Search Results (53)

Search Parameters:
Keywords = wide beamwidth

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
22 pages, 4331 KiB
Article
Simulation-Based Design of a Low-Cost Broadband Wide-Beamwidth Crossed-Dipole Antenna for Multi-Global Navigational Satellite System Positioning
by Songyuan Xu, Jiwon Heo, Won Seok Choi, Seong-Gon Choi and Bierng-Chearl Ahn
Sensors 2025, 25(15), 4665; https://doi.org/10.3390/s25154665 - 28 Jul 2025
Viewed by 142
Abstract
This paper presents the design of a wideband circularly polarized crossed-dipole antenna for multi-GNSS applications, covering the frequency range of 1.16–1.61 GHz. The proposed antenna employs orthogonally placed dipole elements fed by a three-branch quadrature hybrid coupler for broadband and wide gain/axial ratio [...] Read more.
This paper presents the design of a wideband circularly polarized crossed-dipole antenna for multi-GNSS applications, covering the frequency range of 1.16–1.61 GHz. The proposed antenna employs orthogonally placed dipole elements fed by a three-branch quadrature hybrid coupler for broadband and wide gain/axial ratio beamwidth. The design is carried out using CST Studio Suite for a single dipole antenna followed by a crossed-dipole antenna, a feed network, and the entire antenna structure. The designed multi-GNSS antenna shows, at 1.16–1.61 GHz, a reflection coefficient of less than −17 dB, a zenith gain of 3.9–5.8 dBic, a horizontal gain of −3.3 to −0.2 dBic, a zenith axial ratio of 0.6–1.0 dB, and horizontal axial ratio of 0.4–5.9 dB. The proposed antenna has a dimension of 0.48 × 0.48 × 0.25 λ at the center frequency of 1.39 GHz. The proposed antenna can also operate as an LHCP antenna for L-band satellite phone communication at 1.525–1.661 GHz. Full article
Show Figures

Figure 1

26 pages, 42046 KiB
Article
High-Resolution Wide-Beam Millimeter-Wave ArcSAR System for Urban Infrastructure Monitoring
by Wenjie Shen, Wenxing Lv, Yanping Wang, Yun Lin, Yang Li, Zechao Bai and Kuai Yu
Remote Sens. 2025, 17(12), 2043; https://doi.org/10.3390/rs17122043 - 13 Jun 2025
Viewed by 303
Abstract
Arc scanning synthetic aperture radar (ArcSAR) can achieve high-resolution panoramic imaging and retrieve submillimeter-level deformation information. To monitor buildings in a city scenario, ArcSAR must be lightweight; have a high resolution, a mid-range (around a hundred meters), and low power consumption; and be [...] Read more.
Arc scanning synthetic aperture radar (ArcSAR) can achieve high-resolution panoramic imaging and retrieve submillimeter-level deformation information. To monitor buildings in a city scenario, ArcSAR must be lightweight; have a high resolution, a mid-range (around a hundred meters), and low power consumption; and be cost-effective. In this study, a novel high-resolution wide-beam single-chip millimeter-wave (mmwave) ArcSAR system, together with an imaging algorithm, is presented. First, to handle the non-uniform azimuth sampling caused by motor motion, a high-accuracy angular coder is used in the system design. The coder can send the radar a hardware trigger signal when rotated to a specific angle so that uniform angular sampling can be achieved under the unstable rotation of the motor. Second, the ArcSAR’s maximum azimuth sampling angle that can avoid aliasing is deducted based on the Nyquist theorem. The mathematical relation supports the proposed ArcSAR system in acquiring data by setting the sampling angle interval. Third, the range cell migration (RCM) phenomenon is severe because mmwave radar has a wide azimuth beamwidth and a high frequency, and ArcSAR has a curved synthetic aperture. Therefore, the fourth-order RCM model based on the range-Doppler (RD) algorithm is interpreted with a uniform azimuth angle to suit the system and implemented. The proposed system uses the TI 6843 module as the radar sensor, and its azimuth beamwidth is 64°. The performance of the system and the corresponding imaging algorithm are thoroughly analyzed and validated via simulations and real data experiments. The output image covers a 360° and 180 m area at an azimuth resolution of 0.2°. The results show that the proposed system has good application prospects, and the design principles can support the improvement of current ArcSARs. Full article
Show Figures

