies, evaluating their performance compared to conventional approaches. The case studies exhibit superior control effectiveness of the proposed DER power control methods compared to conventional methods when issues such as overvoltage and overcurrent occur simultaneously in the distribution line so that the DER hosting capacity of the system can be improved. Full article

This paper presents an integrated overcurrent relays coordination approach for an Egyptian electric power distribution system. The protection scheme suits all network topologies, including adding distribution generation units (DGs) and creating new paths during fault repair periods. The optimal types, sizes, and locations of DGs are obtained using HOMER software (Homer Pro 3.10.3) and a genetic algorithm (GA). The obtained values align with minimizing energy costs and environmental pollution. The proposed approach maintains dependability and security under all configurations using a single optimum setting for each relay. The calculations consider probable operating conditions, including DGs and fault repair periods. The enhanced coordination procedure partitions the ring into four parts and divides the process into four paths. The worst condition of two cascaded overcurrent relays from the DGs’ presence viewpoint is generalized for future work. Moreover, a novel concept addresses the issue of insensitivity during fault repair periods. The performance is validated through the simulation of an Egyptian primary distribution network. Full article

In recent years, the incorporation of wind turbine distributed generation (WTDG) in addition to a battery energy storage system (BESS) into an electrical distribution network (EDN) has developed into a beneficial solution for ensuring a satisfying balance between energy generation and consumption. The principal approaches used to locate and size multiple WTDG and BESS units inside an EDN are described in this article. To optimize overall multi-objective functions, this research investigates the optimal planning of multiple hybrid WTDG and BESS units in an EDN. In the first scenario, injecting active power into the EDN is accomplished by installing WTDG. In contrast, in the second scenario, hybrid WTDG and BESS units are deployed concurrently to provide the EDN, taking into consideration the seasonal uncertainty of load–source power variation in order to approach the practical case, where there are many parameters to be optimized, considering different constraints, during the uncertain times and variable data of a load and power generator. The suggested work’s originality is in completely designing a novel multi-objective function (MOF) based on the sum of three technical metrics of the active power loss (APL), voltage deviation (VD), and operating time of the overcurrent relay (OTR). The proposed MOF is validated on the standard IEEE 69-bus distribution network by applying a new, recently published meta-heuristic algorithm called the Light Spectrum Optimizer (LSO) algorithm. The optimized outcomes revealed that the LSO showed good behavior in minimizing each parameter included in the MOF during the year season. Full article

This paper provides three different research contributions applied to a Wind Turbine patented in 1606 by the inventor Jerónimo de Ayanz y Beaumont. The windmill under study is the Ayanz Wind Turbine with screw blades. The first contribution consists of an experimental characterization of the Ayanz Wind Turbine, incorporating the enclosure proposed at the patent and showing that the efficiency of the wind turbine is increased between 70% and 90% due to the enclosure being employed. As not many details about the shape of the screw blades are provided at the patent, in this article the nowadays well-studied and commercially available Archimedes Spiral Wind Turbine blade is utilized. It has been observed that by using an enclosure with a cylindrical shape, not only the efficiency of the wind turbine is increased, but the visual impact is reduced as seeing the blades rotating is avoided, which is a very important fact for many potential individual users of this wind turbine. In addition, it also enables the use of a protective mesh for birds, almost totally reducing the probability of bird deaths. The second contribution consists in a simple and low-cost Maximum Power Point Tracking (MPPT) strategy for the wind turbine, which only uses an AC three-phase impedance to capture the maximum energy from the wind, enabling to eliminate the DC-DC converter and microprocessor employed typically for this purpose. Due to this, the cost, complexity, failure rate, and power losses of the electronic power circuit are reduced which is very welcomed for small-scale wind turbines. Finally, the last contribution is a protection electronic circuit that fulfills several objectives: to brake the wind turbine under high winds and to disconnect and protect it when over-currents occur and when the voltage range of the batteries connected to the wind turbine is outside their safety range. Full article

