Search Results (67)

The analytical solutions for groundwater inflow into tunnels are usually developed under the condition of circular tunnels. However, real-world tunnels often have non-circular cross-sections, such as arched, lens-shaped, or egg-shaped profiles. Accurately assessing water inflow for these diverse tunnel shapes remains challenging. To address this gap, this study developed a closed-form analytical solution for water inflow into a deeply buried arched tunnel using the conformal mapping method. When the tunnel circumference degenerates to a circle, the analytical solution degenerates to the widely used Goodman’s equation. The solution also showed excellent agreement with numerical simulations carried out using COMSOL. Based on the analytical solution, the impact of various factors on water inflow Q was further discussed: (1) Q decreases as the boundary distance $D^{\ast }$ increases. And the boundary inclination angle ($\alpha -\pi /2$) significantly affects Q only when the boundary is close to the tunnel ($D^{\ast }<20$); (2) Q increases quickly with the upper arc radius $r_1^{\ast }$, while it shows minimal variation with the change in the lower arc radius $r_2^{\ast }$. The findings provide a theoretical foundation for characterizing water inflow into arched tunnels, thereby supporting improved tunnel planning and grouting system design. Full article

In visible light communication (VLC) systems, lenses are typically used to collimate light at the transmitter. However, due to the wide light emission angle of mini-LEDs, capturing light at large angles using a lens at the transmitter can be challenging. This paper presents a design of a reflective cup at the mini-LED-based VLC transmitter. The redesigned reflective cup can collect most of the light and collimate it, achieving an efficiency of approximately 86% at a distance of 10 m in the simulation. In the experiment, error-free communication was achieved at a distance of 100 m with a data rate of 190 Mbps. To the best of our knowledge, a long-distance VLC system based on mini-LEDs is investigated for the first time. The reflective cup offers advantages, including high efficiency, low cost, and a simple structure. It holds reference value for addressing the issue of limited communication distance in underwater wireless optical communication (UWOC). Full article

Conventional metalenses struggle with chromatic aberration and narrow field of view (FOV), making it challenging to meet the dispersion requirements for large apertures and compensate off-axis aberrations for wide FOV. Here, we demonstrate a hybrid metalens module consisting of five refractive plastic lenses and a polarization-insensitive metalens to achieve broadband achromatic imaging within 400–700 nm and a wide FOV up to 100°. The system exhibits negligible variation in focal length (~1.2%) across the visible range (460–656 nm) and consistently achieves modulation transfer function (MTF) values > 0.2 at 167 lp/mm across all wavelengths and incident angles. We also demonstrate integrated lens modules that capture high-quality images from distances ranging between 0.5 and 4 m without post-processing, showcasing its potential for compact, wide-angle optical systems. Full article

Background: Gonioscopy-assisted transluminal trabeculotomy (GATT) is a minimally invasive, ab interno conjunctival-sparing glaucoma surgery aimed at the trabecular meshwork and the inner wall of Schlemm’s canal. The goal of this study is to report on the success of GATT in a large group of patients with a wide variety of open- and closed-angle glaucomas with or without cataract extraction and to report on risk factors for failure. Methods: A retrospective chart review of consecutive patients with primary or secondary open- or closed-angle glaucoma who underwent GATT, with or without concomitant phacoemulsification. Demographics, baseline clinical characteristics, and postoperative outcomes were collected from patients’ medical records. Primary outcomes were success rates (IOP of 18 mmHg or lower and one of the following: IOP reduction > 30% from baseline on the same or fewer medications or an IOP ≤ baseline with fewer medications as compared to baseline) and complication rates. Intraocular pressure (IOP) and the number of glaucoma medications were secondary outcome measures. Results: GATT was performed on 126 eyes of 121 patients. Mean follow-up was 583 ± 266 days. Cumulative success at 1Y was 0.88 for GATT combined with cataract extraction, 0.96 for GATT alone, 0.88 for primary open-angle glaucoma (POAG), 0.89 for secondary open-angle glaucoma (SOAG), and 0.76 for primary angle-closure glaucoma (PACG). IOP decreased from a mean of 20.65 mmHg to 14.1 mmHg, and medication decreased from a mean of 3.47 to 1.4 at the last follow-up. Forty-four eyes (34%) were classified as failures. Factors associated with an increased risk of failure were worse preoperative corrected visual acuity (OR = 2.46, p = 0.024) and a postoperative IOP spike (OR = 2.62, p = 0.028). Twelve eyes (9.5%) required further surgery for IOP control. Risk factors for requiring further surgery for IOP control were preoperative maximal IOP (OR = 1.066, p = 0.047) and a postoperative IOP spike (OR = 4.531, p = 0.036). Conclusions: GATT achieved good surgical success with good IOP and medication reduction across a wide range of glaucomas, in combination with lens extraction or as a standalone procedure. GATT should be considered early in the treatment paradigm of medically uncontrolled glaucoma. Full article