Figure 1

20 pages, 4829 KiB
Article
Study on Sound Field Properties of Parametric Array Under the Influence of Underwater Waveguide Interface Scattering Based on Non-Paraxial Model—Theory and Experiment
by Yuan Cao, Jie Shi, Jiangyi Zhang, Yuezhu Cheng and Haokang Shi
J. Mar. Sci. Eng. 2025, 13(2), 286; https://doi.org/10.3390/jmse13020286 - 4 Feb 2025
Viewed by 735
Abstract
This paper theoretically and experimentally studies the effect of underwater waveguide interface scattering on the nonlinear sound field characteristics of parametric array (PA) radiation. Based on the image source method, the components of the sound field in the waveguide are first analyzed. Then, [...] Read more.
This paper theoretically and experimentally studies the effect of underwater waveguide interface scattering on the nonlinear sound field characteristics of parametric array (PA) radiation. Based on the image source method, the components of the sound field in the waveguide are first analyzed. Then, a non-paraxial model is developed to account for the influence of interface scattering. This model enables accurate calculation of the wide-angle sound field. The impact of the sound source depth and the interface reflection coefficient on the distribution of the difference-frequency wave (DFW) sound field in the waveguide is studied. The interface alters the phase distribution of the DFW’s virtual source density function, thereby affecting the sound field accumulation process. Waveguide interfaces with different absorption coefficients influence the amplitude oscillation caused by interface reflection and change the sidelobe size of the DFW beam. The DFW sound field distribution is measured at three typical frequencies. Simulation and experimental results show that the attenuation of the DFW’s axial sound pressure level in the waveguide oscillates, and the DFW’s beamwidth gradually widens as the frequency decreases. The calculated results from the proposed model agree well with the measured data, with average errors along the sound axis and depth being less than 3 dB and 6 dB, respectively. This demonstrates the model’s superior applicability compared to the existing free-field model. Full article
(This article belongs to the Topic Advances in Underwater Acoustics and Aeroacoustics)
Show Figures

Figure 1

15 pages, 4125 KiB
Article
A Novel Slot Spiral Symmetric Array Antenna with a Wide Axial Ratio Beamwidth for Microwave-Induced Thermoacoustic Tomography Applications
by An Yan, Yao Zhang, Chengxiang Gao, Jinghua Ye and Zengpei Zhong
Symmetry 2025, 17(2), 197; https://doi.org/10.3390/sym17020197 - 27 Jan 2025
Viewed by 1089
Abstract
Conventional circularly polarized antennas have been employed to deliver microwave illumination in microwave-induced thermoacoustic tomography (TAT). However, these antennas exhibit several limitations in TAT systems, including low efficiency, poor axial ratio (AR) roundness, and narrow axial ratio beamwidth (ARBW). These issues lead to [...] Read more.
Conventional circularly polarized antennas have been employed to deliver microwave illumination in microwave-induced thermoacoustic tomography (TAT). However, these antennas exhibit several limitations in TAT systems, including low efficiency, poor axial ratio (AR) roundness, and narrow axial ratio beamwidth (ARBW). These issues lead to uniform radiation only within a relatively confined area, thereby restricting their effectiveness in clinical applications such as breast imaging. To address these issues, we propose a novel planar slot array antenna that offers a wide ARBW and improved axial ratio (AR) roundness, enabling homogeneous illumination over a larger field. We validated this approach both theoretically and experimentally. Tissue-mimicking phantoms were imaged, demonstrating that the antenna generated a circularly polarized electric field as well as a uniformly illuminated area. These advantages make the antenna proposed in this paper more suitable for clinical imaging compared to traditional microwave radiating antennas. Full article
(This article belongs to the Special Issue Symmetry Study in Electromagnetism: Topics and Advances)
Show Figures