With the rapid expansion of the supply of renewable energy in accordance with the global energy transition policy, the wind power generation industry is attracting attention. Subsequently, various wind turbine control technologies have been widely developed and applied. However, there is a lack of research on optimal pitch control, which detects wind direction and changes the rotation angle of the blade in real time. In areas where the wind speed is not strong, such as South Korea, it is necessary to maintain the optimal angle in real time so that the rotating surface of the blade can face the wind direction. In this study, optimal pitch control was performed through real-time analysis of wind speed, direction, and temperature, which is the core of wind turbine maintenance, using fuzzy rules using FIS (Fuzzy Interface System) and WEKA data mining cluster analysis techniques. In order to prevent fires caused by the over-current of wind turbines, over-current control methods such as VCB (Vacuum Circuit Breaker) utilization, prototype utilization such as a modular MCB (Main Circuit Breaker) incorporating VI (Vacuum Interrupter), and vacuum degree change analysis methods using a PD (Partial Discharge) signal were proposed. The optimal control technique for wind turbine parts and facilities was put forth after judging and predicting the annual average wind distribution suitable for wind power generation using HRWPRM (Korea’s High-Resolution Wind Power Resource Maps). Finally, the various wind turbine control methods carried out in this study were confirmed through computer simulation, such as remote diagnosis and early warning issuance, prediction of power generation increase and decrease situation, and automatic analysis of wind turbine efficiency. Full article

In a system where wind farms are connected to the grid via a bipolar flexible DC transmission, the occurrence of a short-time fault at one of the poles results in the active power emitted by the wind farm being transmitted through the non-faulty pole. This condition leads to an overcurrent in the DC system, thereby causing the wind turbine to disconnect from the grid. Addressing this issue, this paper presents a novel coordinated fault ride-through strategy for flexible DC transmission systems and wind farms, which eliminates the need for additional communication equipment. The proposed strategy leverages the power characteristics of the doubly fed induction generator (DFIG) under different terminal voltage conditions. By considering the safety constraints of both the wind turbine and the DC system, as well as optimizing the active power output during wind farm faults, the strategy establishes guidelines for the wind farm bus voltage and the crowbar switch signal. Moreover, it harnesses the power regulation capability of the DFIG rotor-side crowbar circuit to enable fault ride-through in the presence of single-pole short-time faults in the DC system. Simulation results demonstrate that the proposed coordinated control strategy effectively mitigates overcurrent in the non-faulty pole of flexible DC transmission during fault conditions. Full article

In the last few years, the integration of renewable distributed generation (RDG) in the electrical distribution network (EDN) has become a favorable solution that guarantees and keeps a satisfying balance between electrical production and consumption of energy. In this work, various metaheuristic algorithms were implemented to perform the validation of their efficiency in delivering the optimal allocation of both RDGs based on multiple photovoltaic distributed generation (PVDG) and wind turbine distributed generation (WTDG) to the EDN while considering the uncertainties of their electrical energy output as well as the load demand’s variation during all the year’s seasons. The convergence characteristics and the results reveal that the marine predator algorithm was effectively the quickest and best technique to attain the best solutions after a small number of iterations compared to the rest of the utilized algorithms, including particle swarm optimization, the whale optimization algorithm, moth flame optimizer algorithms, and the slime mold algorithm. Meanwhile, as an example, the marine predator algorithm minimized the seasonal active losses down to 56.56% and 56.09% for both applied networks of IEEE 33 and 69-bus, respectively. To reach those results, a multi-objective function (MOF) was developed to simultaneously minimize the technical indices of the total active power loss index (APLI) and reactive power loss index (RPLI), voltage deviation index (VDI), operating time index (OTI), and coordination time interval index (CTII) of overcurrent relay in the test system EDNs, in order to approach the practical case, in which there are too many parameters to be optimized, considering different constraints, during the uncertain time and variable data of load and energy production. Full article

Overvoltage and overcurrent resulting from various faults cause instability in Doubly Fed Induction Generator (DFIG)-based wind turbines connected to a grid. The grid code requirement must be met during faults to minimize the effect of these problems. Low Voltage Ride Through (LVRT) capability is used to meet the grid code requirement. It is important to use coordinate control for transient states in LVRT capability. This study aimed to improve the stator dynamics for ease of calculation and the rotor dynamic model by damping oscillations caused by balanced and unbalanced faults on the grid side. For this, electromotive force (emf) models were developed for stator and rotor dynamic modeling. Furthermore, for the coordinate control of the DFIG, models were developed for a lookup-table-based supercapacitor and a decoupled Static Synchronous Compensator (STATCOM). Using these models, analyses of three-phase and two-phase faults were conducted. Following different balanced and unbalanced faults within the grid, the system was stabilized in a short time, and the oscillations occurring during the faults were quickly damped using the LVRT models developed in this study. Full article