In the Philippines, dragon fruit has become an essential, high-value crop and is important to the country’s economy. However, due to inefficient manual inspection methods, farmers need help with quality control and market preparation. Therefore, we developed an automated, real-time visual identification system to detect the maturity, size, and defects of dragon fruits. Advanced deep learning models (EfficientNet and YOLOV8) were trained on a diverse dataset of dragon fruit images collected from online sources and a local farm using DSLR and smartphone cameras. A Raspberry Pi 4B with an HQ camera and wide-angle lens was used as a cost-effective and accessible device for farmers. The developed system showed an accuracy of 93.33% for maturity and size classification, 96.67% for defect detection, and an overall accuracy of 83.33%. Regarding accuracy and reliability, the developed method presents a technological advancement for dragon fruit identification and classification. Full article

Background and Objectives: Scleral lenses are widely used for visual rehabilitation in keratoconus patients, but their long-term effects on corneal tomography remain unclear. This study aims to evaluate the impact of 12-month scleral lens wear on corneal tomography in keratoconus patients through a case-controlled design. Materials and Methods: This retrospective study included 220 keratoconus patients, of whom 10 eyes were treated with SoClear (Brighten Optix Corporation, Taipei, Taiwan) mini-scleral lenses for over one year (SL group). A control group of 14 eyes was matched using Mahalanobis distance matching based on anterior maximum keratometry (K_max) and age. Both groups were evaluated at baseline and 12 months. Corneal tomography was assessed using the Pentacam HR (Oculus, Wetzlar, Germany), analyzing parameters such as anterior and posterior corneal curvature, thinnest corneal thickness (TCT), and higher-order aberrations. Generalized estimating equations (GEEs) were employed to assess the time-by-treatment effect between the two groups. Results: The SL group included 10 eyes from eight patients (seven males, one female; mean age 30.40 ± 6.52 years), while the control group included 14 eyes from 11 patients (three males, wight females; mean age 27.43 ± 8.11 years). Best corrected visual acuity with spectacles improved significantly with scleral lenses (p = 0.011) and remained stable (p = 0.044) at 12 months. Significant interaction effects were found in Ambrósio relational thickness (p = 0.006), posterior radius curvature (p = 0.047), posterior mean keratometry (p = 0.019), posterior flat keratometry (p = 0.023), and thinnest corneal thickness angle (p = 0.023); the SL group demonstrated less progression in these parameters compared to the control group. Conclusions: This case-controlled study highlights the 12-month impact of scleral lenses on keratoconus, showing improved visual acuity compared to spectacles, stabilized posterior corneal curvature, and maintained corneal thickness. Further prospective studies with larger cohorts are needed to assess scleral lens effect on keratoconus progression. Full article

Laser space networks are an important development direction for inter-satellite communication. Detecting the angle of arrival (AOA) of multiple satellites in a wide field of view (FOV) is the key to realize inter-satellite laser communication networking. The traditional AOA detection method based on the lens system has a limited FOV. In this paper, we demonstrate a system that uses a spatially distributed sensor array to detect the AOA in a wide FOV. The basic concept is to detect AOA using the signal strength of each sensor at different spatial angles. An AOA detection model was developed, and the relationship of key structural parameters of the spatially distributed sensor array on the FOV and angular resolution was analyzed. Furthermore, a spatially distributed sensor array prototype consisting of 5 InGaAs PIN photodiodes distributed on a 3D-printed structure with an inclination angle of 30° was developed. In order to improve the angle calculation accuracy, a multi-sensor data fusion algorithm is proposed. The experimental results show that the prototype’s maximum FOV is 110°. The root mean square error (RMSE) for azimuth is 0.6° within a 60° FOV, whereas the RMSE for elevation is 0.67°. The RMSE increases to 1.1° for azimuth and 1.7° for elevation when the FOV expands to 110°. The designed spatially distributed sensor array has the advantages of a wide FOV and low size, weight, and power (SWaP), presenting great potential for multi-satellite laser communication applications. Full article