Figure 1

20 pages, 45658 KiB
Article
Design and Modeling of a Reconfigurable Multiple Input, Multiple Output Antenna for 24 GHz Radar Sensors
by Mahmoud Shaban
Modelling 2025, 6(1), 2; https://doi.org/10.3390/modelling6010002 - 6 Jan 2025
Cited by 5 | Viewed by 1540
Abstract
A frequency-reconfigurable MIMO antenna with high gain, low mutual coupling and highly suppressed side lobe level (SLL) for applications in 24 GHz ISM band sensing and automotive radar systems was designed, modeled, and simulated. The reconfigurability feature was modeled with the implementation of [...] Read more.
A frequency-reconfigurable MIMO antenna with high gain, low mutual coupling and highly suppressed side lobe level (SLL) for applications in 24 GHz ISM band sensing and automotive radar systems was designed, modeled, and simulated. The reconfigurability feature was modeled with the implementation of a varactor diode in the model to alter the frequency in a wide band around 24 GHz. The design features 2- and 4-port MIMO antenna each comprising a 1 × 8 microstrip patch array. At the core of achieving both a high gain of 16 dBi and high isolation of 38.4 dB at a resonance frequency of 24.120 GHz lies the integration of a metamaterial absorber, comprising an optimized split-ring unit cell to effectively mitigate interference among the MIMO elements. Noteworthy impedance bandwidths of the sensor antenna span from 23.8 to 24.3 GHz, catering to diverse frequency requirements. The proposed sensor antenna feature a half-power beamwidth of 74° in the E-plane and 11° in the H-plane and an SLL of −24 dB at 24.120 GHz showing its robust performance characteristics across multiple operational dimensions. Full article
Show Figures

Figure 1

12 pages, 5253 KiB
Communication
Hand Gesture Recognition Using Ultrasonic Array with Machine Learning
by Jaewoo Joo, Jinhwan Koh and Hyungkeun Lee
Sensors 2024, 24(20), 6763; https://doi.org/10.3390/s24206763 - 21 Oct 2024
Cited by 2 | Viewed by 2474
Abstract
In the field of gesture recognition technology, accurately detecting human gestures is crucial. In this research, ultrasonic transducers were utilized for gesture recognition. Due to the wide beamwidth of ultrasonic transducers, it is difficult to effectively distinguish between multiple objects within a single [...] Read more.
In the field of gesture recognition technology, accurately detecting human gestures is crucial. In this research, ultrasonic transducers were utilized for gesture recognition. Due to the wide beamwidth of ultrasonic transducers, it is difficult to effectively distinguish between multiple objects within a single beam. However, they are effective at accurately identifying individual objects. To leverage this characteristic of the ultrasonic transducer as an advantage, this research involved constructing an ultrasonic array. This array was created by arranging eight transmitting transducers in a circular formation and placing a single receiving transducer at the center. Through this, a wide beam area was formed extensively, enabling the measurement of unrestricted movement of a single hand in the X, Y, and Z axes. Hand gesture data were collected at distances of 10 cm, 30 cm, 50 cm, 70 cm, and 90 cm from the array. The collected data were trained and tested using a customized Convolutional Neural Network (CNN) model, demonstrating high accuracy on raw data, which is most suitable for immediate interaction with computers. The proposed system achieved over 98% accuracy. Full article
(This article belongs to the Section Electronic Sensors)
Show Figures

Figure 1

19 pages, 11144 KiB
Article
Millimeter-Wave Choke Ring Antenna with Broad HPBW and Low Cross-Polarization for 28 GHz Dosimetry Studies
by Philip Ayiku Dzagbletey and Jae-Young Chung
Electronics 2024, 13(17), 3531; https://doi.org/10.3390/electronics13173531 - 5 Sep 2024
Viewed by 1339
Abstract
A choke ring horn antenna has been designed for use as an RF applicator in a compact range in vitro 28 GHz bioelectromagnetic exposure system. The 30 mm × 50 mm horn antenna was fabricated and measured to operate from 27.75 GHz to [...] Read more.
A choke ring horn antenna has been designed for use as an RF applicator in a compact range in vitro 28 GHz bioelectromagnetic exposure system. The 30 mm × 50 mm horn antenna was fabricated and measured to operate from 27.75 GHz to 34.5 GHz with a −20 dB measured S11 and a measured antenna gain of more than 10 dBi. A wide sectoral (flat top) and symmetric E- and H-plane pattern with a half-power beamwidth of more than 60 degrees was achieved with a cross-polarization discrimination of better than 28 dB. Electromagnetic slots were introduced in the antenna to suppress excess cavity mode radiation which inherently impacts the cross-polarization levels of choke ring antennas. The proposed antenna was successfully integrated into the compact measurement chamber in partnership with the Korea Telecommunication Research Institute (ETRI) and is currently in use for real-time 5G millimeter-wave dosimetry studies. Full article
Show Figures