In present electrical power systems, wind energy conversion systems based on doubly fed induction generators represent one of the most commonly accepted systems in the global market due to their excellent performance under different power system operations. The high wind energy penetration rate makes it challenging for these wind turbines to follow grid code requirements. All operations of a wind energy system during a dip in voltage require special attention; these operations are critically known as fault ride-through and low voltage ride-through. In this paper, various fault ride-through techniques of doubly fed induction generator-based wind energy conversion systems, such as protective circuitry, reactive power injection, and control methods for transient and steady state operations, have been presented to improve the performance. During system disturbances, protective circuitry or control mechanisms are typically used to limit the over-current of the rotor and the generated inappropriate DC link over-voltage. Simultaneously, the reactive power injection system overcomes the reactive power scarcity and enhances the transient response, further limiting the DC bus voltage and rotor current. This review paper compares and suggests appropriate FRT methods that are driven by external modifications and internal system improvements. Furthermore, typical case studies are discussed to illustrate and support the FRT system. The impact of each case study was evaluated and analyzed using the results obtained from the MATLAB/Simulink application and the OPAL-RT (OP4500) real time simulator (RTS). Full article

Due to rapid increase in the installation of renewable energy resources in the grid, the use of power electronic-based devices is increasing day by day. Whenever a wind farm is installed and integrated with the grid, most of the work and control depends on its electronic converters. Whenever a grid fault occurs, it can cause significant overcurrents and overvoltage, placing the entire facility at risk. It can quickly cause the converter system to deteriorate if countermeasures are not taken. Thus, a proper protection scheme is needed to protect the generator and its converter from faults. In this paper, an asymmetrical fault analysis and protection scheme is presented in which a single line to ground fault is created, followed by a check of its effects on the DFIG, rotor circuit and converters. Then, a proper protection scheme for a crowbar circuit is designed and we assess its operation on a 1.5 MW DFIG-based industrial wind turbine model in EMTDC/PSCAD. Full article

In this paper, a generalized predictive control scheme for wind energy conversion systems that consists of a wind turbine and a doubly-fed induction generator is proposed. The design is created by using the maximum power point tracking theory to maximize the extracted wind power, even when the turbine is uncertain or the wind speed varies abruptly. The suggested controller guarantees compliance with current constraints by applying them in the regulator’s conceptual design process to assure that the rotor windings are not damaged due to the over-current. This GPC speed control solves the optimization problem based on the truncated Newton minimization method. Finally, simulation results, which are obtained through the Matlab/Simulink software, show the effectiveness of the proposed speed regulator compared to the widely used Proportional-integral controller for DFIG. Full article

The increase in the use of converter-interfaced generators (CIGs) in today’s electrical grids will require these generators both to supply power and participate in voltage control and provision of grid stability. At the same time, new possibilities of secondary QU droop control in power grids with a large proportion of CIGs (PV panels, wind generators, micro-turbines, fuel cells, and others) open new ways for DSO to increase energy flexibility and maximize hosting capacity. This study extends the existing secondary QU droop control models to enhance the efficiency of CIG integration into electrical networks. The paper presents an approach to decentralized control of secondary voltage through converters based on a multi-agent reinforcement learning (MARL) algorithm. A procedure is also proposed for analyzing hosting capacity and voltage flexibility in a power grid in terms of secondary voltage control. The effectiveness of the proposed static MARL control is demonstrated by the example of a modified IEEE 34-bus test feeder containing CIGs. Experiments have shown that the decentralized approach at issue is effective in stabilizing nodal voltage and preventing overcurrent in lines under various heavy load conditions often caused by active power injections from CIGs themselves and power exchange processes within the TSO/DSO market interaction. Full article