In this paper, we propose a zoom auxiliary imaging lens based on the four-component mechanical zoom method for a modulation transfer function (MTF) test system. The auxiliary imaging lenses of the current MTF test system typically use fixed-focus optical systems, which are unable to meet the test scenarios of fast and batch measurement and measure lenses with an extensive focal length range. Compared with the fixed-focus auxiliary imaging lens, the zoom auxiliary imaging lens can simultaneously satisfy the measurement of wide-angle and telephoto miniature lenses without losing measurement accuracy. The entrance pupil distance of the zoom lens is greater than that of traditional lenses, and it is constant for each focal length of the zoom lens. The zoom lens uses an intermediate real image surface to obtain the perfect image quality and lower the diameter of the rear group. Additionally, the zoom lens dynamically adjusts magnification to optimize image size and align with the detector’s pixel resolution, thereby preventing undersampling and enhancing measurement precision. The optical design is optimized for stability, delivering high resolution and minimal aberrations across the zoom range. The image quality of the zoom lens is nearly at the diffraction limit at each focal length, which significantly reduces the impact of the auxiliary lens on MTF test results, enhancing both flexibility and accuracy. This design is particularly well suited for testing miniature lenses in optoelectronic technology applications. Full article

A light-field display with a near-virtual-image mode, which employs both a lens array and an aperture array, was previously proposed to provide a wide viewing zone angle and bright three-dimensional (3D) images. However, it is desirable to enhance its resolutions, which are presently equal to those of conventional displays. Thus, we proposed a technique for increasing the resolutions of 3D images generated by the light-field display with the near-virtual-image mode. The gap between the flat-panel display and lens array is reduced to decrease the magnification of the virtual images of the pixels and to enable the observation of multiple virtual pixel images through each lens. Further, we imaged the aperture array using the lens array to eliminate the gaps between the multiple pixels observed through adjacent lenses. We constructed a prototype display based on the proposed technique and verified the increase in the resolution of the prototype display compared to the original near-virtual-image light-field display. Full article

Semiconductor near-infrared lasers have been widely used in lidar systems. However, various source types have different shapes and divergence angles, causing more difficulties for long-distance detection. In this paper, an optical collimation system is designed for a long-range lidar system with a shaped laser source (the wavelength is 905 nm, the emitted spot size is 50 µm long by 10 µm wide, and the divergence angles are 33°and 15°, respectively, which are unconventional). On the basis of the traditional method of aspheric lens setting, a pair of asymmetric aspherical lenses were designed using an extended polynomial. The simulation results show that the spot shapes are all close to circular from 100 mm to 30 m and the spot size always remains the same value. The corrected optical system is put into the designed lidar system for verification. It results show that the average divergence angles in the long and short axis directions are 0.06°and 0.07°, which satisfy the project requirements. This optical system designed provides a collimation scheme and expands the application of vehicle-mounted lidar in the field of long-range detection. Full article

This paper reports the successful application of a self-developed, miniaturized, low-power nano-star tracker for precise attitude measurement of a 5-m-long satellite extension boom. Such extension booms are widely used in space science missions to extend and support payloads like magnetometers. The nano-star tracker, based on a CMOS image sensor, weighs 150 g (including the baffle), has a total power consumption of approximately 0.85 W, and achieves a pointing accuracy of about 5 arcseconds. It is paired with a low-cost, commercial lens and utilizes automated calibration techniques for measurement correction of the collected data. This system has been successfully applied to the precise attitude measurement of the 5-m magnetometer boom on the Chinese Advanced Space Technology Demonstration Satellite (SATech-01). Analysis of the in-orbit measurement data shows that within shadowed regions, the extension boom remains stable relative to the satellite, with a standard deviation of 30′′ (1σ). The average Euler angles for the “X-Y-Z” rotation sequence from the extension boom to the satellite are [−89.49°, 0.08°, 90.11°]. In the transition zone from shadow to sunlight, influenced by vibrations and thermal factors during satellite attitude adjustments, the maximum angular fluctuation of the extension boom relative to the satellite is approximately ±2°. These data and the accuracy of the measurements can effectively correct magnetic field vector measurements. Full article