Figure 1

29 pages, 9197 KiB
Article
An Adaptive 3D Neighbor Discovery and Tracking Algorithm in Battlefield Flying Ad Hoc Networks with Directional Antennas
by Yunjie Yuan, Gongye Ren, Xingyu Cai and Xuguang Li
Sensors 2024, 24(17), 5655; https://doi.org/10.3390/s24175655 - 30 Aug 2024
Cited by 1 | Viewed by 1152
Abstract
Neighbor discovery and tracking with directional antennas in flying ad hoc networks (FANETs) is a challenging issue because of dispersed node distribution and irregular maneuvers in three-dimensional (3D) space. In this paper, we propose an adaptive 3D neighbor discovery and tracking algorithm in [...] Read more.
Neighbor discovery and tracking with directional antennas in flying ad hoc networks (FANETs) is a challenging issue because of dispersed node distribution and irregular maneuvers in three-dimensional (3D) space. In this paper, we propose an adaptive 3D neighbor discovery and tracking algorithm in battlefield FANETs with directional antennas. With time synchronization, a flying node transmits/receives the neighbor discovery packets sequentially in each beam around it to execute a two-way handshake for neighbor discovery. The transmitting or receiving status of each discovery slot depends on the binary code corresponding to the identification of the node. Discovered neighbor nodes exchange their 3D positions in tracking slots periodically for node tracking, and the maximum tracking period is determined by node velocity, beamwidth, and the minimum distance between nodes. By configuring the relevant parameters, the proposed algorithm can also apply to two-dimensional planar ad hoc networks. The simulation results suggest that the proposed algorithm can achieve shorter neighbor discovery time and longer link survival time in comparison with the random scanning algorithm in scenarios with narrow beamwidth and wide moving area. When the frame length increases, the protocol overhead decreases but the average neighbor discovery time increases. The suitable frame length should be determined based on the network range, node count, beamwidth, and node mobility characteristics. Full article
(This article belongs to the Special Issue UAV Secure Communication for IoT Applications)
Show Figures

Figure 1

13 pages, 5221 KiB
Proceeding Paper
Deterministic Design Procedures on Limited Field-of-View Planar Arrays for Satellite Communications Employing Aperture Scaling
by Theodoros N. F. Kaifas
Eng. Proc. 2024, 70(1), 17; https://doi.org/10.3390/engproc2024070017 - 31 Jul 2024
Cited by 1 | Viewed by 681
Abstract
The antenna field of view, the angle range that can be accessed by scanning the main beam of a phased array, is one of the key performance prescriptions especially for space-borne aerials. The classical example of the full Earth, continental and subcontinental field [...] Read more.
The antenna field of view, the angle range that can be accessed by scanning the main beam of a phased array, is one of the key performance prescriptions especially for space-borne aerials. The classical example of the full Earth, continental and subcontinental field of view of the geosynchronous satellite is indicative, and it extends to the medium and lower orbit multibeam telecommunication systems. There, a high-gain, very small beamwidth pencil beam should scan a given service area. At the same time, it should exhibit extremely low sidelobes in order not to present interference to adjacent geographical areas, served by neighboring beams, and keep its grating lobes out of the Earth’s surface. High-throughput telecommunication satellites should comply with those prescriptions to be given permission for placement in orbit. Thus, the motivation for delivering solid methods for the design of limited-field-of-view array antennas is high. A proposal in this direction is presented in the work at hand. Indeed, in the present study a scaling transformation is used to map a wide-angle scanning array to a limited-field-of-view one. We start the design from a Full-Field-of-View array with the appropriate half-power beamwidth, sidelobe level, and directivity index, and then we enlarge it to attain the desired one with the limited-field-of-view pattern characteristics. The potential of the method is solid since it augments the limited-field-of-view design methods using the excellent performance of the respective full-field-of-view ones. As a result, the synthesis of a limited-field-of-view array can use any of the well-known array synthesis methods in conjunction with the right scaling. Additionally, one can employ design methods that rely on sampling of planar aperture distributions. Various design examples, employing both sampling of continuous apertures and utilizing classical full-field-of-view array synthesis methods, are included and presented in detail, verifying the merit of our approach. Full article
Show Figures

Figure 1

16 pages, 9546 KiB
Article
Analysis, Design, and Experimental Validation of a High-Isolation, Low-Cross-Polarization Antenna Array Demonstrator for Software-Defined-Radar Applications
by Nicholas Ricciardella, Walter Fuscaldo, Tito Mattei, Anna Maria Fiorello, Leopoldo Infante and Alessandro Galli
Appl. Sci. 2024, 14(14), 6015; https://doi.org/10.3390/app14146015 - 10 Jul 2024
Viewed by 1216
Abstract
In a software-defined radar (SDR) system, most of the signal processing usually implemented in hardware is implemented by software, thus allowing for higher flexibility and modularity compared to conventional radar systems. However, the majority of SDR demonstrators and proofs of concept reported in [...] Read more.
In a software-defined radar (SDR) system, most of the signal processing usually implemented in hardware is implemented by software, thus allowing for higher flexibility and modularity compared to conventional radar systems. However, the majority of SDR demonstrators and proofs of concept reported in the open literature so far have been based on simple antenna systems. As a result, the full potentialities of an SDR approach have not been completely exploited yet. In this work, we propose a flexible antenna module to be integrated into an active electronically scanning array (AESA) with controlled sidelobe level over a wide angular range, exhibiting polarization reconfigurability with a low cross-polarization level and high isolation. For this purpose, analytical and numerically efficient techniques for the synthesis of the aperture distribution and the correct evaluation of the radiating features (e.g., beamwidth, pointing angle, sidelobe levels, etc.) are presented in order to grant real-time control of the digital beamforming network. A sub-array module demonstrator is fabricated and measured to corroborate the concept. Full article
Show Figures

Figure 1

16 pages, 4075 KiB
Article
Optimal Beamwidth for Maximizing Uplink Coverage Probability in Quasi Earth-Fixed LEO Satellite Communication System
by Chun-Tai Liu and Jen-Yi Pan
Electronics 2024, 13(7), 1349; https://doi.org/10.3390/electronics13071349 - 3 Apr 2024
Cited by 1 | Viewed by 2033
Abstract
Satellite communication is proposed to fulfill the ubiquitous coverage for next-generation wireless networks. Considering the propagation delay and path loss, low-earth orbit (LEO) satellites are widely adopted. However, since the beam boresight directions become close in quasi-earth-fixed cells (QEFC) scenarios at low elevation [...] Read more.
Satellite communication is proposed to fulfill the ubiquitous coverage for next-generation wireless networks. Considering the propagation delay and path loss, low-earth orbit (LEO) satellites are widely adopted. However, since the beam boresight directions become close in quasi-earth-fixed cells (QEFC) scenarios at low elevation angles, the interference increases and causes low communication quality. This paper introduces the optimal beamwidth maximizing uplink coverage probability scheme for quasi-earth-fixed cells in LEO satellite communication systems. The proposed scheme dynamically adjusts the beamwidth to achieve max uplink coverage probability at different elevation angles. The simulation results show that the proposed scheme matches the exhaustive search method in different scenarios and target signal-to-interference-plus-noise ratios. Furthermore, the proposed scheme significantly mitigates interference and improves the uplink coverage probability. Compared with the 3GPP setting, the proposed scheme improves the uplink coverage probability by 0.93 at time 100 s, and compared with the three-color frequency reuse, the proposed scheme improves the uplink coverage probability by 0.195 at time 100 s. The dynamic beamwidth and boresight direction adjustments enable the satellite to maintain seamless and reliable communication services across a wide range of operating conditions, ultimately realizing the goal of ubiquitous communications in the QEFC LEO satellite system. Full article
Show Figures