Traboulsi syndrome is a rare genetic disorder characterized by facial dysmorphism, lens subluxation, anterior segment anomalies, and spontaneous filtering blebs. The syndrome is due to mutations in the ASPH gene, which plays a crucial role in the development and maintenance of the lens. This case report describes the clinical and genetic findings in a Mexican male with Traboulsi syndrome, highlighting the identification of a novel ASPH variant. A 21-year-old male presented with trauma to the right eye while playing soccer. He had a history of lens subluxation and dysmorphic facial features. Ophthalmic examination revealed right eye lens subluxation into the anterior chamber (with signs of a previous episode of acute angle closure) and left eye posterior and inferior lens subluxation with sectorial iris atrophy. Genetic analysis identified a pathogenic ASPH variant (NM_004318.3:c.1892G>A, p.Trp631*) and a novel likely pathogenic variant (deletion of exons 20–21), confirming Traboulsi syndrome. This is the first instance of Traboulsi syndrome in the Mexican population. The absence of spontaneous filtering blebs in this patient supports previous reports of the wide phenotypic variability that could be related to the type of mutation. This novel ASPH variant expands the known genetic heterogeneity of Traboulsi syndrome. Full article

In response to the zooming delay issue during the transition from a wide-area search to high-resolution target identification in high-magnification zoom lenses, we propose a drive technology based on voice coil motors. The linear motion of the motor is directly converted into the linear movement of the zoom lens group, significantly enhancing the zoom speed. Additionally, we introduce a high-precision closed-loop control technology utilizing a magnetic scale to achieve the rapid and precise positioning of the zoom lens group. The magnetic scale detection technology achieves precise positioning by detecting periodic changes in the magnetic field, working in conjunction with tunnel magnetoresistance sensors. Demonstrated with a 40× zoom lens example, this study elaborates on the motion trajectory planning and structural dimension design process of a voice coil motor, culminating in the assembly of a physical prototype. Practical validation experiments show that the full zoom time of the lens utilizing our technology is less than 0.3 s, where the full zoom time refers to the time required for the lens to zoom from the wide-angle end to the telephoto end. In positioning accuracy test experiments, lenses using our technology achieved a positioning deviation of less than 5 μm. Full article

In the athermal and apochromatic design of optical systems, the distribution of lens’ optical powers and the selection of optical glass and structural materials are crucial. In this paper, an athermal and apochromatic design method is proposed for optical systems with a long focal length, large relative aperture, and wide spectrum. Firstly, a complex optical system composed of multiple lenses is equivalent to a two-component, single-lens system consisting of a replacement and an equivalent lens group. The optical glass for the replacement lens group is selected based on weight and the principle of material replacement in the 3D glass diagram, thus achieving an athermal and apochromatic design. Secondly, an athermal and apochromatic optical system with a focal length of 130 mm, an F-number of 2.0, a spectral range of 480 nm~800 nm, a field of view angle of 22°, and an operating temperature of −40 °C~+60 °C is designed. The modulation transfer function (MTF) at each field of view is greater than 0.6 at 50 lp/mm in the −40 °C~+60 °C temperature range, and the secondary spectrum aberration is 0.0056 mm, which is within the focal depth range of the optical system. Full article

Multi-beam microwave antennas have attracted enormous attention owing to their wide range of applications in communication systems. Here, we propose a broadband metamaterial-based multi-beam Luneburg lens-antenna with low polarization sensitivity. The lens is constructed from additively manufactured spherical layers, where the effective permittivity of the constituting elements is obtained by adjusting the ratio of dielectric material to air. Flexible microstrip patch antennas operating at different frequencies are used as primary feeds illuminating the lens to validate the radiation features of the lens-antenna system. The proposed Luneburg lens-antenna achieves ±72° beam scanning angle over a broad frequency range spanning from 2 GHz to 8 GHz and presents a gain between 15.3 dBi and 22 dBi, suggesting potential applications in microwave- and millimeter-wave mobile communications, radar detection and remote sensing. Full article