Figure 1

16 pages, 9543 KiB
Article
3D Phased Array Enabling Extended Field of View in Mobile Satcom Applications
by Federico Boulos, Georg Frederik Riemschneider and Stefano Caizzone
Electronics 2024, 13(2), 310; https://doi.org/10.3390/electronics13020310 - 10 Jan 2024
Cited by 1 | Viewed by 1526
Abstract
Satellite communication (satcom) is experiencing increased interest to cover the connectivity gaps of terrestrial networks. To ensure high performance and throughput for the user—and even more so in Communications-On-The-Move(COTM) systems, e.g., in aeronautics—steerable antennas such as phased arrays are required to adjust the [...] Read more.
Satellite communication (satcom) is experiencing increased interest to cover the connectivity gaps of terrestrial networks. To ensure high performance and throughput for the user—and even more so in Communications-On-The-Move(COTM) systems, e.g., in aeronautics—steerable antennas such as phased arrays are required to adjust the beam so as to follow the satellite’s trajectory. The mutual movement of terminals and satellite in COTM systems calls for a broad Field of View (FoV) and, hence, poses a challenge to common planar systems. For improving the FoV, common solutions require ad hoc designs, such as multi-mode antennas, wide half-power-beamwidth antennas or metasurfaces. By contrast, 3D arrays are able to cover a wider angular region by the 3D allocation of the antennas. In this paper, the benefits and drawbacks of moving from 2D (planar) arrays to 3D phased arrays are investigated. Multiple geometrical configurations are analyzed, keeping in mind the size requirements of aeronautic terminals. The best configuration is, hence, an array capable of enhancing the FoV of the terminal. The proposed antenna architecture offers a good trade-off between design complexity and performance, and it could be further developed to become an aeronautic-grade terminal aperture. Full article
(This article belongs to the Special Issue Advanced Antenna Technologies for B5G and 6G Applications)
Show Figures

Figure 1

12 pages, 13164 KiB
Article
Single-Layer Wide-Angle Scanning Linear Phased Arrays Based on Multimode Microstrip Patch Elements
by Dongsheng Li, Jie Yang, Jianing Zhao, Yongzhen Dong, Hao Li, Tianming Li, Haiyang Wang, Biao Hu, Yihong Zhou, Fang Li and Ruoyang Yang
Micromachines 2024, 15(1), 3; https://doi.org/10.3390/mi15010003 - 19 Dec 2023
Viewed by 1602
Abstract
This paper introduces a novel single-layer microstrip patch element designed to achieve a wide beamwidth, in order to address the growing demand for wide-angle scanning capabilities in modern phased array systems. The proposed element, comprising a slot-etched circular patch and an array of [...] Read more.
This paper introduces a novel single-layer microstrip patch element designed to achieve a wide beamwidth, in order to address the growing demand for wide-angle scanning capabilities in modern phased array systems. The proposed element, comprising a slot-etched circular patch and an array of metallized holes arranged in square rings, offers a unique approach to beam shaping. By carefully adjusting parameters such as the slot structure and feeding position, our element is engineered to simultaneously excite both the TM01 and TM21 modes, a key feature that contributes to its wide beamwidth characteristics. Through the constructive interference of these modes, our element demonstrates a remarkable 3 dB beamwidth of approximately 150° in both principal planes, showcasing its potential for wide-angle scanning applications. To validate the practical performance of this proposed element, two linear phased arrays are manufactured and experimentally evaluated. The simulation results confirm the wide-angle scanning capability of the antennas in both the E-plane and H-plane. Furthermore, the experimental assessment demonstrates that these linear phased arrays can effectively generate scanning beams within a frequency range of 25 GHz to 28 GHz, covering a wide angular range from −60° to 60°, while maintaining a gain loss within 3 dB. This innovative design approach not only offers a promising solution for achieving a wide beamwidth in microstrip patch elements, but also holds significant potential for the development of cost-effective phased arrays with wide-angle scanning capabilities, making it a valuable contribution to the advancement of phased array technology. Full article
(This article belongs to the Special Issue Advanced Antenna System: Structural Analysis, Design and Application)
Show Figures

Figure 1

14 pages, 2061 KiB
Article
Clustering and Beamwidth Optimization for UAV-Assisted Wireless Communication
by Weidong Zhao, Jun Zhang and Dongxing Li
Sensors 2023, 23(23), 9614; https://doi.org/10.3390/s23239614 - 4 Dec 2023
Cited by 1 | Viewed by 1588
Abstract
With the development of wireless communication technology, unmanned aerial vehicles (UAV) are now widely used in many complex communication scenarios. When a UAV serves as an aerial base station for urban and rural ground users or marine users, it is necessary to consider [...] Read more.
With the development of wireless communication technology, unmanned aerial vehicles (UAV) are now widely used in many complex communication scenarios. When a UAV serves as an aerial base station for urban and rural ground users or marine users, it is necessary to consider the clustering of ground users and the energy efficiency of the UAV since the users are usually randomly distributed. For the scenario with randomly distributed ground users and different densities of ground users in urban and rural areas, a clustering and beamwidth optimization method for UAV-assisted wireless communication is proposed. Firstly, the energy efficiency expression of a UAV serving ground users was derived in a downlink wireless communication system assisted by a UAV. Secondly, based on the geographical location information of non-uniformly distributed users, an improved k-means method is proposed to cluster ground users, ensuring that the number of users in each cluster is within an appropriate range. Then, based on the clustering results, a fixed-point iteration (FPI) algorithm was proposed to design the optimal beamwidth of UAVs and improve their energy efficiency. Finally, the superiority of the proposed algorithm in improving energy efficiency was verified through simulation analysis, and the impact of parameters such as the cluster number and transmission power on system energy efficiency was also analyzed. Full article
(This article belongs to the Special Issue Wireless Communications with Unmanned Aerial Vehicle)
Show Figures

Figure 1

14 pages, 718 KiB
Article
UAV-Assisted Wideband Terahertz Wireless Communications with Time-Delay Phased UPA under Beam Squint
by Hao Huang, Qinghe Zheng and Hikmet Sari
Drones 2023, 7(10), 608; https://doi.org/10.3390/drones7100608 - 27 Sep 2023
Cited by 2 | Viewed by 1812
Abstract
Future Unmanned Aerial Vehicle (UAV)-assisted wireless communication systems are expected to utilize wide bandwidths available at terahertz (THz) frequencies to enhance system throughput. To compensate for the severe path loss in the THz band, it is essential to have a multitude of antennas [...] Read more.
Future Unmanned Aerial Vehicle (UAV)-assisted wireless communication systems are expected to utilize wide bandwidths available at terahertz (THz) frequencies to enhance system throughput. To compensate for the severe path loss in the THz band, it is essential to have a multitude of antennas in the UAV to generate narrow beams for directional transmission. However, narrow beams severely limit its spatial coverage, which greatly affects the efficiency of large-scale access UAV-assisted THz systems. Moreover, the combination of massive antennas and large bandwidth at THz makes the misalignment of the beams caused by beam squint non-negligible and also high energy consumption. UAV-assisted communication technology can effectively increase spatial coverage and provide reliable LoS communication links. In addition, reducing the number of radio frequency (RF) chains while ensuring the number of transmitted data streams and space division multiplexing capability is also an effective way to reduce energy consumption in the UAV communication. In this paper, a single RF chain uniform planar array (UPA) with true-time-delays (TTDs) is equipped on the UAV to achieve two dimensional (2D) beams and split spatial beams to improve transmission efficiency. We analyze the 2D beam squint of the UPA and design a time-delay phased UPA for UAV-assisted THz communication systems. By introducing TTDs between the single RF chain and phase shifters, the beam squint can be controlled flexibly by introducing the delay between each antenna. When TTDs are arranged in both the horizontal and vertical dimensions, the coverage of the beams becomes more complicated compared to uniform linear arrays (ULA). Simulation results show that the proposed time-delay phased UPA can achieve better performance in both single-beam and multi-beam modes for single user and multi-user scenarios compared with conventional phased UPA, respectively. In addition, we propose frequency division beam multiple access (FDBMA) multi access technology, which achieves more efficient multi access by reusing resources from different frequency beam pairs. Finally, the results also show that the enlargement of the beamwidth through the proposed FDBMA strategy can also increase the performance in multi-user scenarios. Full article
(This article belongs to the Section Drone Communications)
Show Figures

Figure 1
